Gemini VII
Field or Button
Close button
Preview button
Replace button
Save button
Table buttons

Analysis Conditions Files

File > Open > Analysis Conditions (or click the Analysis Conditions tab when in Advanced format
or use the F3 keyboard shortcut)
The Analysis Conditions tab provides details for setting up the sample analysis conditions file.
Use this window to manually enter the pressures or use the Insert Predefined button to insert default
system values.
A pressure table consists of relative pressure points (and possibly calculation assignments) at which
data (isotherms) are to be collected. The relative pressures may span the entire range of 0.00000001 to
o
0.995 p/p . There must be one adsorption branch followed optionally by one desorption branch.
Several analysis conditions files containing complete pressure tables are included with the analysis
program. To use these files, it is recommended to use the File > Save As option to save the file as a dif-
ferent name and edit the new file.
239-42828-01 - Dec 2012
Refer to the field and button table in
Options, page 5-1.
Menu
Description (continued)
Common Fields and Buttons - File
Analysis Conditions Files
5-11
