Parameter Description
U650* [TABLE_NO]
S.SelTable The parameter defines the binector for selecting the table.
2650 Table configuration 0 => 1
Table configuration 1 => 1...2
Table configuration 2 => 1...4
Table configuration 3 => 1...8
Table configuration 4 => 1...8
Depending on the configuration, only the appropriate bits
(according to the binary code) are evaluated.
Exception:
In the case of configuration 0, table 1 is always active.
Function diagram [839.7]
U651* Parameterizable fixed values for scaling the Y-axis of the
Scale Y-Axis Fix table.
The scaling of the Y-axis means that the output value of
2651 the table (Y-axis) is multiplied by a factor. The factor is
made up of a numerator (U651.1) and a denominator
(U652.2).
Function diagram [839.5]
U652* The parameter defines the connectors from which the
S.Scale Y-Axis numerator and denominator of the scaling factor for the Y-
axis of the table are to be read.
2652
Index 1: Numerator
Index 2: Denominator
Function diagram [839.6]
n653 This parameter shows the speed setpoints of
TG SpeedSetpt synchronism in [%].
2653 Index 1:
Speed setpoint at output.
Function diagram [836.7]
Index 2:
Speed setpoint according to displacement angle and
catch-up.
Function diagram [836.4]
Index 3:
Speed setpoint according to 1:1 function, gear or cam.
Function diagram [835.7]
Index 4:
Speed setpoint according to continuous mode, start
mode, stop mode, or catch-up.
Function diagram [834.7]
Index 5:
Speed setpoint from master setpoint source.
Function diagram [834.5]
n654 Display parameter for current gear factor
BoeGl_Gear.Fact.
2654
Siemens AG 6SE7087-6QX70 (Edition AG)
SIMOVERT MASTERDRIVES Compendium Motion Control
Data Read/write
index1: 0 Menus:
Unit: - - Parameter menu
Indices: 3 + Technology
Type: L2 ,B + Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
index1: 1 Menus:
Min: -32767 - Parameter menu
Max: 32767 + Technology
Unit: - + Synchronism
Indices: 2 - Upread/free access
Type: I2 Changeable in:
- Ready to switch on
- Operation enabled
index1: 808 Menus:
Unit: - - Parameter menu
Indices: 2 + Technology
Type: L2 ,K + Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
Dec.Plc.: 3 Menus:
Unit: % - Parameter menu
Indices: 5 + Technology
Type: I4 + Synchronism
- Upread/free access
Dec.Plc.: 0 Menus:
Unit: - - Parameter menu
Indices: 2 + Technology
Type: I2 + Synchronism
- Upread/free access
208
