Parameter Descriptions

3.17 Parameters: 16-** Data Read-outs

16-00 Control Word
3 3
Range:
0 [0 - 65535 ] View the Control word sent from the
*
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 -
*
200 %]
16-03 Status Word
Range:
0 [0 - 65535 ] View the status word sent from the frequency
*
16-05 Main Actual Value [%]
Range:
0 % [-100 - 100
*
%]
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*
146
VLT
Function:
frequency converter via the serial communi-
cation port in hex code.
Function:
[-999999 - View the present
999999 reference value applied
ReferenceFeed- on impulse or analog
backUnit] basis in the unit
resulting from the
configuration selected in
1-00 Configuration Mode
(Hz, Nm, or RPM).
Function:
View the total reference. The total reference
is the sum of digital, analog, preset, bus, and
freeze references, plus catch-up and slow-
down.
Function:
converter via the serial communication port in
hex code.
Function:
View the 2-byte word sent with the status
word to the Bus Master reporting the Main
Actual Value.
Function:
[0 - 0 Custom- View the value of custom
ReadoutUnit] readout from 0-30 Unit for
User-defined Readout to
0-32 Custom Readout Max
Value
®
AutomationDrive FC 301/302 Programming Guide
3.17.1 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0 -
*
10000
kW]
16-11 Power [hp]
Range:
0 hp [0 -
*
10000
hp]
16-12 Motor Voltage
Range:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
16-13 Frequency
Range:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
16-14 Motor current
Range:
0 A [0 -
*
10000 A]
16-15 Frequency [%]
Range:
0 % [-100 -
*
100 %]
16-16 Torque [Nm]
Range:
0 Nm [-3000
*
- 3000
Nm]
MG33MH02 - Rev. 2013-09-30
Function:
Displays motor power in kW. The value shown
is calculated based on the actual motor
voltage and motor current. The value is
filtered, and therefore approx. 30 ms may pass
from when an input value changes to when
the data readout values change. The resolution
of readout value on fieldbus is in 10 W steps.
Function:
View the motor power in hp. The value shown
is calculated based on the actual motor
voltage and motor current. The value is
filtered, and therefore approximately 30 ms
may pass from when an input value changes
to when the data readout values change.
Function:
used for controlling the motor.
Function:
resonance dampening.
Function:
View the motor current measured as a mean
value, I . The value is filtered, and thus
RMS
approximately 30 ms may pass from when an
input value changes to when the data readout
values change.
Function:
View a 2-byte word reporting the actual motor
frequency (without resonance dampening) as a
percentage (scale 0000-4000 Hex) of 4-19 Max
Output Frequency. Set 9-16 PCD Read Configu-
ration index 1 to send it with the status word
instead of the MAV.
Function:
View the torque value with sign, applied to the
motor shaft. Linearity is not exact between
160% motor current and torque in relation to
