C
ONFIGURE THE
S G P
PECIFY AS ORTS AND
Unit [n] > Unit Configuration
In 21CFR11 environments, this feature is applicable to members of the Developer
group only.
The analyzer has gas inlets for up to three analysis gases and a dedicated inlet for helium. The
gases connected to the inlets must be specified in the analysis program. If the gases are changed
on one of the inlets, make the same change on the Unit Configuration window. The analysis
program must be kept informed of any changes in gases.
Unit Configuration
Selections
Configuration
[group box]
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
A
NALYZER
U C
NIT ONFIGURATION
Description
Displays the IP address used by the analysis program, serial number,
and type of analyzer.
IP address. Displays the IP address of the analyzer.
Change IP. Displays the Board ID dialog, which describes the circuit
boards in the analyzer. Use the Board drop-down list to select a board
to view.

Configure the Analyzer

2 - 15
