FC 300 Design Guide
Slave Index Position
Master Index Position
Curve Position
Track Error
Synchronizing Error
Actual Velocity
Actual Master Velocity
Synchronizing Status
Axis Status
Program Status
Idle Time
Paramdb Requests in Queue
Analog input X30/11
Analog input X30/12
Analog output X30/8 mA
Function:
Select a variable for display in line 1, left position.
None [0] No display value selected
Control Word [1600] Present control word
Reference [Unit] [1601] Total reference (sum of
digital/analog/preset/bus/freeze ref./catch-up
and slow-down) in selected unit.
Reference % [1602] Total reference (sum of
digital/analog/preset/bus/freeze ref./catch-up
and slow-down) in percent.
Status Word [binary] [1603] Present status word
Main actual value [1605] [Hex] One or more
warnings in a Hex code
Power [kW] [1610] Actual power consumed
by the motor in kW.
Power [hp] [1611] Actual power consumed
by the motor in HP.
Motor Voltage [V] [1612] Voltage sup-
plied to the motor.
Frequency [Hz] [1613] Motor frequency, i.e.,
the output frequency from the adjustable
frequency drive in Hz.
Motor Current [A] [1614] Phase current of the
motor measured as an effective value.
Frequency [%] [1615] Motor frequency, i.e.,
the output frequency from the adjustable
frequency drive in percent.
Torque [%] [1616] Present motor load as a
percentage of the rated motor torque.
*Speed [RPM] [1617] Speed in RPM (revolutions per
minute), i.e., the motor shaft speed in closed loop.
Motor thermal [1618] Thermal load on the motor,
calculated by the ETR function.
DC Link Voltage [V] [1630] Intermediate circuit
voltage in the adjustable frequency drive.
* default setting ( ) display text
How to Program
[3453] BrakeEnergy/s [1632] Present braking energy
[3454]
transferred to an external brake resistor.
[3455]
Stated as an instantaneous value.
[3456]
BrakeEnergy/2 min [1633] Braking energy
[3457]
transferred to an external brake resistor.
[3458]
The mean power is calculated continuously
[3459]
[3460]
for the latest 120 seconds.
[3461]
Heatsink Temperature [°C] [1634] Present heatsink
[3462]
temperature of the adjustable frequency drive.
[9913]
The cut-out limit is 203 ± 9°F [95 ±5°C]; cutting
[9914]
back in occurs at 158 ± 9°F [70 ±5°C].
[1675]
Inverter thermal [1635] Percentage load
[1676]
[1677]
of the inverters.
Inv. Nom. Current [1636] Nominal current of
the adjustable frequency drive.
Inv. Max. Current [1637] Maximum current
of the adjustable frequency drive.
Condition control state [1638] State of the
event executed by the control.
Control Card Temperature [1639] Temperature
of the control card.
External Reference [1650] [%] Sum of the
external reference as a percentage, i.e., the
sum of analog/pulse/bus.
Pulse Reference [1651] [Hz] Frequency in Hz
connected to the digital inputs (18, 19 or 32, 33).
Feedback [Unit] [1652] Reference value from
programmed digital input(s).
Digital Input [1660] Signal states form the 6
digital terminals (18, 19, 27, 29, 32 and 33).
Input 18 corresponds to the bit at the far left.
Signal low = 0; Signal high = 1 Terminal 53
Switch Setting [1661] Setting of input terminal
54. Current = 0; Voltage = 1.
Analog Input 53 [1662] Actual value at input 53
either as a reference or protection value.
Terminal 54 Switch Setting [1663] Setting of input
terminal 54. Current = 0; Voltage = 1.
Analog Input 54 [1664] Actual value at input 54
either as reference or protection value.
Analog Output 42 [mA] [1665] Actual value
at output 42 in mA. Use par. 6-50 to select
the value to be shown.
Digital output [bin] [1666] Binary value
of all digital outputs.
Frequency input #29 [Hz] [1667] Actual value of the
frequency applied at terminal 29 as an impulse input.
Frequency input #33 [Hz] [1668] Actual value of the
frequency applied at terminal 33 as an impulse input.
[ ] value for use in communication via serial communication port
