Danfoss FC 300 Design Manual page 227

FC 300 Design Guide
Reverse
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL Timeout 0
SL Timeout 1
SL Timeout 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29 (FC 302 only)
Digital input DI32
Digital input DI33
Start command
Stop command
Function:
Select the boolean (TRUE or FALSE) input to
activate Smart Logic Control.
*False [0] (default setting) enters the fixed
value of FALSE in the logic rule.
True [1] enters the fixed value TRUE in the logic rule.
Running [2] See parameter group 5-3*
for further description.
In range [3] See parameter group 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque limit [5] See parameter group 5-3*
for further description.
Current limit [6] See parameter group 5-3*
for further description.
Out of current range [7] See parameter group
5-3* for further description.
Below I low [8] See parameter group 5-3*
for further description.
Above I high [9] See parameter group 5-3*
for further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequency high [12] See parameter group
5-3* for further description.
* default setting ( ) display text
How to Program
[18] Thermal warning [16] See parameter group
[19] 5-3* for further description.
[20] Mains voltage out of range [17] See parameter
[21] group 5-3* for further description.
[22] Reversing [18] See parameter group 5-3*
[23] for further description.
[24]
Warning [19] See parameter group 5-3*
[25] for further description.
[26] Alarm (trip) [20] See parameter group 5-3*
[27] for further description.
[28] Alarm (trip lock) [21] See parameter group
[29] 5-3* for further description.
[30] Comparator 0 [22] Use the result of comparator
[31] 0 in the logic rule.
[32] Comparator 1 [23] Use the result of comparator
[33] 1 in the logic rule.
[34] Comparator 2 [24] Use the result of comparator
[35] 2 in the logic rule.
[36] Comparator 3 [25] Use the result of comparator
[37] 3 in the logic rule.
[38] Logic rule 0 [26] Use the result of logic
[39] rule 0 in the logic rule.
[40] Logic rule 1 [27] Use the result of logic
rule 1 in the logic rule.
Logic rule 2 [28] Use the result of logic
rule 2 in the logic rule.
Logic rule 3 [29] Use the result of logic
rule 3 in the logic rule.
Digital input DI18 [33] Use the value of DI18
in the logic rule (High = TRUE).
Digital input DI19 [34] Use the value of DI19
in the logic rule (High = TRUE).
Digital input DI27 [35] Use the value of DI27
in the logic rule (High = TRUE).
Digital input DI29 [36] Use the value of DI29
in the logic rule (High = TRUE).
Digital input DI32 [37] Use the value of DI32
in the logic rule (High = TRUE).
Digital input DI33 [38] Use the value of DI33
in the logic rule (High = TRUE).
*
Select Reset SLC [1] to reset all group 13
parameters (13-*) to default settings.
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
13-03 Reset SLC
Option:
Do not reset SLC
Reset SLC
Function:
[0]
[1]
