Instrument Schematic Shortcut Menus

Each manually controlled component has a shortcut menu displaying the operations available for that
particular component such as, Open, Close, Pulse. To access the shortcut menu, hover the mouse cur-
sor over the component and right click.
Shortcut Icon
239-42828-01 - Dec 2012
Analysis port valve
Po port valve (Models 22390a and 2390t)
When the cursor changes to this icon, right click to display options for the
selected component:
• For Valves:
Open - opens the selected valve. The valve symbol changes to green. An
alternate method is to either double click the valve or select the valve
and press the keyboard spacebar to turn it off/on.
Open Both - opens valves 4b and 4s or valves 5b and 5s. The valve
symbol changes to green. An alternate method is to either double click
the valve or select the valve and press the keyboard spacebar to turn it
off/on.
Close - closes the selected valve. The valve symbol changes to yellow.
An alternate method is to either double click the valve or select the valve
and press the keyboard spacebar to turn it off/on.
Close Both - closes valves 4b and 4s or valves 5b and 5s. The valve
symbol changes to yellow. An alternate method is to either double click
the valve or select the valve and press the keyboard spacebar to turn it
off/on.
Pulse - select to quickly turn the valve on and off allowing the operation
to proceed in small increments.
• For Balance Servo Valve:
Enable - enables the balance servo valve. Operations for the Sample
servo will also be performed by the Balance servo.
Disable - disables the balance servo valve. Operations for the Sample
servo will also be ignored by the Balance servo.
