Cisco ASR 9000 Series Aggregation Services Router Broadband
Network Gateway Command Reference, Release 5.2.x
First Published: 2014-07-03
Last Modified: 2014-10-24
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883

Advertisement

Table of Contents
loading

Related Manuals for Cisco ASR 9000 Series

Summary of Contents for Cisco ASR 9000 Series

  • Page 1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x First Published: 2014-07-03 Last Modified: 2014-10-24 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387)
  • Page 2 Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks . Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.

  • Page 3: Table Of Contents

    (BNG) radius-server disallow null-username radius-server host (BNG) radius-server ipv4 dscp radius-server key (BNG) radius-server load-balance Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 4 Control Policy Commands C H A P T E R 4 activate authenticate (BNG) authorize Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 5 (BNG) inner-cos interface (DHCP-BNG) interface subscriber-pppoe profile lease lease proxy client-lease-time limit lease per-circuit-id limit lease per-interface limit lease per-remote-id match option match vrf outer-cos Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 6 C H A P T E R 7 dynamic-template dynamic-template type ipsubscriber dynamic-template type ppp dynamic-template type service monitor-session (interface-dynamic-template-BNG) service-policy (BNG) test radius coa activate Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 7 (point-to-point -BNG) ipv4 unreachables disable (BNG) ipv4 verify unicast source reachable-via (BNG) ipv6 enable (BNG) ipv6 mtu (BNG) ipv6 unreachables disable (BNG) show ipv4 interface (BNG) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 8 (BNG) ipv6 nd suppress-cache-learning ipv6 nd suppress-ra (BNG) BNG PPP Commands C H A P T E R 1 3 ppp authentication (BNG) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x viii...
  • Page 9 PPPoE Commands C H A P T E R 1 5 pado delay pado delay circuit-id pado delay remote-id pado delay service-name pppoe bba-group Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 10 (subscriber redundancy) hold-timer (subscriber redundancy) interface-list preferred-role source-interface (subscriber redundancy) subscriber redundancy subscriber redundancy group subscriber redundancy switchover subscriber redundancy synchronize Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 11 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 12 Contents Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 13: Obtaining Documentation And Submitting A Service Request

    From Release 6.1.2 onwards, Cisco introduces support for the 64-bit Linux-based IOS XR operating system. Extensive feature parity is maintained between the 32-bit and 64-bit environments. Unless explicitly marked otherwise, the contents of this document are applicable for both the environments. For more details on Cisco IOS XR 64 bit, refer to the Release Notes for Cisco ASR 9000 Series Routers, Release 6.1.2 document.
  • Page 14 Preface Obtaining Documentation and Submitting a Service Request Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 15 This module describes the Cisco IOS XR software commands used to configure the AAA commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.
  • Page 16 (BNG), page 53 • show aaa trace, page 55 • show radius (BNG), page 57 • show radius server-groups detail, page 60 • statistics period service-accounting, page 62 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 17: Aaa Accounting Service

    Release Modification Release 4.3.1 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operation read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 18: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the aaa accounting service command for the grpFR server group: RP/0/RSP0/CPU0:router(config)# aaa accounting service default group grpFR Related Commands Command Description aaa accounting subscriber, on page 5 Creates an accounting list for subscriber accounting. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 19: Aaa Accounting Subscriber

    Command Modes Global Configuration mode Command History Release Modification Release 4.2.0 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 20: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# aaa accounting subscriber sub1 broadcast group radius group Related Commands Command Description aaa accounting system rp-failover, on page 7 Creates an accounting list for system events. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 21: Aaa Accounting System Rp-Failover

    Examples This is an example of configuring the aaa accounting system rp-failover command for default accounting list: RP/0/RSP0/CPU0:router(config)# aaa accounting system rp-failover default start-stop none Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 22: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG AAA Commands aaa accounting system rp-failover Related Commands Command Description aaa attribute format, on page 9 Create an AAA attribute format name. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 23: Aaa Attribute Format

    Specifies the use of additional identifiers. separator Specifies the separator to be used between keys. separator Separator to be used between keys, default is a semicolon. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 24: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# aaa attribute format form1 RP/0/RSP0/CPU0:router(config-id-format)# format-string "%s%s" RP/0/RSP0/CPU0:router(config-id-format)# username-strip prefix-delimiter @ Related Commands Command Description aaa accounting subscriber, on page 5 Creates an accounting list for subscriber accounting. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 25: Aaa Authentication Subscriber

    Release Modification Release 4.2.0 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operation read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 26: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the aaa authentication subscriber command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# aaa authentication subscriber sub1 group sg1 group sg2 Related Commands Command Description aaa authorization subscriber, on page 13 Creates authorization-related configurations Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 27: Aaa Authorization Subscriber

    Examples This is an example of configuring the aaa authorization subscriber command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# aaa authorization subscriber sub1 group sg1 group sg2 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 28: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG AAA Commands aaa authorization subscriber Related Commands Command Description aaa authentication subscriber, on page 11 Creates a method list for subscriber authentication. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 29: Aaa Group Server Radius (Bng)

    Specifies interface for source address in RADIUS packet. throttle Specifies RADIUS throttling options. Specifies the VRF to which the server group belongs. Command Default None Command Modes Global Configuration mode Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 30: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the aaa group server radius command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)#aaa group server radius SG1 RP/0/RSP0/CPU0:router(config-sg-radius)#server 99.1.1.10 auth-port 1812 acct-port 1813 RP/0/RSP0/CPU0:router(config-sg-radius)#throttle access 10 access-timeout 5 accounting 5 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 31: Aaa Intercept

    This command was introduced. Release 4.3.2 By default, Lawful Intercept (LI) is not a part of the Cisco IOS XR software. The LI package needs to be installed separately. So, this command is enabled only after installing and activating the asr9k-li-px.pie.

  • Page 32: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG AAA Commands aaa intercept Examples This example shows how to configure aaa intercept command: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# aaa intercept Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 33: Aaa Radius Attribute

    The nas port value ranges from 0-44. Command Default None Command Modes Global Configuration mode Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 34: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Examples This is an example of configuring the aaa radius attribute command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# aaa radius attribute format e red type 40 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 35: Aaa Service-Accounting

    Task ID Operation read, write Examples This example shows how to set service accounting parameters to send brief information about service accounting records: RP/0/RSP0/CPU0:router(config)# aaa service-accounting brief Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 36: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    5 Creates an accounting list for subscriber accounting. aaa accounting service, on page 3 Creates an accounting list for service accounting. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 37: Aaa Server Radius Dynamic-Author

    Global Configuration mode. Command History Release Modification Release 4.2.0 This command was introduced. Release 4.2.1 The support for the keywords, auth-key and ignore {session-key} were removed. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 38: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description show radius (BNG), on page 57 Displays various RADIUS statistics. show aaa trace, on page 55 Displays all trace data for AAA sub-system Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 39: Aaa Radius Attribute Nas-Port-Type

    This example shows how to configure the AAA RADIUS attribute, nas-port-type for each physical interface RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface gigabitEthernet 0/0/0/0 RP/0/RSP0/CPU0:router(config-if)# aaa radius attribute nas-port-type 15 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 40: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description aaa radius attribute, on page 19 Configures a format e encode string for particular interface or NAS-Port type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 41: Accounting Aaa List

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the dynamic-template command to enter dynamic template configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 42: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables the dynamic template configuration mode. dynamic-template type ppp, on page 236 Enables the ppp dynamic template type. dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 43: Accounting Aaa List Type Service

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the dynamic-template command to enter dynamic template configuration mode. Task ID Task ID Operation config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 44: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    232 Enables the dynamic template configuration mode. dynamic-template type service, on page 238 Specifies the service template type for a group of subscribers or services. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 45: Radius-Server Attribute

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 46: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the radius-server attribute command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# radius-server attribute list list1 RP/0/RSP0/CPU0:router(config-attribute-filter)# attribute list_1 RP/0/RSP0/CPU0:router(config-attribute-filter)# radius-server attribute vendor-id 429 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 47: Radius-Server Dead-Criteria

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 48: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Examples This is an example of configuring the radius-server dead-criteria command with 100s time and 34 tries: RP/0/RSP0/CPU0:router(config)#radius-server dead-criteria time 100 RP/0/RSP0/CPU0:router(config)#radius-server dead-criteria tries 34 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 49: Radius-Server Deadtime (Bng)

    A RADIUS server marked as dead is skipped by additional requests for the duration of minutes unless all other servers are marked dead and there is no rollover method. Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 50: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example specifies five minutes of deadtime for RADIUS servers that fail to respond to authentication requests for the radius-server deadtime command: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# radius-server deadtime 5 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 51: Radius-Server Disallow Null-Username

    Task ID Task ID Operations read, write Examples This is an example of configuring the radius-server disallow null-username command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)#radius-server disallow null-username Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 52: Radius-Server Host (Bng)

    Command Default No RADIUS host is specified; use global radius-server command values. Command Modes Global Configuration mode Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 53: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. You can use multiple radius-server host commands to specify multiple hosts. The Cisco IOS XR software searches for hosts in the order in which you specify them.

  • Page 54: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG AAA Commands radius-server host (BNG) Command Description radius-server timeout (BNG), on page 49 Sets the interval a router waits for a server host to reply. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 55: Radius-Server Ipv4 Dscp

    Task ID Operations read, write Examples This is an example of configuring the radius-server ipv4 dscp command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)#radius-server ipv4 dscp 34 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 56: Radius-Server Key (Bng)

    If you use spaces in your key, do not enclose the key in quotation marks unless the quotation marks themselves are part of the key. Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 57: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# radius-server key 0 samplekey This example shows how to set the encrypted shared key to “anykey”: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# radius-server key 7 anykey Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 58: Radius-Server Load-Balance

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 59: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the radius-server load-balance command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)#radius-server load-balance method lead-outstanding batch-size RP/0/RSP0/CPU0:router(config)#radius-server load-balance method lead-outstanding batch-size ignore-preferred-server Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 60: Radius-Server Retransmit (Bng)

    (BNG) To specify the number of times the Cisco IOS XR software retransmits a packet to a server before giving up, use the radius-server retransmit command. The no form of this command sets it to the default value of 3 .

  • Page 61: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description radius-server key (BNG), on page 42 Sets the authentication and encryption key for all RADIUS communications between the router and the RADIUS daemon. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 62: Radius-Server Source-Port

    Task ID Task ID Operations read, write Examples This is an example of configuring the radius-server source-port command in theGlobal Configuration mode: RP/0/RSP0/CPU0:router(config)#radius-server source-port extended Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 63: Radius-Server Timeout (Bng)

    Task ID Task ID Operations read, write Examples This example shows how to change the interval timer to 10 seconds: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# radius-server timeout 10 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 64: Radius-Server Vsa Attribute Ignore Unknown

    Examples This is an example of configuring the radius-server vsa attribute ignore unknown command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)#radius-server vsa attribute ignore unknown Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 65: Radius-Server Throttle

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 66: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Examples This is an example of configuring the radius-server throttle command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# radius-server throttle access 10 access-timeout 5 accounting Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 67: Radius Source-Interface (Bng)

    The radius source-interface command is especially useful in cases in which the router has many interfaces or subinterfaces and you want to ensure that all RADIUS packets from a particular router have the same IP address. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 68: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example shows how to make RADIUS use the IP address of subinterface s2 for all outgoing RADIUS packets: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# radius source-interface loopback 10 vrf vrf1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 69: Show Aaa Trace

    Displays the wrapping entries. Displays the output modifiers. Command Default None Command Modes EXEC mode Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 70: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    ENTERING aaa_connect2 Jan 15 06:11:00.962 aaa/func 0/RSP0/CPU0 t5 ENTERING get_unique_context Jan 15 06:11:00.963 aaa/func 0/RSP0/CPU0 t5 EXITTING get_unique_context Jan 15 06:11:00.963 aaa/func 0/RSP0/CPU0 t5 EXITTING aaa_connect2 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 71: Show Radius (Bng)

    IDs. If you suspect user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 72: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    0 requests, 0 timeouts, 0 response, 0 pending RP/0/RSP0/CPU0:router# show rad server-groups SG1 Server group 'SG1' has 1 server(s) (id 0x0) Dead time: 0 minute(s) (inherited from global) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 73: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Number of times the Cisco IOS XR software searches the list of RADIUS server hosts before giving up. Deadtime Length of time in minutes for a RADIUS server to remain marked dead. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 74: Show Radius Server-Groups Detail

    0 timeouts, 0 bad responses, 0 bad authenticators 0 unknown types, 0 dropped, 0 ms latest rtt Throttled: 0 transactions, 0 timeout, 0 failures Estimated Throttled Access Transactions: 0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 75: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Length of time in minutes for a RADIUS server to remain marked dead. Authentication Specifies the authentication details. Automated TEST Stats Specifies the total time taken for sending requests, total timeouts, and the response time. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 76: Statistics Period Service-Accounting

    Task ID Operation diag read, write Examples This example shows how to change the collection period or polling interval for statistics collector: RP/0/RSP0/CPU0:router(config)# statistics period service-accounting 2000 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 77: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    5 Creates an accounting list for subscriber accounting. aaa accounting service, on page 3 Creates an accounting list for service accounting. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 78: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG AAA Commands statistics period service-accounting Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 79: Acl And Abf Commands

    ACL and ABF Commands This module describes the Cisco IOS XR software commands used to configure the ACL and ABF commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 80: Ipv4 Access-Group (Bng)

    Use the ingress keyword to filter on inbound packets or the egress keyword to filter on outbound packets. Use the hardware-count argument to enable hardware counters for the access group. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 81: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    35 deny ipv4 any host 202.175.175.1 ipv4 access-list acl-unique1 10 permit ipv4 host 205.205.205.1 host 203.175.175.1 log-input 15 deny ipv4 any host 203.175.175.1 20 permit ipv4 any any Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 82: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of a configured IPv4 ACL in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv4 access-group a1 egress Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 83: Ipv4 Access-List (Bng)

    Task ID Operations read, write Examples This example shows how to define a standard access list named Internetfilter: RP/0/RSP0/CPU0:router(config)# ipv4 access-list Internetfilter RP/0/RSP0/CPU0:router(config-ipv4-acl)# 10 permit 192.168.34.0 0.0.0.255 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 84: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-ipv4-acl)# 30 permit 10.0.0.0 0.255.255.255 RP/0/RSP0/CPU0:router(config-ipv4-acl)# 39 remark Block BGP traffic from 172.16 net. RP/0/RSP0/CPU0:router(config-ipv4-acl)# 40 deny tcp host 172.16.0.0 eq bgp host 192.168.202.203 range 1300 1400 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 85: Ipv6 Access-Group (Bng)

    The common keyword was added. The compress level keyword was added. Usage Guidelines The ipv6 access-group command is similar to the ipv4 access-group command, except that it is IPv6-specific. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 86: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    ASR 9000 Ethernet Line Card cannot apply ACL. Whereas, an ASR 9000 Enhanced Ethernet Line Card having Cisco IOS XR Software Release 5.1.x or above, can do ingress IP ACL for MPLS labeled packets. Also, for ASR 9000 Ethernet Line Cards, if the label is popped because it is routed to an attached customer edge (CE), then the egress LC sees a plain IP.

  • Page 87: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# interface GigabitEthernet 0/1/0/4 RP/0/RSP0/CPU0:router(config-if)# ipv6 access-group common common-acl interface-acl ingress This example shows how to configure the number of fields to be compressed in hardware: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 88: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    ACL and ABF Commands ipv6 access-group (BNG) RP/0/RSP0/CPU0:router# config RP/0/RSP0/CPU0:router(config)# interface GigabitEthernet 0/1/0/4 RP/0/RSP0/CPU0:router(config-if)# ipv6 access-group acl1 ingress compress level 1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 89: Ipv6 Access-List (Bng)

    • main and sub-interface, bundle interface and bundle sub-interface • vpws and vpls main interface and sub-interface, vpws and vpls on bundle interface and bundle sub-interface, vlan encapsulation QinQ, dot1Q, dot1ad Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 90: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (packets that have the site-local prefix fec0:0:0:2 as the first 64 bits of their source IPv6 address) from exiting out of interface GigabitEthernet 0/2/0/2. The second entry in the ACL permits all other traffic Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 91: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example shows how to configure an IPv6 ACL for an L2 interface: RP/0/RSP0/CPU0:router# config RP/0/RSP0/CPU0:router(config)# interface gigabitEthernet 0/1/0/4 RP/0/RSP0/CPU0:router(config-if)# l2transport RP/0/RSP0/CPU0:router(config-if-l2)# ipv6 access-list list2 ingress RP/0/RSP0/CPU0:router(config-if-l2)# ipv6 access-list list2 ingress Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 92: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    ACL and ABF Commands ipv6 access-list (BNG) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 93: Address Pool Service Commands

    Address Pool Service Commands This chapter describes the Cisco IOS XR software Address Pool Service commands for Broadband Network Gateway (BNG). For details regarding related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 94: Address-Range

    Use the pool ipv4 command to enter IPv4 pool configuration submode and pool ipv6 command to enter IPv6 pool configuration submode. Multiple address-ranges are allowed within a pool. Task ID Task ID Operation ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 95: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables distributed address pool service on vrf. exclude, on page 82 Specifies a range of IP addresses that distributed address pool service should not assign to clients. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 96: Exclude

    The low IP address cannot overlap with the IP address of a reserved address command. Multiple exclude commands are allowed within a pool. To exclude a single address, <highIpAddress> can be omitted. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 97: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    90 Enables distributed address pool service on vrf. network (BNG), on page 84 Specifies a set of addresses or prefixes inside a subnet. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 98: Network (Bng)

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 99: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    90 Enables distributed address pool service on vrf. prefix-length, on page 86 Specifies the length of the prefix that is assigned to the client. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 100: Prefix-Length

    Examples This is an example of configuring the prefix-length command in the IPv6 configuration submode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pool vrf vrf1 ipv6 pool3 RP/0/RSP0/CPU0:router(config-pool-ipv6)# prefix-length 50 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 101: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    90 Enables distributed address pool service on vrf. network (BNG), on page 84 Specifies a set of addresses or prefixes inside a subnet. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 102: Prefix-Range

    Examples This is an example of configuring the prefix-range command in IPv6 configuration submode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pool vrf vrf1 ipv6 pool3 RP/0/RSP0/CPU0:router(config-pool-ipv6)# prefix-range 1001:1:1:1:: 1001:1:1:10:: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 103: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    90 Enables distributed address pool service on vrf. prefix-length, on page 86 Specifies the length of the prefix that is assigned to the client. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 104: Pool Vrf

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the pool ipv4 command to enter IPv4 pool configuration submode and pool ipv6 command to enter IPv6 pool configuration submode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 105: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Command Description pool ipv4, on page 92 Enables distributed address pool service on IPv4. pool ipv6, on page 94 Enables distributed address pool service on IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 106: Pool Ipv4

    Examples This is an example of configuring the pool ipv4 command in the Global Configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pool ipv4 pool1 RP/0/RSP0/CPU0:router(config-pool-ipv4)# address-range 10.10.10.1 10.10.10.254 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 107: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies a range of IP addresses that distributed address pool service should not assign to clients. address-range, on page 80 Specifies a range of IP addresses. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 108: Pool Ipv6

    Examples This is an example of configuring the pool ipv6 command in the Global Configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pool ipv6 p6 prefix-length 45 RP/0/RSP0/CPU0:router(config-pool-ipv6)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 109: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Address Pool Service Commands pool ipv6 Related Commands Command Description pool vrf, on page 90 Enables distributed address pool service on vrf. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 110: Utilization-Mark

    0 and 100. The utilization is defined as the # allocated addresses or # total addresses. Task ID Task ID Operation ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 111: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables distributed address pool service on vrf. exclude, on page 82 Specifies a range of IP addresses that distributed address pool service should not assign to clients. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 112: Show Pool Ipv4 Name

    Operation ip-services read Examples This is the sample output of the show pool ipv4 name command: RP/0/RSP0/CPU0:router# show pool ipv4 name POOL1 Pool POOL1 Allocations --------------------------------------------------- Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 113: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    12.0.0.4 12.0.0.5 12.0.0.6 12.0.0.7 12.0.0.8 12.0.0.9 12.0.0.10 12.0.0.11 12.0.0.12 12.0.0.13 12.0.0.14 12.0.0.15 12.0.0.16 12.0.0.17 12.0.0.18 12.0.0.19 12.0.0.20 12.0.0.21 12.0.0.22 12.0.0.23 12.0.0.24 12.0.0.25 12.0.0.26 12.0.0.27 12.0.0.28 12.0.0.29 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 114: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    12.0.0.76 12.0.0.77 12.0.0.78 12.0.0.79 12.0.0.80 12.0.0.81 12.0.0.82 12.0.0.83 12.0.0.84 12.0.0.85 12.0.0.86 12.0.0.87 12.0.0.88 12.0.0.89 12.0.0.90 12.0.0.91 12.0.0.92 12.0.0.93 12.0.0.94 12.0.0.95 12.0.0.96 12.0.0.97 12.0.0.98 12.0.0.99 12.0.0.100 12.0.0.101 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 115: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies a range of IP addresses that distributed address pool service should not assign to clients. address-range, on page 80 Specifies a range of IP addresses. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 116: Show Pool Ipv6 Name

    This is the sample output for the show pool ipv6 name command: RP/0/RSP0/CPU0:router# show pool ipv4 name POOL_A6_i_1 Pool POOL_A6_i_1 Allocations --------------------------------------------------- VRF: vrf1 Pool Id: 1 Pool Scope: VRF Specific Pool Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 117: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    19::14 DHCPV6 19::15 DHCPV6 19::16 DHCPV6 19::17 DHCPV6 19::18 DHCPV6 19::19 DHCPV6 19::1a DHCPV6 19::1b DHCPV6 19::1c DHCPV6 19::1d DHCPV6 19::1e DHCPV6 19::1f DHCPV6 19::20 DHCPV6 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 118: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    19::5d DHCPV6 19::5e DHCPV6 19::5f DHCPV6 19::60 DHCPV6 19::61 DHCPV6 19::62 DHCPV6 19::63 DHCPV6 19::64 DHCPV6 19::65 DHCPV6 19::66 DHCPV6 19::67 DHCPV6 19::68 DHCPV6 19::69 DHCPV6 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 119: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    19::a6 DHCPV6 19::a7 DHCPV6 19::a8 DHCPV6 19::a9 DHCPV6 19::aa DHCPV6 19::ab DHCPV6 19::ac DHCPV6 19::ad DHCPV6 19::ae DHCPV6 19::af DHCPV6 19::b0 DHCPV6 19::b1 DHCPV6 19::b2 DHCPV6 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 120: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    19::ef DHCPV6 19::f0 DHCPV6 19::f1 DHCPV6 19::f2 DHCPV6 19::f3 DHCPV6 19::f4 DHCPV6 19::f5 DHCPV6 19::f6 DHCPV6 19::f7 DHCPV6 19::f8 DHCPV6 19::f9 DHCPV6 19::fa DHCPV6 19::fb DHCPV6 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 121: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies a range of IP addresses that distributed address pool service should not assign to clients. address-range, on page 80 Specifies a range of IP addresses. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 122: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Address Pool Service Commands show pool ipv6 name Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 123: Show Pool Vrf

    Use the pool ipv4 command to enter IPv4 pool configuration submode and pool ipv6 command to enter IPv6 pool configuration submode. Task ID Task ID Operation ip-services read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 124: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Command Description pool vrf, on page 90 Enables distributed address pool service on vrf. pool ipv4, on page 92 Enables distributed address pool service on ipv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 125: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies a range of IP addresses that distributed address pool service should not assign to clients. address-range, on page 80 Specifies a range of IP addresses. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 126: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Address Pool Service Commands show pool vrf Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 127: Control Policy Commands

    This module describes the Cisco IOS XR software commands used to configure the Control Policy commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 128: Activate

    Release Modification Release 4.2.0 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operation read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 129: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-pmap-c)# 1 activate dynamic-template DL1 aaa list default Related Commands Command Description deactivate, on page 122 Deactivates the dynamic template mode in the class map sub-configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 130: Authenticate (Bng)

    This is an example of configuring the authenticate command in the Global Configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# policy-map type control subscriber PL1 RP/0/RSP0/CPU0:router(config-pmap)# event session-start match-first Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 131: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Control Policy Commands authenticate (BNG) RP/0/RSP0/CPU0:router(config-pmap-e)# class type control subscriber CL2 RP/0/RSP0/CPU0:router(config-pmap-c)# 1 authenticate aaa list default Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 132: Authorize

    Specifies to use source-address-ipv4 as the username in authorize request. source-address-mac Specifies to use source-address-mac as the username in authorize request. Specifies an authorize username. username Command Default None Command Modes Global Configuration mode Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 133: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# policy-map type control subscriber PL1 RP/0/RSP0/CPU0:router(config-pmap)# event session-start match-first RP/0/RSP0/CPU0:router(config-pmap-e)# class type control subscriber CL2 RP/0/RSP0/CPU0:router(config-pmap-c)# 1 authorize aaa list default password DdjkkWE Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 134: Class-Map Type Control Subscriber

    Use the class-map type control subscriber command to enter class-map configuration mode. From Cisco IOS XR Software Release 5.2.2 and later, you can edit the class associated with the subscriber policy even while the sessions are active. Prior to this, new class map actions were not editable if the sessions were up, and any such dynamic policy-map changes resulted in clearing off the subscriber sessions.

  • Page 135: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description policy-map type control subscriber, on page 129 Enables the policy-map. event, on page 124 Enables the event in a policy-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 136: Deactivate

    Examples This is an example of configuring the deactivate command in the class map sub-configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# policy-map type control subscriber PL1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 137: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-pmap-c)# 1 deactivate dynamic-template DL1 aaa list default Related Commands Command Description activate, on page 114 Activates the dynamic template mode in the class map sub-configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 138: Event

    Specifies session activate event. session-start Specifies session start event. Specifies session start event. session-stop timer-expiry Specifies the timer expiry event. Command Default None Command Modes Policy-map configuration Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 139: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example shows how to configure the exception event in policy configuration mode, with the action as disconnect: RP/0/RSP0/CPU0:router(config)# policy-map type control subscriber PL1 RP/0/RSP0/CPU0:router(config-pmap)# event exception match-first Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 140: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-cmap-c)# 10 disconnect Related Commands Command Description class-map type control subscriber, on page 120 Enables the class-map. policy-map type control subscriber, on page 129 Enables the policy-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 141: Match (Class-Map)

    Specifies the service name. service-name Service name as a string. source-address Specifies the source address. timer Specifies the timer. Specifies the name of the user. username Command Default None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 142: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of configuring the service-name matching in the class-map (type subscriber) configuration mode: RP/0/RSP0/CPU0:router(config)# class-map type control subscriber match-any match-svc RP/0/RSP0/CPU0:router(config-cmap)# match service-name idle-to RP/0/RSP0/CPU0:router(config-cmap)# match service-name regexp id* RP/0/RSP0/CPU0:router(config-cmap)# match service-name regexp .* Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 143: Policy-Map Type Control Subscriber

    From Cisco IOS XR Software Release 5.2.2 and later, you can edit the class associated with the subscriber policy even while the sessions are active. Prior to this, new class map actions were not editable if the sessions were up, and any such dynamic policy-map changes resulted in clearing off the subscriber sessions.

  • Page 144: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description class-map type control subscriber, on page 120 Enables the class-map. event, on page 124 Enables the event in the policy-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 145: Policy-Map Type Pbr

    This is an example of configuring the policy-map type pbr command in the Global Configuration mode: RP/0/RSP0/CPU0:router(config)# policy-map type pbr pbr_policy RP/0/RSP0/CPU0:router(config-pmap)# end-policy-map Related Commands Command Description class-map type control subscriber, on page 120 Enables the class-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 146: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Control Policy Commands policy-map type pbr Command Description event, on page 124 Enables the event in the policy-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 147: Service-Policy Type Control Subscriber

    RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 344 RP/0/RSP0/CPU0:router(config-if)# service-policy type control subscriber sub1 Related Commands Command Description class-map type control subscriber, on page 120 Enables the class-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 148: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Control Policy Commands service-policy type control subscriber Command Description event, on page 124 Enables the event in the policy-map. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 149: Show Class-Map

    The show class-map output is as follows: Wed Jan 23 08:55:15.027 GMT 1) ClassMap: PTA_CLASS Type: subscriber_control Referenced by 1 Policymaps This table describes the significant fields shown in the display. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 150: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Command Description class-map type control subscriber, on page 120 Determines the list of actions to be executed for the class and enters the class-map configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 151: Show Policy-Map

    This is a sample output of the show policy-map command in the EXEC mode: RP/0/RSP0/CPU0:router# show policy-map control subscriber pmap-name POLICY1 The show policy-map output is as follows: Wed Jan 23 08:56:13.794 GMT Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 152: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    129 Determines the list of events that are applicable to the subscriber lifecycle and to enter the policy-map configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 153: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This module describes the Cisco IOS XR software commands used to configure the DHCP commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 154: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    213 • show dhcp ipv6 server interface, page 216 • show dhcp ipv6 server profile, page 218 • show dhcp ipv6 server statistics, page 220 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 155: Address-Pool

    This is an example of creating a address-pool name using the address-pool command: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# class class_dhcp RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile-class)# address-pool pool_addr Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 156: Aftr-Name

    This example shows how to configure the AFTR Fully Qualified Domain Name (FQDN) for a server profile: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# aftr-name aftr-server.example.com Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 157: Broadcast-Flag Policy Check (Bng)

    No specific guidelines impact the use of this command. Task ID Task ID Operations ip-services read, write Examples This an example of the broadcast-flag policy check command: RP/0/RSP0/CPU0:router# config Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 158: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 191 Configures how a relay agent processes BOOTREQUEST messages that already contain a relay information option. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 159: Class

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 160: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-dhcpv6)# profile dhcp_profile2 server RP/0/RSP0/CPU0:router(config-dhcpv4-server-profile)# class red Related Commands Command Description class-map type control subscriber, on page 120 This topic describes the class-map type control subscriber command. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 161: Dhcp Ipv4 (Bng)

    Use the dhcp ipv4 command to enter DHCP IPv4 configuration mode. Task ID Task ID Operations ip-services read, write Examples This example shows how to enable DHCP for IPv4: RP/0/RSP0/CPU0:router# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 162: Dhcp Ipv6 (Bng)

    Use the dhcp ipv6 command to enter DHCP IPv6 configuration mode. Task ID Task ID Operations ip-services read, write Examples This example shows how to enable DHCP for IPv6: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 163: Dhcpv6 Address-Pool

    This is an example of creating an IPv6 address pool for PPPoE subscribers using the dhcpv6 address-pool command: RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ppp my-ipv6-pppoe-tempate RP/0/RSP0/CPU0:router(config-dynamic-template-type)# dhcpv6 address-pool my-pppoe-addr-pool Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 164: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of creating an IPv6 address pool for IPoE subscribers using the dhcpv6 address-pool command: RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ppp my-ipv6-tempate RP/0/RSP0/CPU0:router(config-dynamic-template-type)# dhcpv6 address-pool my-ipsub-addr-pool Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 165: Dhcpv6 Delegated-Prefix-Pool

    Examples This is an example of creating a delegated prefix-pool name using the dhcpv6 delegated-prefix-pool command: RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ipsubscriber ipsub1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# dhcpv6 delegated-prefix-pool myPool Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 166: Dns-Server (Bng)

    To enter the DHCP IPv6 server profile class configuration, enter class class_name command in the DHCPv6 server profile configuration mode. Task ID Task ID Operations ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 167: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of setting the DNS address - 2001:db8:1203::1 and 2001:db8:1204::1 - using the dns-server command in the DHCP IPv6 server profile class configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# class proxy-red RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile-class)# dns-server 2001:db8:1203::1 and 2001:db8:1204::1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 168: Domain-Name (Dhcp Ipv6 Pool-Bng)

    If the same parameters are defined in the class scope, then the values defined in the class scope takes precedence. Task ID Task ID Operations ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 169: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of setting the domain name using the domain-name command in the DHCP IPv6 server profile class configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# class proxy-red RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile-class)# domain-name my.domain.com Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 170: Duplicate-Mac-Allowed

    With exclude-vlan option enabled, both inner and outer VLANs get excluded. You cannot exclude just one of them. Task ID Task ID Operation ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 171: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-dhcpv4)# duplicate-mac-allowed exclude-vlan Related Commands Command Description dhcp ipv4 (BNG), on page 147 Enables Dynamic Host Configuration Protocol (DHCP) for IPv4 and enters DHCP IPv4 configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 172: Framed-Prefix-Pool

    Examples This is an example of creating a framed prefix pool name using the framed-prefix-pool command: RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ipv6 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# framed-prefix-pool my-slaac-pool Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 173: Helper-Address (Bng)

    This command is supported in DHCPv6 profile relay configuration submode. Usage Guidelines A maximum of upto eight helper addresses can be configured. Task ID Task ID Operations ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 174: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 191 Configures how a relay agent processes BOOTREQUEST messages that already contain a relay information option. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 175: Inner-Cos

    RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# inner-cos 0 Related Commands Command Description outer-cos, on page 178 Resets the default outer-cos value for DHCPv4 control packets sent on BNG subscriber interfaces. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 176: Interface (Dhcp-Bng)

    DHCP IPv6 configuration DHCP IPv4 configuration Command History Release Modification Release 4.1.0 This command was introduced. Release 4.3.0 The support for IPv6 was added in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 177: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is an example of enabling the DHCP interface mode on a Packet over Sonet/SDH (POS) interface using the interface command: RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# interface POS 0/5/0/0 server profile TEST Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 178: Interface Subscriber-Pppoe Profile

    This is an example for enabling PPPoE subscribers to use the "my-def-pppoe-green" profile for all the PPPoE subscribers using the interface subscriber-pppoe profile command: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# interface subscriber-pppoe profile my-def-pppoe-green Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 179: Lease

    The default lease time is 1 day, when no lease time configuration exists. The lease time is specified in seconds or date format. Task ID Task ID Operation ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 180: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# lease 1 6 0 This example shows how to configure infinite amount of lease time: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# lease infinite Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 181: Lease Proxy Client-Lease-Time

    This is an example of configuring the lease proxy client-lease-time command in the DHCP IPv4 sub configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile myproxyprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv4)# lease proxy client-lease-time 600 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 182: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands lease proxy client-lease-time Related Commands Command Description dhcp ipv4 (BNG), on page 147 Enables the Dynamic Host Configuration Protocol (DHCP) for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 183: Limit Lease Per-Circuit-Id

    This is an example of configuring the limit lease per-circuit-id command in the DHCP IPv4 sub configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile myproxyprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv4)# limit lease per-circuit-id 1000 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 184: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands limit lease per-circuit-id Related Commands Command Description dhcp ipv4 (BNG), on page 147 Enables the Dynamic Host Configuration Protocol (DHCP) for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 185: Limit Lease Per-Interface

    This is an example of configuring the limit lease per-interface command in the DHCP IPv4 sub configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile myproxyprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv4)# limit lease per-interface 1000 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 186: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands limit lease per-interface Related Commands Command Description dhcp ipv4 (BNG), on page 147 Enables the Dynamic Host Configuration Protocol (DHCP) for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 187: Limit Lease Per-Remote-Id

    This is an example of configuring the limit lease per-remote-id command in the DHCP IPv4 sub configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile myproxyprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv4)# limit lease per-remote-id 1000 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 188: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands limit lease per-remote-id Related Commands Command Description dhcp ipv4 (BNG), on page 147 Enables the Dynamic Host Configuration Protocol (DHCP) for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 189: Match Option

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 190: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config-dhcpv4-proxy-profile-class)# match option 124 hex hex_name mask 3445 Related Commands Command Description class, on page 145 Creates a proxy profile class and enters the proxy profile class sub configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 191: Match Vrf

    RP/0/RSP0/CPU0:router(config-dhcpv4)# profile dhcp_profile proxy RP/0/RSP0/CPU0:router(config-dhcpv4-proxy-profile)# class blue RP/0/RSP0/CPU0:router(config-dhcpv4-proxy-profile-class)# match vrf vrf1 Related Commands Command Description match option, on page 175 Matches the proxy with the configured pattern. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 192: Outer-Cos

    RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# outer-cos 0 Related Commands Command Description inner-cos, on page 161 Resets the default inner-cos value for DHCPv4 control packets sent on BNG subscriber interfaces. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 193: Prefix-Pool

    This is an example of creating a prefix-pool name using the prefix-pool command: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# class class_dhcp RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile-class)# prefix-pool pool1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 194: Profile (Bng)

    Release 4.3.0 Support was added for IPv6. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operations ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 195: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example shows how to enable the dhcpv6 configuration mode and how to create a profile called dhcp_v6 in the dhcpv6 configuration submode: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile dhcp_v6 proxy RP/0/RSP0/CPU0:router(config-dhcpv6-proxy-profile)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 196: Rapid Commit

    Examples This is an example of enabling rapid-commit in the DHCP IPv6 server profile configuration mode: RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile my_profile server RP/0/RSP0/CPU0:router(config-dhcpv6-server-profile)# rapid-commit Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 197: Relay Information Authenticate (Bng)

    This example shows how to specify the received relay agent information option for authentication using the relay information authenticate command in DHCP IPv4 proxy profile configuration mode: RP/0/RSP0/CPU0:router# config RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile myprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv4-proxy-profile)# relay information authenticate received Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 198: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 191 Configures how a relay agent processes BOOTREQUEST messages that already contain a relay information option. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 199: Relay Information Check (Bng)

    Examples This example shows how to use the relay information check command: RP/0/RSP0/CPU0:router#config RP/0/RSP0/CPU0:router(config)# dhcp ipv4 RP/0/RSP0/CPU0:router(config-dhcpv4)# profile client relay RP/0/RSP0/CPU0:router(config-dhcpv4-relay-profile)# relay information check Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 200: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 189 Configures the DHCP component to not drop BOOTREQUEST messages that have the relay information option set and the giaddr set to zero. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 201: Relay Information Option (Bng)

    This configuration prevents the server or relay from dropping the DHCP message. Task ID Task ID Operations ip-services read, write basic-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 202: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 189 Configures the DHCP component to not drop BOOTREQUEST messages that have the relay information option set and the giaddr set to zero. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 203: Relay Information Option Allow-Untrusted (Bng)

    Task ID Task ID Operations ip-services read, write basic-services read, write Examples This example shows how to use the relay information option allow-untrusted command: RP/0/RSP0/CPU0:router# config Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 204: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on page 187 Enables the system to insert a DHCP relay agent information option in forwarded BOOTREQUEST messages to a DHCP server. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 205: Relay Information Policy (Bng)

    82 information. This configuration allows the DHCP server to use option 82 information from both relay agents. Task ID Task ID Operations ip-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 206: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (BNG), on Configures the DHCP component to not drop page 189 BOOTREQUEST messages that have the relay information option set and the giaddr set to zero. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 207: Relay Option Remote-Id

    This example shows how to set the remote-id value as "my-remote-id-12345" using the relay option remote-id command in DHCP IPv6 proxy profile configuration mode: RP/0/RSP0/CPU0:router# config RP/0/RSP0/CPU0:router(config)# dhcp ipv6 RP/0/RSP0/CPU0:router(config-dhcpv6)# profile myprofile proxy RP/0/RSP0/CPU0:router(config-dhcpv6-proxy-profile)# relay option remote-id my-remote-id-12345 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 208: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Description relay information option (BNG), on page Enables the system to insert a DHCP relay agent information option in forwarded BOOTREQUEST messages to a DHCP server. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 209: Show Dhcp Ipv4 Proxy Binding

    Displays the output modifiers. Command Default Displays brief information about all DHCP proxy client bindings. Command Modes EXEC mode Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 210: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    VRF: default Subscriber Label: 0x0 RP/0/RSP0/CPU0:router# show dhcp ipv4 proxy binding remote-id RRRRRRRRRR MAC Address: 0000.6602.0102 IP Address: 1.1.1.1 Profile: circuit-id: CCCCCCCCCC remote-id: RRRRRRRRRR State: BOUND Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 211: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Server VRF: default IP Address: 10.10.10.10 Giaddr from client: 0.0.0.0 Giaddr to server: 10.10.10.1 Server IP Address: 20.20.20.2 Server IP Address to client: 10.10.10.1 ReceivedCircuit InsertedCircuit ReceivedRemote Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 212: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables the Dynamic Host Configuration Protocol (DHCP) for IPv4. show dhcp ipv6 proxy binding (BNG), on Shows the client bindings for Dynamic Host Configuration page 205 Protocol (DHCP) proxy. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 213: Show Dhcp Ipv4 Proxy Interface (Bng)

    5 14:25:53.484 UTC Interface: Bundle-Ether70.16 VRF: default Mode: Proxy Profile Name: proxy1 Lease Limit: per circuit id from AAA 2 Lease Count Details: Circuit id from AAA Count Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 214: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies the lease limit value sent from AAA server. Count Specifies the number of sessions on the router having the specific Circuit-ID received from the AAA server. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 215: Show Dhcp Ipv4 Proxy Profile

    RP/0/RSP0/CPU0:router# show dhcp ipv4 proxy profile The show dhcp ipv4 proxy profile output is as follows: Wed Jan 23 17:05:49.760 IST DHCP IPv4 Proxy Profiles -------------------------- Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 216: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This table describes the significant fields shown in the display. Table 10: show dhcp ipv4 proxy profile Field Descriptions Field Description DHCP IPv4 Proxy Profiles Specifies all the DHCP IPv4 proxy profiles. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 217: Show Dhcp Ipv4 Proxy Statistics

    This is the sample output of the show dhcp ipv4 proxy statistics command: RP/0/RSP0/CPU0:router# show dhcp ipv4 proxy statistics The show dhcp ipv4 proxy statistics output is as follows: Wed Jan 23 17:07:12.386 IST ------------------------------------------------------------------------------------------- default **nVSatellite Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 218: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This table describes the significant fields shown in the display. Table 11: show dhcp ipv4 proxy statistics Field Descriptions Field Description Specifies the VRF in the DHCP proxy. The default is nVSatellite. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 219: Show Dhcp Ipv6 Proxy Binding (Bng)

    Release 4.3.0 This command was supported for BNG. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operation ip-services read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 220: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router# show dhcp ipv6 proxy binding summary Total number of clients: 2 STATE COUNT IA-NA IA-PD -------------------------------------------------------- INIT SUB VALIDATING ADDR/PREFIX ALLOCATING| REQUESTING SESSION RESP PENDING ROUTE UPDATING BOUND Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 221: Show Dhcp Ipv6 Proxy Interface (Bng)

    Examples This is a sample output from the show dhcp ipv6 proxy interface command: RP/0/RSP0/CPU0:router# show dhcp ipv6 proxy interface Tue Sep 4 19:14:54.056 UTC Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 222: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    CID - Circuit Id, RID - Remote Id, INTF - Interface Interface Mode Profile Name Amb Lease Limit ------------------------------------------------------------------------------------ BE1.100 pxy1 None BE1.200 pxy1 None BE1.250 pxy1 Yes None BE1.400 pxy1 Yes None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 223: Show Dhcp Ipv6 Proxy Profile

    This is a sample output from the show dhcp ipv6 proxy profile command: RP/0/RSP0/CPU0:router# show dhcp ipv6 proxy profile Tue Sep 4 05:00:57.938 UTC DHCP IPv6 Proxy Profiles -------------------------- Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 224: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands show dhcp ipv6 proxy profile pxy1 pxy_pppoe1 pxy_pppoe2 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 225: Show Dhcp Ipv6 Proxy Statistics

    This is a sample output from the show dhcp ipv6 proxy statistics command: RP/0/RSP0/CPU0:router# show dhcp ipv6 proxy statistics Wed Sep 5 01:10:35.650 UTC ------------------------------------------------------------------------------------------- default Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 226: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands show dhcp ipv6 proxy statistics blue green orange test_vrf dhcpclient dhcpserver Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 227: Show Dhcp Ipv6 Server Binding

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation ip-services read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 228: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Client DUID: 000300010000641e0103 Client Flag: 0x80080811 Subscriber VRF: Class Name: Access Interface: Bundle-Ether2.3 Access VRF: Subscriber Label: 0x82f VLAN Id: ReceivedRemote ID: ReceivedInterface ID: Prefix Pool Name: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 229: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    ReceivedRemote ID: ReceivedInterface ID: Prefix Pool Name: Address Pool Name: IA ID: 0xb102 STATE: BOUND IPv6 Prefix: 2004:4:4:b::/64 (Bundle-Ether2.3) lifetime: 600 secs (00:10:00) expiration: 585 secs (00:09:45) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 230: Show Dhcp Ipv6 Server Interface

    Displays the fully qualified location specification of an interface. Command Default None Command Modes EXEC mode Command History Release Modification Release 4.3.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 231: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This is a sample output from the show dhcp ipv6 server interface command: RP/0/RSP0/CPU0:router# show dhcp ipv6 server interface bundle-Ether 2.3 Tue Sep 4 05:02:03.861 UTC Interface: Bundle-Ether2.3 VRF: Mode: Server Profile Name: test Lease Limit: None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 232: Show Dhcp Ipv6 Server Profile

    This is a sample output from the show dhcp ipv6 server profile command: RP/0/RSP0/CPU0:router# show dhcp ipv6 server profile name test Tue Sep 4 05:00:57.938 UTC Profile: test DNS Addresses:None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 233: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands show dhcp ipv6 server profile Client Lease Time: 0 secs (00:00:00) Framed Address Pool: p1 Delegated Prefix Pool: p2 Interface References: Bundle-Ether2.3 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 234: Show Dhcp Ipv6 Server Statistics

    This is a sample output from the show dhcp ipv6 server statistics command: RP/0/RSP0/CPU0:router# show dhcp ipv6 server statistics Tue Sep 4 19:13:47.472 UTC ------------------------------------------------------------------------------------------- default 10003 11651 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 235: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands show dhcp ipv6 server statistics blue green orange test_vrf dhcpclient dhcpserver Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 236: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG DHCP Commands show dhcp ipv6 server statistics Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 237: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This module describes the Cisco IOS XR software commands used to configure and verify the interfaces for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 238: Encapsulation Ambiguous Dot1Ad

    • encapsulation ambiguous dot1ad {any | vlan-range } • encapsulation ambiguous dot1ad vlan-id dot1q { any | vlan-range } • encapsulation ambiguous dot1ad vlan-range dot1q any Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 239: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    (config-subif)#encapsulation ambiguous dot1ad 1-1000 dot1q any Related Commands Command Description encapsulation ambiguous dot1q, on page Configures encapsulated ambiguous VLANs with IEEE 802.1q encapsulation type, on an access-interface in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 240: Encapsulation Ambiguous Dot1Q

    The valid combinations of ambiguous VLAN configurations in BNG, with IEEE 802.1q encapsulation type are: • encapsulation ambiguous dot1q {any | vlan-range } • encapsulation ambiguous dot1q vlan-id second-dot1q { any | vlan-range } Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 241: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Related Commands Command Description encapsulation ambiguous dot1ad, on Configures encapsulated ambiguous VLANs with IEEE 802.1ad page 224 Provider Bridging (PB) encapsulation type, on an access-interface in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 242: Show Ethernet Tags

    MTU on the sub-interface is calculated by adding 4 (and not 8) bytes to the main interface MTU. That is, 1514 + 4 = 1518 bytes. This behavior is applicable for both physical interfaces and bundle sub-interfaces. Task ID Task ID Operation ethernet-services read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 243: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    GigabitEthernet0/1/0/10.12 is up, service is L3 Interface MTU is 1518 Outer Match: Dot1Q VLAN 11-20,21-30,31-60,61-100,101-140,141-180,181-220,221-260,261-300 Inner Match: Dot1Q VLAN any Local traffic encap: - Pop 0 tags, push none Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 244: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    BNG Interface Commands show ethernet tags Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 245: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This module describes the Cisco IOS XR software commands used to configure the Dynamic Template commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 246: Dynamic-Template

    Use the dynamic-template command to enter dynamic template configuration mode. Task ID Task ID Operation config-services read, write Examples This is an example of configuring the dynamic-template command in the Global Configuration mode: RP/0/RSP0/CPU0:router# configure Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 247: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables the ppp dynamic template type. dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. dynamic-template type service, on page 238 Enables the service dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 248: Dynamic-Template Type Ipsubscriber

    Related Commands Command Description dynamic-template, on page 232 Enables the dynamic template configuration mode. dynamic-template type ppp, on page 236 Enables the ppp dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 249: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Dynamic Template Commands dynamic-template type ipsubscriber Command Description dynamic-template type service, on page 238 Enables the service dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 250: Dynamic-Template Type Ppp

    Related Commands Command Description dynamic-template, on page 232 Enables the dynamic template configuration mode. dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 251: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Dynamic Template Commands dynamic-template type ppp Command Description dynamic-template type service, on page 238 Enables the service dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 252: Dynamic-Template Type Service

    This is an example of configuring the dynamic-template type service command: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type service s1 Related Commands Command Description dynamic-template, on page 232 Enables the dynamic template configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 253: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Command Description dynamic-template type ppp, on page 236 Enables the ppp dynamic template type. dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 254: Monitor-Session (Interface-Dynamic-Template-Bng)

    Before you can associate a traffic mirroring session to a specific interface, you must define it using the monitor-session global configuration command. After the traffic mirroring session is defined, use the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 255: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Example: interface TenGigE0/1/0/1.601 ipv4 address 10.0.1.1 255.255.255.0 encapsulation dot1q 601 For more information about monitoring a session, see Configuring Traffic Monitoring chapter in Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Configuration Guide. Task ID Task ID...

  • Page 256: Service-Policy (Bng)

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the dynamic-template type ppp command to enter the ppp dynamic template type configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 257: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Enables the ppp dynamic template type. dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. accounting aaa list type service, on page 29 Configures service accounting feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 258: Test Radius Coa Activate

    (using dynamic templates), as a pre-requisite for executing test radius coa activate command. Task ID Task ID Operation network read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 259: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Displays status information about configured traffic mirroring sessions. Displays statistics regarding traffic mirroring show monitor-session counters sessions. clear monitor-session counters Clears the traffic mirroring session statistics. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 260: Timeout Idle

    Considers outbound traffic only while deriving the duration of session idleness. Command Default None Command Modes Dynamic template type configuration Command History Release Modification Release 4.2.1 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 261: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. In Cisco IOS XR software release 4.2.1, both the IPoE and PPPoE sessions are retained idle, when the idle timeout period expires. In Cisco IOS XR software release 4.2.3, only the IPoE sessions are terminated when the idle timeout period expires.

  • Page 262: Vrf (Dynamic-Template-Bng)

    Related Commands Command Description dynamic-template, on page 232 Enables the dynamic template configuration mode. dynamic-template type ppp, on page 236 Enables the ppp dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 263: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Dynamic Template Commands vrf (dynamic-template-BNG) Command Description dynamic-template type ipsubscriber, on page 234 Enables the ipsubscriber dynamic template type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 264: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Dynamic Template Commands vrf (dynamic-template-BNG) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 265: Excessive Punt Flow Trap Commands

    This module describes the Cisco IOS XR software commands used to configure the Excessive Punt Flow Trap commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 266: Lpts Punt Excessive-Flow-Trap

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 267: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# lpts punt excessive-flow-trap RP/0/RSP0/CPU0:router(config-control-plane-policer)# Related Commands Command Description show lpts punt excessive-flow-trap, on page 260 Displays the bad actor flows trapped by the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 268: Lpts Punt Excessive-Flow-Trap Dampening

    Task ID Task ID Operation config-services read, write Examples This example shows how to configure a dampening time of 40 milliseconds: RP/0/RSP0/CPU0:router#configure RP/0/RSP0/CPU0:router(config)#lpts punt excessive-flow-trap dampening 40 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 269: Lpts Punt Excessive-Flow-Trap Penalty-Rate

    Command Modes Global Configuration mode Command History Release Modification Release 4.3.0 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 270: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Configuration mode: RP/0/RSP0/CPU0:router(config)# lpts punt excessive-flow-trap penalty-rate arp 4 RP/0/RSP0/CPU0:router(config)# Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 271: Lpts Punt Excessive-Flow-Trap Penalty-Timeout

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 272: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Configuration mode: RP/0/RSP0/CPU0:router(config)# lpts punt excessive-flow-trap penalty-timeout dhcp 70 RP/0/RSP0/CPU0:router(config)# Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 273: Lpts Punt Excessive-Flow-Trap Subscriber-Interfaces

    RP/0/RSP0/CPU0:router(config)# lpts punt excessive-flow-trap subscriber-interfaces RP/0/RSP0/CPU0:router(config)# Related Commands Command Description show lpts punt excessive-flow-trap, on page 260 Displays the bad actor flows trapped by the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 274: Show Lpts Punt Excessive-Flow-Trap

    Displays the bad actors on an interface. For more information on the interface types, use the question mark (?) online help function. type Specifies the interface type. For more information, use the question mark (?) online help function. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 275: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Release 4.3.0 This command was introduced. Usage Guidelines No specific guidelines impact the use of this command. Task ID Task ID Operation lpts read basic-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 276: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    15 penalty-rate pppoe 25 penalty-timeout arp 2 non-subscriber-interfaces Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 277: Show Lpts Punt Excessive-Flow-Trap Information

    Police Rate: 10 pps Penalty Timeout: 15 mins -------------------------------------------------------------- Police Penalty Rate (pps) Timeout (mins) Protocol Default Config Default Config Punt Reasons -------- -------------- -------------- ---------------- Reverse ARP Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 278: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Table 12: show lpts punt excessive-flow-trap information Field Descriptions Field Description penalty-rate The penalty policing rate for a protocol. For arp the value is 15 and for pppoe the value is 25. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 279: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    The penalty timeout value for a protocol. For arp the value is 2. Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 280: Show Lpts Punt Excessive-Flow-Trap Interface

    • ppp—Displays PPP bad actors. • igmp—Displays IGMP bad actors. • ipv4—Displays IPv4 bad actors. • l2tp—Displays L2TP bad actors. • all—Displays bad actors for all protocols. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 281: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies if it uses the IPv4 or IPv6 protocol. punt reason The reason to punt the excessive flow trap. penalty-rate The penalty policing rate for a protocol in pps. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 282: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    The penalty timeout value for a protocol in minutes. Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 283: Show Lpts Punt Excessive-Flow-Trap Protocol

    The protocol option in the show lpts punt excessive-flow-trap protocol command points to the protocol type. The show output for each of the protocol differs depending on the protocol type you select on the router. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 284: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    The penalty timeout value for a protocol in minutes. Related Commands Command Description lpts punt excessive-flow-trap, on page 252 Enables the Excessive Punt Flow Trap feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 285: Ipoe Commands

    This module describes the Cisco IOS XR software commands used to configure the IPoE commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 286: Initiator Dhcp

    This is an example of configuring the initiator dhcp command in the Interface configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 56 RP/0/RSP0/CPU0:router(config-if)# ipsubscriber ipv4 l2-connected RP/0/RSP0/CPU0:router(config-if-ipsub-ipv4-l2conn)# initiator dhcp Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 287: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    293 Displays the ipsubscriber information. initiator unclassified-ip, on page 274 Enables packet-triggered IPv4 or IPv6 routed subscriber session in an access-interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 288: Initiator Unclassified-Ip

    Task ID Operation network read, write Examples This example shows how to host packet-triggered routed IPv4 subscriber sessions in an access-interface: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether101.201 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 289: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    272 Enables l2-connected IP subscriber for IPv4 or IPv6. ipsubscriber routed, on page 282 Enables an access-interface to host routed subscriber sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 290: Initiator Unclassified-Source

    This is an example of configuring the initiator unclassified-source command in the IP subscriber IPv4 L2-connected configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 56 RP/0/RSP0/CPU0:router(config-if)# ipsubscriber ipv4 l2-connected RP/0/RSP0/CPU0:router(config-if-ipsub-ipv4-l2conn)# initiator unclassified-source Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 291: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IPoE Commands initiator unclassified-source Related Commands Command Description show ipsubscriber summary, on page 293 Displays the ipsubscriber information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 292: Ipsubscriber Interface

    547 Displays the subscriber management feature attribute database information. show ipsubscriber access-interface, on page 286 Shows the access interface information for IP subscriber. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 293: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IPoE Commands ipsubscriber interface Command Description show ipsubscriber interface, on page 289 Shows the interface information for IP subscriber interfaces. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 294: Ipsubscriber L2-Connected

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 295: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 56 RP/0/RSP0/CPU0:router(config-if)# ipsubscriber ipv4 l2-connected initiator unclassified-source address-unique Related Commands Command Description show ipsubscriber summary, on page 293 Displays the ipsubscriber information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 296: Ipsubscriber Routed

    Command History Release Modification Release 5.1.1 This command was introduced. Release 5.2.2 Initiator unclassified-ip was added for the support of packet-triggered IPv4 or IPv6 routed subscriber sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 297: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Shows the access interface information for IP subscriber. show subscriber session, on page 566 Displays the subscriber management session information. initiator unclassified-ip, on page 274 Enables packet-triggered routed subscriber sessions on an access-interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 298: Ipsubscriber Session-Limit

    Operation network read, write Examples This is an example of configuring the ipsubscriber session-limit command in the interface configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 56 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 299: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IPoE Commands ipsubscriber session-limit RP/0/RSP0/CPU0:router(config-if)# ipsubscriber session-limit RP/0/RSP0/CPU0:router(config-ipsub-sess-limit)# total per-vlan 25 RP/0/RSP0/CPU0:router(config-ipsub-sess-limit)# unclassified-source per-vlan 452 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 300: Show Ipsubscriber Access-Interface

    For interface-based static sessions in the BNG, the value of Interface Type field in the show ipsubscriber access-interface command output is displayed as static. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 301: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Initiator DHCP disabled Session count 0 FSOL packets 0 FSOL dropped packets 0 FSOL flow rate dropped packets 0 FSOL session limit dropped packets 0 Initiator Packet-Trigger enabled Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 302: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies the various states of the access interface, for example, up, down, deleted, and unknown state. Related Commands Command Description ipsubscriber l2-connected, on page 280 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 303: Show Ipsubscriber Interface

    Inner VLAN ID. The range is from 1 to 4094. subscriber-ip Specifies the subscriber IPv4 address. subscriber-label Specifies the subscriber label. Specifies the subscriber MAC address. subscriber-mac Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 304: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    <-- this line will not be shown if not enabled IPv6: Initiator: DHCPv6 <-- this line will not be shown if not enabled Created: May 11 16:33:08 (age 00:03:08) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 305: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    340 (added) This table describes the significant fields shown in the display. Table 16: show ipsubscriber interface Field Descriptions Field Description Interface Specifies the access interface type. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 306: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies the various states of the access interface, for example, up, down, deleted, and unknown state. Related Commands Command Description ipsubscriber l2-connected, on page 280 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 307: Show Ipsubscriber Summary

    IPSUB Summary for all nodes Interface Counts: DHCP Pkt Trigger ---------- ------------ Invalid: Initialized: Session creation started: Control-policy executing: Control-policy executed: Session features applied: VRF configured: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 308: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Session creation started Specifies the total number of session initiation that was created. Control-policy executing Specifies the control policies that are executing for DHCP and Packet Trigger. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 309: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Specifies the packets that are in the unknown state. Error Specifies the number of packets that are errored out. Related Commands Command Description ipsubscriber l2-connected, on page 280 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 310: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    IPoE Commands show ipsubscriber summary Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 311: Ipv4 And Ipv6 Commands

    IPv4 and IPv6 Commands This module describes the Cisco IOS XR software commands used to configure the IPv4 and IPv6 commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 312: Ipv4 Mtu (Bng)

    The maximum MTU size that can be set on an interface depends on the interface medium. If the Layer 2 MTU is smaller than the Layer 3 MTU, the Cisco IOS XR software uses the Layer 2 MTU value for the Layer 3 MTU.

  • Page 313: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv4 mtu 300 Related Commands Command Description show ipv4 interface (BNG), on page 312 Displays the MTU status of interfaces configured for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 314: Ipv4 Unnumbered (Point-To-Point -Bng)

    Dynamic template configuration (for releases R4.2.0 onward) Command History Release Modification Release 3.7.2 This command was introduced. Release 4.2.0 This command was supported in the dynamic template configuration mode for BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 315: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    For releases R4.2.0 onward, this example shows how the Bundle-Ether interface is assigned address 100.10 in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv4 unnumbered Bundle-Ether100.10 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 316: Ipv4 Unreachables Disable (Bng)

    For releases R4.2.0 onward, to enter the dynamic template configuration mode, run the dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv4 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 317: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    For releases R4.2.0 onward, this example shows how to disable the generation of ICMP unreachable messages on dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv4 unreachables disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 318: Ipv4 Verify Unicast Source Reachable-Via (Bng)

    (spoofed) IP source addresses that pass through a router. Malformed or forged source addresses can indicate denial-of-service (DoS) attacks based on source IP address spoofing. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 319: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    This example shows how to configure strict RPF on dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv4 verify unicast source reachable-via Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 320: Ipv6 Enable (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 321: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 enable Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 322: Ipv6 Mtu (Bng)

    The maximum MTU size that can be set on an interface depends on the interface medium. If the Layer 2 MTU is smaller than the Layer 3 MTU, the Cisco IOS XR software uses the Layer 2 MTU value for the Layer 3 MTU.

  • Page 323: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 mtu 1350 Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 324: Ipv6 Unreachables Disable (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 325: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    For BNG, this example shows how to disable the generation of ICMP unreachable messages on dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 unreachables disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 326: Show Ipv4 Interface (Bng)

    (Optional) Displays the number of interfaces on the router that are assigned, unassigned, summary or unnumbered. Command Default If VRF is not specified, the software displays the default VRF. Command Modes EXEC mode Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 327: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    Shutdown, line protocol is Down Vrf is default (vrfid 0x60000000) Internet protocol processing disabled This table describes the significant fields shown in the display. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 328: Cisco Asr 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference

    1 MTU = maximum transmission unit 2 ARP = Address Resolution Protocoladdress resolution protocol 3 ICMPv4 = Internet Control Message Protocol internet control message protocol version 4 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 329: Show Ipv4 Traffic (Bng)

    0 strict source rt, 0 loose source rt, 0 record rt 0 stream ID, 0 timestamp, 0 alert, 0 cipso Frags: 0 reassembled, 0 timeouts, 0 couldn't reassemble 0 fragmented, 0 fragment count Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 330 IP packets forwarded or discarded in hardware. no route Counted when the Cisco IOS XR software discards a datagram it did not know how to route. 4 TTL = time-to-live Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 331: Show Ipv6 Interface (Bng)

    (Optional) Displays the global IPv6 address. summary (Optional) Displays the number of interfaces on the router that are assigned, unassigned, or unnumbered. Command Default None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 332 Hosts use stateless autoconfig for addresses. Outgoing access list is not set Inbound access list is not set This table describes the significant fields shown in the display. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 333 Displays the global unicast addresses assigned to the interface. ICMP redirects State of Internet Control Message Protocol (ICMP) IPv6 redirect messages on the interface (the sending of the messages is enabled or disabled). Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 334 This is the sample output of the show ipv6 vrf vrf-name interface type interface-path-id brief link-local command: RP/0/RSP0/CPU0:router#show ipv6 vrf vrf1 interface gigabitEthernet 0/0/0/2 brief link-local Interface IPv6-Address Status Protocol GigabitEthernet0/0/0/2 fe80::46:c8ff:fe22:daae Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 335 Interface IPv6-Address Status Protocol GigabitEthernet0/0/0/2 2001:db8::2 Related Commands Command Description show ipv4 interface (BNG), on page 312 Displays the usability status of interfaces configured for IPv4. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 336: Show Ipv6 Neighbors (Bng)

    When the interface-type and interface-number arguments are not specified, cache information for all IPv6 neighbors is displayed. Specifying the interface-type and interface-number arguments displays only cache information about the specified interface. Task ID Task ID Operations ipv6 read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 337 0/2/CPU0 2001:3::b 0013.9400.000b REACH BE3 0/2/CPU0 2001:3::c 0013.9400.000c REACH BE3 0/2/CPU0 2001:3::d 0013.9400.000d REACH BE3 0/2/CPU0 2001:3::e 0013.9400.000e REACH BE3 0/2/CPU0 2001:3::f 0013.9400.000f REACH BE3 0/2/CPU0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 338 Time (in minutes) since the address was confirmed to be reachable. A hyphen (-) indicates a static entry. Link-layer Addr MAC address. If the address is unknown, a hyphen (-) is displayed. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 339 IPv4 and IPv6 Commands show ipv6 neighbors (BNG) Field Description State Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 340 • INCMP (incomplete)—The interface for this entry is down. Note Reachability detection is not applied to static entries in the IPv6 neighbor discovery cache; Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 341 Interface from which the address is reachable. Related Commands Command Description show ipv6 neighbors summary (BNG), on page 328 Displays summary information for the neighbor entries. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 342: Show Ipv6 Neighbors Summary (Bng)

    RP/0/RSP0/CPU0:router# show ipv6 neighbors summary Mcast nbr entries: Subtotal: 0 Static nbr entries: Subtotal: 0 Dynamic nbr entries: Subtotal: 0 Total nbr entries: 0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 343 IPv4 and IPv6 Commands show ipv6 neighbors summary (BNG) Related Commands Command Description show ipv6 neighbors (BNG), on page 322 Displays IPv6 neighbor discovery cache information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 344: Show Ipv6 Traffic (Bng)

    0 unknown protocol 0 fragments, 0 total reassembled 0 reassembly timeouts, 0 reassembly failures 0 reassembly max drop sanity address check drops Sent: 0 generated, 0 forwarded Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 345 An error was found in generic HBH, RH, DH, or HA. Software only. unknown option Unknown option type in IPv6 header. unknown protocol Protocol specified in the IP header of the received packet is unreachable. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 346 Mcast: Multicast packets. ICMP statistics: Internet Control Message Protocol statistics. Related Commands Command Description show ipv4 traffic (BNG), on page 315 Displays statistics about IPv4 traffic. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 347: Multicast Commands

    This module describes the Cisco IOS XR software commands used to configure the Multicast commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 348: Router Igmp Vrf

    This is an example of configuring the router igmp vrf command in the Global Configuration mode: RP/0/RSP0/CPU0:router # configure RP/0/RSP0/CPU0:router(config)# router igmp vrf vrf1 RP/0/RSP0/CPU0:router(config)# router igmp vrf vrf1 traffic profile prof-name Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 349: Igmp Accounting

    Examples This is an example of configuring the igmp accounting command in the Global Configuration mode: RP/0/RSP0/CPU0:router # configure RP/0/RSP0/CPU0:router(config)# router igmp accounting max-history 67 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 350: Igmp Explicit-Tracking

    This is an example of configuring the igmp explicit-tracking command in the dynamic-template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# igmp explicit-tracking igmp1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 351 Management Protocol (IGMP) queries multicast (BNG), on page 342 Configures the mode in which the multicast components will work for subscriber sessions associated with a dynamic template. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 352: Igmp Query-Interval

    To configure the frequency at which the Cisco IOS XR Software sends Internet Group Management Protocol (IGMP) host-query messages, use the igmp query-interval command in the dynamic-template configuration mode. To disable this feature, use the no form of this command.
  • Page 353 346 Displays the internal statistics of the unicast-qos-adjusted feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 354: Igmp Query-Max-Response-Time

    This is the example of configuring the igmp query-max-response-time command in the dynamic-template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# igmp query-max-response-time 12 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 355 (BNG), on page 342 Configures the mode in which the multicast components will work for subscriber sessions associated with a dynamic template. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 356: Multicast (Bng)

    This is an example of configuring the multicast command in the dynamic-template configuration mode for type PPP: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template RP/0/RSP0/CPU0:router(config-dynamic-template)# type ppp foo RP/0/RSP0/CPU0:router(config-dynamic-template-type)# multicast ipv4 qos-correlation Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 357 Configures the maximum response time advertised in Internet Group Management Protocol (IGMP) queries show igmp unicast-qos-adjust statistics, on page 346 Displays the internal statistics of the unicast-qos-adjusted feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 358: Unicast-Qos-Adjust

    Operation multicast read, write Examples This is an example of configuring the unicast-qos-adjust command in the IGMP configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# router igmp RP/0/RSP0/CPU0:router(config-igmp)# unicast-qos-adjust Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 359 Internet Group Management Protocol (IGMP) queries. multicast (BNG), on page 342 Configures the mode in which the multicast components will work for subscriber sessions associated with a dynamic template. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 360: Show Igmp Unicast-Qos-Adjust Statistics

    RP/0/RSP0/CPU0:router# show igmp unicast-qos-adjust statistics The show igmp unicast-qos-adjust statistics output is as follows: Mon Feb 4 08:47:01.640 GMT IGMP to QoS Batch stats Current Queue count Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 361 Configures the IGMP QOS Shaper for subscriber unicast traffic. igmp explicit-tracking, on page 336 Configures explicit host tracking under Internet Group Management Protocol (IGMP) Version 3 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 362 Internet Group Management Protocol (IGMP) queries multicast (BNG), on page 342 Configures the mode in which the multicast components will work for subscriber sessions associated with a dynamic template. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 363: Show Igmp Vrf (Bng)

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation multicast read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 364 Specifies the number of unsupported interfaces. Enabled Interfaces Specifies the number of interfaces that are enabled. Disabled Interfaces Specifies the number of interfaces that are disabled. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 365: Clear Igmp Unicast-Qos-Adjust

    For more information about the syntax for the router, use the question mark (?) online help function. Command Default Clears all unicast qos adjust parameters. Command Modes EXEC mode Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 366 Task ID Task ID Operation multicast exec Examples This is an example of using the clear igmp unicast-qos-adjust command: RP/0/RSP0/CPU0:router# clear igmp unicast-qos-adjust rate interface Loopback 1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 367: Neighbor Discovery Commands

    This module describes the Cisco IOS XR software commands used to configure the Neighbor Discovery Commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 368: Ipv6 Nd Dad Attempts (Bng)

    This is the same management variable used to specify the interval for neighbor solicitation messages during address resolution and neighbor unreachability detection. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 369 0/2/0/1 to 1 and then display the state (tentative or duplicate) of the unicast IPv6 address configured for an interface: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface gigabitethernet 0/2/0/1 RP/0/RSP0/CPU0:router(config-if)# ipv6 nd dad attempts 1 RP/0/RSP0/CPU0:router(config-if)# Uncommitted changes found, commit them before exiting(yes/no/cancel)? [cancel]:y Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 370 Configures the interval between IPv6 neighbor solicitation transmissions on an interface. show ipv6 interface (BNG), on page 317 (Not applicable for BNG) Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 371: Ipv6 Nd Framed-Prefix-Pool

    Examples This example creates an IPv6 framed prefix pool in the dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd framed-prefix-pool pool1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 372: Ipv6 Nd Managed-Config-Flag (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 373 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd managed-config-flag Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 374: Ipv6 Nd Ns-Interval (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 375 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd ns-interval 9000 Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 376: Ipv6 Nd Nud-Enable

    Examples This example shows how to enable IPv6 neighbor un-reachability detection in dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd nud-enable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 377: Ipv6 Nd Other-Config-Flag (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 378 Sets the managed address configuration flag in IPv6 router advertisements. show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 379: Ipv6 Nd Ra-Initial

    This example configures an IPv6 router advertisement count of 5 and an interval of 201 seconds in the dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd ra-initial 5 201 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 380 Neighbor Discovery Commands ipv6 nd ra-initial Related Commands Command Description ipv6 nd ra-interval (BNG), on page 367 Configures the interval between IPv6 router advertisement transmissions on an interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 381: Ipv6 Nd Ra-Interval (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 382 (BNG), on page 369 Configures the lifetime of an IPv6 router advertisement. show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 383: Ipv6 Nd Ra-Lifetime (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 384 Configures the interval between IPv6 router advertisement transmissions on an interface. show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 385: Ipv6 Nd Ra-Unicast

    RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd ra-unicast Related Commands Command Description dynamic-template, on page 232 Groups a set of configuration items that can be applied to a group of subscribers. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 386: Ipv6 Nd Reachable-Time (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 387 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd reachable-time 1700000 Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 388: Ipv6 Nd Suppress-Cache-Learning

    This example shows how to suppress cache learning for IPv6 neighbor discovery in dynamic template configuration mode: RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd suppress-cache-learning Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 389: Ipv6 Nd Suppress-Ra (Bng)

    For BNG, ensure you run this command in the dynamic template configuration mode. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations ipv6 read, write network read, write config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 390 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ipv6 nd suppress-ra Related Commands Command Description show ipv6 interface (BNG), on page 317 Displays the usability status of interfaces configured for IPv6. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 391: Bng Ppp Commands

    This module describes the Cisco IOS XR software commands used to configure the PPP commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 392: Ppp Authentication (Bng)

    CHAP authentication sends a challenge message to the remote device. The remote device encrypts the challenge value with a shared secret and returns the encrypted value and its name to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 393 PPP authentication. In this case, authentication occurs between a personal computer using Microsoft Windows NT or Microsoft Windows 95 and a Cisco router or access server acting as a network access server. Enabling or disabling PPP authentication does not affect the local router authenticating itself to the remote device.
  • Page 394 Configures the PPP chap hostname. ppp ipcp, on page 383 Sets IPCP negotiation options. ppp lcp, on page 385 Configures the lcp global configure for PPP protocol. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 395: Ppp Chap

    This is an example of configuring the ppp chap command in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp chap hostname host1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 396 BNG PPP Commands ppp chap Related Commands Command Description ppp authentication (BNG), on page 378 Sets PPP link authentication method. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 397: Ppp Ipcp

    Specifies the peer negotiation options. renegotiation Specifies the WINS options. wins Command Default None Command Modes Dynamic template configuration Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 398 This is an example of configuring the ppp ipcp command in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp ipcp Related Commands Command Description ppp authentication (BNG), on page 378 Sets PPP link authentication method. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 399 Task ID Operation read, write read, write Examples This is an example of configuring the ppp lcp command in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 400 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp lcp delay 45 890 Related Commands Command Description ppp authentication (BNG), on page 378 Sets PPP link authentication method. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 401: Ppp Max-Bad-Auth (Bng)

    The ppp max-bad-auth command applies to any interface on which PPP encapsulation is enabled. To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations read, write read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 402 This example shows how to allow two additional retries after an initial authentication failure in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp max-configure 5 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 403: Ppp Max-Configure (Bng)

    To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations read, write read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 404 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp ipcp Related Commands Command Description ppp max-failure (BNG), on page 391 Configures the maximum number of consecutive CONFNAKs to permit before terminating a negotiation. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 405: Ppp Max-Failure (Bng)

    To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations read, write read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 406 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp max-failure 4 Related Commands Command Description ppp max-configure (BNG), on page 389 Specifies the maximum number of configure requests to attempt (without response) before stopping the requests. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 407: Ppp Ms-Chap

    This is an example of configuring the ppp ms-chap command in the dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp ms-chap hostname host1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 408 BNG PPP Commands ppp ms-chap Related Commands Command Description ppp authentication (BNG), on page 378 Sets PPP link authentication method. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 409: Ppp Timeout

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the dynamic-template command to enter the dynamic template configuration mode. Task ID Task ID Operation read, write read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 410 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp timeout absolute 56 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp timeout authentication 4 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# ppp timeout retry 5 Related Commands Command Description ppp authentication (BNG), on page 378 Sets PPP link authentication method. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 411: Show Ppp Interfaces (Bng)

    EXEC mode Command History Release Modification Release 3.9.0 This command was introduced. Release 4.2.0 This command was supported in the dynamic template configuration mode for BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 412 Local IPv4 address: 55.0.0.1 Peer IPv4 address: 55.0.0.2 Peer DNS Primary: 55.0.0.254 Peer DNS Secondary: 155.0.0.254 IPV6CP: Open Local IPv6 address: fe80::3531:35ff:fe55:5747/128 Peer IPv6 address: fe80::3531:35ff:fe55:4213/128 MPLSCP: Stopped Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 413 Remote MCMP Classes: Not negotiated Authentication Of Us: CHAP (Completed as 'test-user') Of Peer: PAP (Completed as 'peer-user') Multilink Multilink group id: 100 Member status: ACTIVE Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 414 Password Authentication Protocol (PAP). Closed Lower layer is up, but this layer is not required. Closing Shutting down due to local change. Initial Connection is idle. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 415 • ACKrcvd—IPCP has received a reply to a request it sent. • Open—IPCP is functioning properly. Keepalive Keepalive setting and interval in seconds for echo request packets. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 416 Local MRU Maximum receive unit. The maximum size of the information transported, in bytes, in the PPP packet received by the local equipment. Open Connection open. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 417 Maximum receive unit. The maximum size of the information transported, in bytes, in the PPP packet received by the peer equipment. Req-Sent Configuration request was sent; waiting for peer to respond. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 418 Starting This layer is required, but lower layer is down. Stopped Listening for a configuration request. Stopping Shutting down as a result of interactions with peer. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 419 To use this command, you must be in a user group associated with a task group that includes the proper task IDs. If you suspect user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 420: Show Ppp Statistics

    Term-Req Term-Ack Proto-Rej IPCP Packets Sent Received Conf-Req Conf-Ack Conf-Nak Conf-Rej Term-Req Term-Ack Proto-Rej IPCPIW Packets Sent Received Conf-Req Conf-Ack Conf-Nak Conf-Rej Term-Req Term-Ack Proto-Rej IPv6CP Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 421 Proto-Rej Related Commands Command Description show ppp interfaces (BNG), on page 397 Displays the PPP interfaces. show ppp summary, on page 408 Displays the PPP summary. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 422: Syntax Description

    This example shows the output of the show ppp summary command for interfaces running PPP: RP/0/RSP0/CPU0:router# show ppp summary location 0/5/CPU0 ==================================== Interfaces running PPP ==================================== Serial PPPoE 10000 Multilink Bundles ---------------------------- Total 10300 ==================================== Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 423: Show Ppp Statistics

    Line UP (VPDN Tunneled) Related Commands Command Description show ppp statistics, on page 405 Displays the PPP statistics. show ppp interfaces (BNG), on page 397 Displays the PPP interfaces. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 424 BNG PPP Commands show ppp summary Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 425: Pppoe Lac-Specific Commands

    This module describes the Cisco IOS XR software commands used to configure the PPPoE LAC-specific commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 426: L2Tp-Class

    Receives the window size for control connection. retransmit Specifies the control message retransmission parameters. security Specifies the L2TP security command. timeout Specifies the control connection timeout parameters. Specifies the tunnel settings. tunnel Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 427: Modification

    Task ID Operation tunnel read, write Examples RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# l2tp-class c1 RP/0/RSP0/CPU0:router(config)# l2tp-class c1 congestion-control Related Commands Command Description tunnel, on page 422 Configures l2tp tunnel. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 428: L2Tp Reassembly

    Task ID Operation tunnel read, write Examples This example shows how to enable the L2TP reassembly feature on LAC: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn RP/0/RSP0/CPU0:router(config-vpdn)# l2tp reassembly Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 429: Process-Failures Switchover

    424 Configures VPDN and enters the VPDN sub-configuration mode. redundancy (BNG), on page 417 Enables VPDN redundancy and enters the VPDN redundancy configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 430 PPPoE LAC-Specific Commands process-failures switchover Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 431: Redundancy (Bng)

    This is an example of enabling the vpdn redundancy and entering the vpdn redundancy configuration submode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn RP/0/RSP0/CPU0:router(config-vpdn)# redundancy RP/0/RSP0/CPU0:router(config-vpdn-redundancy)# Related Commands Command Description vpdn, on page 424 Configures VPDN and enters the VPDN sub-configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 432: Session-Limit (Bng)

    Task ID Task ID Operation tunnel read, write Examples This is an example of configuring the session-limit command in vpdn configuration mode: RP/0/RSP0/CPU0:router# configure Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 433 PPPoE LAC-Specific Commands session-limit (BNG) RP/0/RSP0/CPU0:router(config)# vpdn RP/0/RSP0/CPU0:router(config-vpdn)# session-limit 567 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 434: Template (Bng)

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the vpdn command, to enter vpdn configuration submode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 435 Operation tunnel read, write Examples This is an example of configuring the template command in vpdn configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn RP/0/RSP0/CPU0:router(config-vpdn)# template temp1 RP/0/RSP0/CPU0:router(config-vpdn-temp)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 436: Tunnel

    Examples This is an example of configuring the tunnel command in vpdn template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn template RP/0/RSP0/CPU0:router(config-vpdn-template)# tunnel busy list timeout 56 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 437 PPPoE LAC-Specific Commands tunnel Related Commands Command Description vpdn, on page 424 Configures VPDN and to enter the VPDN sub-configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 438: Vpdn

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the vpdn command in Global Configuration mode to enter vpdn sub-configuration mode. Task ID Task ID Operation tunnel read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 439 PPPoE LAC-Specific Commands vpdn Examples This is an example of configuring the vpdn command in Global Configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn RP/0/RSP0/CPU0:router(config-vpdn)# history failure RP/0/RSP0/CPU0:router(config-vpdn)# softshut Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 440 Task ID Operation tunnel read, write Examples This is an example of configuring the vpn command in vpdn template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# vpdn template Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 441 PPPoE LAC-Specific Commands RP/0/RSP0/CPU0:router(config-vpdn-template)# vpn vrf vrf1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 442: Show L2Tpv2

    This is the sample output of the show l2tpv2 command in the EXEC mode: RP/0/RSP0/CPU0:router# show l2tpv2 class name c1 RP/0/RSP0/CPU0:router# show l2tpv2 counters forwarding tunnel id 67 RP/0/RSP0/CPU0:router# show l2tpv2 session brief if 89 789 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 443 Retransmit time distribution: 0 0 0 0 0 0 0 0 0 Control message authentication is disabled Related Commands Command Description l2tp-class, on page 412 Configures the l2tp class. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 444: Show L2Tpv2 Redundancy

    Oct 12 14:00:25 Time Unconfigured: Oct 12 14:00:25 Time Enabled: Oct 12 14:00:35 Time Disabled: Time Ready: Oct 12 14:00:35 Time Not-Ready: L2TP Switchover Resync Statistics: Poisoned sessions: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 445 Other cleared sessions: Poisoned sessions: Peer cleared tunnels: Excess retrans tunnel: Unestablished tunnels: Other cleared tunnels: Related Commands Command Description l2tp-class, on page 412 Configures the L2TP class. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 446: Show L2Tpv2 Redundancy Mirroring

    This is the sample output of the show l2tpv2 redundancy mirroring command in the EXEC mode: RP/0/RSP0/CPU0:router# show l2tpv2 redundancy mirroring L2TPv2 Mirroring Statistics Since Last CLear Send/Receive/Drop Send/Receive/Drop CCSync CCProtoSync CCUnsync CCSyncAck CCIAck CCSessionSyncDone SessionSync AppStatus AddCCSteadyState DelCCSteadyState Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 447 Acks Received: Acks Failed: Timeouts: Messages Processed: Message Drops: Stale Messages: Unknown Acks received: Related Commands Command Description l2tp-class, on page 412 Configures the L2TP class. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 448: Show Vpdn

    These are some of the options to use the show vpdn command in the EXEC mode: RP/0/RSP0/CPU0:router# show vpdn history failure | file tftp: vrf vrf1 | RP/0/RSP0/CPU0:router# show vpdn client location 0/0/CPU0 RP/0/RSP0/CPU0:router# show vpdn tunnel destination detail | Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 449 4 22:36:15.296 PST Destination VRF-name Status Load 3.3.3.4 default active Related Commands Command Description vpdn, on page 424 Configures VPDN and enters the VPDN sub-configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 450: Show Vpdn Redundancy

    VPDN HA SUMMARY Total Sessions 2000 Sessions Synced 2000 VPDN HA TIME STAMPS Init sync started Dec 15 04:37:56 Init sync finished Dec 15 04:37:56 Init sync aborted Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 451 424 Configures VPDN and enters the VPDN sub-configuration mode. redundancy (BNG), on page 417 Enables VPDN redundancy and enters the VPDN redundancy configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 452: Show Vpdn Redundancy Mirroring

    SSO error count SSO batch error count ALLOC error count ALLOC count VPDN QAD Send Statistics Total Since Last Clear Messages : Acks : Messages Failed: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 453 424 Configures VPDN and enters the VPDN sub-configuration mode. redundancy (BNG), on page 417 Enables VPDN redundancy and enters the VPDN redundancy configuration mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 454 PPPoE LAC-Specific Commands show vpdn redundancy mirroring Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 455: Pppoe Commands

    This module describes the Cisco IOS XR software commands used to configure the PPPoE commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 456: Pado Delay

    Examples This example shows how to configure a delay of 1000 milliseconds for the PADO message: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pppoe bba-group bba1 RP/0/RSP0/CPU0:router(config-bbagroup)# pado delay 1000 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 457 Configures a delay for PPPoE PADO message for a PPPoE BBA-Group in BNG, based on the Service-Name received in PADI message. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 458: Pado Delay Circuit-Id

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 459 Configures a delay for PPPoE PADO message for a PPPoE BBA-Group in BNG, based on the Service-Name received in PADI message. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 460: Pado Delay Remote-Id

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 461 Configures a delay for PPPoE PADO message for a PPPoE BBA-Group in BNG, based on the Service-Name received in PADI message. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 462: Pado Delay Service-Name

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 463 446 Configures a delay for PPPoE PADO message for a PPPoE BBA-Group in BNG, based on the Remote-ID received in PADI message. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 464: Pppoe Bba-Group

    Limits PPPoE sessions on any one access interface. Limits PPPoE sessions with any one circuit-id. circuit-id Limits or throttles PPPoE sessions from any one mac-address. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 465 When this configuration changes to use a different BBAGroup, then all existing PPPoE sessions running under the interface are terminated. Task ID Task ID Operation read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 466 RP/0/RSP0/CPU0:router(config-bbagroup)# sessions max limit 45 RP/0/RSP0/CPU0:router(config-bbagroup)# tag ppp-max-payload minimum 689 maximum 788 Related Commands Command Description pppoe enable bba-group, on page 453 Enables PPPoE on an interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 467: Pppoe Enable Bba-Group

    Examples This is an example of configuring the pppoe enable bba-group command in interface configuration mode: RP/0/RSP0/CPU0:router#configure RP/0/RSP0/CPU0:router(config)#interface Bundle-Ether100.10 RP/0/RSP0/CPU0:router(config-if)# pppoe enable bba-group bba1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 468 PPPoE Commands pppoe enable bba-group Related Commands Command Description pppoe bba-group, on page 450 Enables you to add configuration for a particular bba-group. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 469: Pppoe In-Flight-Window

    RP/0/RSP0/CPU0:router(config)# pppoe in-flight-window 200 Related Commands Command Description pppoe sessions limit, on page 457 Configures a limit for PPPoE sessions for a PPPoE BBA-Group in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 470 PPPoE Commands pppoe in-flight-window Command Description pppoe sessions throttle, on page 460 Configures a throttle value for PPPoE sessions for a PPPoE BBA-Group in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 471: Pppoe Sessions Limit

    Specifies the action of generating a log message when the threshold has reached. threshold-value Specifies the threshold value. The range is from 1 to 65535. Command Default None Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 472 This example shows how to configure a pppoe session limit of 5000 and a threshold value of 4900, for each peer mac-address under individual access-interface in a PPPoE BBA-Group: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# pppoe bba-group bba1 RP/0/RSP0/CPU0:router(config-bbagroup)# sessions mac access-interface limit 5000 threshold 4900 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 473 460 Configures a throttle value for PPPoE sessions for a PPPoE BBA-Group in BNG. show pppoe limits, on page 466 Shows the PPPoE session limit information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 474: Pppoe Sessions Throttle

    Specifies the time interval during which no more requests from the subscriber are accepted, when the subscriber has already been throttled. Command Default Sessions throttle is disabled by default. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 475 Configures a limit for PPPoE sessions for a PPPoE BBA-Group in BNG. show pppoe throttles, on page 475 Shows the throttle information for the PPPoE sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 476: Clear Pppoe Statistics

    This example shows the sample output before and after clearing the PPPoE statistics: RP/0/RSP0/CPU0:router# show pppoe statistics Tue Feb 5 21:17:36.137 UTC 0/RSP1/CPU0 ----------- Packets Sent Received Dropped ---------------------------------------------------------------- Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 477 ------------------------------------------------------- ----- TOTAL RP/0/RSP0/CPU0:router# Related Commands Command Description show pppoe statistics, on page 470 Shows the counters for packets received and sent by the PPPoE sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 478: Show Pppoe Interfaces

    Specifies the fully qualified location specification. Shows PPPoE status for all sessions. Command Default None Command Modes EXEC mode Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 479 Loopback1 is Complete Session id: 1 Access interface: Loopback1 BBA-Group: blue Local MAC address: aabb.cc00.8301 Remote MAC address: aabb.cc00.8201 Tags: Service-Name: service1 Max-Payload: 1500 Circuit-ID: circuit1 Remote-ID: remote1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 480: Show Pppoe Limits

    Release 4.2.0 This command was introduced. Release 4.3.1 The command output was extended for the session limits of mac access-interface, mac-iwf access-interface, inner-vlan, outer-vlan, vlan and circuit-id-and-remote-id Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 481 RP/0/RSP0/CPU0:router# show pppoe limits Tue Feb 5 21:09:40.823 UTC 0/RSP1/CPU0 ----------- BBA-Group BNG_BBA ----------------- Card session limits not configured. Access-interface session limits not configured. MAC session limits not configured. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 482 Specifies that the number of sessions is at the maximum limit. Specifies that the number of sessions is below the maximum limit and the warning threshold (if configured). Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 483 470 Shows the counters for packets received and sent by the PPPoE sessions. show pppoe summary, on page 473 Shows summary information of the PPPoE sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 484: Show Pppoe Statistics

    IDs. If you suspect user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 485 Bad vendor tag length field 1 Multiple Host-Uniq tags 1 Multiple Circuit-ID tags 1 Multiple Remote-ID tags 1 Invalid DSL tag 1 Multiple of the same DSL tag 1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 486 Invalid IWF tag 1 Multiple IWF tags 1 Unknown vendor-tag 11 No space left in packet 1 Duplicate Host-Uniq tag received 1 Packet too long 1 ----- TOTAL 140 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 487: Show Pppoe Summary

    COMPLETE: Complete PPPoE Sessions INCOMPLETE: PPPoE sessions being brought up or torn down Interface BBA-Group READY TOTAL COMPLETE INCOMPLETE ------------------------------------------------------------------------------- Fa0/1/0/0 blue Y 20 18 2 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 488 ============================== PPPoE Sessions ============================== Complete 3812 Incomplete 302 ----------------------------- TOTAL 4114 ============================== Flow Control ============================== Limit 1000 In Flight 12 Dropped 212 Disconnected 6 Successful 1021 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 489: Show Pppoe Throttles

    Release Modification Release 4.2.0 This command was introduced. Release 4.3.1 The command output was extended for the throttle for circuit-id, remote-id, inner-vlan, outer-vlan, vlan and circuit-id-and-remote-id. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 490 Another sample output of the show pppoe throttles command: RP/0/RSP0/CPU0:router# show pppoe throttles BBA-Group BNG_BBA1 ------------------ MAC throttles not configured. MAC-Access-interface throttles not configured. MAC-IWF-Access-interface throttles not configured. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 491 Description Block Specifies that the throttle is active and that packets are dropped. Idle Specifies that the packets relevant to the throttle are not yet received. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 492 470 Shows the counters for packets received and sent by the PPPoE sessions. show pppoe summary, on page 473 Shows summary information of the PPPoE sessions. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 493 This module describes the Cisco IOS XR software commands used to configure the QoS commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.

  • Page 494: Qos Account

    Specifies the snap-pppoa snap-rbe Specifies the snap-rbe. Command Default None Command Modes Dynamic template configuration Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 495 RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# qos account AAL5 snap-rbe Related Commands Command Description qos output minimum-bandwidth, on page 482 Sets the minimum guaranteed output bandwidth for a subscriber. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 496: Qos Output Minimum-Bandwidth

    This is an example of configuring the qos output minimum-bandwidth command in dynamic template configuration mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# qos output minimum-bandwidth 10 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 497 QOS Commands qos output minimum-bandwidth Related Commands Command Description qos account, on page 480 Enables QoS Layer 2 overhead accounting. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 498: Service-Policy (Qos-Bng)

    The resource ID value that ranges from 0-3. Command Default None Command Modes Interface configuration Command History Release Modification Release 4.2.0 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 499 RP/0/RSP0/CPU0:router(config-subif)# service-policy input mark This example shows how to configure an egress VLAN policy on an access-interface: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# interface bundle-ether 18.203 RP/0/RSP0/CPU0:router(config-subif)# service-policy output metering Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 500: Service-Policy (Interface Bng)

    Release 3.9.0 This command was updated to support shared policy instance over bundle interfaces. Release 4.3.0 The command was supported in dynamic template configuration mode in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 501 This example shows policy map policy 1 applied to Bundle-Ether interfaces 100.1 and 100.2 RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 100.1 RP/0/RSP0/CPU0:router(config-if)# service-policy policy1 shared-policy-instance subscriber1 RP/0/RSP0/CPU0:router(config-if)# exit RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether 100.2 RP/0/RSP0/CPU0:router(config-if)# service-policy output policy1 shared-policy-instance subscriber1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 502 This example is specific to BNG. It shows policy map policy 1 applied in the dynamic template configuration mode. RP/0/RSP0/CPU0:router(config)#dynamic-template type ppp p1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)#service-policy policy1 shared-policy-instance subscriber1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)#exit RP/0/RSP0/CPU0:router(config)# dynamic-template type ipsubscriber ipsub1 RP/0/RSP0/CPU0:router(config-dynamic-template-type)# service-policy output policy1 shared-policy-instance subscriber1 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 503: Shape Average (Bng)

    Policy map class configuration Command History Release Modification Release 3.7.2 This command was introduced. Release 5.2.0 $shape-rate =rate option was added to support QoS shaper parameterization in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 504 The shaper parameters, used to override the locally-configured values in BNG, can either be sent to BNG by the RADIUS server during connection establishment, as CISCO VSAs in an Access Accept message, or can be sent to BNG as part of the CoA messages.

  • Page 505: Show Qos Inconsistency (Bng)

    Displays summary counts of QoS inconsistency warnings. summary Command Default None Command Modes EXEC mode Command History Release Modification Release 3.7.2 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 506 Summary Counts of QoS Inconsistency Warnings: ========================================================= Node 0/7/CPU0 Inconsistency Warning Type Count -------------------------------------------------------- ANCP - No Shaper at top policymap: ANCP - Downstream Rate less than Shaper Rate: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 507 QOS Commands show qos inconsistency (BNG) Related Commands Command Description show qos interface (BNG), on page 494 Displays QoS information for a specific interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 508: Show Qos Interface (Bng)

    (?) online help function. input Attaches the specified policy map to the input interface. output Attaches the specified policy map to the output interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 509 (Only BNG) To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode. Task ID Task ID Operations read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 510 Bandwidth: 200000 kbps, BW sum for Level 0: 1000000 kbps, Excess Ratio: 100 ---------------------------------------------------------------------- Level: 1 Policy: child-3play Class: 3play-voip Parent Policy: parent-3play-subscriber-line Class: class-default QueueID: 136 (Priority 1) Queue Limit: 16 kbytes Profile: 3 Scale Profile: 0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 511 99968 kbps (1 %) Policer conform burst 124928 bytes (default) Policer conform action Just TX Policer exceed action DROP PKT WRED not configured for this class Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 512 100000 kbps (1 %) Queue Min. BW. 0 kbps (default) Weight 25 (BWR not configured) Guaranteed service rate 100000 kbps TailDrop Threshold 1250000 bytes / 100 ms (default) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 513 Queue Limit: 60 kbytes Abs-Index: 18 Template: 0 Curve: 0 Shape CIR Profile: INVALID Child Mark: set dscp 46 set cos 7 WFQ Profile: 2/39 Committed Weight: 40 Excess Weight: 40 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 514 Number of CAC flows admitted: 0Parent Policy: premium_services Class: dscp_cs6 QueueID: 98 (Port Default) Child Mark: set disc 1 ---------------------------------------------------------------------- Level: 1 Policy: video_flows Class: class-default Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 515 Conform: 2000000 kbps (2 gbps) Burst: 25000000 bytes (0 Default) ---------------------------------------------------------------------- Level: 1 Policy: DSCP_CE-PE_ETM Class: 3play-voip Parent Policy: PW-HE-Ingress Class: class-default QueueID: 160 (Port Priority 1) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 516 Conform: 500000 kbps (25 percent) Burst: 6250000 bytes (0 Default) Child Policer Conform: TX Child Policer Exceed: DROP Child Policer Violate: DROP This table describes the significant fields shown in the display. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 517 Related Commands (not applicable for BNG) Command Description show qos inconsistency (BNG), on page 491 Displays inconsistency information for the QoS policy on an interface. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 518: Show Qos Shared-Policy-Instance (Bng)

    This command was updated to support SPI over PW-Ether subinterface. Usage Guidelines To enter the dynamic template configuration mode, run dynamic-template command in the Global Configuration mode Task ID Task ID Operations read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 519 Shape CIR Profile: INVALID WFQ Profile: 2/9 Committed Weight: 10 Excess Weight: 10 Bandwidth: 0 kbps, BW sum for Level 1: 0 kbps, Excess Ratio: 1 ---------------------------------------------------------------------- Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 520: Show Qos Summary Bng

    The member keyword is available only for bundle-ether, PW-Ether and PW-IW interface types. host-link (Optional) Specifies the host-link. This keyword is applicable only for satellite interfaces. Command Default None Command Modes EXEC mode Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 521 2. A '*' against the counter means the action is drop. 3. Conform displays match counter for non-policer leaf. Policy:Class PoliceID Conform Exceed Violate BVI1 NP1 :dscp48 6145 :class-default 6146 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 522 QOS Commands show qos summary BNG Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 523 This module describes the Cisco IOS XR software commands used to configure the subscriber commands for Broadband Network Gateway (BNG) on the Cisco ASR 9000 Series Router. For details regarding the related configurations, refer to the Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Configuration Guide.
  • Page 524 557 • show subscriber redundancy summary, page 561 • show subscriber running-config, page 564 • show subscriber session, page 566 • clear subscriber session, page 574 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 525: Access-Tracking

    The slave does not advertise the route into the core. For details on configuring track object, see Cisco ASR 9000 Series Aggregation Services Router System Management Configuration Guide.
  • Page 526 200.0.0.0/16 Null0 track mc-lag-be1 address-family ipv6 unicast 20::/64 Null0 track mc-lag-be1 router isis 1 address-family ipv4 unicast redistribute static address-family ipv6 unicast redistribute static Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 527: Accounting Interim Variation

    T (that is, 0% variance from T). • The maximum value of T- L is 900 seconds (that is, 15 minutes). Task ID Task ID Operation config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 528 This example shows how to configure a random delay of 50% variance between successive interim accounting messages of sessions or services: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber manager RP/0/RSP0/CPU0:router(config-subscriber-manager)# accounting interim variation 50 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 529: Core-Tracking

    This example shows how to configure object tracking for detecting core connectivity for the specific SRG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# core-tracking route-to-radius Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 530: Disable (Subscriber Redundancy)

    Task ID Operation config-services read, write Examples This example shows how to disable geo redundancy feature for all SRGs: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 531 Subscriber Commands disable (subscriber redundancy) This example shows how to disable a specific SRG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 532: Hold-Timer (Subscriber Redundancy)

    Operation config-services read, write Examples This example shows how to configure hold-timer across all SRGs, in BNG geo redundancy feature scenario: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 533 This example shows how to configure hold-timer for a specific SRG, in BNG geo redundancy feature scenario: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# hold-timer 20 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 534: Interface-List

    The range is from 1 to 65535. Command Default None Command Modes Subscriber redundancy group configuration. Command History Release Modification Release 5.2.2 This command was introduced. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 535 This example shows how to assign one or more access sub-interface (as a range) under an SRG in BNG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# interface-list RP/0/RSP0/CPU0:router(config-subscr-red-grp-intf)# interface Bundle-Ether1 sub-if-range 1 9 id-range 201 209 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 536: Preferred-Role

    Examples This example shows how to configure preferred role across all SRGs as master, in BNG geo redundancy feature scenario: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 537 This example shows how to configure preferred role for a specific SRG as master, in BNG geo redundancy feature scenario: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# preferred-role master Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 538: Source-Interface (Subscriber Redundancy)

    Task ID Operation config-services read, write Examples This example shows how to configure source interface in subscriber redundancy sub-mode: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# source-interface loopback0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 539: Subscriber Redundancy

    Operation config-services read, write Examples This example shows how to enter subscriber redundancy sub mode to configure subscriber redundancy options: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 540: Subscriber Redundancy Group

    You can configure multiple groups (with unique IDs) for peering with the same peer router or across different peer routers. The SRG does not get activated until the first access-interface is assigned under it. Task ID Task ID Operation config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 541 Subscriber Commands subscriber redundancy group Examples This example shows how to configure a subscriber redundancy group (SRG) in BNG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 542: Subscriber Redundancy Switchover

    BNG and access roles or status. When switchover happens, logs that indicate the reason of the switchover, are generated on the system console and Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 543 This example shows how to initiate subscriber redundancy switchover for a particular SRG: RP/0/RSP0/CPU0:router# subscriber redundancy switchover group 210 Related Commands Command Description subscriber redundancy synchronize, on page 530 Initiates subscriber redundancy synchronization in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 544: Subscriber Redundancy Synchronize

    Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 545 This example shows how to initiate subscriber redundancy synchronization for a particular SRG: RP/0/RSP0/CPU0:router# subscriber redundancy synchronize group 210 Related Commands Command Description subscriber redundancy switchover, on page 528 Executes subscriber redundancy switchover in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 546: Subscriber Session Limit

    The new session can be an authenticated or un-authenticated session. Task ID Task ID Operation config-services read, write Examples This example shows how to configure a limit for subscriber sessions: RP/0/RSP0/CPU0:router# configure Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 547 This example shows how to remove the subscriber sessions limit configuration: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# no subscriber session limit Related Commands Command Description show subscriber session, on page 566 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 548: Tracking-Disable

    This example shows how to temporarily disable the use of tracking objects status for automatic switchovers in BNG geo redundancy: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# tracking-disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 549: Virtual-Mac

    This example shows how to configure virtual MAC explicitly for an SRG in a subscriber redundancy feature scenario in BNG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-gr)# virtual-mac 0001.0002.0001 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 550 Subscriber Commands virtual-mac Related Commands Command Description virtual-mac-prefix, on page 538 Configures the gateway MAC (for the subscribers) used by BNG while being in master redundancy mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 551: Virtual-Mac-Disable

    This example shows how to disable the inheritance of the virtual MAC prefix for a specific subscriber redundancy group in BNG: RP/0/RSP0/CPU0:router# configure RP/0/RSP0/CPU0:router(config)# subscriber redundancy RP/0/RSP0/CPU0:router(config-subscr-red)# group 1 RP/0/RSP0/CPU0:router(config-subscr-red-group)# virtual-mac-disable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 552: Virtual-Mac-Prefix

    The virtual MAC can alternatively be configured for a specific SRG by using virtual-mac command in subscriber redundancy group configuration sub-mode. Task ID Task ID Operation config-services read, write Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 553 Related Commands Command Description virtual-mac, on page 535 Configures the virtual MAC explicitly for a specific subscriber redundancy group (SRG), while BNG being in master redundancy mode. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 554: Show Subscriber Database

    IDs. If you suspect user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation network read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 555 = FALSE client_name = template-mgr timer_running = FALSE spi_cb_info: Persistent Information: in_use = TRUE forced_full_resync = FALSE client_flags = TMPL_PROD state = SUBDB_CLIENT_FULL instance_no num_bpi_regs Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 556 = SUBDB_SESSION_LABEL_TYPE_PPPOE_SUB Activate Required = FALSE Config Set ID Registration Handle = 0x2 whichevent[0] = SUBDB_CB_EVENT_NONE whichevent[1] = SUBDB_CB_EVENT_ALL Feature State = SUBDB_FEATURE_REGISTERED ***Feature Name*** = RSI Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 557 SPI AIPC Information: conn_present tx_attempt_count tx_count rx_count notify_connect_count notify_queue_high_count notify_queue_low_count notify_queue_full_count notify_data_waiting_count = 2 notify_error_count notify_close_count notify_sendstatus_count notify_open_count pulse_data_waiting_count queue_full queue_full_drop outstanding_buffers overflow_queue_size cumulative_overflow_msgs hwm_overflow_msgs BPI AIPC Information: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 558 Jun 15 06:49:40.125 subdb/common 0/0/CPU0 t4153857728 Process SPI END RECONCILE msg for client '2 [ring index '0'] Jun 15 06:49:40.125 subdb/common 0/0/CPU0 t4004322208 Process client ID '2' with connection event 'RECONCILED' Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 559: Show Subscriber Feature Accounting

    EXEC mode Command History Release Modification Release 4.2.0 This command was introduced. Release 5.1 The show command output was extended to display session Idle Timeout feature information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 560 564 Displays the subscriber running configuration derived from dynamic template. show subscriber session, on page 566 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 561: Show Subscriber Manager Sadb

    Length: 168 Attribute list: 135469872 outer-vlan-id len= 10(a) port-type len= Virtual IP over VLAN static-session len= true parent-if-handle len= 1664(680) string-session-id len= 00000049 interface len= 0/0/1/10 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 562 Command Description show subscriber session, on page 566 Displays the subscriber management session information. ipsubscriber interface, on page 278 Enables interface based static session in BNG. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 563: Show Subscriber Manager Statistics

    PRE event, and show subscriber manager statistics PRE action total location <> commands, and to display MA-CoA RB Success and MA-CoA RB Failure fields for show subscriber manager statistics SVM events location <> command. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 564 Attribute format warnings NAS Port = 72 NAS Port id Destination station id = 72 Calling station id = 72 User Name User Profile Statistics User Profile Install Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 565 MA-CoA requests acknowledged, and the number of MA-CoA requests that were not acknowledged. RP/0/0/CPU0server:#show subscriber manager statistics PRE event Wed Jun 27 11:00:27.029 EDT [ EVENT STATISTICS ] Location: 0/0/CPU0 Events executed Success Fail Pending Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 566 [ PRE ACTION STATISTICS ] Actions executed Success Fail Pending ================ ======= ==== ======= Detail Statistics ======================== Type Total Success Fail Pending ==== ===== ======= ==== ======= Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 567 Unapply failed Unapply (unassoc error) Unapply (call back) Unapply (call back error) Replace invocations Replace (bad argument) Replace (Duplicate data) Replace failed User Profile before PM Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 568 HA SP Restart records OK HA SP Rest OK, CLI on Host HA SP Rest OK, SP on Host HA SP Rest OK, SP on Server Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 569 Session disconnect event Session disconnect request Session kill event Session start request Timer expiry event Session deactivate request Passthru Accounting request Author no response event Author failed event Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 570 Authen no response event Authen failed event Session Up and Update request Session Down request Session State AF Register Session info update Mobility Failure event Session disconnect queuing Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 571: Show Subscriber Redundancy Group

    • The session entries that experienced failures in synchronization with the peer. Generally, this may be seen on the slave where provisioning failed due to configuration mismatch or due to some other resource constraints. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 572 This is a sample output of the show subscriber redundancy group command that displays the key information about the sessions active under the SRG: RP/0/RSP0/CPU0:router#show subscriber redundancy group 210 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 573 MAC Address | In/Out VLAN | PPPoE/L2TP ID ------------------------------------------------------------------------------ Bundle-Ether1.10 0000.680b.0102 0/210 Bundle-Ether1.10 0000.680b.0103 0/210 Bundle-Ether1.10 0000.680b.0104 0/210 Bundle-Ether1.10 0000.680b.0105 0/210 Bundle-Ether1.10 0000.680b.0106 0/210 Bundle-Ether1.10 0000.680b.0107 0/210 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 574 Bundle-Ether1.10 0000.680b.010f 0/210 Bundle-Ether1.10 0000.680b.0110 0/210 Related Commands Command Description show subscriber redundancy summary, on page 561 Displays the global status of BNG geo redundancy feature. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 575: Show Subscriber Redundancy Summary

    The details listed under show subscriber redundancy summary interface output also include the mapping group, ID and role of the SRGs. Task ID Task ID Operation network read Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 576 | Status | Group ID | Map ID | Role ----------------------------------------------------------- Bundle-Ether1.1 Master Bundle-Ether1.10 Master Bundle-Ether1.11 Master Bundle-Ether1.12 Master Bundle-Ether1.13 Master Bundle-Ether1.14 Master Bundle-Ether3.1 Slave Bundle-Ether3.10 Slave Bundle-Ether3.11 Slave Bundle-Ether3.12 Slave Bundle-Ether3.13 Slave Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 577 Subscriber Commands show subscriber redundancy summary Bundle-Ether3.14 Slave Related Commands Command Description show subscriber redundancy group, on page 557 Displays the operational summary of subscriber redundancy groups. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 578: Show Subscriber Running-Config

    This is a sample output of the show subscriber running-config command: RP/0/RSP0/CPU0:router# show subscriber running-config Tue Jun 15 09:05:53.769 EDT Session ID: 0x4000000 dynamic-template type ipsubscriber TEMPL1 ipv4 unnumbered Loopback0 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 579 1500 Session ID: 0x4000082 dynamic-template type ipsubscriber TEMPL1 ipv4 unnumbered Loopback0 dynamic-template type ipsubscriber TEMPL2 service-policy input qos_policy vrf blue ipv4 mtu 1500 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 580: Show Subscriber Session

    For interface-based static sessions in the BNG, the value of Type field in the show ipsubscriber session command output is displayed as IP: Static. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 581 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.3.pppoe7 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.3.pppoe8 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.3.pppoe9 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.pppoe10 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.pppoe11 100.0.0.1 (default) PPPoE:PTA Gi0/1/0/0.pppoe12 100.0.0.1 (default) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 582 Type: IP: DHCP-trigger IPv4 State: Up, Thu Feb 13 13:12:07 2014 IPv4 Address: 12.1.93.225, VRF: default IPv4 Up helpers: 0x00000040 {IPSUB} IPv4 Up requestors: 0x00000040 {IPSUB} Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 583 Updates accepted: Updates rejected: Update send failures: Accouting stop state: Final stats available Last COA request: Thu Feb 13 14:06:23 2014 COA Request Attribute List: 0x10011224 Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 584 State Subscriber IP Addr / Prefix LNS Address (Vrf) -------------------------------------------------------------------------------- basic@cisco.com Gi0/0/0/0.pppoe1 10.0.0.2 (default) basic@cisco.com Gi0/0/0/0.pppoe2 10.0.0.3 (default) basic@cisco.com Gi0/0/0/0.pppoe3 10.0.0.1 (default) basic@cisco.com Gi0/0/0/0.1.pppoe1 10.0.0.4 (default) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 585 Acct-Session-Id: 00008ad7 Method-list: default Accounting started: Fri Feb 8 16:43:27 2013 Interim accounting: On, interval 2 mins Last successful update: Never Next update in: 00:01:48 (dhms) Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 586 0000001c Nas-Port: Unknown User name: 0000.6401.0102 Outer VLAN ID: Subscriber Label: 0x00000055 Created: Tue Jan 29 12:46:32 2013 State: Activated Authentication: unauthenticated Access-interface: Bundle-Ether1.10 Policy Executed: Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 587 Tue Jan 29 12:46:32 2013 Interim accounting: On, interval 1 mins Last successful update: Tue Jan 29 12:48:34 2013 Next update in: 00:00:06 (dhms) Last COA request received: unavailable Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

  • Page 588: Clear Subscriber Session

    CPU0. Example: interface MgmtEth0/RP1/CPU0/0. • Virtual interface instance. Number range varies depending on interface type. location Clears the subscriber session information of a specific location. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 589 This example shows how to clear all the subscriber sessions in a particular node location: RP/0/RSP0/CPU0:router# clear subscriber session all location 0/RSP0/CPU0 Related Commands Command Description show subscriber session, on page 566 Displays the subscriber management session information. Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...
  • Page 590 Subscriber Commands clear subscriber session Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release 5.2.x...

Table of Contents
