Logic rule 0 [26] Use the result of logic
rule 0 in the event.
Logic rule 1 [27] Use the result of logic
rule 1 in the event.
Logic rule 2 [28] Use the result of logic
rule 2 in the event.
Logic rule 3 [29] Use the result of logic
rule 3 in the event.
Timeout 0 [30] Use the result of timer 0 in the event.
Timeout 1 [31] Use the result of timer 1 in the event.
Timeout 2 [32] Use the result of timer 2 in the event.
Digital input DI18 [33] Use the value of DI18
in the event (High = TRUE).
Digital input DI19 [34] Use the value of DI19
in the event (High = TRUE).
Digital input DI27 [35] Use the value of DI27
in the event (High = TRUE).
Digital input DI29 [36] Use the value of DI29
in the event (High = TRUE).
Digital input DI32 [37] Use the value of DI32
in the event (High = TRUE).
Digital input DI33 [38] Use the value of DI33
in the event (High = TRUE).
Start command [39] This event is TRUE if
the adjustable frequency drive is started by
any means (either via digital input, serial
communication bus or other).
Drive stopped [40] This event is TRUE if
the adjustable frequency drive is stopped or
coasted by any means (either via digital input,
ser. com. bus or other).
13-52 SL Controller Action
Array [20]
Option:
*
Disabled
No action
Select set-up 0
Select set-up 1
Select set-up 2
Select set-up 3
Select preset ref. 0
Select preset ref. 1
Select preset ref. 2
Select preset ref. 3
Select preset ref. 4
Select preset ref. 5
Select preset ref. 6
Select preset ref. 7
default setting ( ) display text
*
234
How to Program
Select the action corresponding to the SLC event.
Actions are executed when the corresponding event
(defined in par. 13-51) is evaluated as true. The
following actions are available for selection:
*DISABLED [0]
No action [1]
Select set-up 1 [2] - changes the active
[0]
set-up (par. 0-10) to '1'.
[1]
Select set-up 2 [3] - changes the active
[2]
set-up (par. 0-10) to '2'.
[3]
Select set-up 3 [4] - changes the active
[4]
set-up (par. 0-10) to '3'.
[5]
Select set-up 4 [5] - changes the active setup (par.
[10]
0-10) to '4'. If the set-up is changed, it will merge
[11]
with other set-up commands coming from either the
[12]
digital inputs or via a serial communication bus.
[13]
Select preset reference 0 [10] – selects
[14]
preset reference 0.
[15]
Select preset reference 1 [11] – selects
[16]
preset reference 1.
[17]
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
Select ramp 1
Select ramp 2
Select ramp 3
Select ramp 4
Run
Run reverse
Stop
Qstop
Dcstop
Coast
Freeze output
Start timer 0
Start timer 1
Start timer 2
Set dig. out. A low
Set dig. out. B low
Set dig. out. C low
Set dig. out. D low
Set dig. out. E low
Set dig. out. F low
Set dig. out. A high
Set dig. out. B high
Set dig. out. C high
Set dig. out. D high
Set dig. out. E high
Set dig. out. F high
Reset Counter A
Reset Counter B
Function:
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[60]
[61]
