FC 300 Design Guide
13-51 SL Controller Event
Array [20]
Option:
*
False
True
Running
In range
On reference
Torque limit
Current limit
Out of current range
Below I low
Above I high
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Line voltage out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Timeout 0
Timeout 1
Timeout 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Start command
Drive stopped
Function:
Select the boolean input (TRUE or FALSE) to
define the smart logic controller event.
*False [0] enters the fixed value FALSE in the event.
* default setting ( ) display text
How to Program
True [1] enters the fixed value TRUE in the event.
Running [2] See parameter group 5-3*
for further description.
In range [3] See parameter group 5-3*
for further description.
[0]
On reference [4] See parameter group 5-3*
[1]
for further description.
[2]
Torque limit [5] See parameter group 5-3*
[3]
for further description.
[4]
Current limit [6] See parameter group 5-3*
[5]
for further description.
[6]
Out of current range [7] See parameter group
[7]
5-3* for further description.
[8]
Above I low [8] See parameter group 5-3*
[9]
for further description.
[10]
Below I high [9] See parameter group 5-3*
[11]
for further description.
[12]
Out of speed range [10] See parameter group
[13]
5-3* for further description.
[14]
Above frequency low [11] See parameter group
[15]
5-3* for further description.
[16]
Below frequency high [12] See parameter group
[17]
5-3* for further description.
[18]
Out of feedback range [13] See parameter
[19]
group 5-3* for further description.
[20]
Below feedback low [14] See parameter group
[21]
5-3* for further description.
[22]
Above feedback high [15] See parameter group
[23]
5-3* for further description.
[24]
Thermal warning [16] See parameter group
[25]
5-3* for further description.
[26]
Line voltage out of range [17] See parameter
[27]
group 5-3* for further description.
[28]
Reversing [18] See parameter group 5-3*
[29]
for further description.
[30]
Warning [19] See parameter group 5-3*
[31]
for further description.
[32]
Alarm (trip) [20] See parameter group 5-3*
[33]
for further description.
[34]
Alarm (trip lock) [21] See parameter group
[35]
5-3* for further description.
[36]
Comparator 0 [22] Use the result of
[37]
comparator 0 in the event.
[38]
Comparator 1 [23] Use the result of
[39]
comparator 1 in the event.
[40]
Comparator 2 [24] Use the result of
comparator 2 in the event.
Comparator 3 [25] Use the result of
comparator 3 in the event.
[ ] value for use in communication via serial communication port
