FC 300 Design Guide
Connec- Incremental
tor Encoder
Designa-
tion
X31
1 NC
2 NC
3 5 VCC
4 GND
5 A input
6 A inv input
7 B input
8 B inv input
9 Z input
10 Z inv input
11 NC
12 NC
Max. 5V on X31.5-12
76
FC 300 Selection
SinCos Encoder SinCos Encoder
Hiperface EnDat
8 Vcc
5 Vcc
GND
+COS +COS
REFCOS REFCOS
+SIN +SIN
REFSIN REFSIN
+Data RS485 Clock out
-Data RS485 Clock in
NC Data+
NC Data-
MG.33.B6.22 - VLT is a registered Danfoss trademark
Description
24 V Output
8 V Output
5 V Output
GND
A input
A inv input
B input
B inv input
Z input OR +Data RS485
Z input OR -Data RS485
Future use
Future use
