Line Supply 3 x 200 - 240 VAC
"
FC 301/FC 302
Typical Shaft Output [kW]
Output current
Continuous
(3 x 200-240 V) [A]
Intermittent
(3 x 200-240 V) [A]
Continuous
KVA (208 V AC) [KVA]
Max. cable size
(line, motor, brake)
[AWG]
Max. input current
Continuous
(3 x 200-240 V) [A]
Intermittent
(3 x 200-240 V) [A]
Max. pre-fuses
Environment
Estimated power loss
at rated max. load [W]
Enclosure IP 20
Weight, enclosure IP 20
[kg]
Efficiency
0.25
1.8
2.9
0.65
2) [mm 2 ]
1.6
2.6
1)
[A] 10
21
4)
4.7
4) 0.94
MG.33.B6.22 - VLT is a registered Danfoss trademark
0.37 0.55 0.75 1.1 1.5
2.4 3.5 4.6 6.6 7.5
3.8 5.6 7.4 10.6 12.0
0.86 1.26 1.66 2.38 2.70
24 - 10 AWG
0.0079-0.1575 in [0.2-4 mm]
2.2 3.2 4.1 5.9 6.8
3.5 5.1 6.6 9.4 10.9
10 10 10 20 20
29 42 54 63 82
4.7 4.8 4.8 4.9 4.9
0.94 0.95 0.95 0.96 0.96
2.2 3 3.7 4 5.5 7.5
10.6 12.5 16.7 - -
17.0 20.0 26.7 - -
3.82 4.50 6.00 - -
- -
2
9.5 11.3 15.0 - -
15.2 18.1 24.0 - -
20 32 32 - -
116 155 185 - -
4.9 6.6 6.6 - -
0.96 0.96 0.96 - -
-
-
-
-
-
-
-
-
-
-
55
