FC 300 Design Guide
Parameters: Drive
"
Information
15-** Operating Data
"
Parameter group containing adjustable frequency
drive information such as operating data, hardware
configuration and software versions.
15-0* Operating Data
"
Parameter group containing operating data, e.g.,
operating hours, kWh counters, power-ups, etc.
15-00 Operating Hours
Range:
0 - 2147483647 h
Function:
View how many hours the adjustable frequency
drive has run. The value is saved when the
frequency converter is turned off.
15-01 Running Hours
Range:
0 - 2147483647 h
Function:
View how many hours the motor has run. Reset the
counter in par. 15-07. The value is saved when
the adjustable frequency drive is turned off.
15-02 kWh Counter
Range:
0 - 2147483647 kWh
Function:
View the power consumption from mains in
kWh as a mean value over one hour. Reset
the counter in par. 15-06.
15-03 Power-ups
Range:
0 - 2147483647
Function:
View the number of times the adjustable frequency
drive has been powered up.
15-04 Over Temps
Range:
0 - 65535
default setting ( ) display text
*
240
How to Program
View the number of adjustable frequency drive
temperature faults which have occurred.
View the number of adjustable frequency drive
overvoltages which have occurred.
*
0h
Select Reset [1] and press [OK] to reset the kWh
counter to zero (see par 15-02). This parameter
cannot be selected via the serial port, RS 485.
Select Do not reset [0] if no reset of the
kWh counter is desired.
*
0h
*
*
0kWh
Select Reset [1] and press [OK] to reset
the Running Hours counter to zero (see par.
15-01). This parameter cannot be selected
via the serial port, RS 485.
Select Do not reset [0] if no reset of the
Running Hours counter is desired.
15-1* Data Log Settings
"
*
0
The Data Log enables continuous logging of up
to 4 data sources (par. 15-10) at individual
rates (par. 15-11). A trigger event (par. 15-12)
and window (par. 15-14) are used to start and
stop the logging conditionally.
*
0
[ ] value for use in communication via serial communication port
MG.33.B6.22 - VLT is a registered Danfoss trademark
Function:
15-05 Over Volts
Range:
0 - 65535
Function:
15-06 Reset kWh Counter
Option:
*Do not reset
Reset counter
Function:
NOTE
The reset is carried out by pressing [OK].
15-07 Reset Running Hours Counter
Option:
Do not reset
Reset counter
Function:
15-10 Logging Source
Array [4]
*
0
[0]
[1]
[0]
[1]
