Rostock MAX v2 Assembly Guide
Hardware Pack #3
(___) (20) Plastic Bearing Rollers. 4 are used for mounting the
RAMBo and six are used for the belt clamps. [71505]
(___) (12) Small Wire Ties. Used for wire management or Barbie
Handcuffs. Your call.
(___) (1) GT2 2mm pitch belt pulley pack. Includes six grub screws
and hex wrench. [39835]
(___) (3) Carriage base for U-Joints. [68332]
(___) (1) Effector Platform. [70832]
(___) (6) U-Joint Spring Clips. [87940]
19
