Siemens SIMOVERT MASTERDRIVES Manual page 1330

Parameter Description
U675* INDEX 1:
Rel_Correction Binector source for the enable of referencing of
U660.1 -> B0824 Fixed binectors
2675
INDEX 2:
Binector source for the enable of position correction of
U660.2 -> B0825 Fixed binectors
INDEX 3:
Binector source for deleting the remaining distance during
position correction.
U676* 0->1 : Synchronization with positive edge
MastSetpSync
2676
U677* Displacement angle input [LU]
DispAngle_abs
Index 1:
2677 Displacement angle absolute
Index 2:
Displacement angle relative
U678* Index 1: Displacement angle absolute
DisplaceAngle Index 2: Displacement angle setting value
Index 3: Displacement angle relative
2678
U679 Fixed setpoint for the virtual master axis in 10 LU/min at
VsetVirtMastFix KK818 -> U680 (default)
2679
U680* Source of the speed setpoint of the virtual master axis if
S.SpdSetp VMAx this is to be specified in [10*LU/min].
2680 Function diagram [832.1]
U681* Source of the speed setpoint of the virtual master axis if it
S.V set % VMAx is to be specified in %. For this, the speed which should
correspond to the 100% value must be indicated in
2681 increments/sec in U682.
Function diagram [832.1]
Siemens AG 6SE7087-6QX70 (Edition AG)
SIMOVERT MASTERDRIVES Compendium Motion Control
Data Read/write
index1: 824 Menus:
Unit: - - Parameter menu
Indices: 3 + Technology
Type: L2 ,B + Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Init: 0 Menus:
Unit: - - Parameter menu
Indices: - + Technology
Type: L2 ,B + Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
index1: 0 Menus:
Min: - - Parameter menu
2147483648 + Technology
Max: + Synchronism
2147483647 - Upread/free access
Unit: - Changeable in:
Indices: 2 - Ready to switch on
Type: I4 - Operation enabled
index1: 813 Menus:
Unit: - - Parameter menu
Indices: 3 + Technology
Type: L2 ,K + Synchronism
,K - Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Init: 0 Menus:
Min: - - Parameter menu
2147483647 + Technology
Max: + Synchronism
2147483647 - Upread/free access
Unit: - Changeable in:
Indices: - - Ready to switch on
Type: I4 - Operation enabled
Init: 818 Menus:
Unit: - - Parameter menu
Indices: - + Technology
Type: L2 ,K + Synchronism
,K - Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Init: 0 Menus:
Unit: - - Parameter menu
Indices: - + Technology
Type: L2 ,K + Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
213
