Danfoss FC 300 Design Manual page 298

FC 300 Design Guide
Alarm/Warning code list
No. Description
1 10 V low
2 Live zero error
3 No motor
4 Line phase loss
5 DC link voltage high
6 DC link voltage low
7 DC overvoltage
8 DC undervoltage
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor overtemperature
12 Torque limit
13 Overcurrent
14 Ground fault
15 Hardware mesh mash
16 Short Circuit
17 Control word timeout
25 Brake resistor short-circuited
26 Brake resistor power limit
27 Brake chopper short-circuited
28 Brake check
29 Power board overtemp
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Soft-charge fault
34 Serial communication fault
38 Internal fault
47 24 V supply low
48 1.8 V supply low
49 Speed limit
50 AMA calibration failed
51 AMA check U
nom
52 AMA low I
nom
53 AMA motor too big
54 AMA motor too small
55 AMA parameter out of range
56 AMA interrupted by user
57 AMA timeout
58 AMA internal fault
59 Current limit
62 Output Frequency at Maximum Limit
63 Mechanical Brake Low
64 Voltage Limit
65 Control Board Overtemperature
66 Heatsink Temperature Low
67 Option Configuration has Changed
80 Drive Initialized to Default Value
90 Encoder Loss
(X) Dependent on parameter
298
Troubleshooting
Warning
and I
nom
MG.33.B6.22 - VLT is a registered Danfoss trademark
Alarm/Trip Alarm/Trip Lock
X
(X) (X)
(X)
(X) (X)
X
X
X X
X X
X X
(X) (X)
(X) (X)
X X
X X
X X
X
X
(X) (X)
X
(X) (X)
X X
(X) (X)
X X
(X) (X)
(X) (X)
(X) (X)
X
X X
X
X X
X
X
X
X
X
X
X
X
X
X
X X
X
X
(X)
X
X X
X
X
X
(X) (X)
LED indication
Warning
Alarm
Trip-locked
Parameter
Reference
6-01
1-80
(X) 14-12
1-90
1-90
X
X
X
X
8-04
2-13
2-15
X
(X) 4-58
(X) 4-58
(X) 4-58
X
X
X
X
2-20
X
17-61
yellow
flashing red
yellow and red
