FC 300 Design Guide
Option:
None
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RPM]
16-18 Motor Thermal
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy / 2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-60 Digital Input
16-62 Analog Input 53
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-90 Alarm Word
16-92 Warning Word
16-94 Ext. Status Word
Function:
Select which variables are to be logged.
15-11 Logging Interval
Range:
1 - 86400000 ms
Function:
Enter the interval in milliseconds between each
sampling of the variables to be logged.
15-12 Trigger Event
Option:
FALSE
TRUE
Running
In range
On reference
Torque limit
* default setting ( ) display text
How to Program
Select the trigger event. When the trigger
event occurs, a window is applied to freeze
the log. The log will then retain a specified
percentage of samples before the occurrence
* of the trigger event (par. 15-14).
1 ms
*
Select Log always [0] for continuous logging.
[0]
Select Log once on trigger [1] to conditionally start
[1]
and stop logging using par. 15-12 and par.15-14.
[2]
[3]
[4]
[5]
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
Current limit
Out of current range
Below I low
Above I high
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reverse
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Function:
15-13 Logging Mode
Option:
Log always
Log once on trigger
Function:
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
[37]
[38]
[0]
[1]
