Danfoss FC 300 Design Manual page 218

FC 300 Design Guide
9-27 Parameter Edit
Option:
Disabled
*
Enabled
Function:
Parameters can be edited via Profibus, the
standard RS485 interface, or the LCP.
Select Disabled [0] to disable editing via Profibus.
9-28 Process Control
Option:
Disable
*
Enable cyclic master
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via
either Profibus or standard fieldbus but not both
simultaneously. Local control is always possible
via the LCP. Control via process control is possible
via either terminals or fieldbus depending on
the settings in par. 8-50 to 8-56.
Select Disable [0] to disable process control via
Profibus, and enable process control via standard
fieldbus or Profibus Master class 2.
Select Enable cyclic master [1] to enable
process control via Profibus Master Class 1, and
disable process control via standard fieldbus
or Profibus Master class 2.
default setting ( ) display text
*
218
How to Program
[0]
[1]
[0]
[1]
This parameter displays Profibus communication
warnings. Please refer to the Profibus Operating
Instructions for further information.
This parameter displays the actual Profibus
baud rate. The Profibus Master automatically
sets the baud rate.
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
9-53 Profibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 baud rate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 drive is tripped
9 internal CAN error
10 wrong ID sent by PLC
11 Internal error occurred
12 not configured
13 clear command received
14 warning 34 active
Function:
9-63 Actual Baud Rate
Option:
Read-only
9.6 kbit/s
19.2 kbit/s
93.75 kbit/s
187.5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31.25 kbit/s
45.45 kbit/s
No baud rate found
Function:
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
[9]
[10]
[11]
[255]
