Parameter Description
P807* Source for lifetime counter of the receive block.
S.LZ.Receive.Val
In function diagram 170
807
P808* Source for reset of the LC receive block.
S.LZ.Receive.Res
In function diagram 170
808
r809 Display of the transformation ratio between generated and
LZ.Rec.NAPC evaluated ready signal at the ready signal receiver module.
809 In function diagram 170.
r810 Status of the sign-of-life receive block
LZ.ReceiveStatus
In function diagram 170
810
P811* Allow source for output of fault F152 in the event of
S.LZRec.F152 EN communication disturbance.
811
r812 Parameter for output of the current fault value of the LC
LZ.RecActFail receive block:
In the event of a ready signal failure, the fault value is
812 incremented by 10. When a value ready signal is
received, the fault value is decremented by 1.
In function diagram 170.
r813 Parameter for output of the LC receive block ready signal
LZ.Rec.AbsFail that has failed since power up.
813 In function diagram 170.
P814* This parameter determines the bit position of the sign-of-
LZ Bit Position life word. (P807, K0255, K0256)
814 Value:
0: sign of life begins with bit 0
1: sign of life begins with bit12
Value 1 "Sign of life begins with bit12" is implemented for
isochrone mode under PROFIdrive V3. During isochrone
mode via Profibus a CBP2 (parameter P744.2=1) shall be
selected for synchronization.
In function diagram 170.3.
P823* Service parameter, only for Siemens service personnel
Time Slot No
Parameter for entry of serial time slot number for the time
823 slot wait block
Siemens AG 6SE7087-6QX70 (Edition AG)
SIMOVERT MASTERDRIVES Compendium Motion Control
Data Read/write
Init: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: L2 ,K - Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Init: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: L2 ,B - Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Dec.Plc.: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: O2 - Upread/free access
Dec.Plc.: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: L2 - Upread/free access
Init: 1 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: L2 ,B - Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Dec.Plc.: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: O2 - Upread/free access
Dec.Plc.: 0 Menus:
Unit: - - Parameter menu
Indices: - + Free blocks
Type: O2 - Upread/free access
Init: 0 Menus:
Min: 0 - Parameter menu
Max: 1 - Upread/free access
Unit: - Changeable in:
Indices: - - Ready to switch on
Type: O2
Init: 0 Menus:
Min: 0 - Parameter menu
Max: 1023 - Upread/free access
Unit: - Changeable in:
Indices: - - Ready to switch on
Type: O2 - Operation enabled
