FC 300 Design Guide
Set-up example
In this example, a permanent magnet (PM) motor is used with resolver as speed feedback.
A PM motor must usually operate in flux mode.
Wiring:
The max cable length is 490 ft [150 m] when a twisted-pair cable is used.
NOTE
The resolver cable shielding must be correctly connected to the de-coupling plate and
connected to the chassis (ground) on the motor side.
NOTE
Always use shielded motor cables and brake chopper cables.
Adjust the following parameters:
Par. 1-00 Configuration Mode
Par. 1-01 Motor Control Principle
Par. 1-10 Motor Construction
Par. 1-24 Motor Current
Par. 1-25 Motor Nominal Speed
Par. 1-26 Motor Cont. Rated Torque
AMA is not possible on PM motors
Par. 1-30 Stator Resistance
Par. 1-37 d-axis inductance (Ld)
Par. 1-39 Motor Poles
Par. 1-40 Back EMF at 1000 RPM
Par. 1-41 Motor Angle Offset
Par. 17-50 Poles
Par. 17-51 Input Voltage
Par. 17-52 Input Frequency
Par. 17-53 Transformation Ratio
Par. 17-60 Feedback Direction
Par. 17-61 Feedback Signal Monitoring
78
FC 300 Selection
Speed closed-loop [1]
Flux with feedback [3]
PM, non-salient SPM [1]
Nameplate
Nameplate
Nameplate
Motor data sheet
Motor data sheet (mH)
Motor data sheet
Motor data sheet
Motor data sheet (Usually zero)
Resolver data sheet
Resolver data sheet
Resolver data sheet
Resolver data sheet
Hardware check of resolver connections
