FC 300 Design Guide
Contents
How to Read this Design Guide
MG.33.BC.02 - VLT
®
is a registered Danfoss trademark
Contents
5
5
5
6
6
11
11
14
17
17
19
19
20
21
22
22
23
23
26
26
27
27
30
33
37
39
41
43
43
43
43
46
46
47
51
59
59
61
1

Advertisement

Table of Contents
loading

Related Manuals for Danfoss FC 300

Summary of Contents for Danfoss FC 300

  • Page 1: Table Of Contents

    How to Read this Design Guide Symbols Abbreviations Definitions 2 Safety and Conformity Safety Precautions Aggressive Environments 3 Introduction to AutomationDrive FC 300 Product Overview Control Principle AutomationDrive FC 300 Controls AutomationDrive FC 301 vs. AutomationDrive FC 302 Control Principle Control Structure in VVC plus...
  • Page 2 Contents FC 300 Design Guide Electrical Data - 525-600 V Electrical Data - 525-690 V General Specifications Efficiency Acoustic Noise du/dt Conditions Special Conditions Automatic Adaptations to Ensure Performance 5 How to Order Drive Configurator Ordering Form Type Code 6 Mechanical Installation - Frame Size A, B and C...
  • Page 3 Basic Wiring Example Electrical Installation, Control Cables Relay Output Additional Connections How to Connect a PC to the Frequency Converter The AutomationDrive FC 300 PC Software Residual Current Device Final Setup and Test 9 Application Examples Encoder Connection Encoder Direction...
  • Page 4 High Power Options Frame Size F Panel Options 11 RS-485 Installation and Set-up RS-485 Installation and Set-up Network Configuration FC Protocol Message Framing Structure - AutomationDrive FC 300 Examples Modbus RTU Overview Modbus RTU Message Framing Structure How to Access Parameters...

  • Page 5: How To Read This Design Guide

    1 How to Read this Design Guide 1.1.1 How to Read this Design Guide This Design Guide will introduce all aspects of your AutomationDrive FC 300. Available literature for AutomationDrive FC 300 The VLT AutomationDrive Operating Instructions MG.33.AX.YY provide the neccessary information for getting the drive up and running.

  • Page 6: Abbreviations

    1 How to Read this Design Guide FC 300 Design Guide 1.1.3 Abbreviations Alternating current American wire gauge Ampere/AMP Automatic Motor Adaptation Current limit °C Degrees Celsius Direct current Drive Dependent D-TYPE Electro Magnetic Compatibility Electronic Thermal Relay Frequency Converter...
  • Page 7 FC 300 Design Guide 1 How to Read this Design Guide Motor frequency. Output from the frequency converter. Output frequency is related to the shaft speed on motor depending on number of poles and slip frequency. The maximum output frequency the frequency converter applies on its output. The maximum output frequency is set in limit parameters 4-12, 4-13 and 4-19.
  • Page 8 1 How to Read this Design Guide FC 300 Design Guide Stop command See Control commands. References: Analog Reference An analog signal applied to input 53 or 54. The signal can be either Voltage 0-10V (FC 301 and FC 302) or -10 -+10V (FC 302) Current signal 0-20 mA...
  • Page 9 FC 300 Design Guide 1 How to Read this Design Guide The Local Control Panel makes up a complete interface for control and programming of the frequency converter. The control panel is detachable and can be installed up to 3 metres from the frequency converter, i.e. in a front panel by means of the installation kit option.
  • Page 10 In addition, a high power factor indicates that the different harmonic currents are low. All Danfoss frequency converters have built-in DC coils in the DC link to have a high power factor and to reduce the THD on the main supply.

  • Page 11: Safety And Conformity

    FC 300 Design Guide 2 Safety and Conformity 2 Safety and Conformity 2.1 Safety Precautions 2.1.1 Safety Precautions The voltage of the frequency converter is dangerous whenever connected to mains. Incorrect installation of the motor, frequency converter or fieldbus may cause damage to the equipment, serious personal injury or death. Consequently, the instructions in this manual, as well as national and local rules and safety regulations, must be complied with.
  • Page 12 2 Safety and Conformity FC 300 Design Guide Also make sure that other voltage inputs have been disconnected, such as external 24 V DC, load sharing (linkage of DC intermediate circuit), as well as the motor connection for kinetic back up.
  • Page 13 Frequency converters must be CE labelled in accordance with the low-voltage directive of January 1, 1997. The directive applies to all electrical equipment and appliances used in the 50 - 1000 V AC and the 75 - 1500 V DC voltage ranges. Danfoss CE-labels in accordance with the directive and issues a declaration of conformity upon request.

  • Page 14: Aggressive Environments

    It must be noted that the responsibility for the final EMC properties of the appliance, system or installation rests with the installer. As an aid to the installer, Danfoss has prepared EMC installation guidelines for the Power Drive system. The standards and test levels stated for Power Drive...
  • Page 15 D and E enclosures have a stainless steel back-channel option to provide additional protection in aggressive environments. Proper ventilation is still required for the internal components of the drive. Contact Danfoss for additional information. The frequency converter has been tested according to the procedure based on the shown standards: The frequency converter complies with requirements that exist for units mounted on the walls and floors of production premises, as well as in panels bolted to walls or floors.
  • Page 16 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide MG.33.BC.02 - VLT ® is a registered Danfoss trademark...

  • Page 17: Introduction To Automationdrive Fc

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3 Introduction to AutomationDrive FC 300 3.1 Product Overview Frame size depends on enclosure type, power range and mains voltage Frame size Enclosure 20/21 20/21 20/21 55/66 protection NEMA Chassis/Type 1...
  • Page 18 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Frame size Enclosure 21/54 21/54 protection NEMA Type 1/ Type 12 Type 1/ Type 12 Chassis Chassis High overload rated 90-110 kW at 400 V 132-200 kW at 400 V...

  • Page 19: Control Principle

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.2.1 Control Principle A frequency converter rectifies AC voltage from mains into DC voltage, after which this DC voltage is converted into a AC current with a variable amplitude and frequency.

  • Page 20: Automationdrive Fc 301 Vs. Automationdrive Fc 302 Control Principle

    3 Introduction to AutomationDrive FC 300 FC 300 Design Guide 3.2.3 AutomationDrive FC 301 vs. AutomationDrive FC 302 Control Principle AutomationDrive FC 301 is a general purpose frequency converter for variable speed applications. The control principle is based on Voltage Vector Control...

  • Page 21: Control Structure In Vvc Plus Advanced Vector Control

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.2.4 Control Structure in VVC plus Advanced Vector Control Control structure in VVC plus open loop and closed loop configurations: Motor Control Principle plus Configuration Mode In the configuration shown in the illustration above, par. 1-01 is set to “VVC...

  • Page 22: Control Structure In Flux Sensorless (Automationdrive Fc 302 Only)

    3 Introduction to AutomationDrive FC 300 FC 300 Design Guide 3.2.5 Control Structure in Flux Sensorless (AutomationDrive FC 302 only) Control structure in Flux sensorless open loop and closed loop configurations. Motor Control Principle Configuration Mode In the shown configuration, par. 1-01 is set to “Flux sensorless [2]”...

  • Page 23: Internal Current Control In Vvc Plus Mode

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 Flux Motor Feedback The motor control in this configuration relies on a feedback signal from an encoder mounted directly on the motor (set in par. 1-02 Source Configuration Mode Select “Speed closed loop [1]” in par. 1-00 to use the resulting reference as an input for the Speed PID control.
  • Page 24 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Hand On par. 3-13 Reference Site Active Reference Auto LCP Keys Hand Linked to Hand / Auto Local Hand -> Off Linked to Hand / Auto Local Auto Linked to Hand / Auto Remote Auto ->...
  • Page 25 FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.3 Reference Handling Local Reference The local reference is active when the drive is operated with ‘Hand On’ bottom active. Adjust the reference by up/down and left/right arrows respectively. Remote Reference The reference handling system for calculating the Remote reference is shown in the illustration below.

  • Page 26: Reference Limits

    3 Introduction to AutomationDrive FC 300 FC 300 Design Guide 3.3.1 Reference Limits Reference Range Minimum Reference Maximum Reference Par. 3-00 , par. 3-02 and par. 3-03 together define the allowed range of the sum of all references. The sum of all references are clamped when necessary. The relation between the resulting reference (after clamping) and the sum of all references is shown below.

  • Page 27: Scaling Of Analog And Pulse References And Feedback

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.3.3 Scaling of Analog and Pulse References and Feedback References and feedback are scaled from analog and pulse inputs in the same way. The only difference is that a reference above or below the specified minimum and maximum “endpoints”...
  • Page 28 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide The size of the Dead Band is defined by either P1 or P2 as shown in the graph below. Thus a reference endpoint of P1 = (0 V, 0 RPM) will not result in any dead band, but a reference endpoint of e.g. P1 = (1V, 0 RPM) will result in a -1V to +1V dead band in this case provided that the end point P2 is placed in either Quadrant 1 or Quadrant 4.
  • Page 29 FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 Case 2: Positive Reference with Dead band, Digital input to trigger reverse. Clamping rules. This Case shows how Reference input with limits outside -Max – +Max limits clamps to the inputs low and high limits before addition to External reference.

  • Page 30: Speed Pid Control

    3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Case 3: Negative to positive reference with dead band, Sign determines the direction, -Max – +Max 3.4 PID Control 3.4.1 Speed PID Control The table shows the control configurations where the Speed Control is active.
  • Page 31 FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 The following parameters are relevant for the Speed Control: Parameter Description of function Speed PID Feedback Par. 7-00 Select from which input the Speed PID should get its feedback. Source Par.
  • Page 32 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide In the parameter list below it is assumed that all other parameters and switches remain at their default setting. The following must be programmed in order shown - see explanation of settings in the Programming Guide.

  • Page 33: Process Pid Control

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 Motor Power [kW] Note: Par. 1-20 is the motor power in [kW] (i.e. enter ‘4’ kW instead of ‘4000’ W in the formula). A practical value for the Bandwith is Speed PID Proportional Gain 20 rad/s.
  • Page 34 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide The following parameters are relevant for the Process Control Parameter Description of function Process CL Feedback 1 Resource Par. 7-20 Select from which Source (i.e. analog or pulse input) the Process PID should get its feedback Process CL Feedback 2 Resource Par.
  • Page 35 FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.4.4 Example of Process PID Control The following is an example of a Process PID Control used in a ventilation system: In a ventilation system, the temperature is to be settable from - 5 - 35°C with a potentiometer of 0-10 Volt.
  • Page 36 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Example of Process PID Control set-up Function Par. no. Setting Initialize the frequency converter 14-22 [2] Initialization - make a power cycling - press reset 1) Set motor parameters: Set the motor parameters according to name plate data 1-2*...

  • Page 37: Ziegler Nichols Tuning Method

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.4.5 Ziegler Nichols Tuning Method In order to tune the PID controls of the frequency converter, several tuning methods can be used. One approach is to use a technique which was developed in the 1950s but which has stood the test of time and is still used today.
  • Page 38 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide 3.5 General Aspects of EMC 3.5.1 General Aspects of EMC Emissions Electrical interference is usually conducted at frequences in the range 150 kHz to 30 MHz. Airborne interference from the drive system in the range 30 MHz to 1 GHz is generated from the inverter, motor cable, and the motor.

  • Page 39: Emc Test Results

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.5.2 EMC Test Results The following test results have been obtained using a system with a frequency converter (with options if relevant), a screened control cable, a control box with potentiometer, as well as a motor and motor screened cable.
  • Page 40 The immunity requirements for frequency converters depend on the environment where they are installed. The requirements for the industrial environment are higher than the requirements for the home and office environment. All Danfoss frequency converters comply with the requirements for the industrial environment and consequently comply also with the lower requirements for home and office environment with a large safety margin.

  • Page 41: Pelv - Protective Extra Low Voltage

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 See following EMC immunity form. Voltage range: 200-240 V, 380-480 V Basic standard Burst Surge Radiated electromagnetic field RF common IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-3 mode voltage 61000-4-2 IEC 61000-4-6...
  • Page 42 Installation at high altitude: 380 - 500 V, enclosure A, B and C: At altitudes above 2 km, please contact Danfoss regarding PELV. 380 - 500 V, enclosure D, E and F: At altitudes above 3 km, please contact Danfoss regarding PELV.

  • Page 43: Brake Functions In Automationdrive Fc

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.8 Brake Functions in AutomationDrive FC 300 Braking function is applied for braking the load on the motor shaft, either as dynamic braking or static braking. 3.8.1 Mechanical Holding Brake A mechanical holding brake mounted directly on the motor shaft normally performs static braking.
  • Page 44 560 kW at 115% braking torque Danfoss offers brake resistors with duty cycle of 5%, 10% and 40%. If a 10% duty cycle is applied, the brake resistors are able to absorb brake power for 10% of the cycle time. The remaining 90% of the cycle time will be used on dissipating excess heat.
  • Page 45 1130 V * Power size dependent Check that the brake resistor can cope with a voltage of 410 V, 820 V, 850 V, 975 V or 1130 V - unless Danfoss brake resistors are used. Danfoss recommends the brake resistance R , i.e.

  • Page 46: Control With Brake Function

    3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Do not touch the brake resistor as it can get very hot while/after braking. The brake resistor must be placed in a secure environment to avoid fire risk 3.8.4 Control with Brake Function The brake is protected against short-circuiting of the brake resistor, and the brake transistor is monitored to ensure that short-circuiting of the transistor is detected.

  • Page 47: Hoist Mechanical Brake

    FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 In hoisting/lowering applications, it must be possible to control an electro-mehanical brake. Step-by-step Description • To control the mechanical brake any relay output or digital output (terminal 27 or 29) can be used. If necessary use a suitable contactor.
  • Page 48 3 Introduction to AutomationDrive FC 300 FC 300 Design Guide Illustration 3.6: Brake release sequence for hoist mechanical brake control Activate brake delay: mechanical brake engaged The frequency converter starts again from the position. Stop delay: Stop Delay When the time between successive starts is shorter than the setting in par. 2-24 , the frequency converter starts without applying the mechanical brake (e.g.
  • Page 49 FC 300 Design Guide 3 Introduction to AutomationDrive FC 300 3.10 Smart Logic Controller - AutomationDrive FC 300 The Smart Logic Control (SLC) is essentially a sequence of user defined actions (see par. 13-52 SL Controller Action ) executed by the SLC when the...
