Rostock MAX v2 Assembly Guide
Hardware Pack #2
(___) (18) 608 Cheapskate Idler Bearing Spacer. Used for belt idlers.
[68340]
(___) (12) 608 Cheapskate Carriage Bearing Spacers (black). [68326]
(___) (12) 608 Cheapskate Eccentric Bearing Spacers (gray). [68340]
(___) (12) Universal Joints (Injection molded Acetal). [68309]
(___) (6) 3-1/8" Steel Universal Joint axle shafts. [68325]
(___) (3) 1" long machined aluminum hot end platform spacers. [68334]
