Prepping the Upper Tower Mounts
Before you can install the upper tower mounts, three tower depth stop screws need to be
installed as shown below.
Fig. 7-1: Depth stop screws installed.
These screws perform the same function as the ones previously installed in the lower tower
mounts. This helps guarantee that the top section will be at the correct height on all three towers.
Rostock MAX v2 Assembly Guide
92
