Gemini VII
3. Select Unit [n] > Blank Analysis.
4. Click Browse to select an existing file or to create a new one. Click Open.
5. Click Edit to make and save modifications or replace all parameters in the open file using the
Replace All button to select another file. Click Save and Close when done.
6. Click Report after analysis to automatically generate reports to the specified destination when
the analysis is complete. On the Report Settings window, select the report destination. Click OK.
7. Click Start to start the analysis. A window displays data as they are collected. A short delay is
encountered before the port status changes from the Idle state at the bottom of the screen. Review
the analysis results to see if they are within the tolerances shown in the following table. If these
results are not achieved, call a Micromeritics Service Representative.
P/Po
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
239-42828-01 - Dec 2012
Performing a Blank Analysis for Diagnostic Purposes
3
Tolerance in cm
±0.008
±0.010
±0.012
±0.014
±0.016
±0.018
±0.020
±0.022
±0.024
