Bit 05, Not used:
Bit 05 is not used in the status word.
Bit 06, No error / triplock:
Bit 06 = '0': The adjustable frequency drive is not in fault mode. Bit 06 = "1": The
adjustable frequency drive is tripped and locked.
Bit 07, No warning/warning:
Bit 07 = '0': There are no warnings. Bit 07 = '1': A warning has been issued.
Bit 08, Speed≠ reference/speed = reference:
Bit 08 = '0': The motor is running but the present speed is different from the preset speed
reference. It might, e.g., be the case when the speed ramps up/down during start/stop. Bit
08 = '1': The motor speed matches the preset speed reference.
Bit 09, Local operation/bus control:
Bit 09 = '0': [STOP/RESET] is activated on the control unit or local control in par. 3-13 Reference Site is
selected. You cannot control the adjustable frequency drive via serial communication. Bit 09 = '1' It is
possible to control the adjustable frequency drive via serial communication or the serial communication bus.
Bit 10, Out of frequency limit:
Bit 10 = '0': The output frequency has reached the value in par. 4-11 Motor Speed Low Limit or par. 4-13
Motor Speed High Limit. Bit 10 = "1": The output frequency is within the defined limits.
Bit 11, No operation/in operation:
Bit 11 = '0': The motor is not running. Bit 11 = '1': The adjustable frequency drive has a
start signal or the output frequency is greater than 0 Hz.
Bit 12, Drive OK/stopped, autostart:
Bit 12 = '0': There is no temporary overtemperature on the inverter. Bit 12 = '1': The inverter stops because
of overtemperature but the unit does not trip and will resume operation once the overtemperature stops.
Bit 13, Voltage OK/limit exceeded:
Bit 13 = '0': There are no voltage warnings. Bit 13 = '1': The DC voltage in the intermediate
circuit of the adjustable frequency drive is too low or too high.
Bit 14, Torque OK/limit exceeded:
Bit 14 = '0': The motor current is lower than the torque limit selected in par. 4-18 Current Limit.
Bit 14 = '1': The torque limit in par. 4-18 Current Limit is exceeded.
Bit 15, Timer OK/limit exceeded:
Bit 15 = '0': The timers for motor thermal protection and VLT thermal protection are not
exceeded 100%. Bit 15 = '1': One of the timers exceeds 100%.
