FC 300 Design Guide
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Line voltage out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Timeout 0
Timeout 1
Timeout 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Start command
Drive stopped
Function:
Select the first Boolean (TRUE or FALSE) input
for the selected logic rule.
*False [0] (default setting) enters the fixed
value of FALSE in the logic rule.
True [1] enters the fixed value TRUE in the logic rule.
Running [2] See parameter group 5-3*
for further description.
In range [3] See parameter group 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque limit [5] See parameter group 5-3*
for further description.
Current limit [6] See parameter group 5-3*
for further description.
Out of current range [7] See parameter group
5-3* for further description.
default setting ( ) display text
*
230
How to Program
[10] Below I low [8] See parameter group 5-3*
[11] for further description.
[12] Above I high [9] See parameter group 5-3*
[13] for further description.
[14] Out of speed range [10] See parameter group
[15] 5-3* for further description.
[16] Below frequency low [11] See parameter group
[17] 5-3* for further description.
[18] Above frequency high [12] See parameter group
[19] 5-3* for further description.
[20] Out of feedback range [13] See parameter
[21] group 5-3* for further description.
[22] Below feedback low [14] See parameter group
[23] 5-3* for further description.
[24] Above feedback high [15] See parameter group
[25] 5-3* for further description.
[26] Thermal warning [16] See parameter group
[27] 5-3* for further description.
[28] Line voltage out of range [17] See parameter
[29] group 5-3* for further description.
[30] Reversing [18] See parameter group 5-3*
[31] for further description.
[32] Warning [19] See parameter group 5-3*
[33] for further description.
[34] Alarm (trip) [20] See parameter group 5-3*
[35] for further description.
[36] Alarm (trip lock) [21] See parameter group
[37] 5-3* for further description.
[38] Comparator 0 [22] Use the result of comparator
[39] 0 in the logic rule.
[40] Comparator 1 [23] Use the result of comparator
1 in the logic rule.
Comparator 2 [24] Use the result of comparator
2 in the logic rule.
Comparator 3 [25] Use the result of comparator
3 in the logic rule.
Logic rule 0 [26] Use the result of logic
rule 0 in the logic rule.
Logic rule 1 [27] Use the result of logic
rule 1 in the logic rule.
Logic rule 2 [28] Use the result of logic
rule 2 in the logic rule.
Logic rule 3 [29] Use the result of logic
rule 3 in the logic rule.
Timeout 0 [30] Use the result of timer
0 in the logic rule.
Timeout 1 [31] Use the result of timer
1 in the logic rule.
[ ] value for use in communication via serial communication port
