FC 300 Design Guide
Bits 13/14, Set-up selection
Choose between the four parameter set-ups via
bits 13 and 14 according to the shown table:
The function is only possible if you choose multi
setup in par. 0-10. The selection in par. 8-55
Set-up Select determines how bits 13 and 14
links with the corresponding function of the digital
inputs. When the motor is running, you can
only change the set-up if it is linked.
Bit 15, No function/Reverse
Reversion of the motor rotational direction. Bit 15 = "0": No reversion. Bit 15 = "1": Reversion. The
reversion in the default setting in par. 8-54 Reverse Select is "Logic OR". Bit 15 causes a reversion only when
"Bus", "Logic OR", or "Logic AND" is selected ("Logic AND" only in connection with terminal 9, however).
NOTE
Unless otherwise indicated, the control word bit links with the corresponding
digital input function as a logic "OR".
default setting ( ) display text
*
284
How to Program
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
Set-up Bit 13
1 0
2 1
3 0
4 1
Bit 14
0
0
1
1
