Rostock MAX v2 Assembly Guide
(___) (10) #4-40 T-Nuts. Used for belt clamps and RAMBo
mounting. [30222]
(___) (4) #4-40, 3/4" Phillips Flat Head Machine screws. Used for
mounting the RAMBo Controller. [30236]
(___) (6) #4-40, 1/2" Stainless Steel Socket Head Cap screws. Used
for the belt clamps. [30232]
(___) (14) #2-56, 5/8" Pan Head Phillips Machine screws. Used for
LCD mounting and end-stop switch mounting. [30650] (Combined
Package)
(___) (14) 2-56 Finish Nuts. Used for LCD mounting and end-stop
switch mounting. [30642] (Combined Package)
(___) 14 each, #4, 3/8" Phillips Pan Head Sheet Metal screws. Used for
LCD sides and tower alignment stops. [30250]
(___) (12) M3x.5, 10mm Pan Head Machine screws. Used for
mounting the stepper motors. [30318]
