Alcatel-Lucent 060321-10, Rev. B Cli Reference Manual

Omniswitch series

page of 2354

/ 2354
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Part No. 060321-10, Rev. B

March 2011

OmniSwitch

CLI Reference Guide

www.alcatel-lucent.com

Table of Contents

Chapters

Table of Contents

Summary of Contents for Alcatel-Lucent 060321-10, Rev. B

Page 1: Cli Reference Guide
Part No. 060321-10, Rev. B March 2011 OmniSwitch CLI Reference Guide www.alcatel-lucent.com...
Page 2 This user guide documents release 7.1.1 of the OmniSwitch 10K. The functionality described in this guide is subject to change without notice. Copyright © 2011 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.
Page 3: Table Of Contents
Contents About This Guide ...................... xxix Supported Platforms ...................... xxix Who Should Read this Manual? ..................xxix When Should I Read this Manual? ................xxix What is in this Manual? ....................xxx What is Not in this Manual? ................... xxx How is the Information Organized? ................
Page 4 Contents Chapter 2 UDLD Commands ....................... 2-1 udld ...........................2-2 udld port ........................2-3 udld mode .........................2-5 udld probe-timer .......................2-7 udld echo-wait-timer ....................2-9 clear udld statistics port ..................2-11 show udld configuration ..................2-12 show udld configuration port .................2-14 show udld statistics port ..................2-16 show udld neighbor port ..................2-18 show udld status port ....................2-20 Chapter 3...
Page 5 Contents spantree msti path-cost ...................5-41 spantree vlan path-cost ...................5-44 spantree cist mode ....................5-47 spantree vlan mode ....................5-49 spantree cist connection ..................5-51 spantree vlan connection ..................5-53 spantree cist admin-edge ..................5-55 spantree vlan admin-edge ..................5-57 spantree cist auto-edge ...................5-59 spantree vlan auto-edge ..................5-61 spantree cist restricted-role ..................5-63 spantree vlan restricted-role ...................5-65 spantree cist restricted-tcn ..................5-67...
Page 6 Contents linkagg lacp port actor port priority ...............6-45 linkagg lacp port partner admin-port ..............6-47 linkagg lacp port partner admin port-priority ............6-49 linkagg range ......................6-51 show linkagg ......................6-53 show linkagg port ....................6-58 show linkagg range ....................6-64 Chapter 7 Multi-Chassis Commands ..................7-1 multi-chassis chassis-id ....................7-2 multi-chassis chassis-id hello-interval ipc-vlan ............7-4 multi-chassis hello-interval ..................7-6...
Page 7 Contents show lldp local-port ....................9-25 show lldp local-management-address ..............9-30 show lldp remote-system ..................9-31 show lldp config .....................9-33 show lldp statistics ....................9-35 show lldp remote-system med ................9-37 Chapter 10 IP Commands ......................10-1 ip interface ......................10-5 ip interface tunnel ....................10-8 ip router primary-address ..................10-10 ip router router-id ....................10-11 ip static-route ......................10-12 ip route-pref ......................10-14...
Page 8 Contents icmp messages ......................10-86 ip dos scan close-port-penalty ................10-87 ip dos scan tcp open-port-penalty .................10-88 ip dos scan udp open-port-penalty ...............10-89 ip dos scan threshold ....................10-90 ip dos trap ......................10-92 ip dos scan decay ....................10-93 show ip traffic .......................10-94 show ip interface ....................10-97 show ip routes .....................10-102 show ip route-pref ....................10-104 show ip redist .....................10-106...
Page 9 Contents show ipv6 neighbors .....................11-37 clear ipv6 neighbors .....................11-39 show ipv6 prefixes ....................11-40 show ipv6 routes ....................11-42 show ipv6 route-pref ....................11-44 show ipv6 router database ..................11-45 show ipv6 tcp connections ...................11-47 show ipv6 tcp listeners ..................11-49 show ipv6 traffic ....................11-51 show ipv6 tunnel configured ................11-54 show ipv6 tunnel 6to4 ..................11-56 show ipv6 udp ports .....................11-57...
Page 10 Contents ip rip interface admin-state ..................13-6 ip rip interface metric .....................13-8 ip rip interface send-version ...................13-9 ip rip interface recv-version .................13-11 ip rip interface ingress-filter .................13-13 ip rip interface ingress-filter .................13-14 ip rip interface egress-filter ..................13-15 ip rip force-holddowntimer ..................13-16 ip rip host-route ....................13-18 ip rip route-tag ......................13-19 ip rip interface auth-type ..................13-20...
Page 11 Contents Chapter 15 DHCP Relay Commands ..................15-1 ip helper address .....................15-2 ip helper vlan address .....................15-4 ip helper standard ....................15-6 ip helper per-vlan-only ...................15-7 ip helper forward-delay ..................15-9 ip helper maximum-hops ..................15-11 ip helper agent-information ..................15-13 ip helper agent-information policy ...............15-15 ip helper pxe-support ....................15-17 ip helper boot-up ....................15-18 ip helper boot-up enable ..................15-19...
Page 12 Contents Chapter 17 OSPF Commands ...................... 17-1 ip ospf admin-state ....................17-3 ip load ospf ......................17-4 ip ospf asbr ......................17-5 ip ospf exit-overflow-interval .................17-6 ip ospf extlsdb-limit ....................17-7 ip ospf host ......................17-8 ip ospf mtu-checking ....................17-10 ip ospf default-originate ..................17-11 ip ospf route-tag ....................17-13 ip ospf spf-timer ....................17-14 ip ospf virtual-link ....................17-16 ip ospf neighbor ....................17-19...
Page 13 Contents Chapter 18 OSPFv3 Commands ....................18-1 ipv6 ospf admin-state .....................18-3 ipv6 load ospf ......................18-4 ipv6 ospf host ......................18-5 ipv6 ospf mtu-checking ..................18-7 ipv6 ospf route-tag ....................18-8 ipv6 ospf spf-timer ....................18-9 ipv6 ospf virtual-link ....................18-11 ipv6 ospf area .......................18-13 ipv6 ospf interface ....................18-15 ipv6 ospf interface admin-state ................18-16 ipv6 ospf interface area ..................18-17 ipv6 ospf interface dead-interval ................18-18...
Page 14 Contents ip bgp aggregate-address summary-only ..............19-44 ip bgp network ......................19-46 ip bgp network admin-state ..................19-48 ip bgp network community ..................19-50 ip bgp network local-preference ................19-51 ip bgp network metric ..................19-53 ip bgp neighbor .....................19-55 ip bgp neighbor admin-state .................19-56 ip bgp neighbor advertisement-interval ..............19-57 ip bgp neighbor clear ....................19-58 ip bgp neighbor route-reflector-client ..............19-60 ip bgp neighbor default-originate .................19-61...
Page 15 Contents ip bgp policy route-map community-list ............19-127 ip bgp policy route-map community-mode ............19-128 ip bgp policy route-map lpref ................19-130 ip bgp policy route-map lpref-mode ..............19-131 ip bgp policy route-map match-community ............19-133 ip bgp policy route-map match-mask ..............19-135 ip bgp policy route-map match-prefix ..............19-136 ip bgp policy route-map match-regexp ..............19-137 ip bgp policy route-map med ................19-139 ip bgp policy route-map med-mode ..............19-140...
Page 16 Contents ipv6 bgp neighbor conn-retry-interval ...............19-223 ipv6 bgp neighbor default-originate ..............19-224 ipv6 bgp neighbor update-source ...............19-225 ipv6 bgp neighbor ipv4-nexthop ................19-226 show ipv6 bgp neighbors ..................19-227 show ipv6 bgp neighbors statistics ..............19-232 show ipv6 bgp neighbors policy .................19-237 show ipv6 bgp neighbors timers .................19-239 Chapter 20 Server Load Balancing Commands ..............
Page 17 Contents ip multicast router-timeout ...................21-29 ip multicast source-timeout ..................21-31 ip multicast querying ....................21-33 ip multicast robustness ..................21-35 ip multicast spoofing ....................21-37 ip multicast zapping .....................21-39 ip multicast proxying ....................21-41 ip multicast helper-address ...................21-43 ipv6 multicast admin-state ...................21-44 ipv6 multicast querier-forwarding ................21-46 ipv6 multicast version ..................21-48 ipv6 multicast max-group ..................21-50 ipv6 multicast vlan max-group ................21-52...
Page 18 Contents ip dvmrp neighbor-interval ..................22-8 ip dvmrp neighbor-timeout ..................22-9 ip dvmrp prune-lifetime ..................22-10 ip dvmrp prune-timeout ..................22-11 ip dvmrp report-interval ..................22-12 ip dvmrp route-holddown ..................22-13 ip dvmrp route-timeout ..................22-14 ip dvmrp subord-default ..................22-15 ip interface tunnel ....................22-17 show ip dvmrp ......................22-19 show ip dvmrp interface ..................22-22 show ip dvmrp neighbor ..................22-24 show ip dvmrp nexthop ..................22-26...
Page 19 Contents show ip pim bsr ....................23-61 show ip pim notifications ..................23-63 show ip pim groute ....................23-66 show ip pim sgroute .....................23-70 ipv6 pim sparse admin-state .................23-75 ipv6 pim dense admin-state ..................23-76 ipv6 pim ssm group ....................23-77 ipv6 pim dense group ...................23-79 ipv6 pim cbsr ......................23-81 ipv6 pim static-rp ....................23-83 ipv6 pim candidate-rp ...................23-85...
Page 20 Contents clear qos log ......................25-22 qos apply ......................25-23 qos revert ......................25-24 qos flush .......................25-25 qos reset ........................25-27 qos stats reset ......................25-28 qos port reset ......................25-29 qos port .........................25-30 qos port trusted .....................25-32 qos port maximum egress-bandwidth ..............25-34 qos port maximum ingress-bandwidth ..............25-36 qos port maximum depth ..................25-38 qos port default 802.1p ..................25-40 qos port default dscp ....................25-42...
Page 21 Contents policy condition source ip-port ................26-53 policy condition destination ip-port ..............26-55 policy condition source tcp-port ................26-57 policy condition destination tcp-port ..............26-59 policy condition source udp-port ................26-61 policy condition destination udp-port ..............26-63 policy condition ethertype ..................26-65 policy condition established .................26-67 policy condition tcpflags ..................26-69 policy condition service ..................26-71 policy condition service group ................26-72 policy condition icmptype ..................26-74...
Page 22 Contents show policy network group ................26-152 show policy service ....................26-154 show policy service group ..................26-156 show policy mac group ..................26-158 show policy port group ..................26-160 show policy map group ..................26-162 show policy action ....................26-164 show policy condition ..................26-166 show active policy rule ..................26-168 show policy rule ....................26-170 show policy validity period ................26-172 Chapter 27...
Page 23 Contents Chapter 29 Port Mapping Commands ..................29-1 port-mapping user-port network-port ..............29-2 port-mapping ......................29-4 port-mapping [unidirectional | bidirectional] ............29-6 port-mapping unknown-unicast-flooding ...............29-8 show port-mapping status ..................29-10 show port-mapping ....................29-12 Chapter 30 Learned Port Security Commands ..............30-1 port-security ......................30-2 port-security learning-window ................30-4 port-security port maximum ...................30-6 port-security port max-filtering ................30-8 port-security port mac-range ..................30-9...
Page 24 Contents ethernet-service sap uni ..................34-14 ethernet-service sap cvlan ..................34-16 ethernet-service sap-profile ..................34-18 ethernet-service sap sap-profile ................34-21 ethernet-service uni-profile ..................34-23 ethernet-service uni uni-profile ................34-26 show ethernet-service vlan ...................34-28 show ethernet-service ...................34-30 show ethernet-service sap ..................34-33 show ethernet-service ...................34-35 show ethernet-service nni ..................34-38 show ethernet-service uni ..................34-40 show ethernet-service uni-profile .................34-42 show ethernet-service sap-profile .................34-44...
Page 25 Contents show usb statistics ....................37-27 show issu status ....................37-29 Chapter 38 Chassis Management and Monitoring Commands ........38-1 system contact ......................38-3 system name ......................38-4 system location .......................38-5 system date ......................38-6 system time ......................38-7 system timezone .....................38-8 system daylight-savings-time ................38-10 update uboot ......................38-11 update fpga ......................38-12 reload slot ......................38-13 power slot ......................38-14...
Page 26 Contents show ntp client .....................40-24 show ntp client server-list ..................40-26 show ntp server client-list ..................40-28 show ntp server status ..................40-30 show ntp keys .......................40-34 show ntp peers ......................40-36 show ntp server disabled-interfaces ..............40-38 Chapter 41 Session Management Commands ............... 41-1 session login-attempt ....................41-3 session login-timeout ....................41-4 session banner ......................41-5...
Page 27 Contents tty ..........................42-29 show tty ........................42-31 tftp ........................42-32 sftp ........................42-34 ftp .........................42-36 Chapter 43 Web Management Commands ................43-1 webview server .......................43-2 webview access ......................43-3 webview force-ssl ....................43-4 webview http-port ....................43-5 webview https-port ....................43-6 show webview ......................43-7 Chapter 44 Configuration File Manager Commands ............
Page 28 Contents Appendix A Software License and Copyright Statements ............. A-1 Alcatel-Lucent License Agreement ................A-1 ALCATEL-LUCENT SOFTWARE LICENSE AGREEMENT ......A-1 Third Party Licenses and Notices .................. A-4 Appendix B CLI Change Guidelines .................... B-1 AOS Release 6 to AOS Release 7 .................. B-1 List of Changed CLI Commands ................
Page 29: About This Guide
About This Guide This OmniSwitch CLI Reference Guide is a comprehensive resource to all Command Line Interface (CLI) commands available on the OmniSwitch 10K Series switches. Supported Platforms The information in this guide applies only to OmniSwitch 10K switches. Who Should Read this Manual? The audience for this user guide is network administrators and IT support personnel who need to config- ure, maintain, and monitor switches and routers in a live network.
Page 30: What Is In This Manual
What is in this Manual? About This Guide What is in this Manual? This reference guide includes information on every CLI command available in the switch. Command reference information is included for base software commands as well as commands associated with optional software packages, such as Advanced Routing (multicast routing protocols and OSPF).
Page 31: Text Conventions
About This Guide Text Conventions Text Conventions The following table contains text conventions and usage guidelines for CLI commands as they are documented in this guide. bold text Indicates basic command and keyword syntax. Example: show snmp station italicized text Indicates user-specific information such as IP addresses, slot numbers, passwords, names, etc.
Page 32: Documentation Roadmap
Documentation Roadmap About This Guide Documentation Roadmap The OmniSwitch user documentation suite was designed to supply you with information at several critical junctures of the configuration process.The following section outlines a roadmap of the manuals that will help you at each stage of the configuration process. Under each stage, we point you to the manual or manuals that will be most helpful to you.
Page 33 About This Guide Documentation Roadmap Anytime The OmniSwitch CLI Reference Guide contains comprehensive information on all CLI commands supported by the switch. This guide includes syntax, default, usage, example, related CLI command, and CLI-to-MIB variable mapping information for all CLI commands supported by the switch. This guide can be consulted anytime during the configuration process to find detailed and specific information on each CLI command.
Page 34: Related Documentation
OmniSwitch Transceivers Guide Includes SFP and XFP transceiver specifications and product compatibility information. • Technical Tips, Field Notices Includes information published by Alcatel-Lucent’s Customer Support group. • Release Notes Includes critical Open Problem Reports, feature exceptions, and other important information on the features supported in the current release and any limitations to their support.
Page 35: Technical Support
With 24-hour access to Alcatel-Lucent’s Service and Support web page, you’ll be able to view and update any case (open or closed) that you have reported to Alcatel-Lucent’s technical support, open a new case or access helpful release notes, technical bulletins, and manuals.
Page 36 Technical Support About This Guide page -xxxvi OmniSwitch CLI Reference Guide March 2011...
Page 37: Ethernet Port Commands
1 Ethernet Port Commands The Ethernet port software is responsible for configuring and monitoring Ethernet ports (10 Mbps, 100 Mbps, 1 Gbps, and 10 Gbps). This includes: • Performing hardware diagnostics, loading software, and initializing hardware. • Notifying other software modules in the system when Ethernet links become active or inactive. •...
Page 38 Ethernet Port Commands A summary of the available commands is listed here. Interfaces commands interfaces interfaces speed interfaces crossover interfaces duplex interfaces alias clear interfaces l2-statistics interfaces max-frame-size interfaces flood-limit interfaces ingress-bandwidth interfaces pause interfaces link-trap interfaces ddm interfaces ddm-trap clear violation show interfaces alias show interfaces status...
Page 39: Interfaces
Ethernet Port Commands interfaces interfaces Enables or disables auto negotiation or administrative status on a single port, a range of ports, or an entire Network Interface (NI). interfaces {slot| slot/port[-port2]} {admin-state | autoneg } {enable|disable} Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure.
Page 40: Related Commands
interfaces Ethernet Port Commands Related Commands interfaces Configures interface speed. interfaces crossover Configures crossover port settings. interfaces duplex Enables or disables flow (pause). show interfaces alias Displays interface line settings. show interfaces alias Displays auto negotiation, speed, duplex, and crossover settings. MIB Objects esmConfTable esmPortCfgAutoNegotiation...
Page 41: Interfaces Speed
Ethernet Port Commands interfaces speed interfaces speed Configures interface line speed. interfaces { slot | slot/port [-port2] } speed { 10 | 100 | 1000 | auto | max {10 | 100 | 1000}} Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure.
Page 42 interfaces speed Ethernet Port Commands Related Commands show interfaces alias Displays interface line settings. MIB Objects esmConfTable esmPortCfgSpeed page 1-6 OmniSwitch CLI Reference Guide March 2011...
Page 43: Interfaces Crossover
Ethernet Port Commands interfaces crossover interfaces crossover Configures port crossover settings on a single port, a range of ports, or an entire Network Interface (NI). interfaces {slot| slot/port[-port2]} crossover {auto | mdix | mdi} Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure.
Page 44 interfaces crossover Ethernet Port Commands Examples -> interfaces 3 crossover mdi -> interfaces 3/1 crossover mdix -> interfaces 3/1-4 crossover auto Release History Release 7.1.1; command introduced. Related Commands show interfaces alias Displays interface line settings. MIB Objects esmConfTable esmPortCfgCrossover page 1-8 OmniSwitch CLI Reference Guide March 2011...
Page 45: Interfaces Duplex
Ethernet Port Commands interfaces duplex interfaces duplex Configures duplex mode. In full duplex mode, the interface transmits and receives data simultaneously. In half duplex mode, the interface can transmit or receive data at a given time. Auto duplex setting causes the switch to advertise all available duplex modes (half/full/both) for the port during autonegotiation.
Page 46 interfaces duplex Ethernet Port Commands Related Commands interfaces Configures interface line speed. Set to auto to set speed and duplex mode to auto-sensing. show interfaces alias Displays interface line settings (e.g., speed, and mode). MIB Objects esmConfTable esmPortAutoDuplexMode page 1-10 OmniSwitch CLI Reference Guide March 2011...
Page 47: Interfaces Alias
Ethernet Port Commands interfaces alias interfaces alias Configures a description (alias) for a single port. interfaces slot/port alias description Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure. description A description for the port, which can be up to 40 characters long. Description tags with spaces must be enclosed within quotes (e.g., “IP Phone”).
Page 48: Clear Interfaces L2-Statistics
clear interfaces l2-statistics Ethernet Port Commands clear interfaces l2-statistics Resets all statistics counters. clear interfaces {slot | slot/port[-port2} l2-statistics [cli] Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure. port2 Last port number in a range of ports you want to configure.
Page 49: Interfaces Max-Frame-Size
Ethernet Port Commands interfaces max-frame-size interfaces max-frame-size Configures the maximum frame size for Gigabit Ethernet interfaces. interfaces {slot | slot/port[-port2} max-frame-size bytes Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure. port2 Last port number in a range of ports you want to configure.
Page 50: Interfaces Flood-Limit
interfaces flood-limit Ethernet Port Commands interfaces flood-limit Configures the flood rate settings on a single port, a range of ports, or an entire Network Interface (NI). interfaces {slot| slot/port[-port2]} flood-limit {bcast|mcast|uucast|all} rate { pps pps_num| mbps mbps_num | cap% cap_num | enable | disable} Syntax Definitions slot Slot number you want to configure.
Page 51 Ethernet Port Commands interfaces flood-limit Examples -> interfaces 3 flood-limit all rate cap% 50 -> interfaces 2/1 flood-limit bcast rate mbps 100 Release History Release 7.1.1; command introduced. Related Commands show interfaces flood-rate Displays interface flood rate settings. MIB Objects esmConfigTable esmPortCfgFlow dot3PauseTable...
Page 52: Interfaces Ingress-Bandwidth
interfaces ingress-bandwidth Ethernet Port Commands interfaces ingress-bandwidth Configures the ingress bandwidth settings on a single port, a range of ports, or an entire Network Interface (NI). interfaces {slot| slot/port[-port2]} ingress-bandwidth {mbps| enable | disable} Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure.
Page 53: Interfaces Pause
Ethernet Port Commands interfaces pause interfaces pause Configures whether or not the switch will honor flow control PAUSE frames on the specified interface. PAUSE frames are used to temporarily pause the flow of traffic between two connected devices to help prevent packet loss when traffic congestion occurs between switches.
Page 54 interfaces pause Ethernet Port Commands Related Commands clear violation Displays interface line settings. MIB Objects esmConfigTable esmPortCfgFlow dot3PauseTable dot3PauseAdminMode page 1-18 OmniSwitch CLI Reference Guide March 2011...
Page 55: Interfaces Link-Trap
Ethernet Port Commands interfaces link-trap interfaces link-trap Enables trap link messages. If enabled, a trap is generated whenever the port changes state. interfaces [slot | slot/port [-port2]] link-trap {enable|disable} Syntax Definitions slot Slot number you want to configure. port Port number of the interface you want to configure. port2 Last port number in a range of ports you want to configure.
Page 56: Interfaces Ddm
interfaces ddm Ethernet Port Commands interfaces ddm Configures the DDM administrative status. interfaces ddm {enable | disable} Syntax Definitions enable Enables DDM functionality. disable Disables DDM functionality. Defaults parameter default disable Platforms Supported OmniSwitch 10K Usage Guidelines • DDM capability will vary based on the transceiver manufacturer. •...
Page 57: Interfaces Ddm-Trap
Ethernet Port Commands interfaces ddm-trap interfaces ddm-trap Configures the DDM administrative status or trap capability. interfaces ddm-trap {enable | disable} Syntax Definitions enable Enables DDM trap functionality. disable Disables DDM trap functionality. Defaults parameter default ddm-trap disable Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 58: Clear Violation
clear violation Ethernet Port Commands clear violation Clears all port violations set by various applications on the switch. clear violation {port slot/port[-port] | linkagg agg_id[-agg_id]} Syntax Definitions slot/port[-port] Slot and port number to be cleared. User a hyphen to specificy a range of ports.
Page 59: Show Interfaces
Ethernet Port Commands show interfaces show interfaces Displays general interface information (e.g., hardware, MAC address, input errors, and output errors). show interfaces [slot | slot/port[-port2]] Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 60 show interfaces Ethernet Port Commands output definitions Slot/Port Interface slot and port. Operational Status Interface status (up/down). Last Time Link Changed The last time the configuration for this interface was changed. Number of Status Change The total number of times that the configuration of this interface has changed.
Page 61 Ethernet Port Commands show interfaces Related Commands show interfaces accounting Displays interface accounting information (e.g., packets received/ transmitted). show interfaces counters Displays interface counter information (e.g., unicast packets received/transmitted). show interfaces alias Displays the interface line settings (e.g., speed and mode). show interfaces traffic Displays interface traffic statistics (input/output bytes and packets).
Page 62 show interfaces Ethernet Port Commands MIB Objects ifTable ifOperStatus ifType ifPhysAddress ifSpeed ifInDiscards IfOutDiscards esmConfTable esmPortSlot esmPortIF esmPortCfgLongEnable esmPortCfgRuntEnable esmPortCfgMaxFrameSize esmPortCfgRuntSize ifXTable ifHCInOctets ifHCInUcastPkts ifHCInBroadcastPkts ifHCInMulticastPkts IfHCOutOctets IfHCOutUcastPkts IfHCOutBroadcastPkts IfHCOutMulticastPkts alcetherStatsTable alcetherStatsRxUndersizePkts alcetherStatsCRCAlignErrors alcetherStatsTxUndersizePkts alcetherStatsTxOversizePkts alcetherStatsTxCollisions dot3StatsTable dot3StatsFrameTooLong dot3StatsFCSErrors dot3StatsLateCollisions page 1-26 OmniSwitch CLI Reference Guide March 2011...
Page 63: Show Interfaces Alias
Ethernet Port Commands show interfaces alias show interfaces alias Displays interface line settings (e.g., speed and mode). show interfaces [slot | slot/port[-port2]] alias Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 64 show interfaces alias Ethernet Port Commands Related Commands interfaces alias Configures the port alias. MIB Objects ifXTable ifAlias page 1-28 OmniSwitch CLI Reference Guide March 2011...
Page 65: Show Interfaces Status
Ethernet Port Commands show interfaces status show interfaces status Displays interface line settings (e.g., speed and mode). show interfaces [slot | slot/port[-port2]] status Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 66 show interfaces status Ethernet Port Commands Release History Release 7.1.1; command introduced. Related Commands interfaces Enables/disables Trap LinkUpDown. interfaces Configures interface line speed, sets speed, and duplex mode to auto-sensing. interfaces duplex Configures interface duplex mode. MIB Objects ifTable ifLinkUpDownTrapEnable esmConfTable esmPortSlot esmPortIF...
Page 67: Show Interfaces Capability
Ethernet Port Commands show interfaces capability show interfaces capability Displays default auto negotiation, speed, duplex, flow, and cross-over settings for a single port, a range of ports, or all ports on a Network Interface (NI) module. show interfaces [slot | slot//port[-port2]] capability Syntax Definitions slot Slot number you want to display.
Page 68 show interfaces capability Ethernet Port Commands output definitions (continued) Crossover In the row labeled CAP, the field displays the valid cross over configu- rations for the port. In the row label DEF, the field displays the default cross over settings for the port. The possible values are Auto, MDI/X/Auto (MDI/MDIX/Auto), or -- (not configurable and/or not applicable).
Page 69: Show Interfaces Accounting
Ethernet Port Commands show interfaces accounting show interfaces accounting Displays interface accounting information (e.g., packets received/transmitted and deferred frames received). show interfaces [slot | slot/port[-port2]] accounting Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 70 show interfaces accounting Ethernet Port Commands output definitions (continued) Rx packets Octets Number of packets received in each listed octet range. Rx Jabber frames Number of jabber packets received (longer than 1518 octets). Tx deferred frames Number of packets for which transmission was delayed (Ethernet only).
Page 71 Ethernet Port Commands show interfaces accounting MIB Objects esmConfTable esmPortSlot esmPortIF dot3StatsTable dot3StatsFrameTooLong dot3StatsDeferredTransmissions alcetherStatsTable alcetherStatRxsUndersizePkts alcetherStatTxsUndersizePkts alcetherStatsTxOversizePkts alcetherStatsPkts64Octets alcetherStatsPkts65to127Octets alcetherStatsPkts128to255Octets alcetherStatsPkts256to511Octets alcetherStatsPkts512to1023Octets alcetherStatsPkts1024to1518Octets gigaEtherStatsPkts1519to4095Octets gigaEtherStatsPkts4096to9215Octets alcetherStatsRxJabber OmniSwitch CLI Reference Guide March 2011 page 1-35...
Page 72: Show Interfaces Counters
show interfaces counters Ethernet Port Commands show interfaces counters Displays interface counters information (e.g., unicast, broadcast, and multi-cast packets received/transmit- ted). show interfaces [slot | slot/port[-port2]] counters Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 73 Ethernet Port Commands show interfaces counters Release History Release 7.1.1; command introduced. Related Commands show interfaces counters errors Displays interface error frame information (e.g., CRC errors, transit errors, and receive errors). MIB Objects esmConfTable esmPortSlot esmPortIF ifXTable IfHCInOctets IfHCOutOctets IfHCInUcastPkts IfHCOutUcastPkts IfHCInMulticastPkts IfHCOutMulticastPkts...
Page 74: Show Interfaces Counters Errors
show interfaces counters errors Ethernet Port Commands show interfaces counters errors Displays interface error frame information (e.g., CRC errors, transit errors, and receive errors). show interfaces [slot | slot/port[-port2]] counters errors Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display.
Page 75 Ethernet Port Commands show interfaces counters errors Related Commands show interfaces counters Displays interface counters information (e.g., unicast, broadcast, and multi-cast packets received/transmitted). MIB Objects esmConfTable esmPortSlot esmPortIF ifTable ifInErrors ifOutErrors alcetherStatsTable alcetherStatsRxUndersizePkts dot3StatsTable dot3StatsAlignmentErrors dot3StatsFCSErrors dot3StatsFrameTooLong OmniSwitch CLI Reference Guide March 2011 page 1-39...
Page 76: Show Interfaces Flood-Rate
show interfaces flood-rate Ethernet Port Commands show interfaces flood-rate Displays interface peak flood rate settings. show interfaces [slot | slot/port[-port2]] flood-rate Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display.
Page 77 Ethernet Port Commands show interfaces flood-rate Related Commands interfaces flood-limit Configures the peak flood rate for an interface. MIB Objects esmConfTable esmPortSlot esmPortIF esmPortMaxFloodRate esmPortFloodMcastEnable OmniSwitch CLI Reference Guide March 2011 page 1-41...
Page 78: Show Interfaces Traffic
show interfaces traffic Ethernet Port Commands show interfaces traffic Displays interface traffic statistics. show interfaces [slot | slot/port[-port2]] traffic Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port2 Last port number in a range of ports you want to display. Defaults Platforms Supported OmniSwitch 10K...
Page 79 Ethernet Port Commands show interfaces traffic Related Commands interfaces ddm Displays general interface information (e.g., hardware, MAC address, and input/output errors). show interfaces counters Displays interface counter information (e.g., unicast packets received/transmitted). MIB Objects esmConfTable esmPortSlot esmPortIF ifXTable ifHCInOctets ifHCInUcastPkts ifHCInMulticastPkts ifHCInBroadcastPkts ifHCOutOctets...
Page 80: Show Interfaces Ingress-Rate-Limit
show interfaces ingress-rate-limit Ethernet Port Commands show interfaces ingress-rate-limit Displays the ingress-rate-limit set for each interface port. show interfaces [slot| slot/port[-port1]] ingress-rate-limit Syntax Definitions slot Slot number you want to display. port Port number of the interface you want to display. port1 Last port number in a range of ports you want to display.
Page 81 Ethernet Port Commands show interfaces ingress-rate-limit Related Commands interfaces duplex Configures the ingress-rate-limit. MIB Objects esmConfTable esmPortSlot esmPortIF OmniSwitch CLI Reference Guide March 2011 page 1-45...
Page 82: Show Interfaces Ddm
show interfaces ddm Ethernet Port Commands show interfaces ddm Displays the information for the specified transceivers. show interfaces [slot| slot/port[-port1]] ddm [W-LOW W-HIGH STATUS A-LOW A-HIGH ACTUAL] Syntax Definitions slot Display all the transceivers on the specified slot. Display information for the specfied transceiver. port2 Last port number in a range of ports to display.
Page 83 Ethernet Port Commands show interfaces ddm 5.95 3.22 3.22 -> show interfaces 1/1 transceiver Threshold Temp C Voltage(V) Current(mA) Output(dBm) Input(dBm) ------------+------+----------+-----------+----------+---------+ Actual 1.95(WL) 4.92(AH) 3.22 Alarm High 5.75 4.91 4.91 Warning High 3.00 4.77 4.77 Warning Low 2.00 0.00 0.00 Alarm Low 1.75...
Page 84 show interfaces ddm Ethernet Port Commands Related Commands show interfaces ddm Configures the DDM administrative status or trap capability. MIB Objects ddmNotifications ddmTemperature ddmTempLowWarning ddmTempLowAlarm ddmTempHiWarning ddmTempHiAlarm ddmSupplyVoltage ddmSupplyVoltageLowWarning ddmSupplyVoltageLowAlarm ddmSupplyVoltageHiWarning ddmSupplyVoltageHiAlarm ddmTxBiasCurrent ddmTxBiasCurrentLowWarning ddmTxBiasCurrentLowAlarm ddmTxBiasCurrentHiWarning ddmTxBiasCurrentHiAlarm ddmTxOutputPower ddmTxOutputPowerLowWarning ddmTxOutputPowerLowAlarm ddmTxOutputPowerHiWarning ddmTxOutputPowerHiAlarm ddmRxOpticalPower...
Page 85: Show Transceivers
Ethernet Port Commands show transceivers show transceivers Displays transceiver manufactuer and status information. show transceivers [slot slot] Syntax Definitions slot Display all the transceivers on the specified slot. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show transceivers Slot 2 Transceiver 1 Manufacturer Name: FIBERXON INC.
Page 86 show transceivers Ethernet Port Commands Related Commands show interfaces ddm Displays the DDM administrative status or trap capability. page 1-50 OmniSwitch CLI Reference Guide March 2011...
Page 87: Chapter 2 Udld Commands
• It sends continuous echo messages when fast notifications are required. MIB information for the UDLD commands is as follows: Filename: AlcatelIND1UDLD.mib Module: ALCATEL-IND1-UDLD-MIB A summary of available commands is listed here: udld udld port udld mode udld probe-timer udld echo-wait-timer...
Page 88: Udld
udld UDLD Commands udld Globally enables or disables UDLD protocol on the switch. udld {enable | disable} Syntax Definitions enable Globally enables UDLD on the switch. disable Globally disables UDLD on the switch. Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 89: Udld Port
UDLD Commands udld port udld port Enables or disables UDLD status on a specific port or a range of ports. udld port slot/port[-port2] {enable | disable} Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 90 udld port UDLD Commands Related Commands udld Globally enables or disables UDLD protocol on the switch. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. MIB Objects alaUdldPortConfigTable alaUdldPortConfigUdldStatus page 2-4 OmniSwitch CLI Reference Guide...
Page 91: Udld Mode
UDLD Commands udld mode udld mode Configures the operational mode of UDLD on a specific port, a range of ports, or all the ports. udld port [slot/port[-port2]] mode {normal | aggressive} Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 92 udld mode UDLD Commands Related Commands udld Globally enables or disables UDLD protocol on the switch. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. MIB Objects alaUdldPortConfigTable alaUdldPortConfigUdldMode page 2-6 OmniSwitch CLI Reference Guide...
Page 93: Udld Probe-Timer
UDLD Commands udld probe-timer udld probe-timer Configures the probe-message advertisement timer on a specific port, a range of ports, or all the ports. Probe-messages are transmitted periodically after this timer expires. udld port [slot/port[-port2]] probe-timer seconds no udld port [slot/port[-port2]] probe-timer Syntax Definitions slot/port The slot number for the module and the physical port number on that...
Page 94 udld probe-timer UDLD Commands Related Commands udld Globally enables or disables UDLD protocol on the switch. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. MIB Objects alaUdldPortConfigTable alaUdldPortConfigUdldProbeIntervalTimer page 2-8 OmniSwitch CLI Reference Guide...
Page 95: Udld Echo-Wait-Timer
UDLD Commands udld echo-wait-timer udld echo-wait-timer Configures the echo based detection timer on a specific port, a range of ports, or all the ports. This is known as link detection period. udld port [slot/port[-port2]] echo-wait-timer seconds no udld port [slot/port[-port2]] echo-wait-timer Syntax Definitions slot/port The slot number for the module and the physical port number on that...
Page 96 udld echo-wait-timer UDLD Commands Related Commands udld Globally enables or disables UDLD protocol on the switch. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. MIB Objects alaUdldPortConfigTable alaUdldPortConfigUdldDetectionPeriodTimer page 2-10 OmniSwitch CLI Reference Guide...
Page 97: Clear Udld Statistics Port
UDLD Commands clear udld statistics port clear udld statistics port Clears the UDLD statistics for a specific port or for all the ports. clear udld statistics [port slot/port] Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 98: Show Udld Configuration
show udld configuration UDLD Commands show udld configuration Displays the global status of UDLD configuration. show udld configuration Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show udld configuration Global UDLD Status : disabled, Global UDLD Mode : normal, Global UDLD Probe Timer (Sec) : 15,...
Page 99 UDLD Commands show udld configuration Related Commands udld Globally enables or disables UDLD protocol on the switch. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. MIB Objects alaUdldGlobalStatus alaUdldGlobalConfigUdldStatus OmniSwitch CLI Reference Guide...
Page 100: Show Udld Configuration Port
show udld configuration port UDLD Commands show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch. show udld configuration port [slot/port] Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 101 UDLD Commands show udld configuration port output definitions Slot/Port Slot number for the module and physical port number on that module. UDLD-State Indicates the state of interface determined by UDLD operation, which can be notapplicable, shutdown, undetermined or bidirectional. Oper-Mode Indicates the operational mode of UDLD protocol.
Page 102: Show Udld Statistics Port
show udld statistics port UDLD Commands show udld statistics port Displays the UDLD statistics for a specific port. show udld statistics port slot/port Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3). Defaults Platforms Supported OmniSwitch 10K...
Page 103 UDLD Commands show udld statistics port Release History Release 7.1.1; command introduced. Related Commands udld probe-timer Configures the probe-message advertisement timer on a specific port, a range of ports, or all the ports. udld echo-wait-timer Configures the echo based detection timer on a specific port, a range of ports, or all the ports.
Page 104: Show Udld Neighbor Port
show udld neighbor port UDLD Commands show udld neighbor port Displays the UDLD neighbor ports. show udld neighbor port slot/port Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3). Defaults Platforms Supported OmniSwitch 10K...
Page 105 UDLD Commands show udld neighbor port Related Commands udld echo-wait-timer Configures the echo based detection timer on a specific port, a range of ports, or all the ports. This is known as link detection period. show udld statistics port Displays the UDLD statistics for a specific port. MIB Objects alaUdldPortNeighborStatsTable alaUdldNeighborName...
Page 106: Show Udld Status Port
show udld status port UDLD Commands show udld status port Displays the UDLD status for all ports or for a specific port. show udld status port [slot/port] Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 107 UDLD Commands show udld status port Release History Release 7.1.1; command introduced. Related Commands udld port Enables or disables UDLD status on a specific port or a range of ports. show udld configuration port Displays the configuration information for all UDLD ports or for a particular UDLD port on the switch.
Page 108 show udld status port UDLD Commands page 2-22 OmniSwitch CLI Reference Guide March 2011...
Page 109: Source Learning Commands
MAC addresses, and display MAC Address Table entries and statistics. MIB information for Source Learning commands is as follows: Filename: AlcatelInd1MacAddress.mib Module: ALCATEL-IND1-MAC-ADDRESS-MIB A summary of the available commands is listed here: mac-learning mac-learning vlan static mac-address mac-learning vlan multicast mac-address...
Page 110: Mac-Learning
mac-learning Source Learning Commands mac-learning Configures the status of source MAC address learning on a single port, a range of ports, or on a link aggregate of ports. mac-learning {port slot/port | linkagg linkagg} {enable | disable} Syntax Definitions slot/port The slot number for the module and the physical port number on that module (for example, 3/1 specifies port 1 on slot 3).
Page 111 Source Learning Commands mac-learning Related Commands show mac-learning Displays Source Learning status of and individual port or link aggregate ports on a switch. Related MIB Objects slMacAddressTable slMacLearningControlTable slMacLearningControlEntry slMacLearningControlStatus OmniSwitch CLI Reference Guide March 2011 page 3-3...
Page 112: Mac-Learning Vlan Static Mac-Address
mac-learning vlan static mac-address Source Learning Commands mac-learning vlan static mac-address Configures a static destination unicast MAC address. The configured MAC address is assigned to a fixed switch port or link aggregate ID and VLAN. If the destination of the data packets received on the VLAN ports is the configured MAC address, then they are forwarded to the specific MAC address port.
Page 113 Source Learning Commands mac-learning vlan static mac-address Usage Guidelines • Use the no form of this command to remove a static or dynamic MAC address from the Source Learn- ing MAC Address Table. • The specified port or link aggregate ID mentioned along with the linkagg keyword must already belong to the specified VLAN.
Page 114: Mac-Learning Vlan Multicast Mac-Address
mac-learning vlan multicast mac-address Source Learning Commands mac-learning vlan multicast mac-address Configures a static multicast MAC address and assigns the address to one or more egress ports. Packets received on ports associated with the specified VLAN that contain a destination MAC address that matches the static multicast address are forwarded to the specified egress ports.
Page 115 Source Learning Commands mac-learning vlan multicast mac-address • The configured (static) multicast MAC address is assigned to a fixed switch port or link aggregate ID and VLAN. • In addition to configuring the same static multicast address for multiple ports within a given VLAN, it is also possible to use the same multicast address across multiple VLANs.
Page 116 mac-learning vlan multicast mac-address Source Learning Commands MIB Objects slMacAddressTable slMacAddress slMacAddressManagement slMacAddressDisposition page 3-8 OmniSwitch CLI Reference Guide March 2011...
Page 117: Mac-Learning Aging-Time
Source Learning Commands mac-learning aging-time mac-learning aging-time Configures aging time, in seconds, for static and dynamically learned MAC addresses. When a MAC address has aged beyond the aging-time value, the MAC address is discarded. mac-learning aging-time {seconds | default} no mac-learning aging-time Syntax Definitions seconds Aging time value (in seconds).
Page 118 mac-learning aging-time Source Learning Commands Related Commands show mac-learning Displays Source Learning MAC Address Table information. show mac-learning aging-time Displays the current aging time value for the Source Learning MAC Address Table. MIB Objects slMacAddressAgingTable slMacAgingValue page 3-10 OmniSwitch CLI Reference Guide March 2011...
Page 119: Mac-Learning Mode
Source Learning Commands mac-learning mode mac-learning mode Enables or disables the distributed MAC source learning mode for the chassis. mac-learning mode [centralized | distributed] Syntax Definitions centralized Enables centralized MAC source learning mode. distributed Enables distributed MAC source learning mode. Defaults By default, distributed MAC source learning mode is disabled for the chassis.
Page 120: Show Mac-Learning
show mac-learning Source Learning Commands show mac-learning Displays Source Learning MAC Address Table information. show mac-learning [summary] [multicast | static | dynamic] [vlan vlan_id [-vlan_id2]] [slot slot | port slot/port] [linkagg linkagg] [mac-address mac_address] Syntax Definitions summary Displays summary of all the parameters. multicast Display all the static multicast MAC addresses information contained in the MAC address table.
Page 121 Source Learning Commands show mac-learning Examples -> show mac-learning summary Mac Address Table Count: Permanent Address Count = 0, Dynamic Learned Address Count = 16, Static Multicast Address Count = 0, Total MAC Address In Use = 16 -> show mac-learning Legend: Mac Address: * = address not valid Vlan Mac Address...
Page 122 show mac-learning Source Learning Commands Related Commands show mac-learning aging-time Displays the current aging time value for the Source Learning MAC Address Table. MIB Objects slMacAddressTable slMacAddress slMacAddressManagement slMacAddressDisposition slMacAddressProtocol page 3-14 OmniSwitch CLI Reference Guide March 2011...
Page 123: Show Mac-Learning Aging-Time
Source Learning Commands show mac-learning aging-time show mac-learning aging-time Displays the current aging time value for the Source Learning MAC Address Table. show mac-learning aging-time Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Note that the aging time is the same for all VLANs because it is not configurable on a per-VLAN basis. The aging time value on this platform is a global parameter that applies to all VLANs.
Page 124: Show Mac-Learning Learning-State
show mac-learning learning-state Source Learning Commands show mac-learning learning-state Displays the source learning status of a VLAN, port or link aggregate. show mac-learning learning-state [vlan vlan[-vlan2] | port slot/port | linkagg linkagg] Syntax Definitions vlan The VLAN ID number. -vlan2 The last VLAN ID in a range of VLAN IDs.
Page 125 Source Learning Commands show mac-learning learning-state -> show mac-learning learning-state linkagg 10 port mac-learning -----+------------- 0/10 disabled output definitions port The slot/port number for a switch port or a link aggregate ID number. If the interface is a link aggregate ID, zero is displayed as the slot number (for example, 0/29).
Page 126: Show Mac-Learning Mode
show mac-learning mode Source Learning Commands show mac-learning mode Displays the current status (enabled or disabled) of the distributed MAC source learning mode. show mac-learning mode Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines N/A. Examples -> show mac-learning mode MAC Learning Mode Configuration = CENTRALIZED New Configured MAC Learning Mode After Reboot = DISTRIBUTED ->...
Page 127: Chapter 4 Vlan Management Commands
VLAN, and display VLAN configuration information. MIB information is as follows: Filename: AlcatelIND1VlanManager.mib Module: ALCATEL-IND1-VLAN-MGR-MIB A summary of the available commands is listed here: vlan vlan members untagged vlan members tagged vlan mtu-ip...
Page 128: Vlan
vlan VLAN Management Commands vlan Creates a new VLAN with the specified VLAN ID (VID) and an optional description. vlan vlan_id [admin-state {enable | disable}] [name description] no vlan vlan_id Syntax Definitions vlan_id A numeric value that uniquely identifies an individual VLAN. This value becomes the VLAN ID for the new VLAN.
Page 129: Vlan Members Untagged
VLAN Management Commands vlan Examples -> vlan 200 name “Corporate VLAN” -> vlan 720 admin-state disable -> no vlan 1020 Release History Release 7.1.1; command introduced. Related Commands vlan members untagged Statically assigns ports to a VLAN. show vlan Displays a list of existing VLANs. show vlan members Displays VLAN port assignments.
Page 130: Vlan Members Untagged
vlan members untagged VLAN Management Commands vlan members untagged Configures a new default VLAN for a single port or an aggregate of ports. The VLAN specified with this command is referred to as the configured default VLAN for the port. vlan vlan_id [-vlan_id2] members {port slot/port[-port1] | linkagg linkagg_id[-linkagg_id2]} untagged no vlan vlan_id [-vlan_id2] members {port slot/port[-port1]| linkagg_id linkagg_id[-linkagg_id2]} Syntax Definitions...
Page 131: Vlan Members Tagged
VLAN Management Commands vlan members untagged Related Commands vlan Creates a VLAN. vlan members tagged Configures a port to accept 802.1q-tagged packets for a specific VLAN. show vlan Displays list of existing VLANs. show vlan members Displays VLAN port assignments. MIB Objects vpaTable vpaVlanNumber...
Page 132: Vlan Members Tagged
vlan members tagged VLAN Management Commands vlan members tagged Configures a port or link aggregate ID to send and receive 802.1q-tagged packets with the specified VLAN ID. vlan vlan_id[-vlan_id2] members {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} tagged no vlan vlan_id[-vlan_id2] members {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} Syntax Definitions vlan_id The VLAN ID number for a preconfigured VLAN that will handle the...
Page 133 VLAN Management Commands vlan members tagged Related Commands vlan Creates a VLAN. vlan members untagged Configures the default VLAN for the specified port or link aggregate. show vlan members Displays VLAN port assignments. MIB Objects qPortVlanTable qPortVlanSlot qPortVlanPort qPortVLanStatus qPortVlanTagValue qPortVlanDescription qAggregateVlanTagValue qAggregateVlanAggregateId...
Page 134: Vlan Mtu-Ip
vlan mtu-ip VLAN Management Commands vlan mtu-ip Configures the maximum transmission unit (MTU) packet size allowed for all ports associated with a VLAN. This value is configured on a per VLAN basis, so all IP interfaces assigned to the VLAN apply the same MTU value to packets sent on VLAN ports.
Page 135: Show Vlan
VLAN Management Commands vlan mtu-ip Related Commands vlan Creates a VLAN. icmp type Configures a port to accept 802.1q-tagged packets for a specific VLAN. show vlan Displays list of existing VLANs. MIB objects vlanTable vlanMtu OmniSwitch CLI Reference Guide March 2011 page 4-9...
Page 136: Show Vlan
show vlan VLAN Management Commands show vlan Displays a list of VLANs configured on the switch. show vlan [vlan_id] Syntax Definitions vlan_id VLAN ID number. Defaults By default, a list of all VLANs is displayed. Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 137 VLAN Management Commands show vlan output definitions (continued) IP router interface status: Ena (IP interface exists for the VLAN) or Dis (no IP router interface exists for the VLAN). Use the ip interface command to define an IP router interface for a VLAN. Maximum Transmission Unit: Size of largest data packet that the VLAN port can transmit.
Page 138: Show Vlan Members
show vlan VLAN Management Commands Related Commands show vlan members Displays VLAN port assignments. MIB Objects vlanMgrVlan vlanTable vlanNumber vlanDescription vlanAdmStatus vlanOperStatus vlanStatus page 4-12 OmniSwitch CLI Reference Guide March 2011...
Page 139: Show Vlan Members
VLAN Management Commands show vlan members show vlan members Displays VLAN port associations (VPAs) for all VLANs, a specific VLAN, or for a specific port. show vlan [vlan_id [-vlan_id2]] members [port [slot/port[-port2]| linkagg linkagg_id [-linkagg_id2]] Syntax Definitions vlan_id VLAN ID number. -vlan_id2 The last VLAN ID in a range of VLAN IDs.
Page 140 show vlan members VLAN Management Commands Examples -> show vlan members vlan port type status +-----+-------+---------+------------+ default inactive default blocking 11/4 qtagged forwarding qtagged blocking 11/4 default forwarding dynamic forwarding -> show vlan 10 members port type status +------+--------+------------+ default forwarding qtagged forwarding...
Page 141 VLAN Management Commands show vlan members Release History Release 7.1.1; command introduced. Related Commands show vlan Displays list of VLANs configured on the switch. show ip interface Displays IP router information. MIB Objects vlanMgrVpa vpaTable vpaVlanNumber vpaIfIndex vpaType vpaState vpaStatus vlanMgrVlan vlanTable vlanAdmStatus...
Page 142 show vlan members VLAN Management Commands page 4-16 OmniSwitch CLI Reference Guide March 2011...
Page 143: Distributed Spanning Tree Commands
The Spanning Tree Algorithm and Protocol (STP) is a self-configuring algorithm that maintains a loop-free topology while providing data path redundancy and network scalability. Based on the IEEE 802.1D standard, the Alcatel-Lucent STP implementation distributes the Spanning Tree load between the primary management module and the network interface modules. This functionality improves network robustness by providing a Spanning Tree that continues to respond to BPDUs and port link up and down states in the event of a fail over to a backup management module or switch.
Page 144 Distributed Spanning Tree Commands A summary of the available commands is listed here: Bridge commands spantree mode spantree protocol spantree priority spantree hello-time spantree max-age spantree forward-delay spantree bpdu-switching spantree path-cost-mode spantree vlan admin-state spantree auto-vlan-containment show spantree show spantree cist show spantree msti show spantree vlan show spantree mode...
Page 145: Spantree Mode
Distributed Spanning Tree Commands spantree mode spantree mode Selects the flat Spanning Tree or per-VLAN Spanning Tree operating mode for the switch. These modes are exclusive; however, it is not necessary to reboot the switch when the STP modes are changed. spantree mode {flat | per-vlan} Syntax Definitions flat...
Page 146 spantree mode Distributed Spanning Tree Commands Note. Active ports associated with such a VLAN are excluded from any Spanning Tree calculations and remain in a forwarding state. Examples -> spantree mode flat -> spantree mode per-vlan Release History Release 7.1.1; command introduced. Related Commands spantree protocol Selects the Spanning Tree protocol for the specified instance.
Page 147: Spantree Protocol
Distributed Spanning Tree Commands spantree protocol spantree protocol Configures the Spanning Tree protocol for the flat mode Common and Internal Spanning Tree (CIST) instance or for an individual VLAN instance. spantree [cist | vlan vlan_id] protocol {stp | rstp | mstp} Syntax Definitions cist The CIST instance (also known as MSTI 0).
Page 148 spantree protocol Distributed Spanning Tree Commands Examples -> spantree protocol mstp -> spantree cist protocol mstp -> spantree vlan 5 protocol rstp Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch.
Page 149: Spantree Vlan Admin-State
Distributed Spanning Tree Commands spantree vlan admin-state spantree vlan admin-state Enables or disables the Spanning Tree status for a VLAN. spantree vlan vlan_id [-vlan_id2] admin-state {enable | disable} Syntax Definitions vlan_id[-vlan_id2] An existing VLAN ID number. Use a hyphen to specify a range of VLANs (10-15).
Page 150: Spantree Mst Region Name
Syntax Definitions name An alphanumeric string. Use quotes around string if the name contains multiple words with spaces between them (for example “Alcatel-Lucent Marketing”). Defaults By default, the MST region name is left blank. Platforms Supported...
Page 151 Distributed Spanning Tree Commands spantree mst region name Related Commands spantree mst region revision- Defines the revision level for an MST region. level spantree mst region max-hops Defines the maximum number of hops for the MST region. spantree msti Defines a MSTI number that identifies an association between a range of VLANs and a Spanning Tree instance.
Page 152: Spantree Mst Region Revision-Level
spantree mst region revision-level Distributed Spanning Tree Commands spantree mst region revision-level Defines the revision level for a Multiple Spanning Tree (MST) region. One of three attributes (name, revision level, and a VLAN to MST instance association table) that defines an MST region as required by the IEEE 802.1Q 2005 standard.
Page 153: Spantree Mst Region Max-Hops
Distributed Spanning Tree Commands spantree mst region max-hops spantree mst region max-hops Configures the maximum number of hops that are authorized to receive Multiple Spanning Tree (MST) regional information. Use this command to assign the maximum number of hops a BPDU is allowed to traverse, before it is discarded and related information is aged out.
Page 154 spantree mst region max-hops Distributed Spanning Tree Commands Related Commands spantree mst region name Defines the name for an MST region. spantree mst region revision- Defines the revision level for an MST region. level spantree msti Defines a MSTI number that identifies an association between a range of VLANs and a Spanning Tree instance.
Page 155: Spantree Msti
MSTI ID number. name An alphanumeric string. Use quotes around string if the name contains multiple words with spaces between them (for example “Alcatel-Lucent Marketing”). Defaults By default, a flat mode Common and Internal Spanning Tree (CIST) instance always exists. The MSTI ID number for this instance is 0.
Page 156 spantree msti Distributed Spanning Tree Commands Related Commands spantree mst region name Defines the name for an MST region. spantree mst region revision- Defines the revision level for an MST region. level spantree mst region max-hops Defines the maximum number of hops for the MST region. spantree msti vlan Defines an association between a range of VLANs and a single MSTI.
Page 157: Spantree Msti Vlan
Distributed Spanning Tree Commands spantree msti vlan spantree msti vlan Defines an association between a range of VLANs and a single Multiple Spanning Tree Instance (MSTI). The MSTI-to-VLAN mapping created with this command is one of three attributes (name, revision level, and a VLAN to MST instance association table) that defines an MST region as required by the IEEE 802.1Q 2005 standard.
Page 158 spantree msti vlan Distributed Spanning Tree Commands Release History Release 7.1.1; command introduced. Related Commands spantree mst region name Defines the name for an MST region. spantree mst region revision- Defines the revision level for an MST region. level spantree mst region max-hops Defines the maximum number of hops for the MST region.
Page 159: Spantree Priority
Distributed Spanning Tree Commands spantree priority spantree priority Configures the bridge priority value for the Common and Internal Spanning Tree (CIST) instance, a Multi- ple Spanning Tree Instance (MSTI), or a VLAN instance. This command is also used to configure the priority value for a port or link aggregate associated with the CIST, an MSTI, or a VLAN.
Page 160 spantree priority Distributed Spanning Tree Commands • If none of the optional instance parameters (cist, msti, or vlan) or port and linkagg parameters are specified with this command, the bridge priority is configured for the CIST instance by default. This is true regardless of which mode (flat or per-VLAN) is active for the switch.
Page 161 Distributed Spanning Tree Commands spantree priority Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. show spantree Displays the Spanning Tree instance configuration. show spantree ports Displays the Spanning Tree port configuration. MIB Objects vStpInsTable vStpInsNumber vStpInsMode...
Page 162: Spantree Hello-Time
spantree hello-time Distributed Spanning Tree Commands spantree hello-time Configures the Spanning Tree hello time value for the flat mode Common and Internal Spanning Tree (CIST) instance or for a per-VLAN mode VLAN instance. This value specifies the amount of time, in seconds, between each transmission of a BPDU on any port that is the Spanning Tree root or is attempting to become the Spanning Tree root.
Page 163 Distributed Spanning Tree Commands spantree hello-time Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. show spantree Displays the Spanning Tree instance configuration. MIB Objects vStpInsTable vStpInsNumber vStpInsMode vStpInsBridgeHelloTime OmniSwitch CLI Reference Guide...
Page 164: Spantree Max-Age
spantree max-age Distributed Spanning Tree Commands spantree max-age Configures the bridge maximum age time value for the flat mode Common and Internal Spanning Tree (CIST) instance or for a per-VLAN mode VLAN instance. This value is the amount of time, in seconds, that the Spanning Tree Protocol information learned from the network on any port is retained.
Page 165 Distributed Spanning Tree Commands spantree max-age Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. show spantree Displays the Spanning Tree instance configuration. MIB Objects vStpInsTable vStpInsNumber vStpInsBridgeMaxAge OmniSwitch CLI Reference Guide March 2011...
Page 166: Spantree Forward-Delay
spantree forward-delay Distributed Spanning Tree Commands spantree forward-delay Configures the bridge forward delay time for the flat mode Common and Internal Spanning Tree (CIST) instance or for a per-VLAN mode VLAN instance. This value is the amount of time, in seconds, that determines how fast a port changes its Spanning Tree state until it reaches a forwarding state.
Page 167 Distributed Spanning Tree Commands spantree forward-delay Examples -> spantree forward-delay 30 -> spantree cist forward-delay 30 -> spantree vlan 5 forward-delay 10 Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch.
Page 168: Spantree Bpdu-Switching
spantree bpdu-switching Distributed Spanning Tree Commands spantree bpdu-switching Enables or disables the switching of Spanning Tree BPDU for VLAN and CIST instances if the switch is running in the per-VLAN mode. spantree {vlan vlan_id | cist} bpdu-switching {enable | disable} Syntax Definitions vlan_id An existing VLAN ID number.
Page 169 Distributed Spanning Tree Commands spantree bpdu-switching Related Commands vlan members untagged Enables or disables Spanning Tree instance for the specified VLAN. show spantree Displays VLAN Spanning Tree parameter values. MIB Objects vStpInsTable vStpInsBpduSwitching OmniSwitch CLI Reference Guide March 2011 page 5-27...
Page 170: Spantree Path-Cost-Mode
spantree path-cost-mode Distributed Spanning Tree Commands spantree path-cost-mode Configures the automatic selection of a 16-bit path cost for STP/RSTP ports and a 32-bit path cost for MSTP ports or sets all path costs to use a 32-bit value. spantree path-cost-mode {auto | 32bit} Syntax Definitions auto The port path cost value is automatically set depending on which...
Page 171 Distributed Spanning Tree Commands spantree path-cost-mode MIB Objects vStpBridge vStpPathCostMode OmniSwitch CLI Reference Guide March 2011 page 5-29...
Page 172: Spantree Pvst+Compatibility
spantree pvst+compatibility Distributed Spanning Tree Commands spantree pvst+compatibility Enables or disables PVST+ mode on the switch, port or link aggregate enabling them to operate with Cisco switches. spantree pvst+compatibility {port slot/port] | linkagg linkagg_id} {enable | disable | auto} Syntax Definitions enable Enables the PVST+ mode.
Page 173 Distributed Spanning Tree Commands spantree pvst+compatibility Related Commands show spantree Displays Spanning Tree bridge information for all flat mode Common and Internal Spanning Tree (CIST) instance and per-VLAN mode VLAN instance. show spantree ports Displays Spanning Tree port information for the flat mode Common and Internal Spanning Tree (CIST) instance or a per-VLAN mode VLAN instance.
Page 174: Spantree Auto-Vlan-Containment
spantree auto-vlan-containment Distributed Spanning Tree Commands spantree auto-vlan-containment Enables or disables Auto VLAN Containment (AVC). When enabled, AVC prevents a port that has no VLANs mapped to an Multiple Spanning Tree Instance (MSTI) from becoming the root port for that instance.
Page 175 Distributed Spanning Tree Commands spantree auto-vlan-containment Release History Release 7.1.1; command introduced. Related Commands show spantree msti ports Displays Spanning Tree port information for a flat mode Multiple Spanning Tree Instance (MSTI). MIB Objects vStpInsTable vStpInsAutoVlanContainment vStpBridge vStpBridgeAutoVlanContainment OmniSwitch CLI Reference Guide March 2011 page 5-33...
Page 176: Spantree Cist
spantree cist Distributed Spanning Tree Commands spantree cist Enables or disables the Spanning Tree status on a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST) instance. spantree cist {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} {enable | disable} Syntax Definitions slot/port[-port2] The slot number and port number of the physical port.
Page 177 Distributed Spanning Tree Commands spantree cist Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree vlan Configures the Spanning Tree status on a port or a link aggregate of ports for a VLAN instance. MIB Objects vStpInsPortTable vStpInsPortNumber...
Page 178: Spantree Vlan
spantree vlan Distributed Spanning Tree Commands spantree vlan Enables or disables the Spanning Tree status on a port or a link aggregate of ports for the specified VLAN instance. spantree vlan vlan_id [-vlan2] {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} {enable | disable} Syntax Definitions vlan_id...
Page 179 Distributed Spanning Tree Commands spantree vlan -> spantree vlan 3 linkagg 16 disable -> spantree vlan 3 linkagg 22-25 disable Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch.
Page 180: Spantree Cist Path-Cost
spantree cist path-cost Distributed Spanning Tree Commands spantree cist path-cost Configures the Spanning Tree path cost value for a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST) instance. This value is the contribution of this port to the path cost towards the Spanning Tree root bridge that includes this port.
Page 181 Distributed Spanning Tree Commands spantree cist path-cost • Is a 16-bit path cost value is in use and the path_cost is set to zero, the following IEEE 802.1D recommended default path cost values based on link speed are used: IEEE 802.1D Link Speed Recommended Value 4 Mbps...
Page 182 spantree cist path-cost Distributed Spanning Tree Commands Aggregate Size Default Path Link Speed (number of links) Cost Value 1 Gbps 10 Gbps Examples -> spantree cist port 4/1 path-cost 19 -> spantree cist port 4/2-5 path-cost 19 -> spantree cist linkagg 16 path-cost 12000 ->...
Page 183: Spantree Msti Path-Cost
Distributed Spanning Tree Commands spantree msti path-cost spantree msti path-cost Configures the Spanning Tree path cost value for a port or a link aggregate of ports for the specified flat mode Multiple Spanning Tree Instance (MSTI). This value is the contribution of this port to the path cost towards the Spanning Tree root bridge that includes this port.
Page 184 spantree msti path-cost Distributed Spanning Tree Commands • If zero is entered for the path_cost value, then the following recommended default path cost values based on link speed are used: IEEE 802.1D Link Speed Recommended Value 10 MB 2,000,000 100 MB 200,000 1 GB 20,000...
Page 185 Distributed Spanning Tree Commands spantree msti path-cost Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree cist path-cost Configures the Spanning Tree path cost value for a port or a link aggre- gate of ports for the CIST instance.
Page 186: Spantree Vlan Path-Cost
spantree vlan path-cost Distributed Spanning Tree Commands spantree vlan path-cost Configures the Spanning Tree path cost value for a port or a link aggregate of ports for the specified VLAN instance. This value is the contribution of this port to the path cost towards the Spanning Tree root bridge that includes this port.
Page 187 Distributed Spanning Tree Commands spantree vlan path-cost IEEE 802.1D Link Speed Recommended Value 1 GB 20,000 10 Gbps 2,000 • Is a 16-bit path cost value is in use and the path_cost is set to zero, the following IEEE 802.1D recommended default path cost values based on link speed are used: IEEE 802.1D Link Speed...
Page 188 spantree vlan path-cost Distributed Spanning Tree Commands Aggregate Size Default Path Link Speed (number of links) Cost Value 10 Mbps 100 Mbps 1 Gbps 10 Gbps Examples -> spantree vlan 200 port 4/1 path-cost 4 -> spantree vlan 200 port 4/2-5 path-cost 4 ->...
Page 189: Spantree Cist Mode
Distributed Spanning Tree Commands spantree cist mode spantree cist mode Configures manual mode (forwarding or blocking) or dynamic mode to manage the state of a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST) instance. Dynamic mode defers the management of the port state to the Spanning Tree algorithm.
Page 190 spantree cist mode Distributed Spanning Tree Commands Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree vlan mode Configures the Spanning Tree mode for a port or a link aggregate of ports for the specified VLAN instance. MIB Objects vStpInsPortTable vStpInsPortNumber...
Page 191: Spantree Vlan Mode
Distributed Spanning Tree Commands spantree vlan mode spantree vlan mode Configures Manual mode (forwarding or blocking) or Dynamic mode to manage the state of a port or a link aggregate of ports for the specified VLAN instance. Dynamic mode defers the management of the port state to the Spanning Tree algorithm.
Page 192 spantree vlan mode Distributed Spanning Tree Commands Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree cist mode Configures the Spanning Tree mode for a port or a link aggregate of ports for the CIST instance.
Page 193: Spantree Cist Connection
Distributed Spanning Tree Commands spantree cist connection spantree cist connection Configures the connection type for a port or a link aggregate of ports for the flat mode Common and Inter- nal Spanning Tree (CIST). spantree cist {port slot/port [-port2] | linkagg linkagg_id [-linkagg_id2]} connection {noptp | ptp | autoptp} Syntax Definitions slot/port[-port2]...
Page 194 spantree cist connection Distributed Spanning Tree Commands Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree cist admin-edge Configures the administrative edge port status for a port or aggregate of ports for the CIST instance.
Page 195: Spantree Vlan Connection
Distributed Spanning Tree Commands spantree vlan connection spantree vlan connection Configures the connection type for a port or a link aggregate of ports for a VLAN instance. spantree vlan vlan_id {port slot/port [-port2] | linkagg linkagg_id [-linkagg_id2]} connection {noptp | ptp | autoptp} Syntax Definitions vlan_id...
Page 196 spantree vlan connection Distributed Spanning Tree Commands Examples -> spantree vlan 255 port 7/24 connection noptp -> spantree vlan 255 port 7/25-27 connection ptp -> spantree vlan 255 linkagg 3 connection autoptp -> spantree vlan 255 linkagg 3-7 connection autoptp Release History Release 7.1.1;...
Page 197: Spantree Cist Admin-Edge
Distributed Spanning Tree Commands spantree cist admin-edge spantree cist admin-edge Configures the administrative edge port status for a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST). spantree cist {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} admin-edge {enable | disable} Syntax Definitions slot/port[-port2] The slot number and port number of the physical port.
Page 198 spantree cist admin-edge Distributed Spanning Tree Commands Examples -> spantree cist linkagg 15 admin-edge enable -> spantree cist linkagg 4-10 admin-edge enable -> spantree cist port 8/25 admin-edge disable -> spantree cist port 2/2-5 admin-edge enable Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the...
Page 199: Spantree Vlan Admin-Edge
Distributed Spanning Tree Commands spantree vlan admin-edge spantree vlan admin-edge Configures the administrative edge port status for a port or a link aggregate of ports for a VLAN instance. spantree vlan vlan_id {port slot/port[-port2] | linkagg linkagg_id[-linkagg_id2]} admin-edge {enable | disable} Syntax Definitions vlan_id...
Page 200 spantree vlan admin-edge Distributed Spanning Tree Commands Examples -> spantree vlan 4 linkagg 15 admin-edge enable -> spantree vlan 5 linkagg 12-14 admin-edge enable -> spantree vlan 255 port 8/23 admin-edge disable -> spantree vlan 3 port 2/2-5 admin-edge enable Release History Release 7.1.1;...
Page 201: Spantree Cist Auto-Edge
Distributed Spanning Tree Commands spantree cist auto-edge spantree cist auto-edge Configures whether or not Spanning Tree automatically determines the operational edge port status of a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST). spantree cist {port slot/port[-port2] | linkagg linkagg_id [-linkagg_id2]} auto-edge {enable | disable} Syntax Definitions slot/port[-port2]...
Page 202 spantree cist auto-edge Distributed Spanning Tree Commands Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch spantree vlan auto-edge Configures whether or not Spanning Tree determines the operational edge port status for a port or aggregate of ports for the specified per- VLAN mode VLAN instance.
Page 203: Spantree Vlan Auto-Edge
Distributed Spanning Tree Commands spantree vlan auto-edge spantree vlan auto-edge Configures whether or not Spanning Tree determines the operational edge port status for a port or a link aggregate of ports for the specified per-VLAN mode VLAN instance. spantree vlan vlan_id {port slot/port[-port2] | linkagg linkagg_id [-linkagg_id2]} auto-edge {enable | disable} Syntax Definitions vlan_id...
Page 204 spantree vlan auto-edge Distributed Spanning Tree Commands Examples -> spantree vlan 255 port 8/23 auto-edge disable -> spantree vlan 4 port 2/2-10 auto-edge enable -> spantree vlan 100 linkagg 10 auto-edge disable -> spantree vlan 200 linkagg 1-5 auto-edge enable Release History Release 7.1.1;...
Page 205: Spantree Cist Restricted-Role
Distributed Spanning Tree Commands spantree cist restricted-role spantree cist restricted-role Configures the restricted role status for a port or a link aggregate of ports. Enabling this parameter blocks the port from becoming the Root Port, even if it is the most likely candidate for root. Once a root port is selected, the restricted port is selected as an Alternate Port.
Page 206 spantree cist restricted-role Distributed Spanning Tree Commands Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree vlan restricted-role Configures the restricted role status for a port or aggregate of ports for the per-VLAN mode VLAN instance. MIB Objects vStpInsPortTable vStpInsPortNumber...
Page 207: Spantree Vlan Restricted-Role
Distributed Spanning Tree Commands spantree vlan restricted-role spantree vlan restricted-role Configures the restricted role status for a port or a link aggregate of ports for the specified VLAN instance. Enabling this parameter blocks the port from becoming the Root Port, even if it is the most likely candidate for root.
Page 208 spantree vlan restricted-role Distributed Spanning Tree Commands Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree cist restricted-role Configures the restricted role status for a port or aggregate of ports for the flat mode CIST instance. MIB Objects vStpInsPortTable vStpInsPortNumber...
Page 209: Spantree Cist Restricted-Tcn
Distributed Spanning Tree Commands spantree cist restricted-tcn spantree cist restricted-tcn Configures the restricted TCN status for a port or a link aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST). When this parameter is enabled, the port does not propagate topology changes and notifications to/from other ports.
Page 210 spantree cist restricted-tcn Distributed Spanning Tree Commands Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree vlan restricted-tcn Configures the restricted TCN status for a port or aggregate of ports for the specified per-VLAN mode VLAN instance. MIB Objects vStpInsPortTable vStpInsPortNumber...
Page 211: Spantree Vlan Restricted-Tcn
Distributed Spanning Tree Commands spantree vlan restricted-tcn spantree vlan restricted-tcn Configures the restricted TCN status for a port or a link aggregate of ports for the specified VLAN instance. When this parameter is enabled, the port does not propagate topology changes and notifications to/from other ports.
Page 212 spantree vlan restricted-tcn Distributed Spanning Tree Commands Release History Release 7.1.1; command introduced. Related Commands spantree mode Selects the Spanning Tree operating mode (flat or per-VLAN) for the switch. spantree cist restricted-tcn Configures the restricted TCN status for a port or aggregate of ports for the flat mode Common and Internal Spanning Tree (CIST).
Page 213: Spantree Cist Txholdcount
Distributed Spanning Tree Commands spantree cist txholdcount spantree cist txholdcount This command is used to rate limit the transmission of BPDU through a given port for the flat mode Common and Internal Spanning Tree (CIST) instance. spantree cist txholdcount value Syntax Definitions value A numeric value that controls the transmission of BPDU through the...
Page 214: Spantree Vlan Txholdcount
spantree vlan txholdcount Distributed Spanning Tree Commands spantree vlan txholdcount This command is used to rate limit the transmission of BPDU through a given port for the VLAN instance. spantree vlan vlan_id txholdcount {value} Syntax Definitions vlan_id An existing VLAN ID number. value A numeric value that controls the transmission of BPDU through the port.
Page 215: Show Spantree
Distributed Spanning Tree Commands show spantree show spantree Displays Spanning Tree bridge information for the flat mode Common and Internal Spanning Tree (CIST) instance or the per-VLAN mode VLAN instances. show spantree Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 216 show spantree Distributed Spanning Tree Commands -> spantree mode flat -> spantree protocol mstp -> show spantree Spanning Tree Path Cost Mode : AUTO Msti STP Status Protocol Priority (Prio:SysID) -----+----------+--------+--------------------- MSTP 32768 (0x8000:0x0000) MSTP 32770 (0x8000:0x0002) MSTP 32771 (0x8000:0x0003) output definitions Spanning Tree Path Cost The Spanning Tree path cost mode for the switch (32 BIT or AUTO)
Page 217 Distributed Spanning Tree Commands show spantree output definitions (continued) Protocol The Spanning Tree protocol applied to this instance (STP or RSTP). Configured through the spantree protocol command. Priority The Spanning Tree bridge priority for the instance. The lower the number, the higher the priority. Configured through the spantree pri- ority command.
Page 218: Show Spantree Cist
show spantree cist Distributed Spanning Tree Commands show spantree cist Displays the Spanning Tree bridge configuration for the flat mode Common and Internal Spanning Tree (CIST) instance. show spantree cist Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guideline This command displays Spanning Tree bridge information for the flat mode CIST instance regardless of which mode (per-VLAN or flat) is active on the switch.
Page 219 Distributed Spanning Tree Commands show spantree cist System Hello Time BPDU Switching Enabled -> spantree mode per-vlan -> show spantree cist Per Vlan Spanning Tree is enforced !! (Per VLAN mode) INACTIVE Spanning Tree Parameters for Flat Mode Spanning Tree Status : Protocol IEEE Rapid STP, Priority...
Page 220 show spantree cist Distributed Spanning Tree Commands output definitions (continued) Topology Changes The number of topology changes detected by this Spanning Tree instance since the management entity was last reset or initialized. Topology age The amount of time (in hundredths of seconds) since the last topology change was detected by this Spanning Tree instance (hh:mm:ss or dd days and hh:mm:ss).
Page 221 Distributed Spanning Tree Commands show spantree cist MIB Objects vStpInsTable vStpInsNumber vStpInsMode vStpInsProtocolSpecification vStpInsPriority vStpInsBridgeAddress vStpInsTimeSinceTopologyChange vStpInsTopChanges vStpInsDesignatedRoot vStpInsRootCost vStpInsRootPortNumber vStpInsNextBestRootCost vStpInsNextBestRootPortNumber vStpInsMaxAge vStpInsHelloTime vStpInsBridgeTxHoldCount vStpInsForwardDelay vStpInsBridgeMaxAge vStpInsBridgeHelloTime vStpInsBridgeForwardDelay vStpInsCistRegionalRootId vStpInsCistPathCost OmniSwitch CLI Reference Guide March 2011 page 5-79...
Page 222: Show Spantree Msti
show spantree msti Distributed Spanning Tree Commands show spantree msti Displays Spanning Tree bridge information for a Multiple Spanning Tree Instance (MSTI). show spantree msti [msti_id] Syntax Definitions msti_id An existing MSTI ID number. Defaults By default, displays information for all MSTIs. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 223 Distributed Spanning Tree Commands show spantree msti Cost to CST Root Next CST Best Cost Designated Root 8000-00:d0:95:6b:08:40, Cost to Root Bridge Root Port Slot 9 Interface 2, Next Best Root Cost Next Best Root Port None, TxHoldCount Topology Changes Topology age 0:30:46 Current Parameters (seconds)
Page 224 show spantree msti Distributed Spanning Tree Commands -> show spantree msti 0 per-vlan Spanning Tree is enforced !! (per-vlan mode) INACTIVE Spanning Tree Parameters for Cist Spanning Tree Status : Protocol IEEE Multiple STP, Priority 32768 (0x8000), TxHoldCount System Max Age (seconds) System Forward Delay (seconds) = System Hello Time (seconds) ->...
Page 225 Distributed Spanning Tree Commands show spantree msti output definitions (continued) Next Best Root Cost The cost of the next best root port for this Spanning Tree instance. Next Best Root Port The port that offers the next best (second lowest) cost path to the root bridge for this Spanning Tree instance.
Page 226 show spantree msti Distributed Spanning Tree Commands MIB Objects vStpInsTable vStpInsNumber vStpInsMode vStpInsProtocolSpecification vStpInsPriority vStpInsBridgeAddress vStpInsTimeSinceTopologyChange vStpInsTopChanges vStpInsDesignatedRoot vStpInsRootCost vStpInsRootPortNumber vStpInsNextBestRootCost vStpInsNextBestRootPortNumber vStpInsMaxAge vStpInsHelloTime vStpInsBridgeTxHoldCount vStpInsForwardDelay vStpInsBridgeMaxAge vStpInsBridgeHelloTime vStpInsBridgeForwardDelay vStpInsCistRegionalRootId vStpInsCistPathCost vStpInsMstiNumber page 5-84 OmniSwitch CLI Reference Guide March 2011...
Page 227: Show Spantree Vlan
Distributed Spanning Tree Commands show spantree vlan show spantree vlan Displays Spanning Tree bridge information for a per-VLAN mode VLAN instance. show spantree vlan [vlan_id] Syntax Definitions vlan_id An existing VLAN ID number. Defaults By default, displays information for all VLAN instances. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 228 show spantree vlan Distributed Spanning Tree Commands Next Best Root Port Slot 1 Interface 1, Tx Hold Count Topology Changes Topology age 00:00:00, Current Parameters (seconds) Max Age Forward Delay Hello Time Parameters system uses when attempting to become root System Max Age System Forward Delay = System Hello Time...
Page 229 Distributed Spanning Tree Commands show spantree vlan output definitions (continued) Tx Hold Count The count to limit the transmission of BPDU through the port. Topology Changes The number of topology changes detected by this Spanning Tree instance since the management entity was last reset or initialized. Topology age The amount of time (in hundredths of seconds) since the last topology change was detected by this Spanning Tree instance (hh:mm:ss or dd...
Page 230 show spantree vlan Distributed Spanning Tree Commands vStpInsDesignatedRoot vStpInsRootCost vStpInsRootPortNumber vStpInsNextBestRootCost vStpInsNextBestRootPortNumber vStpInsMaxAge vStpInsHelloTime vStpInsBridgeTxHoldCount vStpInsForwardDelay vStpInsBridgeMaxAge vStpInsBridgeHelloTime vStpInsBridgeForwardDelay page 5-88 OmniSwitch CLI Reference Guide March 2011...
Page 231: Show Spantree Ports
Distributed Spanning Tree Commands show spantree ports show spantree ports Displays Spanning Tree port information. show spantree ports [forwarding | blocking | active | configured] Syntax Definitions forwarding Displays Spanning Tree operational port parameters for ports that are forwarding for the specified instance. blocking Displays Spanning Tree operational port parameters for ports that are blocked for the specified instance.
Page 232 show spantree ports Distributed Spanning Tree Commands 1/10 1/11 1/12 -> spantree protocol mstp -> show spantree ports Msti Port Oper Status Path Cost Role -----+-----+------------+---------+------- 1/10 1/11 1/12 -> spantree mode per-vlan -> show spantree ports Vlan Port Oper Status Path Cost Role Notes...
Page 233 Distributed Spanning Tree Commands show spantree ports output definitions (continued) Path Cost The contribution of this port to the path cost towards the Spanning Tree root bridge that includes this port. Path cost is a measure of the distance of the listed port from the root bridge in the number of hops. Config- ured through the spantree msti path-cost spantree vlan...
Page 234: Show Spantree Cist Ports
show spantree cist ports Distributed Spanning Tree Commands show spantree cist ports Displays Spanning Tree port information for the flat mode Common and Internal Spanning Tree (CIST) instance. show spantree cist ports [forwarding | blocking | active | configured] Syntax Definitions forwarding Displays Spanning Tree operational port parameters for ports that are forwarding for the CIST instance.
Page 235 Distributed Spanning Tree Commands show spantree cist ports -> show spantree cist ports active Spanning Tree Port Summary for Cist Oper Path Desig Prim. Op Port Cost Cost Role Port Cnx Edg Desig Bridge ID Note -----+----+-------+-------+----+----+----+----+----------------------+--------- FORW 200000 52 ROOT 8000-00:30:f1:5b:37:73 ->...
Page 236 show spantree cist ports Distributed Spanning Tree Commands -> show spantree cist ports configured Spanning Tree Port Admin Configuration for Vlan 1 Port Adm Man. Config Rstr Rstr Role/ PVST+ Port St. Mode Cost Root Guard Cfg Stat -----+----+----+----+-------+----+----+----+----+-----------+----------- output definitions Port The slot number for the module and the physical port number or a logical port.
Page 237 Distributed Spanning Tree Commands show spantree cist ports Related Commands show spantree ports Implicit command for displaying Spanning Tree port information for the flat mode CIST instance or a per-VLAN mode VLAN instance. show spantree msti ports Displays Spanning Tree port information for an MSTI when the switch is operating in the per-VLAN or flat Spanning Tree mode.
Page 238: Show Spantree Msti Ports
show spantree msti ports Distributed Spanning Tree Commands show spantree msti ports Displays Spanning Tree port information for a flat mode Multiple Spanning Tree Instance (MSTI). show spantree msti [msti_id] ports [forwarding | blocking | active | configured] Syntax Definitions msti_id An existing MSTI ID number.
Page 239 Distributed Spanning Tree Commands show spantree msti ports Examples -> show spantree msti ports Msti Port Oper Status Path Cost Role -----+-----+------------+---------+----- FORW 200000 ROOT 1/10 1/11 1/12 1/13 1/14 1/15 1/16 1/17 1/18 1/19 1/20 1/21 1/22 1/23 1/24 FORW 200000 MSTR...
Page 240 show spantree msti ports Distributed Spanning Tree Commands -> show spantree msti 0 ports Per Vlan Spanning Tree is enforced !! (Per VLAN mode) INACTIVE Spanning Tree Parameters Oper Path Desig Prim. Op Port Cost Cost Role Port Cnx Edg Desig Bridge ID Note -----+----+-------+-------+----+-----+---+---+----------------------+---------...
Page 241 Distributed Spanning Tree Commands show spantree msti ports output definitions (continued) Op Edg Operational connection type: EDG. Shows the current operational state of the port connection type. See the spantree vlan connection command for more information. Desig Bridge ID The bridge identifier for the designated bridge for this port segment. PVST+ Cfg Indicates the current PVST+ port configuration (auto, enable or disable).
Page 242 show spantree msti ports Distributed Spanning Tree Commands output definitions (continued) Aut Edg The edge port automatic status: yes indicates that the port is an auto- matic edge port; no indicates that the port is not an automatic edge port. Configured through the spantree cist auto-edge spantree vlan...
Page 243 Distributed Spanning Tree Commands show spantree msti ports MIB Objects vStpInsPortTable vStpInsPortNumber vStpInsPortPriority vStpInsPortState vStpInsPortEnable vStpInsPortPathCost vStpInsPortDesignatedCost vStpInsPortDesignatedBridge vStpInsPortAdminEdge vStpInsPortAutoEdge vStpInsPortRestrictedRole vStpInsPortRestrictedTcn vStpInsPortManualMode vStpInsPortRole vStpPortConfigPVST vStpPortConfigStatePVST vStpBridgeModePVST vStpInsPrimaryPortNumber vStpInsPortAdminConnectionType vStpInsPortOperConnectionType OmniSwitch CLI Reference Guide March 2011 page 5-101...
Page 244: Show Spantree Vlan Ports
show spantree vlan ports Distributed Spanning Tree Commands show spantree vlan ports Displays Spanning Tree port information for a VLAN instance. show spantree vlan [vlan_id[-vlan_id2]] ports [forwarding | blocking | active | configured] Syntax Definitions vlan_id[-vlan_id2] An existing VLAN ID number. Use a hyphen to specify a range of VLAN IDs (10-15) forwarding Displays Spanning Tree operational port parameters for ports that are...
Page 245 Distributed Spanning Tree Commands show spantree vlan ports Examples -> show spantree vlan ports Vlan Port Oper Status Path Cost Role Note -----+-----+------------+---------+-------+--------- 1/10 1/11 1/12 FORW -> show spantree vlan 1 ports Spanning Tree Port Summary for Vlan 1 Oper Path Desig...
Page 246 show spantree vlan ports Distributed Spanning Tree Commands Spanning Tree Port Summary for Vlan 12 Oper Path Desig Prim. Op Port Cost Cost Role Port Cnx Edg Desig Bridge ID Note -----+----+-------+-------+----+-----+---+---+----------------------+--------- 1/42 DIS 1/42 EDG 0000-00:00:00:00:00:00 1/43 DIS 1/43 NO 0000-00:00:00:00:00:00 Spanning Tree Port Summary for Vlan 13 Oper...
Page 247 Distributed Spanning Tree Commands show spantree vlan ports -> show spantree vlan 1 ports configured Spanning Tree Port Admin Configuration for Vlan 1 Port Adm Man. Config Rstr Rstr Role/ PVST+ Port St. Mode Cost Root Guard Cfg Stat -----+----+----+----+-------+----+----+-----+----+---------+---------- AUT OFF AUT OFF AUT OFF...
Page 248 show spantree vlan ports Distributed Spanning Tree Commands output definitions (continued) Man. Mode The manual mode setting for the port: yes indicates that the blocking or forwarding state of the port was manually set and the port does not par- ticipate in the Spanning Tree Algorithm;...
Page 249 Distributed Spanning Tree Commands show spantree vlan ports Related Commands show spantree ports Displays Spanning Tree port information for the flat mode CIST instance or a per-VLAN mode VLAN instance. show spantree cist ports Displays Spanning Tree port information for a CIST instance when the switch is operating in the per-VLAN or flat Spanning Tree mode.
Page 250: Show Spantree Mode
show spantree mode Distributed Spanning Tree Commands show spantree mode Displays the current global Spanning Tree mode parameter values for the switch. show spantree mode Syntax Definition Defaults Platforms Supported OmniSwitch 10K Usage Guidelines The global parameters for spanning tree can be activated or configured using the related commands. Examples ->...
Page 251 Distributed Spanning Tree Commands show spantree mode Related Commands spantree mode Assigns a flat Spanning Tree or per-VLAN Spanning Tree operating mode for the switch. spantree protocol Configures the Spanning Tree protocol for the flat mode Common and Internal Spanning Tree (CIST) instance or for an individual VLAN instance if the switch is running in the per-VLAN mode.
Page 252: Show Spantree Mst
show spantree mst Distributed Spanning Tree Commands show spantree mst Displays the Multiple Spanning Tree (MST) information for a MST region or the specified port or link aggregate on the switch. show spantree mst {region | port slot/port | linkagg linkagg_id} Syntax Definitions slot/port Specifies the slot number for the module and the physical port number...
Page 253 Distributed Spanning Tree Commands show spantree mst -> show spantree mst linkagg 4 Role State Pth Cst Edge Boundary Op Cnx Vlans ---+------+-----+--------+----+--------+------+--------------- DESG FORW 6000 DESG FORW DESG FORW output definitions Configuration Name An alphanumeric string that identifies the name of the MST region. Use spantree mst region name command to define this value.
Page 254: Show Spantree Msti Vlan-Map
show spantree msti vlan-map Distributed Spanning Tree Commands show spantree msti vlan-map Displays the range of VLANs associated with the specified Multiple Spanning Tree Instance (MSTI). show spantree msti [msti_id] vlan-map Syntax Definitions msti_id An existing MSTI ID number. Defaults By default, the VLAN to MSTI mapping is displayed for all MSTIs.
Page 255 Distributed Spanning Tree Commands show spantree msti vlan-map output definitions (continued) Name An alphanumeric value that identifies an MSTI name. Use the spantree msti command to define an MSTI name. VLAN list The range of VLAN IDs that are associated with this MSTI. Release History Release 7.1.1;...
Page 256: Show Spantree Cist Vlan-Map
show spantree cist vlan-map Distributed Spanning Tree Commands show spantree cist vlan-map Displays the range of VLANs associated with the flat mode Common and Internal Spanning Tree (CIST) instance. show spantree cist vlan-map Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines This command is available when the switch is operating in either the per-VLAN or flat Spanning Tree mode.
Page 257 Distributed Spanning Tree Commands show spantree cist vlan-map MIB Objects vStpMstInstanceTable vStpMstInstanceNumber vStpMstInstanceName vStpMstInstanceVlanBitmapState OmniSwitch CLI Reference Guide March 2011 page 5-115...
Page 258: Show Spantree Map-Msti
show spantree map-msti Distributed Spanning Tree Commands show spantree map-msti Displays the Multiple Spanning Tree Instance (MSTI) that is associated to the specified VLAN. show spantree [vlan vlan_id] map-msti Syntax Definitions vlan_id An existing VLAN ID number. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 259: Chapter 6 Link Aggregation Commands
The dynamic aggregation software is compatible only with the following IEEE standard: 802.3ad — Aggregation of Multiple Link Segments MIB information for the link aggregation commands is as follows: Filename: AlcatelIND1LAG.MIB Module: ALCATEL-IND1-LAG-MIB OmniSwitch CLI Reference Guide March 2011 page 6-1...
Page 260 Link Aggregation Commands A summary of available commands is listed here: Static link aggregates linkagg static agg size linkagg static agg name linkagg static agg admin-state linkagg static port agg Dynamic link aggregates linkagg lacp agg size linkagg lacp agg name linkagg lacp agg admin-state linkagg lacp agg actor admin-key linkagg lacp agg actor system-priority...
Page 261: Linkagg Static Agg Size
Link Aggregation Commands linkagg static agg size linkagg static agg size Creates a static aggregate group between two switches. A static aggregate group contains static links. linkagg static agg agg_num1 [-agg_num2] size size [name name] [admin-state {enable | disable}] [multi-chassis active] no linkagg static agg agg_num1 [-agg_num2] Syntax Definitions agg_num1...
Page 262 linkagg static agg size Link Aggregation Commands Examples -> linkagg static agg 3-10 size 8 -> linkagg static agg 4 size 2 admin-state disable -> linkagg static agg 4 size 2 multichassis-active -> no linkagg static agg 3-10 Release History Release 7.1.1;...
Page 263: Linkagg Static Agg Name
Link Aggregation Commands linkagg static agg name linkagg static agg name Configures a name for an existing static aggregate group. linkagg static agg agg_num1 [-agg_num2] name name no linkagg static agg agg_num1 [-agg_num2] name Syntax Definitions agg_num1 The number corresponding to the static aggregate group. -agg_num2 The last link aggregate ID in a range of link aggregate IDs.
Page 264 linkagg static agg name Link Aggregation Commands Related Commands linkagg static agg size Creates a static aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggName page 6-6 OmniSwitch CLI Reference Guide March 2011...
Page 265: Linkagg Static Agg Admin-State
Link Aggregation Commands linkagg static agg admin-state linkagg static agg admin-state Enables or disables the administrative state of a static link aggregation group. linkagg static agg agg_num1[-agg_num2] admin-state {enable | disable} Syntax Definitions agg_num1 The number corresponding to the static aggregate group. -agg_num2 The last link aggregate ID in a range of link aggregate IDs.
Page 266: Linkagg Static Port Agg
linkagg static port agg Link Aggregation Commands linkagg static port agg Configures a slot and port for a static aggregate group. linkagg static port slot/port[-port2] agg agg_num no linkagg static port slot/port[-port2] Syntax Definitions slot The slot number for this aggregate. port The port that the switch initially uses as the Spanning Tree virtual port for this aggregate.
Page 267 Link Aggregation Commands linkagg static port agg Related Commands linkagg static agg size Creates a static aggregate group. show linkagg port Displays information about link aggregation ports. MIB Objects alclnkaggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortLacpType alclnkaggAggPortSelectedAggNumber OmniSwitch CLI Reference Guide March 2011 page 6-9...
Page 268: Linkagg Lacp Agg Size
linkagg lacp agg size Link Aggregation Commands linkagg lacp agg size Creates a dynamic aggregate group that uses the Link Aggregation Control Protocol (LACP) to establish and maintain link aggregation. The size parameter is required to create the link aggregate group. linkagg lacp agg agg_num1 [-agg_num2] size size [name name] [admin-state {enable | disable}]...
Page 269 Link Aggregation Commands linkagg lacp agg size Defaults parameter default enable | disable enable Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of this command to remove a dynamic aggregate group from the configuration. • You must disable the group with the linkagg lacp agg admin-state command before you can delete a dynamic link aggregate group.
Page 270 linkagg lacp agg size Link Aggregation Commands alclnkaggAggPartnerAdminKey page 6-12 OmniSwitch CLI Reference Guide March 2011...
Page 271: Linkagg Lacp Agg Name
Link Aggregation Commands linkagg lacp agg name linkagg lacp agg name Configures a name for a dynamic aggregate group. linkagg lacp agg agg_num name name no linkagg lacp agg agg_num1 [-agg_num2] name Syntax Definitions agg_num The number corresponding to the dynamic aggregate group. -agg_num2 The last link aggregate ID in a range of link aggregate IDs.
Page 272 linkagg lacp agg name Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggName page 6-14 OmniSwitch CLI Reference Guide March 2011...
Page 273: Linkagg Lacp Agg Admin-State
Link Aggregation Commands linkagg lacp agg admin-state linkagg lacp agg admin-state Configures the administrative state of a dynamic aggregate group or a range of dynamic aggregate groups. linkagg lacp agg agg_num1 [-agg_num2] admin-state {enable | disable} Syntax Definitions agg_num1 The number corresponding to the dynamic aggregate group. -agg_num2 The last link aggregate ID in a range of link aggregate IDs.
Page 274 linkagg lacp agg admin-state Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregates.
Page 275: Linkagg Lacp Agg Actor Admin-Key
Link Aggregation Commands linkagg lacp agg actor admin-key linkagg lacp agg actor admin-key Configures the administrative key associated with a dynamic aggregate group. linkagg lacp agg agg_num1 [-agg_num2] actor admin-key actor_admin_key no linkagg lacp agg agg_num1 [-agg_num2] actor admin-key Syntax Definitions agg_num1 The number corresponding to the dynamic aggregate group.
Page 276: Linkagg Lacp Agg Actor System-Priority
linkagg lacp agg actor system-priority Link Aggregation Commands linkagg lacp agg actor system-priority Configures the priority of the dynamic aggregate group. linkagg lacp agg agg_num1 [-agg_num2] actor system-priority actor_system_priority no linkagg lacp agg agg_num1 [-agg_num2] actor system-priority Syntax Definitions agg_num1 The number corresponding to the link aggregate group.
Page 277 Link Aggregation Commands linkagg lacp agg actor system-priority Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggActorSystemPriority OmniSwitch CLI Reference Guide March 2011 page 6-19...
Page 278: Linkagg Lacp Agg Actor System-Id
linkagg lacp agg actor system-id Link Aggregation Commands linkagg lacp agg actor system-id Configures the MAC address of a dynamic aggregate group on the switch. linkagg lacp agg agg_num1 [-agg_num2] actor system-id actor_system_id no linkagg lacp agg agg_num1 [-agg_num2] actor system-id Syntax Definitions agg_num1 The number corresponding to the dynamic aggregate group.
Page 279 Link Aggregation Commands linkagg lacp agg actor system-id Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggActorSystemID OmniSwitch CLI Reference Guide March 2011 page 6-21...
Page 280: Linkagg Lacp Agg Partner System-Id
linkagg lacp agg partner system-id Link Aggregation Commands linkagg lacp agg partner system-id Configures the MAC address of the dynamic aggregate group of the remote system that is attached to the dynamic aggregate group of the local switch. linkagg lacp agg agg_num1 [-agg_num2] partner system-id partner_system_id no linkagg lacp agg agg_num1 [-agg_num2] partner system-id Syntax Definitions agg_num1...
Page 281 Link Aggregation Commands linkagg lacp agg partner system-id Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggPartnerSystemID OmniSwitch CLI Reference Guide March 2011 page 6-23...
Page 282: Linkagg Lacp Agg Partner System-Priority
linkagg lacp agg partner system-priority Link Aggregation Commands linkagg lacp agg partner system-priority Configures the priority of the dynamic aggregate group of the remote system which is attached to the dynamic aggregate group of the local switch. linkagg lacp agg agg_num1 [-agg_num2] partner system-priority partner_system_priority no linkagg lacp agg agg_num1 [-agg_num2] partner system-priority Syntax Definitions agg_num1...
Page 283 Link Aggregation Commands linkagg lacp agg partner system-priority Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggPartnerSystemPriority OmniSwitch CLI Reference Guide March 2011 page 6-25...
Page 284: Linkagg Lacp Agg Partner Admin-Key
linkagg lacp agg partner admin-key Link Aggregation Commands linkagg lacp agg partner admin-key Configures the administrative key for the remote partner of the dynamic aggregation group. linkagg lacp agg agg_num1[-agg_num2] partner admin-key partner_admin_key no linkagg lacp agg agg_num1[-agg_num2] partner admin-key Syntax Definitions agg_num1 The number corresponding to the dynamic aggregate group.
Page 285 Link Aggregation Commands linkagg lacp agg partner admin-key Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups. MIB Objects alclnkaggAggTable alclnkaggAggNumber alclnkaggAggPartnerAdminKey OmniSwitch CLI Reference Guide March 2011 page 6-27...
Page 286: Linkagg Lacp Port Actor Admin-Key
linkagg lacp port actor admin-key Link Aggregation Commands linkagg lacp port actor admin-key Configures an actor administrative key for a port, which allows the port to join a dynamic aggregate group. linkagg lacp port slot/port[-port2] actor admin-key actor_admin_key [actor admin-state {[active] [timeout] [aggregate] [synchronize] [collect] [distribute] [default] [expire] | none}] [actor system id actor_system_id] [actor system priority actor_system_priority]...
Page 287 Link Aggregation Commands linkagg lacp port actor admin-key partner_admin_system_priority The priority of the remote system to which the dynamic aggregation group is attached. partner admin-state See the linkagg lacp agg partner admin-state command. actor_port_priority The priority of the actor port. partner_admin_port The administrative state of the partner port.
Page 288 linkagg lacp port actor admin-key Link Aggregation Commands alclnkaggAggPortActorSystemPriority alclnkaggAggPortPartnerAdminSystemID alclnkaggAggPortPartnerAdminKey alclnkaggAggPortPartnerAdminSystemPriority alclnkaggAggPortPartnerAdminState alclnkaggAggPortActorPortPriority alclnkaggAggPortPartnerAdminPort alclnkaggAggPortPartnerAdminPortPriority page 6-30 OmniSwitch CLI Reference Guide March 2011...
Page 289: Linkagg Lacp Port Actor Admin-State
Link Aggregation Commands linkagg lacp port actor admin-state linkagg lacp port actor admin-state Configures the system administrative state of the slot and port for the dynamic aggregate group on the local switch. The state values correspond to bits in the actor state octet in the LACPDU frame. linkagg lacp port slot/port[-port2] actor admin-state {[active] [timeout] [aggregate] [synchronize] [collect] [distribute] [default] [expire] | none} no linkagg lacp port slot/port[-port2] actor admin-state {[active] [timeout] [aggregate] [synchronize]...
Page 290 linkagg lacp port actor admin-state Link Aggregation Commands expire Specifying that this keyword has no effect because the system always determines its value. When this bit (bit 7) is set by the system, the actor cannot receive LACPDU frames. none Resets all administrative states to their default configurations.
Page 291: Linkagg Lacp Port Actor System-Id
Link Aggregation Commands linkagg lacp port actor system-id linkagg lacp port actor system-id Configures the system ID (i.e., MAC address) for the local port associated with a dynamic aggregate group. linkagg lacp port slot/port[-port2] actor system-id actor_system_id no linkagg lacp port slot/port[-port2] actor system-id Syntax Definitions slot The slot number for this aggregate.
Page 292 linkagg lacp port actor system-id Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects alclnkaggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortActorSystemID page 6-34 OmniSwitch CLI Reference Guide...
Page 293: Linkagg Lacp Port Actor System-Priority
Link Aggregation Commands linkagg lacp port actor system-priority linkagg lacp port actor system-priority Configures the system priority of the port on the switch that belongs to the dynamic aggregate group. linkagg lacp port slot/port[-port2] actor system-priority actor_system_priority no linkagg lacp port slot/port[-port2] actor system-priority Syntax Definitions slot The slot number for this aggregate.
Page 294 linkagg lacp port actor system-priority Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregates. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortActorSystemPriority page 6-36 OmniSwitch CLI Reference Guide March 2011...
Page 295: Linkagg Lacp Agg Partner Admin-State
Link Aggregation Commands linkagg lacp agg partner admin-state linkagg lacp agg partner admin-state Configures the system administrative state of the slot and port for the dynamic aggregate group on the remote switch. The state values correspond to bits in the actor state octet in the LACPDU frame. linkagg lacp port slot/port[-port2] partner admin-state {[active] [timeout] [aggregate] [synchronize] [collect] [distribute] [default] [expire] | none} no linkagg lacp port slot/port[-port2] partner admin-state...
Page 296 linkagg lacp agg partner admin-state Link Aggregation Commands expire Specifying that this keyword has no effect because the system always determines its value. When this bit (bit 7) is set by the system, the partner cannot receive LACPDU frames. none Resets all administrative states to their default configurations.
Page 297: Linkagg Lacp Port Partner Admin System-Id
Link Aggregation Commands linkagg lacp port partner admin system-id linkagg lacp port partner admin system-id Configures the partner administrative system ID for a dynamic aggregate group port. linkagg lacp port slot/port[-port2] partner admin system-id partner_admin_system_id no linkagg lacp port slot/port[-port2] partner admin system-id Syntax Definitions slot The slot number for this aggregate.
Page 298 linkagg lacp port partner admin system-id Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortPartnerAdminSystemID page 6-40...
Page 299: Linkagg Lacp Port Partner Admin-Key
Link Aggregation Commands linkagg lacp port partner admin-key linkagg lacp port partner admin-key Configures the partner administrative key for a dynamic aggregate group port. linkagg lacp port slot/port[-port2] partner admin-key partner_admin_key no linkagg lacp port slot/port[-port2] partner admin-key Syntax Definitions slot The slot number for this aggregate.
Page 300 linkagg lacp port partner admin-key Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortPartnerAdminKey page 6-42 OmniSwitch CLI Reference Guide...
Page 301: Linkagg Lacp Port Partner Admin System-Priority
Link Aggregation Commands linkagg lacp port partner admin system-priority linkagg lacp port partner admin system-priority Configures the partner system priority for a dynamic aggregate group port. linkagg lacp port slot/port[-port2] partner admin system-priority partner_admin_system_priority no linkagg lacp port slot/port[-port2] partner admin system-priority Syntax Definitions slot The slot number for this aggregate.
Page 302 linkagg lacp port partner admin system-priority Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortAdminSystemPriority page 6-44...
Page 303: Linkagg Lacp Port Actor Port Priority
Link Aggregation Commands linkagg lacp port actor port priority linkagg lacp port actor port priority Configures the priority for an actor port. linkagg lacp port slot/port[-port2] actor port-priority actor_port_priority no linkagg lacp port slot/port[-port2] actor port-priority Syntax Definitions slot The slot number for this aggregate. port The port that the switch initially uses as the Spanning Tree virtual port for this aggregate.
Page 304 linkagg lacp port actor port priority Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortActorPortPriority page 6-46...
Page 305: Linkagg Lacp Port Partner Admin-Port
Link Aggregation Commands linkagg lacp port partner admin-port linkagg lacp port partner admin-port Configures the administrative status of a partner port. linkagg lacp port slot/port[-port2] partner admin-port partner_admin_port no linkagg lacp port slot/port[-port2] partner admin-port Syntax Definitions slot The slot number for this aggregate. port The port that the switch initially uses as the Spanning Tree virtual port for this aggregate.
Page 306 linkagg lacp port partner admin-port Link Aggregation Commands Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber alclnkaggAggPortPartnerAdminPort page 6-48 OmniSwitch CLI Reference Guide...
Page 307: Linkagg Lacp Port Partner Admin Port-Priority
Link Aggregation Commands linkagg lacp port partner admin port-priority linkagg lacp port partner admin port-priority Configures the priority for a partner port. linkagg lacp port slot/port[-port2] partner admin port-priority partner_admin_port_priority no linkagg lacp port slot/port[-port2] partner admin port-priority Syntax Definitions slot The slot number for this aggregate.
Page 308 linkagg lacp port partner admin port-priority Link Aggregation Commands Release History Release 7.1.1; command introduced. Related Commands linkagg lacp agg size Creates a dynamic aggregate group. show linkagg port Displays information about ports associated with a particular aggregate group or all aggregate groups. MIB Objects AlcLnkAggAggPortTable alclnkaggAggPortGlobalPortNumber...
Page 309: Linkagg Range
Link Aggregation Commands linkagg range linkagg range Modifies the range of standard and MC-LAG link aggregation identifiers. linkagg range local {agg_num-agg_num | none} peer {agg_num-agg_num | none} multi-chassis {agg_num-agg_num | none} Syntax Definitions agg_num The first or last identifier in the range. local The range of standard local aggregate identifiers.
Page 310 linkagg range Link Aggregation Commands Related Commands show linkagg range Displays the link aggregate ranges. MIB Objects alclnkaggAggConfig alclnkAggLocalRangeOperMin alclnkAggLocalRangeOperMax alclnkAggLocalRangeConfiguredMin alclnkAggLocalRangeConfiguredMax alclnkAggPeerRangeOperMin alclnkAggPeerRangeOperMax alclnkAggPeerRangeConfiguredMin alclnkAggPeerRangeConfiguredMax alclnkAggMcLagRangeOperMin alclnkAggMcLagRangeOperMax alclnkAggMcLagRangeConfiguredMin alclnkAggMcLagRangeConfiguredMax page 6-52 OmniSwitch CLI Reference Guide March 2011...
Page 311: Show Linkagg
Link Aggregation Commands show linkagg show linkagg Displays information about static and dynamic (LACP) aggregate groups. show linkagg {agg [agg_num1 [-agg_num2]} Syntax Definitions agg_num1 Specifies the aggregate group. Configured through the linkagg static agg size or linkagg lacp agg size command. -agg_num2 The last link aggregate ID in a range of link aggregate IDs.
Page 312 show linkagg Link Aggregation Commands output definitions (continued) Admin State The current administrative state of the aggregate group, which can be ENABLED or DISABLED. You can modify this parameter with the linkagg static agg admin-state command (see page 6-7) for static aggregate groups and with the linkagg lacp agg admin-state command...
Page 313 Link Aggregation Commands show linkagg output definitions (continued) Number of Attached Ports The number of ports actually attached to this static aggregate group. Primary Port The port number of the first port to join this static aggregate group. If the first port to join the aggregate is no longer part of the aggregate group, the switch automatically assigns another port in the aggregate group to be the primary port.
Page 314 show linkagg Link Aggregation Commands output definitions (continued) Primary Port The port number of the first port to join this dynamic aggregate group. If the first port to join the aggregate group is no longer part of the aggregate group, the switch automatically assigns another port in the aggregate group to be the primary port.
Page 315 Link Aggregation Commands show linkagg MIB Objects alclnkaggAggTable alclnkAggSize alclnkaggAggNumber alclnkaggAggDescr alclnkaggAggName alclnkaggAggLacpType alclnkaggAggAdminState alclnkaggAggOperState alclnkaggAggNbrSelectedPorts alclnkaggAggNbrAttachedPorts alclnkaggPrimaryPortIndex alclnkaggAggMACAddress alclnkaggAggActorSystemPriority alclnkaggAggActorSystemID alclnkaggAggPartnerAdminKey alclnkaggAggActorAdminKey alclnkaggAggActorOperKey alclnkAggLocalRangeOperMin alclnkAggLocalRangeOperMax alclnkAggLocalRangeConfiguredMin alclnkAggLocalRangeConfiguredMax alclnkAggPeerRangeOperMin alclnkAggPeerRangeOperMax alclnkaggAggPartnerSystemID alclnkaggAggPartnerSystemPriority alclnkaggAggPartnerOperKey OmniSwitch CLI Reference Guide March 2011 page 6-57...
Page 316: Show Linkagg Port
show linkagg port Link Aggregation Commands show linkagg port Displays information about link aggregation ports. show linkagg {agg agg_num1 [-agg_num2]} port [slot/port] Syntax Definitions agg_num1 The number corresponding to the link aggregate group. -agg_num2 The last link aggregate ID in a range of link aggregate IDs. slot The slot number for this aggregate.
Page 317 Link Aggregation Commands show linkagg port -> show linkagg agg 1-5 port Slot/Port Aggregate SNMP Id Status Agg Oper Link Prim ---------+-----------+--------+--------------+------+----+----+----+----- 1/16 Static 2016 CONFIGURED 1/17 Static 2017 CONFIGURED Static 3001 CONFIGURED Static 3045 CONFIGURED Static 3069 CONFIGURED Output fields are defined here: output definitions Slot/Port The slot/port associated with the aggregate group.
Page 318 show linkagg port Link Aggregation Commands output definitions (continued) Link State The current operational state of the link from this port to its remote partner, which can be UP or DOWN. Selected Agg Number The number associated with the static aggregate group to which the port is attached.
Page 319 Link Aggregation Commands show linkagg port Partner Admin Port : 0, Partner Oper Port : 0, Partner Admin Port Priority : 0, Partner Oper Port Priority : 0, Actor Admin State : act1.tim1.agg1.syn0.col0.dis0.def1.exp0 Actor Oper State : act1.tim1.agg1.syn0.col0.dis0.def1.exp0, Partner Admin State : act0.tim0.agg1.syn1.col1.dis1.def1.exp0, Partner Oper State : act0.tim0.agg1.syn0.col1.dis1.def1.exp0...
Page 320 show linkagg port Link Aggregation Commands output definitions (continued) Partner Oper System Id The MAC address that corresponds to the system ID of the remote partner. Partner Admin Key The administrative value of the key for the remote partner. This value is used along with Partner Admin System Priority, Partner Admin System, Partner Admin Port, and Partner Admin Port Priority to manually con- figure aggregation.
Page 321 Link Aggregation Commands show linkagg port Related Commands linkagg static port agg Configures a slot and port for a static aggregate group. linkagg lacp port actor admin- Configures a slot and port for a dynamic aggregate group. show linkagg Displays information about static and dynamic (LACP) aggregate groups.
Page 322: Show Linkagg Range
show linkagg range Link Aggregation Commands show linkagg range Displays information about the configured or operational link aggregate range identifiers for standard and MC-LAG link aggregates. show linkagg range [operation | config] Syntax Definitions operation Displays the operational ranges. config Displays the configured ranges.
Page 323 Link Aggregation Commands show linkagg range Related Commands linkagg range Configures the standard and MC-LAG aggregate identifier ranges. MIB Objects alclnkaggAggConfig alclnkAggLocalRangeOperMin alclnkAggLocalRangeOperMax alclnkAggLocalRangeConfiguredMin alclnkAggLocalRangeConfiguredMax alclnkAggPeerRangeOperMin alclnkAggPeerRangeOperMax alclnkAggPeerRangeConfiguredMin alclnkAggPeerRangeConfiguredMax alclnkAggMcLagRangeOperMin alclnkAggMcLagRangeOperMax alclnkAggMcLagRangeConfiguredMin alclnkAggMcLagRangeConfiguredMax OmniSwitch CLI Reference Guide March 2011 page 6-65...
Page 324 show linkagg range Link Aggregation Commands page 6-66 OmniSwitch CLI Reference Guide March 2011...
Page 325: Multi-Chassis Commands
The overall system provides fast fail-over with a bound convergence time for all cases when edge uplinks fail. MIB information for the Multi-Chassis commands is as follows: Filename: ALCATEL-IND1-MULTI-CHASSIS-MIB.mib Module: alcatelIND1MultiChassisMIB A summary of available commands is listed here:...
Page 326: Multi-Chassis Chassis-Id
multi-chassis chassis-id Multi-Chassis Commands multi-chassis chassis-id Assigns a globally unique chassis identifier to the switch and enables the switch to operate in multi- chassis mode. multi-chassis chassis-id chassis_id no multi-chassis chassis-id chassis_id Syntax Definitions chassis_id Chassis identifier within the multi-chassis operational range [1 - 2]. The chassis identifier must be globally unique within the set of switches configured to operate together providing multi-chassis services.
Page 327 Multi-Chassis Commands multi-chassis chassis-id Related Commands show multi-chassis status Displays the configured and operational parameters related to the multi- chassis feature on the switch. show multi-chassis consistency Displays the system level mandatory consistency parameters of both the local and peer switches. MIB Objects multiChassisConfig multiChassisConfigChassisId...
Page 328: Multi-Chassis Chassis-Id Hello-Interval Ipc-Vlan
multi-chassis chassis-id hello-interval ipc-vlan Multi-Chassis Commands multi-chassis chassis-id hello-interval ipc-vlan Configures the multi-chassis feature parameters on the switch. A chassis identifier within the range [1 - 2] must be configured in order for the multi-chassis feature to become operational. Optionally, the multi- chassis control VLAN and hello interval may be configured.
Page 329 Multi-Chassis Commands multi-chassis chassis-id hello-interval ipc-vlan Examples -> multi-chassis chassis-id 1 hello-interval 5 ipc-vlan 4000 -> multi-chassis chassis-id 2 ipc-vlan 1000 hello-interval 10 Release History Release 7.1.1; command introduced. Related Commands multi-chassis chassis-id Assigns a globally unique chassis identifier to the switch and enables or disables the switch to operate in multi-chassis mode.
Page 330: Multi-Chassis Hello-Interval
multi-chassis hello-interval Multi-Chassis Commands multi-chassis hello-interval Configures the multi-chassis hello interval parameter on the switch. The hello interval must be configured with the same values on the switches that will operate in multi-chassis mode. multi-chassis hello-interval interval Syntax Definitions interval Time interval, in seconds, at which multi-chassis control hello messages are to be sent to the peer switch within the range [1 - 10].
Page 331 Multi-Chassis Commands multi-chassis hello-interval Related Commands multi-chassis chassis-id Assigns a globally unique chassis identifier to the switch and enables or disables the switch to operate in multi-chassis mode. multi-chassis ipc-vlan Configures the IPC-VLAN parameter, which is used for multi-chassis control communication, on the local switch. show multi-chassis status Displays the configured and operational parameters related to the multi- chassis feature on the switch.
Page 332: Multi-Chassis Ipc-Vlan
multi-chassis ipc-vlan Multi-Chassis Commands multi-chassis ipc-vlan Configures the multi-chassis control VLAN on the switch. The multi-chassis control VLAN must be configured with the same values on the switches that will operate in multi-chassis mode. multi-chassis ipc-vlan vid Syntax Definitions vlan Multi-chassis control VLAN used for all multi-chassis control communication between the peer switches within the range [2 - 4094].
Page 333 Multi-Chassis Commands multi-chassis ipc-vlan Related Commands multi-chassis chassis-id Assigns a globally unique chassis identifier to the switch and enables or disables the switch to operate in multi-chassis mode. multi-chassis hello-interval Configures the multi-chassis hello interval parameter on the switch. show multi-chassis status Displays the configured and operational parameters related to the multi- chassis feature on the switch.
Page 334: Multi-Chassis Loop-Detection
The user must be aware that the neighbor switches in the network may learn the proprietary MAC addresses used as source addresses for the loop detection control packets. Some of the Alcatel-Lucent switches, notably the OS10K switches, are aware of the MAC adddress range used and they will not learn these addresses in order to limit MAC address table size.
Page 335 Multi-Chassis Commands multi-chassis loop-detection Related Commands show multi-chassis loop- .Displays the configured and operational parameters related to the multi- detection chassis loop-detection feature on the switch. multi-chassis loop-detection Configures the loop-detection transmit interval, which determines the transmit-interval time interval between the transmission of sucessive loop-detection pack- ets on each VLAN active on the switch.
Page 336: Multi-Chassis Loop-Detection Transmit-Interval
multi-chassis loop-detection transmit-interval Multi-Chassis Commands multi-chassis loop-detection transmit-interval Configures the loop-detection transmit interval, which determines the time interval between the transmis- sion of sucessive loop-detection packets on each VLAN active on the switch. multi-chassis loop-detection transmit-interval interval Syntax Definitions interval Transmit interval, in seconds, which determines the time interval between the transmission of sucessive loop-detection packets on each VLAN active on the switch within the range [1 - 10].
Page 337 Multi-Chassis Commands multi-chassis loop-detection transmit-interval Related Commands show multi-chassis loop- Displays the configured and operational parameters related to the multi- detection chassis loop-detection feature on the switch. multi-chassis loop-detection Configures the multi-chassis loop-detection function on the switch. MIB Objects multiChassisConfig multiChassisLoopDetectionTransmitInterval OmniSwitch CLI Reference Guide March 2011...
Page 338: Multi-Chassis Vf-Link Create
multi-chassis vf-link create Multi-Chassis Commands multi-chassis vf-link create Configures a virtual fabric link between two peer switches to enable them to operate in multi-chassis mode. multi-chassis vf-link create no multi-chassis vf-link Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 339 Multi-Chassis Commands multi-chassis vf-link create MIB Objects multiChassisLinkTable multiChassisLinkIfIndex multiChassisLinkOperStatus multiChassisLinkActivePortNum multiChassisLinkRowStatus OmniSwitch CLI Reference Guide March 2011 page 7-15...
Page 340: Multi-Chassis Vf-Link Member-Port
multi-chassis vf-link member-port Multi-Chassis Commands multi-chassis vf-link member-port Adds a port to the list of member ports of the virtual fabric link. multi-chassis vf-link member-port slot/port no multi-chassis vf-link member-port slot/port Syntax Definitions slot/port Slot number for the module and the physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 341 Multi-Chassis Commands multi-chassis vf-link member-port Examples -> multi-chassis vf-link member-port 3/1 -> no multi-chassis vf-link member-port 3/2 Release History Release 7.1.1; command introduced. Related Commands multi-chassis vf-link create Configures a virtual fabric link between two peer switches to enable them to operate in multi-chassis mode. multi-chassis vf-link default- Configures the default VLAN on the virtual fabric link.
Page 342: Multi-Chassis Vf-Link Default-Vlan
multi-chassis vf-link default-vlan Multi-Chassis Commands multi-chassis vf-link default-vlan Configures the default VLAN on the virtual fabric link. multi-chassis vf-link default-vlan vlan no multi-chassis vf-link default-vlan vlan Syntax Definitions vlan VLAN to be configured as the default VLAN on the virtual fabric link in the range [1 - 4094].
Page 343 Multi-Chassis Commands multi-chassis vf-link default-vlan Related Commands multi-chassis vf-link create Configures a virtual fabric link between two peer switches to enable them to operate in multi-chassis mode. show multi-chassis vf-link Adds a port to the list of member ports of the virtual fabric link. member-port show multi-chassis vf-link Displays a summary of the configured and operational parameters...
Page 344: Multi-Chassis Vip-Vlan
multi-chassis vip-vlan Multi-Chassis Commands multi-chassis vip-vlan Creates a virtual IP VLAN, which is a special type of VLAN used to provide the underlying LAN infra- structure for the support of basic IP/Layer 3 services on a multi-chassis link aggregation group. multi-chassis vip-vlan vlan no multi-chassis vip-vlan vlan Syntax Definitions...
Page 345 Multi-Chassis Commands multi-chassis vip-vlan Examples -> multi-chassis vip-vlan 3 -> no multi-chassis vip-vlan 3 Release History Release 7.1.1; command introduced. Related Commands show vlan < Intra cross reference to VLAN chapter > ip interface vlan address vip- < Intra cross reference to IP chapter > address MIB Objects vlanTable...
Page 346: Show Multi-Chassis Status
show multi-chassis status Multi-Chassis Commands show multi-chassis status Displays the configured and operational parameters related to the multi-chassis feature on the switch. show multi-chassis status Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show multi-chassis status Multi-Chassis Operational Configured ----------------+-----------+--------- Chassis ID Chassis Role...
Page 347 Multi-Chassis Commands show multi-chassis status output definitions Time interval, in seconds, at which multi-chassis control hello mes- Hello Interval sages are to be sent to the peer switch within the range [1 - 10].. Multi-chassis control VLAN used for all multi-chassis control commu- IPC VLAN nication between the peer switches within the range [2 - 4094].
Page 348: Show Multi-Chassis Loop-Detection
show multi-chassis loop-detection Multi-Chassis Commands show multi-chassis loop-detection Displays the configured and operational parameters related to the multi-chasiss loop-detection feature on the switch. show multi-chassis loop-detection Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show multi-chassis loop-detection Status : Enabled, Transmit Interval...
Page 349 Multi-Chassis Commands show multi-chassis loop-detection Related Commands multi-chassis loop-detection Configures the multi-chassis loop-detection function on the switch. multi-chassis loop-detection Configures the loop-detection transmit interval, which determines the transmit-interval time interval between the transmission of sucessive loop-detection pack- ets on each VLAN active on the switch. MIB Objects multiChassisLoopDetection multiChassisLoopDetectionTransmitCount...
Page 350: Show Multi-Chassis Vf-Link
show multi-chassis vf-link Multi-Chassis Commands show multi-chassis vf-link Displays a summary of the configured and operational parameters related to the virtual fabric link on the switch. show multi-chassis vf-link Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show multi-chassis vf-link VFLink ID Oper Primary Port...
Page 351 Multi-Chassis Commands show multi-chassis vf-link Release History Release 7.1.1; command introduced. Related Commands multi-chassis vf-link create Configures a virtual fabric link between two peer switches to enable them to operate in multi-chassis mode. multi-chassis vf-link member- Adds a port to the list of member ports of the virtual fabric link. port multi-chassis vf-link default- Configures the default VLAN on the virtual fabric link.
Page 352: Show Multi-Chassis Vf-Link Member-Port
show multi-chassis vf-link member-port Multi-Chassis Commands show multi-chassis vf-link member-port Displays detailed information about the configured and operational parameters related to the virtual fabric link member ports on the switch. show multi-chassis vf-link member-port [slot/port] Syntax Definitions slot/port Specify the slot number for the module and the physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 353 Multi-Chassis Commands show multi-chassis vf-link member-port output definitions The current status of each virtual fabric link member port, which can be Oper Disabled, Down or Up.The Disabled state occurs whenever the multi- chassis feature is disabled because the operational chassis identifier currenty effective is the standalone chassis identifier, i.e.
Page 354: Show Multi-Chassis Consistency
show multi-chassis consistency Multi-Chassis Commands show multi-chassis consistency Displays the system level mandatory consistency parameters of both the local and peer switches. show multi-chassis consistency Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show multi-chassis consistency Consistency Local Peer Status...
Page 355 Multi-Chassis Commands show multi-chassis consistency output definitions Status Specifies the overall status of a consistency parameter within the entire multi-chasiss system comprised by the individual switches. The possi- ble values are OK, NOK or N/A. or If there is a mismatch of any of the parameters listed in this command or if the chassis identifier of the two switches is the same, the multi-chassis operational status will not become Up.
Page 356 show multi-chassis consistency Multi-Chassis Commands multiChassisPeerHelloInterval multiChassisHelloIntervalConsistency multiChassisLocalStpPathCostMode multiChassisPeerStpPathCostMode multiChassisStpPathCostModeConsistency multiChassisLocalStpMode multiChassisPeerStpMode multiChassisStpModeConsistency vlanTable vlanEntry page 7-32 OmniSwitch CLI Reference Guide March 2011...
Page 357: Show Multi-Chassis Consistency Linkagg
Multi-Chassis Commands show multi-chassis consistency linkagg show multi-chassis consistency linkagg Displays the per-multi-chassis aggregate level optional consistency parameters of both the local and peer switches. show multi-chassis consistency linkagg agg_num Syntax Definitions agg_num The number corresponding to the static or dynamic multi-chassis aggre- gate group within the range [0-127] and subject to the settings specified through the linkagg range command.
Page 358 show multi-chassis consistency linkagg Multi-Chassis Commands Output fields are defined here: output definitions Consistency Provides a list of per-multi-chassis aggregate optional consistency parameters for the local and remote switches operating in multi-chassis mode. Local Value of a given consistency parameter on the local switch. Peer Value of a given consistency parameter on the peer switch.
Page 359 Multi-Chassis Commands show multi-chassis consistency linkagg multiChassisLinkaggPeerVlanType multiChassisLinkaggVlanTypeConsistency multiChassisLinkaggLocalVlanListConfig multiChassisLinkaggLocalVlanListConfig multiChassisLinkaggVlanListConfigConsistency multiChassisLinkaggLocalAggActorSystemID multiChassisLinkaggPeerAggActorSystemID multiChassisLinkaggAggActorSystemIDConsistency multiChassisLinkaggLocalAggActorSystemPriority multiChassisLinkaggPeerAggActorSystemPriority multiChassisLinkaggAggActorSystemPriorityConsistency OmniSwitch CLI Reference Guide March 2011 page 7-35...
Page 360: Clear Multi-Chassis Loop-Detection
clear multi-chassis loop-detection Multi-Chassis Commands clear multi-chassis loop-detection Clears the configured and operational parameters related to the multi-chasiss loop-detection feature on the switch. clear multi-chassis loop-detection Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> clear multi-chassis loop-detection Release History Release 7.1.1;...
Page 361: Ethernet Ring Protection Commands
Ethernet OAM to alert ERP of a link failure through non-ERP nodes. MIB information for the Ethernet ring protection command is as follows: Filename: AlcatelIND1Erp.mib Module: ALCATEL-IND1-ERP-MIB A summary of available commands is listed here: erp-ring erp-ring rpl-node erp-ring wait-to-restore erp-ring enable...
Page 362: Erp-Ring
erp-ring Ethernet Ring Protection Commands erp-ring Creates an Ethernet Ring Protection (ERP) ring using the specified ports and service VLAN ID. The service VLAN transmits ERP control traffic, such as Ring Automatic Protection Switching (R-APS) messages, through the ring and the specified level number identifies an APS Management Entity Group (MEG) to which the service VLAN belongs.
Page 363 Ethernet Ring Protection Commands erp-ring • ERP is not supported on mobile ports, mirroring ports, link aggregate member ports, high availability ports, Multicast VLAN receiver ports (ERP is supported on Multicast VLAN sender ports only), VLAN Stacking user network interface (UNI) ports, or RRSTP ring ports. •...
Page 364 erp-ring Ethernet Ring Protection Commands MIB Objects alaErpRingId alaErpRingServiceVid alaErpRingMEGLevel alaErpRingStatus alaErpRingPort1 alaErpRingPort2 alaErpRingWaitToRestore alaErpRingGuardTimer alaErpRingRowStatus page 8-4 OmniSwitch CLI Reference Guide March 2011...
Page 365: Erp-Ring Rpl-Node
Ethernet Ring Protection Commands erp-ring rpl-node erp-ring rpl-node Configures a switch as a Ring Protection Link (RPL) node. This command also identifies the ERP port as an RPL connection port. The RPL remains blocked to prevent loops within the ERP ring. erp-ring ring_id rpl-node {port slot/port | linkagg agg_num} no erp-ring ring_id rpl-node Syntax Definitions...
Page 366 erp-ring rpl-node Ethernet Ring Protection Commands Related Commands erp-ring Configures an ERP ring. erp-ring wait-to-restore Configures the wait-to-restore timer value for the Ring Protection Link (RPL) node. show erp Displays the ERP ring configuration for the switch. MIB Objects alaErpRingId alaErpRingPortIfIndex alaErpRingPortType page 8-6...
Page 367: Erp-Ring Wait-To-Restore
Ethernet Ring Protection Commands erp-ring wait-to-restore erp-ring wait-to-restore Configures the wait-to-restore timer value for the Ring Protection Link (RPL) switch. This timer deter- mines the number of minutes the RPL switch waits before returning the RPL ports to a blocked state after the ERP ring has recovered from a link failure.
Page 368: Erp-Ring Enable
erp-ring enable Ethernet Ring Protection Commands erp-ring enable Enables or disables an ERP ring identified by the specified ring ID. This command applies to enabling or disabling existing ERP rings. erp-ring ring_id {enable | disable} Syntax Definitions ring_id An existing ERP ring ID number. The valid range is 1- 2147483647. Defaults By default, ERP rings are disabled when they are created.
Page 369: Erp-Ring Guard-Timer
Ethernet Ring Protection Commands erp-ring guard-timer erp-ring guard-timer Configures the guard timer value for the specified ERP ring node. The guard timer is used to prevent ring nodes from receiving outdated Ring Automatic Protection Switching (R-APS) messages. During the amount of time determined by this timer, all received R-APS messages are ignored by the ring protection control process.
Page 370: Clear Erp Statistics
clear erp statistics Ethernet Ring Protection Commands clear erp statistics Clears ERP statistics for all rings, a specific ring, or a specific ring port. clear erp statistics [ring ring_id [port slot/port | linkagg agg_num]] Syntax Definitions ring_id An existing ERP ring ID number. The valid range is 1- 2147483647. slot/port The slot number for the module and the physical port number on that module.
Page 371 Ethernet Ring Protection Commands clear erp statistics Related Commands erp-ring Configures an ERP ring. show erp Displays the ERP ring configuration for the switch. show erp statistics Displays ERP ring statistics. MIB Objects alaErpClearStats alaErpRingTable alaErpRingId alaErpRingClearStats alaErpRingPortTable alaErpRingPortIfIndex alaErpRingPortClearStats OmniSwitch CLI Reference Guide March 2011 page 8-11...
Page 372: Show Erp
show erp Ethernet Ring Protection Commands show erp Displays the ERP configuration information for all rings, a specific ring, or for a specific ring port. show erp [ring ring_id | [port slot/port | linkagg agg_num]] Syntax Definitions ring_id An existing ERP ring ID number. The valid range is 1- 2147483647. slot/port The slot number for the module and the physical port number on that module.
Page 373 Ethernet Ring Protection Commands show erp Ring Port2 : 1/1, Ring Status : enabled, Service VLAN : 4094, WTR Timer (min) : 3, Guard Timer (centi-sec) : 50, MEG Level : 2, Ring State : idle, Ring Node Type : rpl, RPL Port : 1/1, Last State Change...
Page 374 show erp Ethernet Ring Protection Commands Release History Release 7.1.1; command was introduced. Related Commands show erp statistics Displays ERP ring statistics. MIB Objects alaErpRingId alaErpRingStatus alaErpRingServiceVid alaErpRingMEGLevel alaErpRingPort1 alaErpRingPort2 alaErpRingPortIfIndex alaErpRingState alaErpRingPortStatus alaErpRingPortType alaErpRingPortEthOAMEvent alaErpRingPortRmepId alaErpRingWaitToRestoreTimer alaErpRingGuardTimer alaErpRingLastStateChange alaErpRingTimeToRevert page 8-14 OmniSwitch CLI Reference Guide March 2011...
Page 375: Show Erp Statistics
Ethernet Ring Protection Commands show erp statistics show erp statistics Displays the ERP statistics for all rings, a specific ring, or a specific ring port. show erp statistics [ring ring_id [port slot/port | linkagg agg_num]] Syntax Definitions ring_id An existing ERP ring ID number. The valid range is 1- 2147483647. slot/port The slot number for the module and the physical port number on that module.
Page 376 show erp statistics Ethernet Ring Protection Commands Ring Port : 1/1 Signal Fail PDUs Sent : 6, Recv : 0, Drop : 0 No Request PDUs Sent : 37, Recv : 38, Drop : 0 No Request RPL Block PDUs Sent : 4322, Recv : 0, Drop : 0...
Page 377 Ethernet Ring Protection Commands show erp statistics Recv : 0, Drop : 0 No Request PDUs Sent : 13, Recv : 13, Drop : 0 No Request RPL Block PDUs Sent : 4358, Recv : 0, Drop : 0 Invalid R-APS PDUs Recv : 0 ->...
Page 378 show erp statistics Ethernet Ring Protection Commands Related Commands show erp Displays the ERP ring configuration for the switch. clear erp statistics Clears ERP ring statistics. MIB Objects alaERPClearStats alaERPRingClearStats alaErpRingPortClearStats alaErpRingId alaErpRingPortIfIndex alaErpStatsSignalFailPduTx alaErpStatsSignalFailPduRx alaErpStatsSignalFailPduDrop alaErpStatsNoRequestPduTx alaErpStatsNoRequestPduRx alaErpStatsNoRequestPduDrop alaErpStatsRPLBlockPDUTx alaErpStatsRPLBlockPDURx alaErpStatsRPLBlockPDUDrop alaErpStatsPDUErr...
Page 379: Chapter 9 802.1Ab Commands
TLV (Time, Length, Value) format. This chapter details configuring and monitoring 802.1AB on a switch. Alcatel-Lucent’s version of 802.1AB complies with the IEEE 802.1AB-2005 Station and Media Access Control Discovery and ANSI-TIA 1057-2006 Link Layer Discovery Protocol for Media End Point Devices.
Page 380: 802.1Ab Commands
lldp transmit interval 802.1AB Commands lldp transmit interval Sets the transmit time interval for LLDPDUs. lldp transmit interval seconds Syntax Definitions seconds The transmit interval between LLDPDUs, in seconds. The valid range is 5 - 32768. Defaults parameter default seconds Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 381: Lldp Transmit Hold-Multiplier
802.1AB Commands lldp transmit hold-multiplier lldp transmit hold-multiplier Sets the transmit hold multiplier value, which is used to calculate the Time To Live TLV. lldp transmit hold-multiplier num Syntax Definitions The transmit hold multiplier value. The valid range is 2-10. Defaults parameter default...
Page 382: Lldp Transmit Delay
lldp transmit delay 802.1AB Commands lldp transmit delay Sets the minimum time interval between successive LLDPDUs transmitted. lldp transmit delay seconds Syntax Definitions seconds The time interval between successive LLDPDUs transmitted, in seconds. The valid range is 1-8192. Defaults parameter default seconds Platforms Supported...
Page 383: Lldp Reinit Delay
802.1AB Commands lldp reinit delay lldp reinit delay Sets the time interval that must elapse before the current status of a port is reinitialized after a status change. lldp reinit delay seconds Syntax Definitions seconds The number of seconds to reinitialize the ports status after a status change.
Page 384: Lldp Notification Interval
lldp notification interval 802.1AB Commands lldp notification interval Sets the time interval that must elapse before a notification about the local system MIB change is generated. lldp notification interval seconds Syntax Definitions seconds The minimum number of seconds for generating a notification-event. The valid range is 5-3600.
Page 385: Lldp Lldpdu
802.1AB Commands lldp lldpdu lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port. lldp {port slot/port [-port ]| slot slot | chassis} lldpdu {tx | rx | tx-and-rx | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module...
Page 386 lldp lldpdu 802.1AB Commands Related Commands lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port. lldp notification Specifies the switch to control per port notification status about the remote device change.
Page 387: Lldp Notification
802.1AB Commands lldp notification lldp notification Specifies the switch to control per port notification status about the remote device change. lldp {port slot/port[-port ] | slot slot | chassis} notification {enable | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 388 lldp notification 802.1AB Commands Related Commands lldp notification interval Sets the time interval that must elapse before a notification about the local system MIB change is generated. lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port.
Page 389: Lldp Tlv Management
802.1AB Commands lldp tlv management lldp tlv management Specifies the switch to control per port management TLVs to be incorporated in the LLDPDUs. lldp {port slot/port [-port ] | slot slot | chassis} tlv management {port-description | system-name | system-description | system-capabilities | management-address} {enable | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module...
Page 390 lldp tlv management 802.1AB Commands Release History Release 7.1.1; command introduced. Related Commands lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port. show lldp local -system Displays local system information.
Page 391: Lldp Tlv Dot1
802.1AB Commands lldp tlv dot1 lldp tlv dot1 Specifies the switch to control per port 802.1 TLVs to be incorporated in the LLDPDUs. lldp {port slot/port [-port ] | slot slot | chassis} tlv dot1 {port-vlan | vlan-name} {enable | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module...
Page 392 lldp tlv dot1 802.1AB Commands Related Commands lldp tlv management Specifies the switch to control per port management TLVs to be incor- porated in the LLDPDUs. show lldp statistics Displays per port statistics. show lldp local -port Displays per port information. MIB Objects lldpPortConfigTable lldpPortConfigPortNum...
Page 393: Lldp Tlv Dot3
802.1AB Commands lldp tlv dot3 lldp tlv dot3 Specifies the switch to control per port 802.3 TLVs to be incorporated in the LLDPDUs. lldp {port slot/port [-port ]| slot slot | chassis} tlv dot3 mac-phy {enable | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 394 lldp tlv dot3 802.1AB Commands Related Commands lldp tlv management Specifies the switch to control per port management TLVs to be incorporated in the LLDPDUs. lldp tlv dot1 Specifies the switch to control per port 802.1 TLVs to be incorporated in the LLDPDUs.
Page 395: Lldp Tlv Med
802.1AB Commands lldp tlv med lldp tlv med Specifies the switch to control per port LLDP-MED (Media Endpoint Device) TLVs to be incorporated in the LLDPDUs. lldp {port slot/port [-port ] | slot slot | chassis} tlv med {power | capability} {enable | disable} Syntax Definitions slot/port Slot number for the module and physical port number on that module...
Page 396 lldp tlv med 802.1AB Commands Related Commands lldp tlv management Specifies the switch to control per port management TLVs to be incor- porated in the LLDPDUs. lldp tlv dot1 Specifies the switch to control per port 802.1 TLVs to be incorporated in the LLDPDUs.
Page 397: Show Lldp System-Statistics
802.1AB Commands show lldp system-statistics show lldp system-statistics Displays system-wide statistics. show lldp system-statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show lldp system-statistics Local LLDP Agent System Statistics: Remote Systems Last Change = 0 days 0 hours 3 minutes and 10 seconds, Remote Systems MIB Inserts = 2, Remote Systems MIB Deletes...
Page 398 show lldp system-statistics 802.1AB Commands Related Commands lldp notification Specifies the switch to control per port notification status about the remote device change. lldp notification interval Sets the time interval that must elapse before a notification about the local system MIB change is generated. MIB Objects lldpStatistics lldpStatsRemTablesLastChangeTime...
Page 399: Show Lldp Statistics
802.1AB Commands show lldp statistics show lldp statistics Displays per port statistics. show lldp [port slot/port [-port ]] statistics Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3). Defaults By default, a list of all lldp ports is displayed.
Page 400 show lldp statistics 802.1AB Commands Related Commands lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port. lldp tlv management Specifies the switch to control per port management TLVs to be incor- porated in the LLDPDUs.
Page 401: Show Lldp Local-System
802.1AB Commands show lldp local -system show lldp local-system Displays local system information. show lldp local-system Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show lldp local-system Local LLDP Agent System Data: Chassis ID Subtype = 4 (MAC Address), Chassis ID = 00:d0:95:e9:c9:2e, System Name...
Page 402 show lldp local -system 802.1AB Commands output definitions (continued) LLDPDU Transmit Delay The minimum transmit time between successive LLDPDUs. Reintialization Delay The minimum time interval before the reinitialization of local port objects between port status changes. MIB Notification Interval The minimum time interval between consecutive notifications of local system MIB change.
Page 403: Show Lldp Local-Port
-> show lldp local-port Local Slot 1/Port 1 LLDP Info: Port ID = 1001 (Locally assigned), Port Description = Alcatel 1/1 6.3.1.636.R01, Local Slot 1/Port 2 LLDP Info: Port ID = 1002 (Locally assigned), Port Description = Alcatel 1/2 6.3.1.636.R01,...
Page 404 -port 802.1AB Commands Local Slot 1/Port 10 LLDP Info: Port ID = 1010 (Locally assigned), Port Description = Alcatel 1/10 6.3.1.636.R01, Local Slot 1/Port 11 LLDP Info: Port ID = 1011 (Locally assigned), Port Description = Alcatel 1/11 6.3.1.636.R01,...
Page 405 802.1AB Commands show lldp local -port Port Description = Alcatel 2/3 6.3.1.636.R01, Local Slot 2/Port 4 LLDP Info: Port ID = 2004 (Locally assigned), Port Description = Alcatel 2/4 6.3.1.636.R01, Local Slot 2/Port 5 LLDP Info: Port ID = 2005 (Locally assigned), Port Description = Alcatel 2/5 6.3.1.636.R01,...
Page 406 -port 802.1AB Commands Port ID = 2023 (Locally assigned), Port Description = Alcatel 2/23 6.3.1.636.R01, Local Slot 2/Port 24 LLDP Info: Port ID = 2024 (Locally assigned), Port Description = Alcatel 2/24 6.3.1.636.R01, Local Slot 2/Port 25 LLDP Info:...
Page 407 -port Local Slot 2/Port 43 LLDP Info: Port ID = 2043 (Locally assigned), Port Description = Alcatel 2/43 6.3.1.636.R01, Local Slot 2/Port 44 LLDP Info: Port ID = 2044 (Locally assigned), Port Description = Alcatel 2/44 6.3.1.636.R01,...
Page 408: Show Lldp Local-Management-Address
show lldp local-management-address 802.1AB Commands show lldp local-management-address Displays the local management address information. show lldp local-management-address Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show lldp local-management-address Local LLDP Agent Management Address: Management Address Type = 1 (IPv4), Management IP Address = 10.255.11.100 output definitions...
Page 409: Show Lldp Remote-System
802.1AB Commands show lldp remote-system show lldp remote-system Displays per local port and information of remote system. show lldp [port slot/port [-port ] | slot slot] remote-system Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 410 show lldp remote-system 802.1AB Commands output definitions Remote LLDP Agents on Local The Slot number to which the remote system entry is associated and the Slot/Port physical port number on that module. Chassis ID Subtype The sub type that describes chassis ID. Chassis ID The chassis ID (MAC address).
Page 411: Show Lldp Config
802.1AB Commands show lldp config show lldp config Displays the general LLDP configuration information for LLDP ports. show lldp { slot | slot/port [-port ]} config Syntax Definitions slot The slot number for a specific module. slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 412 show lldp config 802.1AB Commands output definitions 802.3 Mask Specifies the standard 802.3 mask set for the port. MED Mask Specifies the standard MED mask set for the port. Release History Release 7.1.1; command introduced. Related Commands lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port.
Page 413: Show Lldp Statistics
802.1AB Commands show lldp statistics show lldp statistics Displays per port statistics. show lldp [port slot/port [-port ] slot slot] statistics Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3). slot The slot number for a specific module.
Page 414 show lldp statistics 802.1AB Commands Related Commands lldp lldpdu Specifies the switch to control the transmission and the reception of LLDPDUs for a particular chassis, a slot, or a port. lldp tlv management Specifies the switch to control per port management TLVs to be incor- porated in the LLDPDUs.
Page 415: Show Lldp Remote-System Med
802.1AB Commands show lldp remote-system med show lldp remote-system med Displays remote system MED information for a single port or all ports on a slot. show lldp [slot/port [-port ] | slot] remote-system [med {network-policy | inventory}] Syntax Definitions slot/port Slot number for the module and physical port number on that module (e.g., 3/1 specifies port 1 on slot 3).
Page 416 show lldp remote-system med 802.1AB Commands output definitions (continued) Unknown Policy Flag Whether the network policy for the specified application type is cur- rently defined or unknown. Tagged Flag Whether the specified application type is using a tagged or an untagged VLAN.
Page 417 802.1AB Commands show lldp remote-system med MIB Objects lldpXMedRemMediaPolicyTable lldpXMedRemMediaPolicyAppType lldpXMedRemMediaPolicyDscp lldpXMedRemMediaPolicyPriority lldpXMedRemMediaPolicyTagged lldpXMedRemMediaPolicyUnknown lldpXMedRemMediaPolicyVlanID lldpXMedRemInventoryTable lldpXMedRemAssetID lldpXMedRemFirmwareRev lldpXMedRemHardwareRev lldpXMedRemMfgName lldpXMedRemModelName lldpXMedRemSerialNum lldpXMedRemSoftwareRev OmniSwitch CLI Reference Guide March 2011 page 9-39...
Page 418 show lldp remote-system med 802.1AB Commands page 9-40 OmniSwitch CLI Reference Guide March 2011...
Page 419 10 IP Commands This chapter details Internet Protocol (IP) commands for the switch. IP is a network-layer (Layer 3) protocol that contains addressing information and some control information that enables packets to be forwarded. IP is documented in RFC 791 and is the primary network-layer protocol in the Internet protocol suite.
Page 420 IP Commands MIB information for the IP commands is as follows: Filename: IpForward.mib Module: IpForward Filename: Ip.mib Module: Filename: AlcatelIND1Ip.mib Module: alcatelIND1IPMIB Filename: AlcatelIND1Iprm.mib Module: alcatelIND1IPRMMIB page 10-2 OmniSwitch CLI Reference Guide March 2011...
Page 421 IP Commands A summary of the available commands is listed here: ip interface ip interface tunnel ip router primary-address ip router router-id ip static-route ip route-pref ip default-ttl ping traceroute ip directed-broadcast ip service ip service port show ip traffic show ip interface show ip routes show ip route-pref...
Page 422 IP Commands clear arp-cache ip dos arp-poison restricted-address arp filter clear arp filter show arp show ip dos arp-poison show arp filter ICMP icmp type icmp unreachable icmp echo icmp timestamp icmp addr-mask icmp messages show icmp control show icmp statistics show tcp statistics show tcp ports show udp statistics...
Page 423 Syntax Definitions name Text string of interface name. Use quotes around string if description contains multiple words with spaces between them (e.g. “Alcatel-Lucent Marketing”). Note that this value is case sensitive. Modifies the shared EMP port IP address. address ip_address An IP host address (e.g.
Page 424 ip interface IP Commands Defaults parameter default ip_address 0.0.0.0 subnet_mask IP address class enable | disable enable vlan_id none (unbound) forward | no forward forward local-proxy-arp | no local-proxy-arp no local-proxy-arp e2 | snap primary | no primary First interface bound to a VLAN.
Page 425: Ip Commands Ip Interface
IP Commands ip interface -> ip interface “Human Resources” 10.200.12.101 vlan 500 no forward snap -> ip interface “Distribution” 11.255.14.102 vlan 500 local-proxy-arp primary Release History Release 7.1.1; command introduced Related Commands show ip interface Displays the status and configuration of IP interfaces. MIB Objects alaIpInterfaceTable alaIpInterfaceName...
Page 426: Ip Interface Tunnel
[source ip_address] [destination ip_address] [protocol {ipip | gre}] Syntax Definitions name Text string. Use quotes around string if description contains multiple words with spaces between them (e.g. “Alcatel-Lucent Marketing”). Note that this value is case sensitive. source ip_address Source IP address of the tunnel.
Page 427 IP Commands ip interface tunnel alaIpInterfaceTunnelDst alaIpInterfaceDeviceType OmniSwitch CLI Reference Guide March 2011 page 10-9...
Page 428: Ip Router Primary-Address
ip router primary-address IP Commands ip router primary-address Configures the router primary IP address. By default, the router primary address is derived from the first IP interface that becomes operational on the router. ip router primary-address ip_address Syntax Definitions ip_address 32-bit IP address.
Page 429: Ip Router Router-Id
IP Commands ip router router-id ip router router-id Configures the router ID for the router. By default, the router primary address of the router is used as the router ID. However, if a primary address has not been explicitly configured, the router ID defaults to the address of the first IP interface that becomes operational.
Page 430: Ip Static-Route
ip static-route IP Commands ip static-route Creates/deletes an IP static route. Static routes are user-defined; they carry a higher priority than routes created by dynamic routing protocols. That is, static routes always have priority over dynamic routes, regardless of the metric value. ip static-route ip_address [mask mask] gateway gateway|follows ip_address [metric metric] no ip static-route ip_address [mask mask] gateway ip_address|follows ip_address [metric metric] Syntax Definitions...
Page 431 IP Commands ip static-route Release History Release 7.1.1; command introduced Related Commands show ip routes Displays the IP Forwarding table. show ip router database Displays the IP router database contents. MIB Objects alaIprmStaticRoute alaIprmStaticRouteDest alaIprmStaticRouteMask alaIprmStaticRouteNextHop alaIprmStaticRouteMetric alaIprmStaticRouteStatus OmniSwitch CLI Reference Guide March 2011 page 10-13...
Page 432: Ip Route-Pref
ip route-pref IP Commands ip route-pref Configures the route preference of a router. ip route-pref {static | ospf | rip | ebgp | ibgp} value Syntax Definitions static Configures the route preference of static routes. ospf Configures the route preference of OSPF routes. Configures the route preference of RIP routes.
Page 433 IP Commands ip route-pref Related Commands show ip route-pref Displays the configured route-preference of a router. MIB Objects alaIprmRtPrefTable alaIprmRtPrefLocal alaIprmRtPrefStatic alaIprmRtPrefOspf alaIprmRtPrefRip alaIprmRtPrefEbgp alaIprmRtPrefIbgp OmniSwitch CLI Reference Guide March 2011 page 10-15...
Page 434: Ip Default-Ttl
ip default-ttl IP Commands ip default-ttl Configures the Time To Live value (TTL) for IP packets. The TTL value is the maximum number of hops an IP packet travels before being discarded. ip default-ttl hops Syntax Definitions hops TTL value, in hops. Valid range is 1–255. Defaults parameter default...
Page 435: Ping
IP Commands ping ping Tests whether an IP destination can be reached from the local switch. This command sends an ICMP echo request to a destination and then waits for a reply. To ping a destination, enter the ping command and enter either the IP address or hostname of the destination.
Page 436 ping IP Commands Usage Guidelines If you change the default values they are only applied to the current ping. The next time you use the ping command, the default values are used unless you again enter different values. Examples -> ping 10.255.11.242 PING 10.255.11.242: 56 data bytes 64 bytes from 10.255.11.242: icmp_seq=0.
Page 437: Traceroute
IP Commands traceroute traceroute Finds the path taken by an IP packet from the local switch to a specified destination. This command displays the individual hops to the destination as well as some timing information. traceroute {ip_address | hostname} [max-hop max_hop_count] [min-hop min_hop_count] [source- interface ip_interface] [probes probe_count] [timeout seconds] [port port_number_value] Syntax Definitions ip_address...
Page 438 traceroute IP Commands 128.251.14.253 0 ms 0 ms 0 ms 128.251.17.224 0 ms 0 ms 0 ms -> traceroute 128.251.17.224 max-hop 3 traceroute to 128.251.17.224, 3 hops max, 40 byte packets 10.255.11.254 0 ms 0 ms 0 ms 172.23.0.251 16.6667 ms 0 ms 0 ms 128.251.14.253 0 ms...
Page 439: Ip Directed-Broadcast
IP Commands ip directed-broadcast ip directed-broadcast Enables or disables IP directed broadcasts routed through the switch. An IP directed broadcast is an IP datagram that has all zeros or all 1’s in the host portion of the destination address. The packet is sent to the broadcast address of a subnet to which the sender is not directly attached.
Page 440: Ip Service
ip service IP Commands ip service Enables (opens) or disables (closes) well-known or user-defined TCP/UDP service ports. Selectively enabling or disabling these types of ports provides an additional method for protecting against unautho- rized switch access or Denial of Service (DoS) attacks. ip service {all | service_name | port service_port} admin-state {enable | disable} Syntax Definitions Configures access to all TCP/UDP ports.
Page 441 IP Commands ip service • The following table lists the ip service command options for specifying TCP/UDP services and also includes the well-known port number associated with each service: service name port telnet http https snmp Examples -> ip service all admin-state disable ->...
Page 442: Ip Service Port
ip service port IP Commands ip service port Configures a user-defined TCP/UDP service port for the specified service. ip service {service_name} port {default | service_port} Syntax Definitions service_name The name of the TCP/UDP service to enable or disable. (Refer to the table in the “Usage Guidelines”...
Page 443 IP Commands ip service port -> ip service telnet port 20003 -> ip service telnet port default Release History Release 7.1.1; command introduced Related Commands ip service Enables or disables well-known or user-defined service ports. show ip service Displays the IP service TCP/UDP port configuration and status. MIB Objects alaIpServiceTable alaIpServiceType...
Page 444: Ip Redist
ip redist IP Commands ip redist Controls the conditions for redistributing IPv4 routes between different protocols. ip redist {local | static | rip | ospf | isis | bgp} into {rip | ospf | isis | bgp} route-map route-map-name [status {enable | disable}] no ip redist {local | static | rip | ospf | isis | bgp} into {rip | ospf | bgp} [route-map route-map-name] Syntax Definitions local...
Page 445 IP Commands ip redist Examples -> ip redist rip into bgp route-map rip-to-bgp1 -> ip redist rip into bgp route-map rip-to-bgp2 -> no ip redist rip into bgp route-map rip-to-bgp2 -> ip redist ospf into rip route-map ospf-to-rip -> ip redist ospf into rip route-map ospf-to-rip disable Release History Release 7.1.1;...
Page 446: Ip Access-List
ip access-list IP Commands ip access-list Creates an access list for adding multiple IPv4 addresses to route maps. ip access-list access-list-name no ip access-list access-list-name Syntax Definitions access-list-name Name of the access list (up to 20 characters). Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the no form of this command to delete the access list.
Page 447: Ip Access-List Address
IP Commands ip access-list address ip access-list address Adds multiple IPv4 addresses to the specified IPv4 access list. ip access-list access-list-name address address/prefixLen [action {permit | deny}] [redist-control {all-subnets | no-subnets | aggregate}] no ip access-list access-list-name address address/prefixLen Syntax Definitions access-list-name Name of the access list.
Page 448 ip access-list address IP Commands Examples -> ip access-list access1 address 10.0.0.0/8 action permit -> ip access-list access1 address 11.1.0.0/16 action permit -> ip access-list access1 address 10.1.1.0/24 redist-control aggregate -> no ip access-list access1 address 10.0.0.0/8 Release History Release 7.1.1; command introduced Related Commands ip access-list Creates an access list for adding multiple IPv4 addresses to route maps.
Page 449: Ip Route-Map Action
IP Commands ip route-map action ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. ip route-map route-map-name [sequence-number number] action {permit | deny} no ip route-map route-map-name [sequence-number number] Syntax Definitions route-map-name The name of the route map (up to 20 characters).
Page 450 ip route-map action IP Commands Related Commands show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapSequenceTable alaRouteMapSequenceIndex alaRouteMapSequenceNumber alaRouteMapSequenceAction alaRouteMapSequenceRowStatus page 10-32 OmniSwitch CLI Reference Guide March 2011...
Page 451: Ip Route-Map Match Ip Address
IP Commands ip route-map match ip address ip route-map match ip address Matches the route with the specified IPv4 address or an address defined in the specified IPv4 access list. ip route-map route-map-name [sequence-number number] match ip-address {access-list-name | ip_address/prefixLen [redist-control {all-subnets | no-subnets | aggregate}] [permit | deny] no ip route-map route-map-name [sequence-number number] match ip-address {access-list-name | ip_address/prefixLen [redist-control {all-subnets | no-subnets | aggregate}] [permit | deny] Syntax Definitions...
Page 452 ip route-map match ip address IP Commands • Note that configuring the combination of redist-control aggregate with deny is not allowed. • Multiple addresses in the same route map sequence are matched using the longest prefix match. • If the best matching address is type deny, then the route is not redistributed. If the best matching address is type permit and the route map action is deny, the route is not redistributed.
Page 453: Ip Route-Map Match Ipv6 Address
IP Commands ip route-map match ipv6 address ip route-map match ipv6 address Matches the route with the specified IPv6 address or an address defined in the specified IPv6 access list. ip route-map route-map-name [sequence-number number] match ipv6-address {access-list-name | ipv6_address/prefixLen [redist-control {all-subnets | no-subnets | aggregate}] [permit | deny] no ip route-map route-map-name [sequence-number number] match ipv6-address ipv6_address/prefix- Len [redist-control {all-subnets | no-subnets | aggregate}] [permit | deny] Syntax Definitions...
Page 454 ip route-map match ipv6 address IP Commands • Note that configuring the combination of redist-control aggregate with deny is not allowed. • Multiple addresses in the same route map sequence are matched using the longest prefix match. • If the best matching address is type deny, then the route is not redistributed. If the best matching address is type permit and the route map action is deny, the route is not redistributed.
Page 455: Ip Route-Map Match Ip-Nexthop
IP Commands ip route-map match ip-nexthop ip route-map match ip-nexthop Matches any routes that have a next-hop router address permitted by the specified access list name or the IP address specified in the route map. ip route-map route-map-name [sequence-number number] match ip-nexthop {access-list-name | ip_address/prefixLen [permit | deny]} no ip route-map route-map-name [sequence-number number] match ip-nexthop {access-list-name | ip_address/prefixLen [permit | deny]}...
Page 456 ip route-map match ip-nexthop IP Commands Examples -> ip route-map route1 sequence-number 10 match ip-nexthop list1 -> no ip route-map route1 sequence-number 10 match ip-nexthop list1 -> ip route-map route1 sequence-number 10 match ip-nexthop 10.0.0.0/8 -> no ip route-map route1 sequence-number 10 match ip-nexthop 10.0.0.0/8 Release History Release 7.1.1;...
Page 457: Ip Route-Map Match Ipv6-Nexthop
IP Commands ip route-map match ipv6-nexthop ip route-map match ipv6-nexthop Matches any routes that have an IPv6 next-hop router address permitted by the specified access list name or the IPv6 address specified in the route map. ip route-map route-map-name [sequence-number number] match ipv6-nexthop {access-list-name | ipv6_address/prefixLen [permit | deny]} no ip route-map route-map-name [sequence-number number] match ipv6-nexthop {access-list-name | ipv6_address/prefixLen [permit | deny]}...
Page 458 ip route-map match ipv6-nexthop IP Commands Examples -> ip route-map route1 sequence-number 10 match ipv6-nexthop list1 -> no ip route-map route1 sequence-number 10 match ipv6-nexthop list1 -> ip route-map route1 sequence-number 10 match ipv6-nexthop 2001::/64 -> no ip route-map route1 sequence-number 10 match ipv6-nexthop 2001::/64 Release History Release 7.1.1;...
Page 459: Ip Route-Map Match Tag
IP Commands ip route-map match tag ip route-map match tag Matches the tag value specified in the route map with the one that the routing protocol learned the route ip route-map route-map-name [sequence-number number] match tag tag-number no ip route-map route-map-name [sequence-number number] match tag tag-number Syntax Definitions route-map-name The name of the route map.
Page 460 ip route-map match tag IP Commands MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence alaRouteMapType alaRouteMapValue alaRouteMapRowStatus page 10-42 OmniSwitch CLI Reference Guide March 2011...
Page 461: Ip Route-Map Match Ipv4-Interface
IP Commands ip route-map match ipv4-interface ip route-map match ipv4-interface Matches the IPv4 interface name specified in the route map with the one that the routing protocol learned the route on. ip route-map route-map-name [sequence-number number] match ipv4-interface interface-name no ip route-map route-map-name [sequence-number number] match ipv4-interface interface-name Syntax Definitions route-map-name The name of the route map.
Page 462 ip route-map match ipv4-interface IP Commands MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence alaRouteMapType alaRouteMapValue alaRouteMapRowStatus page 10-44 OmniSwitch CLI Reference Guide March 2011...
Page 463: Ip Route-Map Match Ipv6-Interface
IP Commands ip route-map match ipv6-interface ip route-map match ipv6-interface Matches the IPv6 interface name specified in the route map with the one that the routing protocol learned the route on. ip route-map route-map-name [sequence-number number] match ipv6-interface interface-name no ip route-map route-map-name [sequence-number number] match ipv6-interface interface-name Syntax Definitions route-map-name The name of the route map.
Page 464 ip route-map match ipv6-interface IP Commands MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence alaRouteMapType alaRouteMapValue alaRouteMapRowStatus page 10-46 OmniSwitch CLI Reference Guide March 2011...
Page 465: Ip Route-Map Match Metric
IP Commands ip route-map match metric ip route-map match metric Matches the metric value specified in the route map with the actual metric value of the route. ip route-map route-map-name [sequence-number number] match metric metric [deviation deviation] no ip route-map route-map-name [sequence-number number] match metric metric [deviation deviation] Syntax Definitions route-map-name...
Page 466 ip route-map match metric IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 467: Ip Route-Map Match Route-Type
IP Commands ip route-map match route-type ip route-map match route-type Matches the specified route type with actual route type of the route. ip route-map route-map-name [sequence-number number] match route-type {internal | external [type1 | type2] | level1 | level2} no ip route-map route-map-name [sequence-number number] match route-type {internal | external [type1 | type2] | level1 | level2} Syntax Definitions route-map-name...
Page 468 ip route-map match route-type IP Commands Examples -> ip route-map 111 sequence-number 50 match route-type internal -> no ip route-map 111 sequence-number 50 match route-type internal Release History Release 7.1.1; command introduced Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny.
Page 469: Ip Route-Map Set Metric
IP Commands ip route-map set metric ip route-map set metric Configures the metric value of the route being distributed. ip route-map route-map-name [sequence-number number] set metric metric [effect {add | subtract | replace | none}] no ip route-map route-map-name [sequence-number number] set metric metric [effect {add | subtract | replace | none}] Syntax Definitions route-map-name...
Page 470 ip route-map set metric IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 471: Ip Route-Map Set Metric-Type
IP Commands ip route-map set metric-type ip route-map set metric-type Configures the metric type for the redistributed route. ip route-map route-map-name [sequence-number number] set metric-type {internal | external [type1 | type2]} no ip route-map route-map-name [sequence-number number] set metric-type {internal | external [type1 | type2]} Syntax Definitions route-map-name The name of the route map.
Page 472 ip route-map set metric-type IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 473: Ip Route-Map Set Tag
IP Commands ip route-map set tag ip route-map set tag Configures the tag value of the route being distributed. ip route-map route-map-name [sequence-number number] set tag tag-number no ip route-map route-map-name [sequence-number number] set tag tag-number Syntax Definitions route-map-name The name of the route map. number A number that links together the route maps.
Page 474 ip route-map set tag IP Commands MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence alaRouteMapType alaRouteMapValue alaRouteMapRowStatus page 10-56 OmniSwitch CLI Reference Guide March 2011...
Page 475: Ip Route-Map Set Community
IP Commands ip route-map set community ip route-map set community Configures the community name of the route being redistributed into BGP. ip route-map route-map-name [sequence-number number] set community community-string no ip route-map route-map-name [sequence-number number] set community community-string Syntax Definitions route-map-name The name of the route map.
Page 476 ip route-map set community IP Commands MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence alaRouteMapType alaRouteMapValue alaRouteMapRowStatus page 10-58 OmniSwitch CLI Reference Guide March 2011...
Page 477: Ip Route-Map Set Local-Preference
IP Commands ip route-map set local-preference ip route-map set local-preference Configures the local preference value for a route being distributed into BGP. ip route-map route-map-name [sequence-number number] set local-preference value no ip route-map route-map-name [sequence-number number] set local-preference value Syntax Definitions route-map-name The name of the route map.
Page 478 ip route-map set local-preference IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 479: Ip Route-Map Set Level
IP Commands ip route-map set level ip route-map set level Configures the level of the ISIS route being redistributed. ip route-map route-map-name [sequence-number number] set level {level1 | level2 | level1-2} no ip route-map route-map-name [sequence-number number] set level {level1 | level2 | level1-2} Syntax Definitions route-map-name The name of the route map.
Page 480 ip route-map set level IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 481: Ip Route-Map Set Ip-Nexthop
IP Commands ip route-map set ip-nexthop ip route-map set ip-nexthop Configures the IP address of the next hop in a route map. ip route-map route-map-name [sequence-number number] set ip-nexthop ip_address no ip route-map route-map-name [sequence-number number] set ip-nexthop ip_address Syntax Definitions route-map-name The name of the route map.
Page 482 ip route-map set ip-nexthop IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaIPRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 483: Ip Route-Map Set Ipv6-Nexthop
IP Commands ip route-map set ipv6-nexthop ip route-map set ipv6-nexthop Configures the IPv6 address of the next hop in a route map. ip route-map route-map-name [sequence-number number] set ipv6-nexthop ipv6_address no ip route-map route-map-name [sequence-number number] set ipv6-nexthop ipv6_address Syntax Definitions route-map-name The name of the route map.
Page 484 ip route-map set ipv6-nexthop IP Commands Related Commands ip route-map action Creates a route map for redistribution and sets the status of the route map to permit or deny. show ip route-map Displays the configured IP route maps. MIB Objects alaIPRouteMapTable alaRouteMapIndex alaRouteMapSequence...
Page 485: Vrf
IP Commands Configures and selects a virtual routing and forwarding (VRF) instance on the switch. vrf [name | default] no vrf name Syntax Definitions name The alphanumeric name (1–20 characters) assigned to the VRF instance. default Optional. Selects the default VRF instance. Defaults A default VRF instance exists in the switch configuration.
Page 486 IP Commands Examples -> vrf IpOne IpOne: -> IpOne: -> vrf IpTwo IpTwo: -> IpTwo: -> vrf -> IpTwo: -> vrf default -> -> vrf IpOne ip interface intf100 address 100.1.1.1/24 vlan 100 -> Release History Release 7.1.1; command was introduced. Related Commands show vrf Displays the VRF instance configuration for the switch.
Page 487: Arp
IP Commands Adds a permanent entry to the ARP table. To forward packets, the switch dynamically builds an ARP Table to match the IP address of a device with its physical (MAC) address. These entries age out of the table when the timeout value is exceeded. This command is used to add a permanent entry to the table. Permanent entries do not age out of the table.
Page 488 IP Commands Examples -> arp 171.11.1.1 00:05:02:c0:7f:11 Release History Release 7.1.1; command was introduced. Related Commands clear arp-cache Deletes all dynamic entries from the ARP table. ip interface Enables or disables the Local Proxy ARP feature for an IP inter- face.
Page 489: Clear Arp-Cache
IP Commands clear arp-cache clear arp-cache Deletes all dynamic entries from the ARP table. clear arp-cache Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • This commands only clears dynamic entries. If permanent entries have been added to the table, they must be removed using the no form of the ip service command.
Page 490: Ip Dos Arp-Poison Restricted-Address
ip dos arp-poison restricted-address IP Commands ip dos arp-poison restricted-address Adds or deletes an ARP Poison restricted address. ip dos arp-poison restricted-address ip_address no ip dos arp-poison restricted-address ip_address Syntax Definitions ip_address 32-bit IP address. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the no form of the command to remove an already configured ARP Poison restricted address.
Page 491: Arp Filter
IP Commands arp filter arp filter Configures an ARP filter that determines if ARP Request packets containing a specific IP address are processed by the switch or discarded. arp filter ip_address [mask ip_mask] [vlan_id] [sender | target] [allow | block] no arp filter ip_address Syntax Definitions ip_address...
Page 492 arp filter IP Commands Examples -> arp filter 171.11.1.1 -> arp filter 172.0.0.0 mask 255.0.0.0 -> arp filter 198.0.0.0 mask 255.0.0.0 sender -> arp filter 198.172.16.1 vlan 200 allow -> no arp filter 171.11.1.1 Release History Release 7.1.1; command introduced Related Commands clear arp filter Clears all ARP filters from the filter database.
Page 493: Clear Arp Filter
IP Commands clear arp filter clear arp filter Clears the ARP filter database of all entries. clear arp-cache Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines This commands clears all ARP filters configured on the switch. To remove an individual filter entry, use the no form of the arp filter command.
Page 494: Icmp Type
icmp type IP Commands icmp type Enables or disables a specific type of ICMP message, and sets the minimum packet gap. The minimum packet gap is the number of microseconds that must pass between ICMP messages of the same type. icmp type type code code {{enable | disable} | min-pkt-gap gap} Syntax Definitions type...
Page 495 IP Commands icmp type Usage Guidelines • This command allows the user to enable or disable all types of ICMP messages, and set the minimum packet gap between messages of the specified type. • While this command can be used to enable or disable all ICMP message, some of the more common ICMP messages have their own CLI commands, as described in the pages below.
Page 496: Icmp Unreachable
icmp unreachable IP Commands icmp unreachable Enables or disables ICMP messages pertaining to unreachable destinations, and sets the minimum packet gap. The minimum packet gap is the number of microseconds that must pass between ICMP messages of the same type. icmp unreachable [net-unreachable | host-unreachable | protocol-unreachable | port-unreachable] {{enable | disable} | min-pkt-gap gap} Syntax Definitions...
Page 497 IP Commands icmp unreachable -> icmp unreachable protocol-unreachable enable -> icmp unreachable port-unreachable enable -> icmp unreachable port-unreachable min-pkt-gap 50 Release History Release 7.1.1; command introduced Related Commands show icmp control Allows the viewing of the ICMP control settings. MIB Objects alaIcmpCtrlTable alaIcmpCtrlType alaIcmpCtrlTable...
Page 498: Icmp Echo
icmp echo IP Commands icmp echo Enables or disables ICMP echo messages, and sets the minimum packet gap. The minimum packet gap is the number of microseconds that must pass between ICMP messages of the same type. icmp echo [request | reply] {{enable | disable} | min-pkt-gap gap} Syntax Definitions request Specifies the echo request ICMP message.
Page 499 IP Commands icmp echo Related Commands show icmp control Allows the viewing of the ICMP control settings. MIB Objects alaIcmpCtrlTable alaIcmpCtrlType alaIcmpCtrlTable alaIcmpCtrlCode alaIcmpCtrlStatus alaIcmpCtrlPktGap OmniSwitch CLI Reference Guide March 2011 page 10-81...
Page 500: Icmp Timestamp
icmp timestamp IP Commands icmp timestamp Enables or disables ICMP timestamp messages, and sets the minimum packet gap. The minimum packet gap is the number of microseconds that must pass between ICMP messages of the same type. icmp timestamp [request | reply] {{enable | disable} | min-pkt-gap gap} Syntax Definitions request Specifies timestamp request messages.
Page 501 IP Commands icmp timestamp Release History Release 7.1.1; command introduced Related Commands show icmp control Allows the viewing of the ICMP control settings. MIB Objects alaIcmpCtrlTable alaIcmpCtrlType alaIcmpCtrlTable alaIcmpCtrlCode alaIcmpCtrlStatus alaIcmpCtrlPktGap OmniSwitch CLI Reference Guide March 2011 page 10-83...
Page 502: Icmp Addr-Mask
icmp addr-mask IP Commands icmp addr-mask Enables or disables ICMP address mask messages, and sets the minimum packet gap. The minimum packet gap is the number of microseconds that must pass between ICMP messages of the same type. icmp add-mask [request | reply] {{enable | disable} | min-pkt-gap gap} Syntax Definitions request Specifies request address mask messages.
Page 503 IP Commands icmp addr-mask Related Commands show icmp control Allows the viewing of the ICMP control settings. MIB Objects alaIcmpCtrlTable alaIcmpCtrlType alaIcmpCtrlTable alaIcmpCtrlCode alaIcmpCtrlStatus alaIcmpCtrlPktGap OmniSwitch CLI Reference Guide March 2011 page 10-85...
Page 504: Icmp Messages
icmp messages IP Commands icmp messages Enables or disables all Internet Control Message Protocol (ICMP) messages. icmp messages {enable | disable} Syntax Definitions enable Enables ICMP messages. disable Disables ICMP messages. Defaults parameter default enable | disable enable Platforms Supported OmniSwitch 10K Usage Guidelines Examples...
Page 505: Ip Dos Scan Close-Port-Penalty
IP Commands ip dos scan close-port-penalty ip dos scan close-port-penalty Assigns a penalty value to be added to the Denial of Service penalty scan value when a TCP or UDP packet is received on a closed port. ip dos scan close-port-penalty penalty_value Syntax Definitions penalty_value A penalty value added to the penalty scan value.
Page 506: Ip Dos Scan Tcp Open-Port-Penalty
ip dos scan tcp open-port-penalty IP Commands ip dos scan tcp open-port-penalty Assigns a penalty value to be added to the Denial of Service penalty scan value when a TCP packet is received on an open port. ip dos scan tcp open-port-penalty penalty_value Syntax Definitions penalty_value A penalty value added to the penalty scan value.
Page 507: Ip Dos Scan Udp Open-Port-Penalty
IP Commands ip dos scan udp open-port-penalty ip dos scan udp open-port-penalty Assigns a penalty value to be added to the Denial of Service penalty scan value when a UDP packet is received on an open port. ip dos scan udp open-port-penalty penalty_value Syntax Definitions penalty_value A penalty value added to the penalty scan value.
Page 508: Ip Dos Scan Threshold
ip dos scan threshold IP Commands ip dos scan threshold Sets the threshold for the port scan value, at which a DoS attack is recorded. ip dos scan threshold threshold_value Syntax Definitions threshold_value A numerical value representing the total acceptable penalty before a DoS attack is noted.
Page 509 IP Commands ip dos scan threshold Related Commands ip dos scan close-port-penalty Assigns a penalty value to be added to the Denial of Service pen- alty scan value when a TCP or UDP packet is received on a closed port. ip dos scan tcp open-port- Assigns a penalty value to be added to the Denial of Service pen- penalty...
Page 510: Ip Dos Trap
ip dos trap IP Commands ip dos trap Sets whether the switch generates SNMP DoS traps when an attack is detected. ip dos trap {enable | disable} Syntax Definitions enable Enables the generation of DoS traps. disable Disables the generation of DoS traps. Defaults parameter default...
Page 511: Ip Dos Scan Decay
IP Commands ip dos scan decay ip dos scan decay Sets the decay speed of the port scan penalty value for the switch when calculating DoS attacks. ip dos scan decay decay_value Syntax Definitions decay_value The decay value amount for reducing the port scan penalty. This value can be any non-negative integer.
Page 512: Show Ip Traffic
show ip traffic IP Commands show ip traffic Displays IP datagram traffic and errors. show ip traffic Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • The statistics show the cumulative totals since the last time the switch was powered on or since the last reset of the switch was executed.
Page 513 IP Commands show ip traffic Reassemble failed Datagrams sent Fowarded 2801, Generated 578108, Local discards No route discards Fragmented 2801, Fragment failed Fragments generated Event Source Total Last 33 seconds -------------+-------+------------+------------------------ spoof 5/26 last mac 00:08:02:e2:17:70 output definitions Total Total number of input datagrams received including those received in error.
Page 514 show ip traffic IP Commands output definitions (continued) Local discards Number of output IP datagrams that were discarded, even though they had no errors to prevent transmission (e.g., lack of buffer space). This number includes datagrams counted as “Forwarded” if the packets are discarded for these reasons.
Page 515: Show Ip Interface
IP Commands show ip interface show ip interface Displays the configuration and status of IP interfaces. show ip interface [name | emp | vlan vlan id] Syntax Definitions name The name associated with the IP interface. Displays the configuration and status of the Ethernet Management Port interface.
Page 516 show ip interface IP Commands output definitions Name Interface name. Generally, this is the name configured for the interface (e.g., Accounting). EMP refers to the Ethernet Management Port. Loopback refers to a loopback interface configured for testing. IP Address IP address of the interface. Configured through the ip interface com- mand.
Page 517 IP Commands show ip interface output definitions (continued) Device The type of device bound to the interface: • unbound—No device is bound to the interface. • vlan—The VLAN ID that is bound to the interface. • EMP—The Ethernet Management Port is bound to the interface. •...
Page 518 show ip interface IP Commands The following are examples of the output display on OmniSwitch 10K switches: -> show ip interface ipip-1 Interface Name = ipip-1 SNMP Interface Index 13600001, IP Address 25.25.25.1, Subnet Mask 255.255.255.0, Device IPIP Tunnel, Tunnel Source Address 23.23.23.1 Tunnel Destination Address 23.23.23.2,...
Page 519 IP Commands show ip interface output definitions (continued) Operational State Reason Indicates why the operational state of the interface is down: • interface-up—The admin state of the interface is up. • unbound—No device is bound to the interface. • device-down—Device bound to the interface is down. •...
Page 520: Show Ip Routes
show ip routes IP Commands show ip routes Displays the IP Forwarding table. show ip routes [summary] Syntax Definitions summary Displays a summary of routing protocols that appear in the IP Forward- ing table. Defaults By default, all routes are displayed. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 521 IP Commands show ip routes output definitions Dest Addr Destination IP address. Subnet Mask Destination IP address IP subnet mask. Gateway Addr IP address of the gateway from which this address was learned. Age of the entry. If the entry is less than a day old, it is displayed in hh/mm/ss format.
Page 522: Show Ip Route-Pref
show ip route-pref IP Commands show ip route-pref Displays the IPv4 routing preferences of a router. show ip route-pref Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip route-pref Protocol Route Preference Value ------------+------------------------ Local Static OSPF EBGP IBGP...
Page 523 IP Commands show ip route-pref MIB Objects alaIprmRtPrefTable alaIprmRtPrefLocal alaIprmRtPrefStatic alaIprmRtPrefOspf alaIprmRtPrefRip alaIprmRtPrefEbgp alaIprmRtPrefIbgp OmniSwitch CLI Reference Guide March 2011 page 10-105...
Page 524: Show Ip Redist
show ip redist IP Commands show ip redist Displays the IPv4 route map redistribution configuration. show ipv6 redist [rip | ospf | bgp] Syntax Definitions Displays route map redistribution configurations that use RIP as the destination (into) protocol. ospf Displays route map redistribution configurations that specify OSPF as the destination (into) protocol.
Page 525 IP Commands show ip redist output definitions Source Protocol The protocol from which the routes are learned. Destination Protocol The protocol into which the source protocol routes are redistributed. Status The administrative status (Enabled or Disabled) of the route map redistribution configuration.
Page 526: Show Ip Access-List
show ip access-list IP Commands show ip access-list Displays the details of the access list. show ip access-list [access-list-name] Syntax Definitions access-list-name Name of the access list. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines If the access-list-name is not specified in this command, all the access lists are displayed. Examples ->...
Page 527 IP Commands show ip access-list Release History Release 7.1.1; command was introduced Related Commands ip access-list Creates an access list for adding multiple IPv4 addresses to route maps. ip access-list address Adds multiple IPv4 addresses to the access list. MIB objects alaRouteMapAccessListIndex alaRouteMapAccessListAddressType alaRouteMapAccessListAddress...
Page 528: Show Ip Route-Map
show ip route-map IP Commands show ip route-map Displays the IP route maps configured on the switch. show ip route-map [route-map-name] Syntax Definitions route-map-name The name of the specific route map. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines If the route-map-name is not specified in this command, all the route maps are displayed. Examples ->...
Page 529 IP Commands show ip route-map Related Commands ip route-map action Creates a route map for redistribution and sets the status of route map to permit or deny. ip route-map match ip address Matches the route with the specified IPv4 address or with addresses contained in an IPv4 access list specified by the access list name.
Page 530: Show Ip Router Database
show ip router database IP Commands show ip router database Displays a list of all routes (static and dynamic) that exist in the IP router database. This database serves as a central repository where routes are first processed for redistribution and where duplicate routes are compared to determine the best route to use.
Page 531 IP Commands show ip router database Examples -> show ip router database Destination Gateway Protocol Metric VLAN -------------------+----------------+--------+------+----- 10.212.31.0/24 10.212.60.27 OSPF 10.212.31.0/24 10.212.61.27 OSPF 10.212.59.0/24 10.212.59.17 LOCAL 10.212.60.0/24 10.212.60.17 LOCAL 10.212.61.0/24 10.212.61.17 LOCAL 10.212.62.0/24 10.212.60.27 OSPF 10.212.62.0/24 10.212.61.27 OSPF 10.212.63.0/24 10.212.60.27 OSPF 10.212.63.0/24...
Page 532: Show Ip Routes
show ip router database IP Commands Release History Release 7.1.1; command introduced Related Commands show ip routes Displays the IP Forwarding table. page 10-114 OmniSwitch CLI Reference Guide March 2011...
Page 533: Show Ip Emp-Routes
IP Commands show ip emp-routes show ip emp-routes Displays the IP routes associated with the Ethernet Management Port (EMP). show ip emp-routes Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • This command displays the routes that are connected to the Ethernet Management Port (EMP). •...
Page 534 show ip emp-routes IP Commands Related Commands ping Tests whether an IP destination can be reached from the local switch. traceroute Finds the path taken by an IP packet from the local switch to a specified destination. page 10-116 OmniSwitch CLI Reference Guide March 2011...
Page 535: Show Ip Config
IP Commands show ip config show ip config Displays IP configuration parameters. show ip config Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip config IP directed-broadcast OFF, IP default TTL output definitions IP directed-broadcast Indicates whether the IP directed-broadcast feature is on or off. IP default TTL IP default TTL interval.
Page 536: Show Ip Protocols
show ip protocols IP Commands show ip protocols Displays switch routing protocol information and status. show ip protocols Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip protocols IP Protocols RIP status = Not Loaded, OSPF status = Loaded, ISIS status = Not Loaded,...
Page 537 IP Commands show ip protocols Related Commands ip router primary-address Configures the router primary IP address. ip router router-id Configures the router ID for the router. MIB Objects alaIpRouteSumTable alaIpRouteProtocol OmniSwitch CLI Reference Guide March 2011 page 10-119...
Page 538: Show Ip Router-Id
show ip router-id IP Commands show ip router-id Displays the primary IP address and router ID of the switch, if configured. show ip router-id Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip router-id Router ID = 1.1.1.1, Primary addr = 31.0.0.1 output definitions...
Page 539: Show Ip Service
IP Commands show ip service show ip service Displays the current status of TCP/UDP service ports. show ip service Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines The display output from this command also includes the service port number. Examples ->...
Page 540 show ip service IP Commands Related Commands ip service Enables (opens) or disables (closes) well-known TCP/UDP service ports. MIB Objects alaIpServiceTable alaIpServiceType alaIpServicePort alaIpServiceStatus alaIpPortServiceTable alaIpPortServicePort alaIpPortServiceStatus page 10-122 OmniSwitch CLI Reference Guide March 2011...
Page 541: Show Ip Dos Arp-Poison
IP Commands show ip dos arp-poison show ip dos arp-poison Displays the number of attacks detected for configured ARP poison restricted-addresses. show ip dos arp-poison Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip dos arp-poison IP Address Attacks -----------------------------------+------------...
Page 542: Show Arp
show arp IP Commands show arp Displays the ARP table. The ARP table contains a listing of IP addresses and their corresponding transla- tions to physical MAC addresses. show arp [ip_address | hardware_address] Syntax Definitions ip_address IP address of the entry you want to view. hardware_address MAC address of the entry you want to view.
Page 543 IP Commands show arp output definitions (continued) Port The port on the switch attached to the device identified by the IP address. Interface The interface to which the entry belongs (e.g., VLAN, EMP). Release History Release 7.1.1; command introduced Related Commands ip service Adds a permanent entry to the ARP table.
Page 544: Show Arp Filter
show arp filter IP Commands show arp filter Displays a list of ARP filters configured for the switch. show arp filter [ip_address] Syntax Definitions ip_address IP address of the filter entry you want to view. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 545 IP Commands show arp filter Release History Release 7.1.1; command introduced Related Commands arp filter Adds a permanent entry to the ARP table. clear arp filter Deletes all dynamic entries from the ARP table. MIB Objects alaIpArpFilterTable alaIpArpFilterIpAddr alaIpArpFilterIpMask alaIpArpFilterVlan alaIpArpFilterMode alaIpArpFilterType OmniSwitch CLI Reference Guide...
Page 546: Show Icmp Control
show icmp control IP Commands show icmp control Allows the viewing of the ICMP control settings. show icmp control Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use this command to view the status of the various ICMP messages. It is also useful to determine the type and code of the less common ICMP messages.
Page 547 IP Commands show icmp control timestamp reply enabled information request(obsolete) enabled information reply(obsolete) enabled address mask request enabled address mask reply enabled output definitions Name The name of the ICMP message. Type The ICMP message type. This along with the ICMP code specify the kind of ICMP message.
Page 548: Show Icmp Statistics
show icmp statistics IP Commands show icmp statistics Displays Internet Control Message Protocol (ICMP) statistics and errors. ICMP is a network layer proto- col within the IP protocol suite that provides message packets to report errors and other IP packet process- ing information back to the source.
Page 549 IP Commands show icmp statistics output definitions (continued) Time exceeded Number of “time exceeded” messages that were sent/received by the switch. These occur when a packet is dropped because the TTL counter reaches zero. When a large number of these occur, it is a symptom that packets are looping, that congestion is severe, or that the TTL counter value is set too low.
Page 550: Show Tcp Statistics
show tcp statistics IP Commands show tcp statistics Displays TCP statistics. show tcp statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show tcp statistics Total segments received = 235080, Error segments received = Total segments sent 363218, Segments retransmitted Reset segments sent...
Page 551 IP Commands show tcp statistics output definitions (continued) Attempt fails Number of times attempted TCP connections have failed. Established resets Number of times TCP connections have been reset from the "Estab- lished" or "Close Wait" state to the “Closed” state. Release History Release 7.1.1;...
Page 552: Show Tcp Ports
show tcp ports IP Commands show tcp ports Displays the TCP connection table. show tcp ports Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use this table to check the current available TCP connections. Examples -> show tcp ports Local Address Local Port Remote Address...
Page 553 IP Commands show tcp ports output definitions (continued) Remote Port Remote port number for this TCP connection. The range is 0–65535. State State of the TCP connection, as defined in RFC 793. A connection progresses through a series of states during its lifetime: •...
Page 554: Show Udp Statistics
show udp statistics IP Commands show udp statistics Displays UDP errors and statistics. show udp statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines This command displays cumulative statistics since the last time the switch was powered on or since the last reset of the switch.
Page 555: Show Udp Ports
IP Commands show udp ports show udp ports Displays the UDP Listener table. The table shows the local IP addresses and the local port number for each UDP listener. show udp ports Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 556: Show Ip Dos Config
show ip dos config IP Commands show ip dos config Displays the configuration parameters of the DoS scan for the switch. show ip dos config Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines This command allows the user to view the configuration parameters of the DoS scan. The scan keeps a record of the penalties incurred by certain types of packets on TCP and UDP ports.
Page 557 IP Commands show ip dos config output definitions DoS trap generation Displays the status of DoS trap generation. It is either ENABLED or DISABLED. This is set using the ip dos trap command. DoS port scan threshold The penalty threshold setting. When enough packets have increased the penalty number to this setting, a trap is generated to warn the adminis- trator that a DoS attack is in progress.
Page 558: Show Ip Dos Statistics
show ip dos statistics IP Commands show ip dos statistics Displays the statistics on detected DoS attacks for the switch. show ip dos statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • This command displays the number of attacks the switch has detected for several types of DoS attacks. •...
Page 559 IP Commands show ip dos statistics Related Commands show ip dos config Displays the configuration parameters of the DoS scan for the switch. MIB Objects alaDoSTable alaDoSType OmniSwitch CLI Reference Guide March 2011 page 10-141...
Page 560: Show Vrf
show vrf IP Commands show vrf Displays the Multiple VRF instance configuration for the switch. show vrf Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Information is displayed for all VRF instances configured on the switch. Examples -> show vrf Virtual Routers Protocols -----------------------------...
Page 561: Chapter 11 Ipv6 Commands
11 IPv6 Commands This chapter details Internet Protocol Version 6 (IPv6) commands for the switch (including RIPng commands). IPv6 (documented in RFC 2460) is designed as a successor to IPv4. The changes from IPv4 to IPv6 fall primarily into the following categories: Expanded Routing and Addressing Capabilities - IPv6 increases the IP address size from 32 bits to 128 bits, to support more levels of addressing hierarchy and a much greater number of addressable nodes, and simpler auto-configuration of addresses.
Page 562 IPv6 Commands A summary of the IPv6 commands is listed here: IPv6 ipv6 interface ipv6 address ipv6 address global-id ipv6 address local-unicast ipv6 dad-check ipv6 hop-limit ipv6 pmtu-lifetime ipv6 neighbor stale-lifetime ipv6 neighbor ipv6 prefix ipv6 static-route ipv6 static-route ipv6 route-pref ping6 traceroute6 show ipv6 icmp statistics...
Page 563: Ipv6 Interface
IPv6 Commands ipv6 interface ipv6 interface Configures an IPv6 interface on a VLAN or IPv6 tunnel. ipv6 interface if_name [vlan vid | tunnel {tid | 6to4}] admin-state [enable | disable] [base-reachable-time time] [ra-send {yes | no}] [ra-max-interval interval] [ra-managed-config-flag {true | false}] [ra-other-config-flag {true | false}] [ra-reachable-time time] [ra-retrans-timer time]...
Page 564 ipv6 interface IPv6 Commands ra-retrans-timer time Value, in milliseconds, to be placed in the retransmit timer field in router advertisements sent on this interface. The value zero indicates that the time is unspecified by the router. mtu size The maximum transmission unit for a tunnel interface. Use the vlan command’s mtu-ip to set for a VLAN.
Page 565 IPv6 Commands ipv6 interface Defaults parameter default ra-send ra-max-interval ra-managed-config-flag false ra-reachable-time ra-retrans-timer ra-default-lifetime calculated ra-min-interval calculated ra-send-mtu ra-clock-skew base-reachable-time retrans-timer 1000 dad-transmits ra-other-config-flag false ra-hop-limit Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of this command to delete an interface. •...
Page 566 ipv6 interface IPv6 Commands Examples -> ipv6 interface Test vlan 1 -> ipv6 interface Test_Tunnel tunnel 2 Release History Release 7.1.1; command was introduced. Related Commands show ipv6 interface Displays IPv6 Interface Table. show ipv6 tunnel configured Displays IPv6 Configured Tunnel. show ipv6 tunnel 6to4 Displays IPv6 6to4 tunnel information.
Page 567: Ipv6 Interface Tunnel Source Destination
IPv6 Commands ipv6 interface tunnel source destination ipv6 interface tunnel source destination Configures the source and destination IPv4 addresses for a configured tunnel. ipv6 interface if_name tunnel {[source ipv4_source] [destination ipv4_destination]} Syntax Definitions if_name Name assigned to the tunnel interface. ipv4_source Source IPv4 address for the configured tunnel.
Page 568: Ipv6 Address
ipv6 address IPv6 Commands ipv6 address Configures an IPv6 address for an IPv6 interface on a VLAN, configured tunnel, or a 6to4 tunnel. There are different formats for this command depending on the address type. ipv6 address ipv6_address /prefix_length [anycast] {if_name | loopback} no ipv6 address ipv6_address [anycast] {if_name | loopback} ipv6 address ipv6_prefix eui-64 {if_name | loopback} no ipv6 address ipv6_prefix eui-64 {if_name | loopback}...
Page 569 IPv6 Commands ipv6 address Examples -> ipv6 address 2001:DB8:4132:86::19A/64 Test_Lab -> ipv6 address 2002:C633:6489::35/64 Test_6to4 Release History Release 7.1.1; command was introduced. Related Commands show ipv6 interface Displays IPv6 Interface Table. MIB Objects IPv6IfIndex alaIPv6InterfaceAddressTable alaIPv6InterfaceAddress alaIPv6InterfaceAddressAnycastFlag alaIPv6InterfaceEUI64AddressPrefixLength alaIPv6InterfaceEUI64AddressrowStatus For EUI-64 Addresses: alaIPv6InterfaceEUI64AddresssTable alaIPv6InterfaceEUI64Address alaIPv6InterfaceEUI64AddressPrefixLength...
Page 570: Ipv6 Address Global-Id
ipv6 address global-id IPv6 Commands ipv6 address global-id Automatically generates or allows a new global ID to be entered. ipv6 address global-id {generate | globalID} Syntax Definitions generate Automatically generates the global ID. globalID A 5-byte global ID value specified in the form hh:hhhh:hhhh Defaults By default, the IPv6 global ID is set to all zeros.
Page 571: Ipv6 Address Local-Unicast
IPv6 Commands ipv6 address local-unicast ipv6 address local-unicast Creates a IPv6 local unicast address using the configured global ID. ipv6 address local-unicast [global-id globalID] [subnet-id subnetID] {interface-id interfaceID | eui-64} [prefix-length prefixLength] {if-name | loopback} [no] ipv6 address local-unicast [global-id globalID] [subnet-id subnetID] {interface-id interfaceID | eui-64} [prefix-length prefixLength] {if-name | loopback} Syntax Definitions globalID...
Page 572 ipv6 address local-unicast IPv6 Commands Examples -> ipv6 address local-unicast global-id 0073:110:255 subnet-id 23 interface-id 215:60ff:fe7a:adc0 prefix-length 64 loopback Release History Release 7.1.1; command was introduced. Related Commands ipv6 address global-id Automatically generates or allows a new global ID to be entered. show ipv6 information Displays IPv6 information.
Page 573: Ipv6 Dad-Check
IPv6 Commands ipv6 dad-check ipv6 dad-check Runs a Duplicate Address Detection (DAD) check on an address that was marked as duplicated. ipv6 dad-check ipv6_address if_name Syntax Definitions ipv6_address IPv6 address. ip_name Name assigned to the interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines The switch performs DAD check when an interface is attached and its VLAN first enters the active state.
Page 574: Ipv6 Hop-Limit
ipv6 hop-limit IPv6 Commands ipv6 hop-limit Configures the value placed in the hop limit field in the header of all IPv6 packets that are originated by the switch. It also configures the value placed in the hop limit field in router advertisements. ipv6 hop-limit value no ipv6 hop-limit Syntax Definitions...
Page 575: Ipv6 Pmtu-Lifetime
IPv6 Commands ipv6 pmtu-lifetime ipv6 pmtu-lifetime Configures the minimum lifetime for entries in the path MTU Table. ipv6 pmtu-lifetime time Syntax Definitions time Minimum path MTU entry lifetime, in minutes. Valid range is 10–1440. Defaults parameter default time Platforms Supported OmniSwitch 10K Usage Guidelines Examples...
Page 576: Ipv6 Neighbor Stale-Lifetime
ipv6 neighbor stale-lifetime IPv6 Commands ipv6 neighbor stale-lifetime Configures the minimum lifetime for neighbors in the unconfirmed state. ipv6 neighbor stale-lifetime stale-lifetime Syntax Definitions stale-lifetime Minimum lifetime for neighbor entries in the stale state (5–2800). Defaults parameter default stale-lifetime Platforms Supported OmniSwitch 10K Usage Guidelines Examples...
Page 577: Ipv6 Neighbor
IPv6 Commands ipv6 neighbor ipv6 neighbor Configures a static entry in IPv6 Neighbor Table. ipv6 neighbor ipv6_address hardware_address {if_name} {port slot/port|linkagg num} no ipv6 neighbor ipv6_address {if_name} Syntax Definitions ipv6_address IPv6 address that corresponds to the hardware address. hardware_address MAC address in hex format (e.g., 00:00:39:59:F1:0C). if_name Name assigned to the interface on which the neighbor resides.
Page 578 ipv6 neighbor IPv6 Commands MIB Objects IPv6IfIndex alaIPv6NeighborTable alaIPv6NeighborNetAddress alaIPv6NeighborPhysAddress alaIPv6NeighborSlot alaIPv6NeighborPort alaIPv6NeighborRowStatus alaIPv6NeighborStaleLifetime page 11-18 OmniSwitch CLI Reference Guide March 2011...
Page 579: Ipv6 Prefix
IPv6 Commands ipv6 prefix ipv6 prefix Configures an IPv6 prefix on an interface. Used for configuring prefixes for router advertisements. ipv6 prefix ipv6_address /prefix_length if_name [valid-lifetime time] [preferred-lifetime time] [on-link-flag {true | false} [autonomous-flag {true | false}] if_name no ipv6 prefix ipv6_address /prefix_length if_name Syntax Definitions ipv6_address IPv6 address of the interface.
Page 580 ipv6 prefix IPv6 Commands Release History Release 7.1.1; command was introduced. Related Commands show ipv6 prefixes Displays IPv6 prefixes used in router advertisements. MIB Objects IPv6IfIndex alaIPv6InterfacePrefixTable alaIP6vInterfacePrefix alaIP6vInterfacePrefixLength alaIP6vInterfacePrefixValidLifetime alaIP6vInterfacePrefixPreferredLifetime alaIP6vInterfacePrefixonLinkFlag alaIP6vInterfacePrefixAutonomousFlag alaIP6vInterfacePrefixRowStatus page 11-20 OmniSwitch CLI Reference Guide March 2011...
Page 581: Ipv6 Static-Route
IPv6 Commands ipv6 static-route ipv6 static-route Creates/deletes an IPv6 static route. Static routes are user-defined; they carry a higher priority than routes created by dynamic routing protocols. That is, static routes always have priority over dynamic routes, regardless of the metric value. ipv6 static-route ipv6_prefix/prefix_length gateway ipv6_address [if_name] [metric metric] no ipv6 static-route ipv6_prefix/prefix_length gateway ipv6_address [if_name] Syntax Definitions...
Page 582 ipv6 static-route IPv6 Commands Related Commands show ipv6 routes Displays IPv6 Forwarding Table. show ipv6 router database Displays a list of all routes (static and dynamic) that exist in the IPv6 router database. MIB Objects alaIprmv6StaticRouteTable alaIprmv6StaticRouteDest alaIprmv6StaticRoutePrefixLength alaIprmv6StaticRouteNextHop alaIprmv6StaticRouteIfIndex alaIprmv6StaticRouteMetric alaIprmv6StaticRouteRowStatus page 11-22...
Page 583: Ipv6 Route-Pref
IPv6 Commands ipv6 route-pref ipv6 route-pref Configures the route preference of a router. ipv6 route-pref {static | ospf | rip | ebgp | ibgp} value Syntax Definitions static Configures the route preference of static routes. ospf Configures the route preference of OSPF3 routes. Configures the route preference of RIPng routes.
Page 584 ipv6 route-pref IPv6 Commands Related Commands show ipv6 route-pref Displays the configured route preference of a router. MIB Objects alaIprmRtPrefTable alaIprmRtPrefLocal alaIprmRtPrefStatic alaIprmRtPrefOspf alaIprmRtPrefRip alaIprmRtPrefEbgp alaIprmRtPrefIbgp page 11-24 OmniSwitch CLI Reference Guide March 2011...
Page 585: Ping6
IPv6 Commands ping6 ping6 Tests whether an IPv6 destination can be reached from the local switch. This command sends an ICMPv6 echo request to a destination and then waits for a reply. To ping a destination, enter the ping6 command and enter either the destination’s IPv6 address or hostname.
Page 586 ping6 IPv6 Commands Examples -> ping6 2001:db8:302::44 -> ping6 fe80::2d0:95ff:fe6a:f458 vlanif-23 Release History Release 7.1.1; command was introduced. Related Commands traceroute6 Finds the path taken by an IPv6 packet from the local switch to a specified destination. page 11-26 OmniSwitch CLI Reference Guide March 2011...
Page 587: Traceroute6
IPv6 Commands traceroute6 traceroute6 Finds the path taken by an IPv6 packet from the local switch to a specified destination. This command displays the individual hops to the destination as well as some timing information. traceroute6 {ipv6_address | hostname} [if_name] [max-hop hop_count] [dest-port port_number] [probe-count probe] [size size] [host-names {yes|no}] Syntax Definitions ipv6_address...
Page 588 traceroute6 IPv6 Commands Release History Release 7.1.1; command was introduced. Related Commands ping6 Tests whether an IPv6 destination can be reached from the local switch. page 11-28 OmniSwitch CLI Reference Guide March 2011...
Page 589: Show Ipv6 Icmp Statistics
IPv6 Commands show ipv6 icmp statistics show ipv6 icmp statistics Displays IPv6 ICMP statistics. show ipv6 icmp statistics [if_name] Syntax Definitions if_name Display statistics only for this interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the ICMP table to monitor and troubleshoot the switch. Examples ->...
Page 590 show ipv6 icmp statistics IPv6 Commands Router Advertisements Neighbor Solicitations Neighbor Advertisements Redirects Administratively Prohibited output definitions Total Total number of ICMPv6 messages the switch received or attempted to send. Errors Number of ICMPv6 messages the switch sent or received but was unable to process because of ICMPv6-specific errors (bad checksums, bad length, etc.).
Page 591 IPv6 Commands show ipv6 icmp statistics MIB Objects ipv6IfIcmpTable ipv6IfIcmpInMsgs ipv6IfIcmpInErrors ipv6IfIcmpInDestUnreachs ipv6IfIcmpInAdminProhibs ipv6IfIcmpInTimeExcds ipv6IfIcmpInParmProblems ipv6IfIcmpInPktTooBigs ipv6IfIcmpInEchos ipv6IfIcmpInEchoReplies ipv6IfIcmpInRouterSolicits ipv6IfIcmpInRouterAdvertisements ipv6IfIcmpInNeighborSolicits ipv6IfIcmpInNeighborAdvertisements ipv6IfIcmpInRedirects ipv6IfIcmpInGroupMembQueries ipv6IfIcmpInGroupMembResponses ipv6IfIcmpInGroupMembReductions ipv6IfIcmpOutMsgs ipv6IfIcmpOutErrors ipv6IfIcmpOutDestUnreachs ipv6IfIcmpOutAdminProhibs ipv6IfIcmpOutTimeExcds ipv6IfIcmpOutParmProblems ipv6IfIcmpOutPktTooBigs ipv6IfIcmpOutEchos ipv6IfIcmpOutEchoReplies ipv6IfIcmpOutRouterSolicits ipv6IfIcmpOutRouterAdvertisements ipv6IfIcmpOutNeighborSolicits ipv6IfIcmpOutNeighborAdvertisements ipv6IfIcmpOutRedirects ipv6IfIcmpOutGroupMembQueries ipv6IfIcmpOutGroupMembResponses ipv6IfIcmpOutGroupMembReductions...
Page 592: Show Ipv6 Interface
show ipv6 interface IPv6 Commands show ipv6 interface Displays IPv6 Interface Table. show ipv6 interface [if_name | loopback] Syntax Definitions if_name Interface name. Limits the display to a specific interface. loopback Limits display to loopback interfaces. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 593 IPv6 Commands show ipv6 interface -> show ipv6 interface tunnel_6to4 tunnel_6to4 IPv6 interface index = 16777216(0x Administrative status = Disabled Operational status = Inactive Link-local address(es): Global unicast address(es): Anycast address(es): VRRP address(es): Joined group addresses: ff02::1 Maximum Transfer Unit (MTU) = 1280 Neighbor reachable time (sec) = 465 Base reachable time (sec)
Page 594 show ipv6 interface IPv6 Commands output definitions (continued) Send Router Advertisements Indicates if the router sends periodic router advertisements and responds to router solicitations on the interface. Maximum RA interval (sec) Maximum time between the transmission of unsolicited router adver- tisements over the interface.
Page 595 IPv6 Commands show ipv6 interface alaIPv6InterfaceTable alaIPv6InterfaceName alaIPv6InterfaceAddress alaIPv6InterfaceAddressPrefixLength alaIPv6InterfaceAddressVRRPFlag alaIPv6MulticastGroupAddress alaIPv6InterfaceMtu alaIPv6InterfaceReachableTime alaIPv6InterfaceBaseReachableTime alaIPv6InterfaceRetransTimer alaIPv6InterfaceDADTransmits alaIPv6InterfaceSendRouterAdvertisements alaIPv6InterfaceMaxRtrAdvInterval alaIPv6InterfaceMinRtrAdvInterval alaIPv6InterfaceAdvManagedFlag alaIPv6InterfaceAdvOtherConfigFlag alaIPv6InterfaceAdvReachableTime alaIPv6InterfaceAdvRetransTimer alaIPv6InterfaceClockSkew alaIPv6InterfaceAdvHopLimit alaIPv6InterfaceAdvSendMtu alaIPv6InterfaceAdvDefaultLifetime OmniSwitch CLI Reference Guide March 2011 page 11-35...
Page 596: Show Ipv6 Pmtu Table
show ipv6 pmtu table IPv6 Commands show ipv6 pmtu table Displays the IPv6 Path MTU Table. show ipv6 pmtu table Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 pmtu table 1-PMTU Entry PMTU entry minimum lifetime = 10m Destination Address Expires --------------------------------------------------------+--------+-------...
Page 597: Show Ipv6 Neighbors
IPv6 Commands show ipv6 neighbors show ipv6 neighbors Displays IPv6 Neighbor Table. show ipv6 neighbors [ipv6_prefix/prefix_length | if_name | hw hardware_address | static] Syntax Definitions ipv6_prefix/prefix_length IPv6 prefix. Restricts the display to those neighbors starting with the specified prefix. if_name Interface name.
Page 598 show ipv6 neighbors IPv6 Commands Release History Release 7.1.1; command was introduced. Related Commands ipv6 neighbor Configures a static entry in the IPv6 Neighbor Table. MIB Objects ipv6IfIndex alaIPv6NeighborTable alaIPv6NeighborNetAddress alaIPv6NeighborPhysAddress alaIPv6NeighborSlot alaIPv6NeighborPort alaIPv6NeighborType alaIPv6NeighborState page 11-38 OmniSwitch CLI Reference Guide March 2011...
Page 599: Clear Ipv6 Neighbors
IPv6 Commands clear ipv6 neighbors clear ipv6 neighbors Removes all entries, except static entries, from IPv6 Neighbor Table. clear ipv6 neighbors Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines This commands only clears dynamic entries. If static entries have been added to the table, they must be removed using the no form of the ipv6 neighbor command.
Page 600: Show Ipv6 Prefixes
show ipv6 prefixes IPv6 Commands show ipv6 prefixes Displays IPv6 prefixes used in router advertisements. show ipv6 prefixes Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 prefixes Legend: Flags: A = Autonomous Address Configuration, L = OnLink Valid Preferred Name...
Page 601 IPv6 Commands show ipv6 prefixes Release History Release 7.1.1; command was introduced. Related Commands ipv6 prefix Configures an IPv6 prefix on an interface. Used for configuring prefixes for router advertisements. MIB Objects IPv6AddrPrefixTable IPv6AddressPrefixEntry IPv6AddressPrefixLength IPv6AddressPrefixLinkFlag IPv6AddressPrefixAdvvalidLifetime IPv6AddressPrefixAdvPreferredLifetime alaIPv6InterfacePrefixTable alaIPv6InterfacePrefix alaIPv6InterfacePrefixLength alaIPv6InterfacePrefixValidLifetime alaIPv6InterfacePrefixPreferredLifetime...
Page 602: Show Ipv6 Routes
show ipv6 routes IPv6 Commands show ipv6 routes Displays IPv6 Forwarding Table. show ipv6 routes [ipv6_prefix/prefix_length | static] Syntax Definitions ipv6_prefix/prefix_length IPv6 prefix. Restricts the display to those routes starting with the speci- fied prefix. static Restricts display to statically configured routes. Defaults Platforms Supported OmniSwitch 10K...
Page 603 IPv6 Commands show ipv6 routes Release History Release 7.1.1; command was introduced. Related Commands ipv6 static-route Configures a static entry in the IPv6 route. MIB Objects IPv6RouteTable IPv6Routes IPv6RoutesPrefix IPV6RoutesStatic alaIPv6StaticRouteTable alaIPv6StaticRouteEntry OmniSwitch CLI Reference Guide March 2011 page 11-43...
Page 604: Show Ipv6 Route-Pref
show ipv6 route-pref IPv6 Commands show ipv6 route-pref Displays the IPv6 routing preference of the router. show ipv6 route-pref Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines The IPv6 version of BGP is not supported in the current release. Examples ->...
Page 605: Show Ipv6 Router Database
IPv6 Commands show ipv6 router database show ipv6 router database Displays a list of all routes (static and dynamic) that exist in the IPv6 router database. This database serves as a central repository where routes are first processed for redistribution and where duplicate routes are compared to determine the best route to use.
Page 606 show ipv6 router database IPv6 Commands Examples -> show ipv6 router database Legend: + indicates routes in use Total IPRM IPv6 routes: 5 Destination/Prefix Gateway Address Interface Protocol Metric -------------------+-------------------------+-----------------+---------+------- ::/0 2002:d468:8a89::137 v6if-6to4-137 Static 137:35:35::/64 fe80::2d0:95ff:fe12:f470 v6if-tunnel-137 OSPF 195:35::/64 fe80::2d0:95ff:fe12:f470 v6if-to-eagle OSPF 212:95:5::/64...
Page 607: Show Ipv6 Tcp Connections
IPv6 Commands show ipv6 tcp connections show ipv6 tcp connections Displays the TCP connections over the IPV6 table. show ipv6 tcp connections Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 tcp connections Local Address Port Remote Address Port State...
Page 608 show ipv6 tcp connections IPv6 Commands Related Commands show ipv6 tcp listeners Displays the TCP connections over the IPV6 listeners (endpoints awaiting a connection request). MIB Objects alaRipngInterfaceTable alaRipngInterfaceStatus alaRipngRouteTag alaRipngInvalidTimer alaRipngGarbageTimer alaRipngHolddownTimer alaRipngJitter alaRipngTriggeredSends page 11-48 OmniSwitch CLI Reference Guide March 2011...
Page 609: Show Ipv6 Tcp Listeners
IPv6 Commands show ipv6 tcp listeners show ipv6 tcp listeners Displays the TCP connections over the IPV6 listeners (endpoints awaiting a connection request). show ipv6 tcp listeners Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 tcp listeners Local Address Port ---------------------------------------------+-----...
Page 610 show ipv6 tcp listeners IPv6 Commands alaRipngRouteTag laRipngInvalidTimer alaRipngGarbageTimer alaRipngHolddownTimer alaRipngJitter alaRipngTriggeredSends page 11-50 OmniSwitch CLI Reference Guide March 2011...
Page 611: Show Ipv6 Traffic
IPv6 Commands show ipv6 traffic show ipv6 traffic Displays IPv6 traffic statistics. show ipv6 traffic [if_name] Syntax Definitions if_name Interface name. Restricts the display to the specified interface instead of global statistics. Defaults N/A. Platforms Supported OmniSwitch 10K Usage Guidelines The statistics show the cumulative totals since the last time the switch was powered on, the last reset of the switch was executed or the traffic statistics were cleared using the command.
Page 612 show ipv6 traffic IPv6 Commands Multicast packets output definitions Total Total number of input packets received, including those received in error. Header errors Number of input packets discarded due to errors in their IPv6 headers (e.g., version number mismatch, other format errors, hop count exceeded, and errors discovered in processing their IPv6 options).
Page 613 IPv6 Commands show ipv6 traffic Release History Release 7.1.1; command was introduced. Related Commands show ipv6 icmp statistics Displays IPv6 ICMP statistics. MIB Objects ipv6IfStatsTable ipv6IfStatsInReceives ipv6IfStatsInHdrErrors ipv6IfStatsInTooBigErrors ipv6IfStatsInNoRoutes ipv6IfStatsInAddrErrors ipv6IfStatsInUnknownProtos ipv6IfStatsInTruncatedPkts ipv6IfStatsInDiscards ipv6IfStatsInDelivers ipv6IfStatsOutForwDatagrams ipv6IfStatsOutRequests ipv6IfStatsOutDiscards ipv6IfStatsOutFragOKs ipv6IfStatsOutFragFails ipv6IfStatsOutFragCreates ipv6IfStatsReasmReqds ipv6IfStatsReasmOKs ipv6IfStatsReasmFails...
Page 614: Show Ipv6 Tunnel Configured
show ipv6 tunnel configured IPv6 Commands show ipv6 tunnel configured Displays IPv6 tunnel information and whether the 6to4 tunnel is enabled. show ipv6 tunnel configured Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 tunnel configured IPv6 6to4 tunnel: Enabled Configured Tunnels: Tunnel...
Page 615 IPv6 Commands show ipv6 tunnel configured Related Commands ipv6 interface Configures an IPv6 interface on a VLAN or IPv6 tunnel. MIB Objects alaIPv6ConfigTunnelTable alaIPv6Tunnel6to4 alaIPv6ConfigTunnelv4Source alaIPv6ConfigTunnelv4Dest OmniSwitch CLI Reference Guide March 2011 page 11-55...
Page 616: Show Ipv6 Tunnel 6To4
show ipv6 tunnel 6to4 IPv6 Commands show ipv6 tunnel 6to4 Displays IPv6 tunnel information and whether the 6to4 tunnel is enabled. show ipv6 tunnel 6to4 Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 tunnel 6to4 tunnel_6to4 Status = Disabled IPv6 Address(es):...
Page 617: Show Ipv6 Udp Ports
IPv6 Commands show ipv6 udp ports show ipv6 udp ports Displays UDP Over IPv6 Listener Table. This table contains information about UDP/IPv6 endpoints. show ipv6 udp ports Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Only endpoints utilizing IPv6 addresses are displayed in this table. Examples ->...
Page 618 show ipv6 udp ports IPv6 Commands MIB Objects IPv6UdpTable IPv6UdpEntry IPv6UdpLocalAddress IPv6UdpLocalPort IPv6UdpIfIndex page 11-58 OmniSwitch CLI Reference Guide March 2011...
Page 619: Show Ipv6 Information
IPv6 Commands show ipv6 information show ipv6 information Displays IPv6 information. show ipv6 information Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 information Default hop limit = 64 Path MTU entry minimum lifetime (min) = 10 Neighbor stale lifetime (min) = 10 Local Unicast Global ID...
Page 620 show ipv6 information IPv6 Commands MIB Objects ipv6MibObjects Ipv6DefaultHopLimit alaIPv6ConfigTable alaIPv6PMTUMinLifetime alaIPv6NeighborTable alaIPv6NeighborStaleLifetime page 11-60 OmniSwitch CLI Reference Guide March 2011...
Page 621: Ipv6 Redist
IPv6 Commands ipv6 redist ipv6 redist Controls the conditions for redistributing IPv6 routes between different protocols. ipv6 redist {local | static | rip | ospf | isis | bgp} into {rip | ospf | isis | bgp} route-map route-map-name [admin-state {enable | disable}] no ipv6 redist {local | static | ospf | isis | bgp} into {rip | ospf | isis | bgp} [route-map route-map-name] Syntax Definitions local...
Page 622 ipv6 redist IPv6 Commands Examples -> ipv6 redist rip into ospf route-map rip-to-ospf1 -> ipv6 redist rip into ospf route-map rip-to-ospf2 -> no ipv6 redist rip into ospf route-map rip-to-ospf2 -> ipv6 redist local into rip route-map local-to-rip -> ipv6 redist local into rip route-map local-to-rip disable Release History Release 7.1.1;...
Page 623: Ipv6 Access-List
IPv6 Commands ipv6 access-list ipv6 access-list Creates an IPv6 access list that is used to specify multiple IPv6 addresses for a route map configuration. ipv6 access-list access-list-name no ipv6 access-list access-list-name Syntax Definitions access-list-name Name of the IPv6 access list (up to 20 characters). Defaults Platforms Supported OmniSwitch 10K...
Page 624: Ipv6 Access-List Address
ipv6 access-list address IPv6 Commands ipv6 access-list address Adds IPv6 addresses to the specified IPv6 access list. ipv6 access-list access-list-name address address/prefixLen [action {permit | deny}] [redist-control {all-subnets | no-subnets | aggregate}] no ipv6 access-list access-list-name address address/prefixLen Syntax Definitions access-list-name Name of the IPv6 access list (up to 20 characters).
Page 625 IPv6 Commands ipv6 access-list address • Use this command multiple times with the same access list name to add multiple addresses to the exist- ing IPv6 access list. Examples -> ipv6 access-list access1 address 2001::1/64 action permit -> ipv6 access-list access1 address 2001::1/64 redist-control aggregate ->...
Page 626: Show Ipv6 Redist
show ipv6 redist IPv6 Commands show ipv6 redist Displays the IPv6 route map redistribution configuration. show ipv6 redist [rip | ospf | bgp] Syntax Definitions Displays the route map redistribution configurations that specify RIP as the destination (into) protocol. ospf Displays the route map redistribution configurations that specify OSPF as the destination (into) protocol.
Page 627 IPv6 Commands show ipv6 redist output definitions Source Protocol The protocol from which the routes are learned. Destination Protocol The protocol into which the source protocol routes are redistributed.. Status The administrative status (Enabled or Disabled) of the route map redistribution configuration.
Page 628: Show Ipv6 Access-List
show ipv6 access-list IPv6 Commands show ipv6 access-list Displays the contents of the specified IPv6 access list. show ip access-list [access-list-name] Syntax Definitions access-list-name Name of the IPv6 access list. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines If the access-list-name is not specified in this command, all the access lists will be displayed. Examples ->...
Page 629 IPv6 Commands show ipv6 access-list Related Commands ipv6 access-list Creates an IPv6 access list for adding multiple IPv6 addresses to route maps. ipv6 access-list address Adds multiple IPv6 addresses to the IPv6 access list. MIB objects alaRouteMapAccessListIndex alaRouteMapAccessListAddressType alaRouteMapAccessListAddress alaRouteMapAccessListPrefixLength alaRouteMapAccessListAction alaRouteMapAccessListRedistControl OmniSwitch CLI Reference Guide...
Page 630: Ipv6 Load Rip
ipv6 load rip IPv6 Commands ipv6 load rip Loads RIPng into memory. When the switch is initially configured, you must load RIPng into memory to enable RIPng routing. ipv6 load rip Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 631: Ipv6 Rip Admin-State
IPv6 Commands ipv6 rip admin-state ipv6 rip admin-state Enables or disables RIPng on the switch. ipv6 rip admin-state {enable | disable} Syntax Definitions Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K Usage Guidelines RIPng must be loaded on the switch (ipv6 load rip) to enable RIP on the switch.
Page 632: Ipv6 Rip Invalid-Timer
ipv6 rip invalid-timer IPv6 Commands ipv6 rip invalid-timer Configures the amount of time a route remains active in RIB before being moved to the "Garbage" state. ipv6 rip invalid-timer seconds Syntax Definitions seconds Time, in seconds, that a route will remain in an “Active” state. Valid range is 1 - 300.
Page 633: Ipv6 Rip Garbage-Timer
IPv6 Commands ipv6 rip garbage-timer ipv6 rip garbage-timer Configures the RIPng garbage timer value. When a route in the RIB exceeds the configured Invalid Timer Value, the route is moved to a “Garbage” state in the the RIB. The garbage timer is the length of time a route will stay in this state before it is flushed from the RIB.
Page 634: Ipv6 Rip Holddown-Timer
ipv6 rip holddown-timer IPv6 Commands ipv6 rip holddown-timer Configures the amount of time a route is placed in a holddown state. Whenever a route is seen from the same gateway with a higher metric than the route in RIB, the route goes into holddown. This excludes route updates with an INFINITY metric.
Page 635: Ipv6 Rip Jitter
IPv6 Commands ipv6 rip jitter ipv6 rip jitter Configures an offset value for RIPng updates. This is the maximum (positive or negative) value that can be used to offset the update interval. For example, with an update interval of 30 seconds, and a jitter value of 5 seconds, the RIPng update packet would be sent somewhere (random) between 25 and 35 seconds from the previous update.
Page 636: Ipv6 Rip Route-Tag
ipv6 rip route-tag IPv6 Commands ipv6 rip route-tag Configures the route tag value for RIP routes generated by the switch. ipv6 rip route-tag value Syntax Definitions value Route tag value. Valid range is 0 – 65535. Defaults parameter default value Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 637: Ipv6 Rip Update-Interval
IPv6 Commands ipv6 rip update-interval ipv6 rip update-interval Configures the RIPng update interval. This is the interval, in seconds, that RIPng routing updates will be sent out. ipv6 rip update-interval seconds Syntax Definitions seconds Interval, in seconds, that RIPng routing updates are sent out. Valid range is 0–120.
Page 638: Ipv6 Rip Triggered-Sends
ipv6 rip triggered-sends IPv6 Commands ipv6 rip triggered-sends Configures the behavior of triggered updates. ipv6 rip triggered-sends {all | updated-only | none} Syntax Definitions All RIPng routes are added to any triggered updates. updated-only Only route changes that are causing the triggered update are included in the update packets.
Page 639: Ipv6 Rip Interface
IPv6 Commands ipv6 rip interface ipv6 rip interface Creates or deletes a RIPng interface. ipv6 rip interface if_name [no] ipv6 rip interface if_name Syntax Definitions if_name IPv6 interface name. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • By default, a RIPng interface is created in the enabled state. •...
Page 640 ipv6 rip interface IPv6 Commands Related Commands ipv6 redist Loads RIPng into memory. ipv6 rip admin-state Enables or disables RIPng on the switch. ipv6 rip interface recv-status Configures IPv6 RIPng interface “Receive” status. When this status is set to "enable", packets can be received on this interface. ipv6 rip interface send-status Configures IPv6 RIPng interface “Send”...
Page 641: Ipv6 Rip Interface Metric
IPv6 Commands ipv6 rip interface metric ipv6 rip interface metric Configures the RIPng metric or cost for a specified interface. You can set priorities for routes generated by a switch by assigning a metric value to routes generated by that switch’s RIPng interface. For example, routes generated by a neighboring switch may have a hop count of 1.
Page 642: Ipv6 Rip Interface Recv-Status
ipv6 rip interface recv-status IPv6 Commands ipv6 rip interface recv-status Configures IPv6 RIPng interface “Receive” status. When this status is set to "enable", packets can be received on this interface. When it is set to "disable", packets will not be received on this interface. ipv6 rip interface if_name recv-status {enable | disable} Syntax Definitions if_name...
Page 643: Ipv6 Rip Interface Send-Status
IPv6 Commands ipv6 rip interface send-status ipv6 rip interface send-status Configures IPv6 RIPng interface “Send” status. When this status is set to "enable", packets can be sent from this interface. When it is set to "disable", packets will not be sent from this interface. ipv6 rip interface if_name send-status {enable | disable} Syntax Definitions if name...
Page 644: Ipv6 Rip Interface Horizon
ipv6 rip interface horizon IPv6 Commands ipv6 rip interface horizon Configures the routing loop prevention mechanisms. ipv6 rip interface if_name horizon {none | split-only | poison} Syntax Definitions if_name IPv6 interface name. none | split-only | poison none - Disables loop prevention mechanisms. split-only - Enables split-horizon, without poison-reverse.
Page 645: Show Ipv6 Rip
IPv6 Commands show ipv6 rip show ipv6 rip Displays the RIPng status and general configuration parameters. show ipv6 rip Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ipv6 rip Status = Enabled, Number of routes = 10, Route tag = 0, Update interval...
Page 646 show ipv6 rip IPv6 Commands Related Commands ipv6 rip admin-state Enables or disables RIPng routing on the switch. ipv6 rip route-tag Configures the route tag value for RIP routes generated by the switch. ipv6 rip update-interval Configures the Interval, in seconds, so that RIPng routing updates are sent out.
Page 647: Show Ipv6 Rip Interface
IPv6 Commands show ipv6 rip interface show ipv6 rip interface Displays information for all or specified RIPng interfaces. show ipv6 rip interface [if_name] Syntax Definitions if_name IPv6 interface name. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines If you do not specify an interface, all IPv6 RIP interfaces are displayed. Examples ->...
Page 648 show ipv6 rip interface IPv6 Commands output definitions (continued) Packets Sent Number of packets sent by the interface. Metric RIPng metric (cost) configured for the interface. IPv6 interface index IPv6 interface index number. Interface status Interface status (Active/Inactive). Next update Seconds remaining until the next update on this interface.
Page 649 IPv6 Commands show ipv6 rip interface MIB Objects alaRipngInterfaceTable alaRipngInterfaceEntry alaRipngInterfaceStatus alaRipngInterfacePacketsRcvd alaRipngInterfacePacketsSent alaRipngInterfaceMetric alaRipngInterfaceIndex alaRipngInterfaceNextUpdate alaRipngInterfaceHorizon alaRipngInterfaceMTU alaRipngInterfaceSendStatus alaRipngInterfaceRecvStatus OmniSwitch CLI Reference Guide March 2011 page 11-89...
Page 650: Show Ipv6 Rip Peer
show ipv6 rip peer IPv6 Commands show ipv6 rip peer Displays a summary of the observed RIPng peers, or specific information about a peer when a peer address is provided. show ipv6 rip peer [ipv6_addresss] Syntax Definitions ipv6_addresss IPv6 address of the peer. Defaults N/A.
Page 651 IPv6 Commands show ipv6 rip peer output definitions Address IPv6 address of the peer. Seen on Interface Interface used to reach the peer. Packets Recvd Number of packets received from the peer. Last Update Number of seconds since the last update was received from the peer. Peer address Peer IPv6 address.
Page 652: Show Ipv6 Rip Routes
show ipv6 rip routes IPv6 Commands show ipv6 rip routes Displays all or a specific set of routes in RIPng Routing Table. show ipv6 rip routes [dest <ipv6_prefix/prefix_length>] | [gateway <ipv6_addr>] | [detail <ipv6 prefix/prefix_length>] Syntax Definitions dest Displays all routes whose destination matches the IPv6 prefix/prefix length.
Page 653 IPv6 Commands show ipv6 rip routes -> show ipv6 rip routes detail 9900::/100 Destination = 9900::, Mask length = 100, Gateway(1) = fe80::2d0:95ff:fe12:e050, Protocol = Local, Out Interface = nssa23, Metric = 1, Status = Installed, State = Active, = 10544s, = 0, Gateway(2) = fe80::2d0:95ff:fe12:da40,...
Page 654 show ipv6 rip routes IPv6 Commands MIB Objects alaRipngRouteTable alaRipngRouteEntry alaRipngRoutePrefixLen alaRipngRouteNextHop alaRipngRouteType alaRipngRouteAge alaRipngRouteTag alaRipngRouteStatus alaRipngRouteMetric page 11-94 OmniSwitch CLI Reference Guide March 2011...
Page 655: Chapter 12 Ipsec Commands
12 IPsec commands IPsec is a suite of protocols for securing IPv6 communications by authenticating and/or encrypting each IPv6 packet in a data stream. IPsec provides security services such as Encrypting traffic, Integrity validation, Authenticating the peers, and Anti-replay. IPsec protocols operate at network layer using appropriate security protocols, cryptographic algorithms, and cryptographic keys.
Page 656: Ipsec Key
ipsec key IPsec commands ipsec key Adds, modifies or deletes the authentication and encryption keys for a manually configured IPsec SA. ipsec key name {sa-authentication | sa-encryption} [encrypted] key no ipsec key name {sa-authentication | sa-encryption} Syntax Definitions name The name of this key (maximum 20 characters). sa-authentication Indicates that the key value is used for Authentication Header.
Page 657 IPsec commands ipsec key Release History Release 7.1.1; command introduced. Related Commands ipsec sa Adds, modifies, or deletes a manually configured IPsec Security Association (SA). show ipsec key Displays the keys for the manually configured IPsec SA. MIB Objects AlaIPsecKeyTable alaIPsecKeyName alaIPsecKeyType alaIPsecKeyEncrypted...
Page 658: Ipsec Security-Key
ipsec security-key IPsec commands ipsec security-key Sets the master security key for the switch. The master security key is used to encrypt and decrypt the configured SA keys. ipsec security-key [old_key] new_key Syntax Definitions old_key The current master security key. The key can be specified either in the hexadecimal format or as a string.
Page 659 IPsec commands ipsec security-key Related Commands ipsec key Adds, modifies or deletes the authentication and encryption keys for a manually configured IPsec SA. MIB Objects AlaIPsecSecurityKeyTable alaIPsecSecurityKeyCurrent alaIPsecSecurityKeyNew OmniSwitch CLI Reference Guide March 2011 page 12-5...
Page 660: Ipsec Policy
ipsec policy IPsec commands ipsec policy Adds, modifies, or removes a security policy. ipsec policy name [priority priority] [source {ipv6_address [/prefix_length]} [port port]] [destination {ipv6_address [/prefix_length]} [port port]] [protocol {any | icmp6 [type type]| tcp | udp | ospf | vrrp | number protocol}] [in | out] [discard | ipsec | none] [description description] [admin-state {enable | disable}] no ipsec policy name...
Page 661 IPsec commands ipsec policy Defaults parameter default priority port any | icmp6 | tcp | udp | ospf | vrrp | number icmp6 type not present discard | ipsec | none ipsec admin-state enable Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 662 ipsec policy IPsec commands Examples -> ipsec policy tcp_out source 2001:db8:3::12 destination 201:db8:4::a3e protocol tcp out ipsec description “Outbound TCP traffic” admin-state disable -> no ipsec policy tcp_out Release History Release 7.1.1; command introduced. Related Commands ipsec policy rule Adds, modifies, or removes an IPsec rule for a security policy. show ipsec policy Displays information about the security policies.
Page 663: Ipsec Policy Rule
IPsec commands ipsec policy rule ipsec policy rule Adds, modifies, or removes an IPsec rule for a security policy. ipsec policy name rule index [ah | esp] no ipsec policy name Syntax Definitions name The name of the security policy created by using the ipsec policy command.
Page 664 ipsec policy rule IPsec commands MIB Objects AlaIPsecSecurityPolicyRuleTable alaIPsecSecurityPolicyName alaIPsecSecurityPolicyRuleIndex alaIPsecSecurityPolicyRuleProtocol page 12-10 OmniSwitch CLI Reference Guide March 2011...
Page 665: Ipsec Sa
IPsec commands ipsec sa ipsec sa Adds, modifies, or deletes a manually configured IPsec Security Association (SA). ipsec sa name {esp | ah} [source ipv6_address ] [destination ipv6_address] [spi spi] [encryption {null | 3des-cbc | aes-cbc [key-size key_length]}] [authentication {none | hmac-md5 | hmac-sha1 | aes-xcbc- mac}] [description description] [admin-state {enable | disable}] no ipsec sa name Syntax Definitions...
Page 666 ipsec sa IPsec commands Usage Guidelines • The encryption parameter must be specified with the none option, if ESP is being used to verify integ- rity only. • If null is specified as the option for encryption, an integrity algorithm must be specified using the authentication parameter.
Page 667: Show Ipsec Policy
IPsec commands show ipsec policy show ipsec policy Displays information about the security policies. show ipsec policy [name] Syntax Definitions name The policy name. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the name parameter to display information about a specific security policy. Examples ->...
Page 668 show ipsec policy IPsec commands 1) esp 2) ah Description: Require AH and ESP headers on outgoing telnet traffic. output definitions Name The name of the security policy. Source Indicates the source of the traffic covered by this policy. Destination Indicates the destination of the traffic covered by this policy.
Page 669: Show Ipsec Sa
IPsec commands show ipsec sa show ipsec sa Displays information about manually configured IPsec Security Associations. show ipsec sa [name | esp | ah] Syntax Definitions name The name of the Security Association. Restricts the display to ESP type SAs. Restricts the display to AH type SAs.
Page 670 show ipsec sa IPsec commands -> show ipsec sa telnet-in-esp Name = telnet-in-esp Type = ESP Source = 2001:db8::/48 Destination = 2001:db8:1::24 = 8920 Encryption = aes-cbc(128) Authentication = hmac-sha1 State = active Description: Security association for traffic from 2001:db8::/48 to 2001:db8:1::24.
Page 671: Show Ipsec Key
IPsec commands show ipsec key show ipsec key Displays the keys for the manually configured IPsec SA. show ipsec key [sa-encryption | sa-authentication] Syntax Definitions sa-encryption Displays the encryption keys. sa-authentication Displays the authentication keys. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines The key values are not be displayed due to security reasons.
Page 672 show ipsec key IPsec commands Related Commands ipsec key Adds, modifies or deletes the authentication and encryption keys for a manually configured IPsec SA. MIB Objects AlaIPsecKeyTable alaIPsecKeyName alaIPsecKey page 12-18 OmniSwitch CLI Reference Guide March 2011...
Page 673: Show Ipsec Ipv6 Statistics
IPsec commands show ipsec ipv6 statistics show ipsec ipv6 statistics Displays IPsec statistics. show ipsec ipv6 statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples Inbound: Discarded = 2787 Policy violation Authentication Failure No SA found Outbound: Discarded = 5135 No SA found = 19...
Page 674 show ipsec ipv6 statistics IPsec commands MIB Objects AlaIPsecStatisticsTable alaIPsecStatisticsInDiscarded alaIPsecStatisticsInPolicyViolation alaIPsecStatisticsInAHAuthenticationFail alaIPsecStatisticsInNoSA alaIPsecStatisticsOutDiscarded alaIPsecStatisticsOutPolicyViolation alaIPsecStatisticsOutNoSA page 12-20 OmniSwitch CLI Reference Guide March 2011...
Page 675: Chapter 13 Rip Commands
13 RIP Commands Routing Information Protocol (RIP) is an Interior Gateway Protocol (IGP) that uses hop count as its rout- ing metric. RIP-enabled switches update neighboring switches by transmitting a copy of their own routing table. The RIP routing table always uses the most efficient route to a destination, that is, the route with the fewest hops and longest matching prefix.
Page 676: Ip Load Rip
ip load rip RIP Commands ip load rip Loads RIP into memory. When the switch is initially configured, you must load RIP into memory before it can be enabled. ip load rip Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 677: Ip Rip Admin-State
RIP Commands ip rip admin-state ip rip admin-state Enables/disables RIP on the switch. RIP performs well in small networks. By default, RIP packets are broadcast every 30 seconds, even if no change has occurred anywhere in a route or service. Depending on the size and speed of the network, these periodic broadcasts can consume a significant amount of band- width.
Page 678: Ip Rip Interface
ip rip interface RIP Commands ip rip interface Creates/deletes a RIP interface. Routing is enabled on a VLAN when you create a router interface. However, to enable RIP routing, you must also configure and enable a RIP routing interface on the VLAN’s IP router interface.
Page 679 RIP Commands ip rip interface Related Commands ip interface Creates a VLAN router interface. ip load rip Loads RIP into memory. When the switch is initially configured, you must load RIP into memory before it can be enabled. ip rip admin-state Enables/disables RIP routing on the switch.
Page 680: Ip Rip Interface Admin-State
ip rip interface admin-state RIP Commands ip rip interface admin-state Enables/disables a RIP interface. By default, a RIP interface is created in the disabled state. After creating a RIP interface, you must use this command to enable the interface. ip rip interface {interface_name} admin-state {enable | disable} Syntax Definitions interface_name The name of the interface.
Page 681 RIP Commands ip rip interface admin-state Related Commands ip interface Creates a VLAN router interface. ip load rip Loads RIP into memory. When the switch is initially configured, you must load RIP into memory before it can be enabled. ip rip admin-state Enables/disables RIP routing on the switch.
Page 682: Ip Rip Interface Metric
ip rip interface metric RIP Commands ip rip interface metric Configures the RIP metric or cost for a specified interface. You can set priorities for routes generated by a switch by assigning a metric value to routes generated by that switch’s RIP interface. For example, routes generated by a neighboring switch may have a hop count of 1.
Page 683: Ip Rip Interface Send-Version
RIP Commands ip rip interface send-version ip rip interface send-version Configures the send option for a RIP interface. This defines the type(s) of RIP packets that the interface will send. ip rip interface {interface_name} send-version {none | v1 | v1compatible | v2} Syntax Definitions interface_name The name of the interface.
Page 684 ip rip interface send-version RIP Commands Related Commands ip rip interface recv-version Configures the receive option for a RIP interface. MIB Objects rip2IfConfTable rip2IfConfAddress rip2IfConfSend page 13-10 OmniSwitch CLI Reference Guide March 2011...
Page 685: Ip Rip Interface Recv-Version
RIP Commands ip rip interface recv-version ip rip interface recv-version Configures the receive option for a RIP interface. This defines the type(s) of RIP packets that the inter- face will accept. ip rip interface {interface_name} recv-version {v1 | v2 | both | none} Syntax Definitions interface_name The name of the interface.
Page 686 ip rip interface recv-version RIP Commands Related Commands ip rip interface send-version Configures the send option for a RIP interface. MIB Objects rip2IfConfTable rip2IfConfAddress rip2IfConfReceive page 13-12 OmniSwitch CLI Reference Guide March 2011...
Page 687: Ip Rip Interface Ingress-Filter
RIP Commands ip rip interface ingress-filter ip rip interface ingress-filter Assigns an ingress route map filter to the specified RIP interface. Received route advertisements are compared against ingress filters. When a prefix matches the corresponding filter, that prefix is accepted on the interface.
Page 688 ip rip interface ingress-filter RIP Commands ip rip interface ingress-filter Assigns an ingress route map filter to the specified RIP interface. Received route advertisements are compared against ingress filters. When a prefix matches the corresponding filter, that prefix is accepted on the interface.
Page 689: Ip Rip Interface Egress-Filter
RIP Commands ip rip interface egress-filter ip rip interface egress-filter Assigns an egress route map filter to the specified RIP interface. Outbound route advertisements are compared against egress filters. When a prefix matches the corresponding filter, that prefix is sent on the interface.
Page 690: Ip Rip Force-Holddowntimer
ip rip force-holddowntimer RIP Commands ip rip force-holddowntimer Configures the forced hold-down timer value, in seconds, that defines an amount of time during which routing information regarding better paths is suppressed. A route enters into a forced hold-down state when an update packet is received that indicates the route is unreachable and when this timer is set to a non-zero value.
Page 691 RIP Commands ip rip force-holddowntimer Related Commands show ip rip Displays the RIP status and general configuration parameters (e.g., forced hold-down timer). MIB Objects alaProtocolRip alaRipForceHolddownTimer OmniSwitch CLI Reference Guide March 2011 page 13-17...
Page 692: Ip Rip Host-Route
ip rip host-route RIP Commands ip rip host-route Specifies whether or not RIP can add host routes (routes with a 32-bit mask) to the RIP table. ip rip host-route no ip rip host-route Syntax Definitions Defaults The default is to enable a default host route. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 693: Ip Rip Route-Tag
RIP Commands ip rip route-tag ip rip route-tag Configures the route tag value for RIP routes generated by the switch. ip rip route-tag value Syntax Definitions value Route tag value. Valid range is 0–2147483647. Defaults parameter default value Platforms Supported OmniSwitch 10K Usage Guidelines Only RIPv2 supports route tags.
Page 694: Ip Rip Interface Auth-Type
ip rip interface auth-type RIP Commands ip rip interface auth-type Configures the type of authentication that will be used for the RIP interface. By default, there is no authen- tication used for RIP. However, you can configure a password for a RIP interface. To configure a pass- word, you must first select the authentication type (simple or MD5), then configure a password.
Page 695: Ip Rip Interface Auth-Key
RIP Commands ip rip interface auth-key ip rip interface auth-key Configures the text string that will be used as the password for the RIP interface. If you configure simple or MD5 authentication, you must configure a text string that will be used as the password for the RIP interface.
Page 696: Ip Rip Update-Interval
ip rip update-interval RIP Commands ip rip update-interval Configures the time interval during which RIP routing updates are sent out. ip rip update-interval seconds Syntax Definitions seconds The RIP routing update interval, in seconds. The valid range is 1–120. Defaults parameter default seconds...
Page 697: Ip Rip Invalid-Timer
RIP Commands ip rip invalid-timer ip rip invalid-timer Configures the RIP invalid timer value that defines the time interval during which a route will remain active in Routing Information Base (RIB) before moving to the invalid state. ip rip invalid-timer seconds Syntax Definition seconds The RIP invalid timer value, in seconds.
Page 698: Ip Rip Garbage-Timer
ip rip garbage-timer RIP Commands ip rip garbage-timer Configures the RIP garbage timer value that defines the time interval, which must elapse before an expired route is removed from the RIB. ip rip garbage-timer seconds Syntax Definition seconds The RIP garbage timer value, in seconds. The valid range is 0–180. Defaults parameter default...
Page 699: Ip Rip Holddown-Timer
RIP Commands ip rip holddown-timer ip rip holddown-timer Configures the RIP hold-down timer value that defines the time interval during which a route remains in the hold-down state. ip rip holddown-timer seconds Syntax Definition seconds The hold-down time interval, in seconds. The valid range is 0–120. Defaults parameter default...
Page 700: Show Ip Rip
show ip rip RIP Commands show ip rip Displays the RIP status and general configuration parameters (e.g., forced hold-down timer). show ip rip Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip rip Status = Enabled Number of routes Host Route Support = Enabled...
Page 701 RIP Commands show ip rip Release History Release 7.1.1; command was introduced. Related Commands ip rip admin-state Enables/disables RIP routing on the switch. ip rip force-holddowntimer Configures the interval during which a RIP route remains in the forced hold-down state. ip rip update-interval Configures the time interval during which RIP routing updates are sent out.
Page 702: Show Ip Rip Routes
show ip rip routes RIP Commands show ip rip routes Displays the RIP routing database. The routing database contains all of the routes learned through RIP. show ip rip routes [ip_address ip_mask] Syntax Definitions ip_address 32-bit IP address. ip_mask The mask corresponding to the IP address. Defaults Platforms Supported OmniSwitch 10K...
Page 703 RIP Commands show ip rip routes output definitions Destination Destination network IP address. Gateway The Gateway IP address (switch from which the destination address was learned). State The associated state of the route, which can be A (Active), H (Holddown), or G (Garbage). Metric Metric associated with this network.
Page 704 show ip rip routes RIP Commands Release History Release 7.1.1; command was introduced. Related Commands ip rip host-route Enables/disables a host route to an individual host on a network. MIB Objects alaRipEcmpRouteTable alaRipEcmpRouteDest alaRipEcmpRouteMask alaRipEcmpRouteNextHop alaRipEcmpRouteType alaRipEcmpMetric alaRipEcmpStatus alaRipEcmpAge alaRipEcmpTag alaRipEcmpRouteState alaRipEcmpRouteStatus page 13-30...
Page 705: Show Ip Rip Interface
RIP Commands show ip rip interface show ip rip interface Displays RIP interface status and configuration. show ip rip interface [interface_name] Syntax Definitions interface_name The interface name. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Enter an IP address to view a specific interface. Enter the basic show ip rip interface command to show status for all interfaces.
Page 706 show ip rip interface RIP Commands output definitions (continued) Interface Config AuthKey The authentication key length used for the RIP interface. Length Interface Config Send-Version Interface send option (none, v1, v2, and v1 compatible). Interface Config Receive-Ver- Interface receive option (none, v1, v2, and both). sion Interface Config Default Met- Default redistribution metric.
Page 707: Show Ip Rip Peer
RIP Commands show ip rip peer show ip rip peer Displays active RIP neighbors (peers). An active peer is a switch that has sent a RIP packet within the last 180 seconds. If a peer does not send a RIP packet (request or response) within 180 seconds, it is aged out and will not be displayed.
Page 708 show ip rip peer RIP Commands Related Commands show ip rip interface Displays the RIP interface status and configuration. MIB Objects rip2PeerTable rip2PeerAddress rip2PeerDomain rip2PeerLastUpdate rip2PeerVersion rip2PeerRcvBadPackets rip2PeerRcvBadRoutes page 13-34 OmniSwitch CLI Reference Guide March 2011...
Page 709: Chapter 14 Bfd Commands
If the number of packets transmitted is not echoed back, then the system is declared down. Echo mode can be operated along with Asynchronous mode. MIB information for the BFD commands is as follows: Filename: ALCATEL-IND1-BFD-MIB Module: ALCATEL-IND-BFD-MIB A summary of the available commands is listed here:...
Page 710 BFD Commands BFD Interface commands ip bfd interface ip bfd interface admin-state ip bfd interface transmit ip bfd interface receive ip bfd interface multiplier ip ospf bfd-state ip bfd interface echo-interval show ip bfd interfaces Commands to configure BFD ip ospf bfd-state supported protocols ip ospf bfd-state all-interfaces ip ospf interface bfd-state...
Page 711: Ip Bfd Admin-State
BFD Commands ip bfd admin-state ip bfd admin-state Enables or disables the global BFD protocol status for the switch. ip bfd admin-state {enable | disable} Syntax Definitions enable Enables BFD. disable Disables BFD. Defaults By default, BFD is disabled for the switch. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 712: Ip Bfd Transmit
ip bfd transmit BFD Commands ip bfd transmit Configures the global transmit time interval for BFD control packets. This command specifies the mini- mum amount of time BFD waits between each transmission of control packets. ip bfd transmit transmit_interval Syntax Definitions transmit_interval The transmit time interval, in milliseconds.
Page 713: Ip Bfd Receive
BFD Commands ip bfd receive ip bfd receive Configures the global receive time interval for BFD control packets. This command specifies the mini- mum amount of time BFD waits to receive control packets before determining there is a problem. ip bfd receive receive_interval Syntax Definitions receive_interval The receive time interval, in milliseconds.
Page 714: Ip Bfd Multiplier
ip bfd multiplier BFD Commands ip bfd multiplier Configures the global BFD detection time multiplier. This command specifies a number that is used to calculate the BFD detection time used in the asynchronous mode. The detection time value that is speci- fied determines how long to wait before declaring that the BFD session is down.
Page 715: Ip Bfd Echo-Interval
BFD Commands ip bfd echo-interval ip bfd echo-interval Configures the global BFD echo packet time interval. The echo function is available with the asynchro- nous mode. Echo packets are transmitted to BFD peers to see if they loop back to the peer from which they originated.
Page 716: Ip Bfd Interface
ip bfd interface BFD Commands ip bfd interface Configures a BFD interface. ip bfd interface if_name no ip bfd interface if_name Syntax Definitions if_name The name of an existing IP interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of this command to delete a BFD interface. •...
Page 717: Ip Bfd Interface Admin-State
BFD Commands ip bfd interface admin-state ip bfd interface admin-state Enables or disables the administrative status of a BFD interface. ip bfd interface if_name admin-state {enable | disable} Syntax Definitions if_name The name of an existing BFD interface. enable Enables the BFD interface. disable Disables the BFD interface.
Page 718: Ip Bfd Interface Transmit
ip bfd interface transmit BFD Commands ip bfd interface transmit Configures the transmit time interval for the BFD interface. This command specifies the minimum amount of time BFD waits between each transmission of control packets from the interface. ip bfd interface if_name transmit transmit_interval Syntax Definitions if_name The name of an existing BFD interface.
Page 719: Ip Bfd Interface Receive
BFD Commands ip bfd interface receive ip bfd interface receive Configures the receive time interval for the BFD interface. This command specifies the minimum amount of time BFD waits to receive control packets on the interface before determining there is a problem. ip bfd interface if_name receive receive_interval Syntax Definitions if_name...
Page 720: Ip Bfd Interface Multiplier
ip bfd interface multiplier BFD Commands ip bfd interface multiplier Configures the BFD interface detection time multiplier. This command specifies a number that is used to calculate the BFD detection time used in the asynchronous mode. When an interface stops receiving pack- ets from a neighbor, the interface uses the detection time value to determine how long to wait before declaring that the BFD session is down.
Page 721: Ip Bfd Interface Echo-Interval
BFD Commands ip bfd interface echo-interval ip bfd interface echo-interval Configures the echo time interval for the BFD interface. The echo function is available with the asynchro- nous mode. Echo packets are transmitted to BFD peers to see if they loop back to the peer from which they originated.
Page 722: Ip Ospf Bfd-State
ip ospf bfd-state BFD Commands ip ospf bfd-state Enables or disables the BFD status for the OSPF protocol. ip ospf bfd-state {enable | disable} Syntax Definitions enable Enables BFD Status. disable Disables BFD Status. Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K...
Page 723 BFD Commands ip ospf bfd-state Related Commands ip ospf bfd-state all-interfaces Enables or disables BFD for all OSPF interfaces configured. ip ospf interface bfd-state Enables or disables BFD for a specific OSPF interface. ip ospf interface bfd-state drs- Establishes BFD sessions only on neighbors in full state. only ip ospf interface bfd-state all- Establishes BFD sessions with all neighbors of the corresponding...
Page 724: Ip Ospf Bfd-State All-Interfaces
ip ospf bfd-state all-interfaces BFD Commands ip ospf bfd-state all-interfaces Enables or disables BFD for all OSPF interfaces in the switch configuration. ip ospf bfd-state all-interfaces {enable | disable} Syntax Definitions enable Enables BFD for all the OSPF interfaces. disable Disables BFD for all the OSPF interfaces.
Page 725: Ip Ospf Interface Bfd-State
BFD Commands ip ospf interface bfd-state ip ospf interface bfd-state Enables or disables BFD for a specific OSPF interface. ip ospf interface if_name bfd-state {enable | disable} Syntax Definitions if_name The name of an existing OSPF interface. enable Enables the OSPF interface. disable Disables the OSPF interface.
Page 726: Ip Ospf Interface Bfd-State Drs-Only
ip ospf interface bfd-state drs-only BFD Commands ip ospf interface bfd-state drs-only Establishes BFD sessions only with neighbors that are in the full state. ip ospf interface if_name bfd-state drs-only Syntax Definitions if_name The name of an existing OSPF interface. Defaults By default, BFD is enabled for DR neighbors only.
Page 727: Ip Ospf Interface Bfd-State All-Neighbors
BFD Commands ip ospf interface bfd-state all-neighbors ip ospf interface bfd-state all-neighbors Establishes BFD sessions with all neighbors of the corresponding interface which are greater than or equal to “2-way” state. ip ospf interface if_name bfd-state all-neighbors {enable | disable } Syntax Definitions if_name The name of an existing OSPF interface.
Page 728: Ip Bgp Bfd-State
ip bgp bfd-state BFD Commands ip bgp bfd-state Enables or disables BFD for the BGP protocol. ip bgp bfd-state {enable | disable} Syntax Definitions enable Enables BGP. disable Disables BGP. Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 729: Ip Bgp Bfd-State All-Neighbors
BFD Commands ip bgp bfd-state all-neighbors ip bgp bfd-state all-neighbors Enables or disables BFD for all BGP neighbors. ip bgp bfd-state all-neighbors {enable | disable} Syntax Definitions enable Enables BFD for all the BGP neighbors. disable Disables BFD for all the BGP neighbors. Defaults Platforms Supported OmniSwitch 10K...
Page 730: Ip Bgp Neighbor Bfd-State
ip bgp neighbor bfd-state BFD Commands ip bgp neighbor bfd-state Enables or disables BFD for a specific BGP neighbor. ip bgp neighbor ipv4_address bfd-state {enable | disable} Syntax Definitions ipv4_address The IP address of the BGP neighbor. enable Enables BGP neighbor. disable Disables BGP neighbor.
Page 731: Vrrp Bfd-State
BFD Commands vrrp bfd-state vrrp bfd-state Enables or disables VRRP with the BFD protocol. vrrp bfd-state {enable | disable} Syntax Definitions enable Enables BFD for VRRP. disable Disables BFD for VRRP. Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 732: Vrrp Track Address Bfd-State
vrrp track address bfd-state BFD Commands vrrp track address bfd-state Enables or disable BFD for a specific track policy. vrrp track track_id address ipv4_address bfd-state {enable| disable} Syntax Definitions track_id The VRRP track number. ipv4_address The remote IP address. enable Enables BFD.
Page 733: Show Ip Bfd
BFD Commands show ip bfd show ip bfd Displays the global BFD configuration table. show ip bfd Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples -> show ip bfd BFD Version Number = 1, Admin Status = Enabled, Desired Tranmit Interval = 300, Minimum Receive Interval...
Page 734 show ip bfd BFD Commands Related Commands ip bfd admin-state Configures BFD at global level. ip bfd interface Configures BFD at interface level. MIB Objects alaBfdIntfTable alaBfdGlobalVersionNumber alaBfdGlobalAdminStatus alaBfdGlobalTxInterval alaBfdGlobalRxInterval alaBfdGlobalDetectMult alaBfdGlobalEchoRxInterval alaBfdGlobalProtocolApps page 14-26 OmniSwitch CLI Reference Guide March 2011...
Page 735: Show Ip Bfd Interfaces
BFD Commands show ip bfd interfaces show ip bfd interfaces Displays the BFD interface configuration table. show ip bfd interfaces [if_name] Syntax Definitions if_name The name of the BFD interface. Defaults By default, the configuration for all BFD interfaces is displayed. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 736 show ip bfd interfaces BFD Commands output definitions (continued) Authentication Present Refers to availability of BFD message authentication on the BFD inter- face. Oper Status Refers to BFD interface operational status. Release History Release 7.1.1; command was introduced. Related Commands ip bfd admin-state Configures BFD at global level.
Page 737: Show Ip Bfd Sessions
BFD Commands show ip bfd sessions show ip bfd sessions Displays all the BFD sessions for the switch. show ip bfd sessions [session_num] [slot slot_num] Syntax Definitions The BFD session number. Valid range is 1–1024. slot The current slot position used by the switch. Defaults Platforms Supported OmniSwitch 10K...
Page 738 show ip bfd sessions BFD Commands output definitions Local discriminator The local discriminator. Neighbor IP address The IP address of the BFD neighbor. Requested Session Type The bit map of the session type that is requested. . Interface IP address The IP address of the outgoing BFD interface for this session.
Page 739: Show Ip Bfd Sessions Statistics
BFD Commands show ip bfd sessions statistics show ip bfd sessions statistics Displays the statistics for all BFD sessions, a specific session or a specific slot. show ip bfd sessions statistics session_num Syntax Definitions session_num The BFD session number. Valid range is 1–1024. Defaults Platforms Supported OmniSwitch 10K...
Page 740 show ip bfd sessions statistics BFD Commands Release History Release 7.1.1; command was introduced. Related Commands show ip bfd Displays the global BFD configuration table. show ip bfd sessions Displays all BFD sessions. MIB Objects alaBfdSessPerfTable alaBfdSessDiscriminator alaBfdSessNeighborAddr alaBfdSessPerfPktOut alaBfdSessPerfPktIn alaBfdSessPerfEchoOut alaBfdSessPerfEchoIn alaBfdSessPerfLastCommLostDiag...
Page 741: Ip Static-Route All Bfd-State
BFD Commands ip static-route all bfd-state ip static-route all bfd-state Enables BFD for all static routes. ip static-route all bfd-state {enable| disable} Syntax Definitions enable Enables BFD. disable Disables BFD. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • When there are static route configured in the switch, BFD is enabled to track the gateway. •...
Page 742: Ip Static-Route Bfd-State
ip static-route bfd-state BFD Commands ip static-route bfd-state Enables or disables BFD for a specific static route. ip static-route ipv4_prefix/pfx_length gateway ipv4_host_address bfd-state {enable| disable} Syntax Definitions ipv4_prefix The destination IP address. pfx_length The prefix length for the destination IP address. gateway ipv4_host_address The gateway IP address.
Page 743: 15 Dhcp Relay Commands
BOOTP/DHCP packets occur. These CLI commands are applicable for all VRF instances. MIB information for DHCP Relay commands is as follows: Filename: AlcatelIND1UDPRelay.MIB Module: ALCATEL-IND1-UDP-RELAY-MIB A summary of the available commands is listed here. ip helper address ip helper vlan address ip helper standard ip helper per-vlan-only...
Page 744: Ip Helper Address
ip helper address DHCP Relay Commands ip helper address Adds or deletes a DHCP server IP address. DHCP Relay forwards BOOTP/DHCP broadcasts to and from the specified address. If multiple DHCP servers are used, configure one IP address for each server. ip helper address ip_address no ip helper address [ip_address] Syntax Definitions...
Page 745 DHCP Relay Commands ip helper address Related Commands ip helper vlan address Specifies or deletes DHCP Relay based on the VLAN of the DHCP request. ip helper forward-delay Sets the forward delay time value. DHCP Relay does not process a client packet unless the packet contains an elapsed boot time value that is equal to or greater than the configured value of the forward delay time.
Page 746: Ip Helper Vlan Address
ip helper vlan address DHCP Relay Commands ip helper vlan address Configures a DHCP Relay service for the specified VLAN. This command is used when a per-VLAN only relay service is active on the switch. It does not apply when a standard relay service is used. ip helper vlan vlan_id[-vlan_id2] address ip_address no ip helper vlan vlan_id[-vlan_id2] address ip_address Syntax Definitions...
Page 747 DHCP Relay Commands ip helper vlan address Related Commands ip helper per-vlan-only Sets the DHCP Relay forwarding option to process only DHCP packets received from a specific, identified VLAN. show ip helper Displays current DHCP Relay configuration information. show ip helper statistics Displays DHCP Relay statistics, including the number of client packets received and transmitted to the DHCP server and packets dropped due to forward delay time and maximum hops violations.
Page 748: Ip Helper Standard
ip helper standard DHCP Relay Commands ip helper standard Sets the DHCP Relay forwarding option to standard. All DHCP packets are processed by a global relay service. ip helper standard Syntax Definitions Defaults By default, the DHCP Relay forwarding option is set to standard. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 749: Ip Helper Per-Vlan-Only
DHCP Relay Commands ip helper per-vlan-only ip helper per-vlan-only Sets the DHCP Relay forwarding option to process only DHCP packets received from a specific, identified VLAN. This option allows each VLAN to have its own relay. ip helper per-vlan-only Syntax Definitions Defaults By default, the UDP forwarding option is set to standard.
Page 750 ip helper per-vlan-only DHCP Relay Commands MIB Objects iphelperStatTable iphelperForwOption page 15-8 OmniSwitch CLI Reference Guide March 2011...
Page 751: Ip Helper Forward-Delay
DHCP Relay Commands ip helper forward-delay ip helper forward-delay Sets the forward delay time value for the DHCP Relay configuration. The BOOTP/DHCP packet sent from the client contains the elapsed boot time. This is the amount of time, in seconds, since the client last booted.
Page 752 ip helper forward-delay DHCP Relay Commands MIB Objects iphelperStatTable iphelperForwDelay page 15-10 OmniSwitch CLI Reference Guide March 2011...
Page 753: Ip Helper Maximum-Hops
DHCP Relay Commands ip helper maximum-hops ip helper maximum-hops Sets the maximum number of hops value for the DHCP Relay configuration. This value specifies the maximum number of relays a BOOTP/DHCP packet is allowed to traverse until it reaches its server destination.
Page 754 ip helper maximum-hops DHCP Relay Commands MIB Objects iphelperStatTable iphelperMaxHops page 15-12 OmniSwitch CLI Reference Guide March 2011...
Page 755: Ip Helper Agent-Information
DHCP Relay Commands ip helper agent-information ip helper agent-information Enables or disables the DHCP relay agent information option (Option-82) feature. When this feature is enabled, local relay agent information is inserted into client DHCP packets when the agent forwards these packets to a DHCP server.
Page 756 ip helper agent-information DHCP Relay Commands MIB Objects iphelperAgentInformation page 15-14 OmniSwitch CLI Reference Guide March 2011...
Page 757: Ip Helper Agent-Information Policy
DHCP Relay Commands ip helper agent-information policy ip helper agent-information policy Configures a policy that determines how the DHCP relay agent handles the DHCP packets that already contain an Option-82 field. ip helper agent-information policy {drop | keep | replace} Syntax Definitions drop Drop DHCP packets that already contain an Option-82 field.
Page 758 ip helper agent-information policy DHCP Relay Commands Related Commands ip helper agent-information Enables the insertion of relay agent information Option-82 into DHCP packets. show ip helper Displays current DHCP Relay configuration information. show ip helper statistics Displays DHCP Relay statistics, including the number of client packets received and transmitted to the DHCP server and packets dropped due to forward delay time and maximum hops violations.
Page 759: Ip Helper Pxe-Support
DHCP Relay Commands ip helper pxe-support ip helper pxe-support Enables or disables relay agent support for Preboot Execution Environment (PXE) devices. ip helper pxe-support {enable | disable} Syntax Definitions enable Enables PXE support. disable Disables PXE support. Defaults By default, PXE support is disabled for the switch. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 760: Ip Helper Boot-Up
ip helper boot-up DHCP Relay Commands ip helper boot-up Enables or disables automatic IP address configuration for default VLAN 1 when an unconfigured switch boots up. If enabled, the switch broadcasts a BootP or a DHCP request packet at boot time. When the switch receives an IP address from a BootP/DHCP server, the address is assigned to default VLAN 1.
Page 761: Ip Helper Boot-Up Enable
DHCP Relay Commands ip helper boot-up enable ip helper boot-up enable Specifies the type of packet to broadcast (BootP or DHCP) when automatic IP address configuration is enabled for the switch. Note. Automatic IP address configuration only supports the assignment of a permanent IP address to the switch.
Page 762: Ip Udp Relay Port
ip udp relay port DHCP Relay Commands ip udp relay port Enables or disables UDP port relay for user-defined service ports that are not well-known. ip udp relay port port_num [description description] ip udp relay no port port_num Syntax Definitions port_num A service port number that is not well-known or user-defined.
Page 763 DHCP Relay Commands ip udp relay port MIB Objects iphelperxServicePortAssociationTable iphelperxServicePortAssociationService iphelperxServicePortAssociationPort iphelperxServicePortAssociationName iphelperxPortServiceAssociationTable iphelperxPortServiceAssociationService iphelperxPortServiceAssociationPort iphelperxPortServiceAssociationName OmniSwitch CLI Reference Guide March 2011 page 15-21...
Page 764: Ip Udp Relay Service
ip udp relay service DHCP Relay Commands ip udp relay service Enables or disables UDP port relay for generic UDP service ports ( NBNS, NBDD, or other well-known UDP ports). ip udp relay service {TFTP | TACACS | NTP | NBNS | NBDD | DNS} [description description] ip udp relay no service {TFTP | TACACS | NTP | NBNS | NBDD | DNS} Syntax Definitions TFTP...
Page 765 DHCP Relay Commands ip udp relay service Release History Release 7.1.1; command introduced. Related Commands ip udp relay service vlan Specifies the VLAN to which traffic from the specified UDP service port is forwarded. MIB Objects iphelperxServicePortAssociationTable iphelperxServicePortAssociationService iphelperxServicePortAssociationPort iphelperxServicePortAssociationName iphelperxPortServiceAssociationTable iphelperxPortServiceAssociationService iphelperxPortServiceAssociationPort...
Page 766: Ip Udp Relay Service Vlan
ip udp relay service vlan DHCP Relay Commands ip udp relay service vlan Specifies a VLAN on which traffic destined for a UDP port is forwarded. ip udp relay service {TFTP | TACACS | NTP | NBNS | NBDD | DNS} | port port_num [description description] vlan vlan_id[-vlan_id2] ip udp relay service {TFTP | TACACS | NTP | NBNS | NBDD | DNS} | port port_num no vlan vlan_id[-vlan_id2]...
Page 767 DHCP Relay Commands ip udp relay service vlan Examples -> ip udp relay service DNS vlan 10 -> ip udp relay service DNS vlan 500-550 -> ip udp relay service DNS no vlan 10 -> ip udp relay port 3047 vlan 20 ->...
Page 768: Show Ip Helper
show ip helper DHCP Relay Commands show ip helper Displays the current DHCP Relay and Relay Agent Information. show ip helper Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Displays information for all IP addresses configured. Examples The following example shows the show ip helper command output: ->...
Page 769 DHCP Relay Commands show ip helper output definitions PXE support Specifies the status (Enabled or Disabled) of the relay agent support for PXE devices. By default the PXE support is disabled. Configured through the ip helper pxe-support command. Forward option The current forwarding option setting: standard mode.
Page 770: Show Ip Helper Statistics
show ip helper statistics DHCP Relay Commands show ip helper statistics Displays the number of packets DHCP Relay has received, the number of packets dropped due to forward delay and maximum hops violations. It also displays the number of packets processed since the last time these statistics were displayed.
Page 771 DHCP Relay Commands show ip helper statistics output definitions Reception From Client Number of packets DHCP Relay has received from the DHCP client. Forw Delay Violation Number of packets dropped as a result of forward delay violations. A violation occurs if a client packet contains an elapsed boot time value that is less than the configured DHCP Relay forward delay time value.
Page 772: Show Ip Udp Relay
show ip udp relay DHCP Relay Commands show ip udp relay Displays the VLAN assignments to which the traffic received on the UDP service ports is forwarded. Displays the current configuration for UDP services by service name or by service port number. show ip udp relay [service {TFTP | TACACS | NTP | NBNS | NBDD | DNS} | port port_num] Syntax Definitions TFTP...
Page 773 DHCP Relay Commands show ip udp relay output definitions (continued) Port The UDP service port number. VLANs The VLAN assigned to the UDP service port that forwards traffic destined for that port. Use the ip udp relay service vlan command to configure this value.
Page 774: Show Ip Udp Relay Statistics
show ip udp relay statistics DHCP Relay Commands show ip udp relay statistics Displays the current statistics for each UDP port relay service. These statistics include the name of the service, the forwarding VLAN(s) configured for that service, and the number of packets the service has sent and received.
Page 775 DHCP Relay Commands show ip udp relay statistics -> show ip udp relay statistics port 1776 Service Vlan Pkts Sent Pkts Recvd -------------------+--------+-----------+----------- A UDP Protocol output definitions Service The active UDP service name. VLAN The VLAN assigned to the UDP service port that forwards traffic destined for that port.
Page 776: No Ip Helper Statistics
no ip helper statistics DHCP Relay Commands no ip helper statistics Resets the IP helper statistics for the specified VRF instances. no ip helper statistics [ global-only | server-only | address ip_address | vlan vlan_id {address ip_address}] Syntax Definitions global-only Specifies that only the global IP helper statistics must be reset.
Page 777 DHCP Relay Commands no ip helper statistics Related Commands show ip helper statistics Displays the current statistics for each UDP port relay service. MIB Objects iphelperStatsTable iphelperResetAllStats iphelperResetSrvStats OmniSwitch CLI Reference Guide March 2011 page 15-35...
Page 778: Ip Udp Relay No Statistics
ip udp relay no statistics DHCP Relay Commands ip udp relay no statistics Resets all the generic UDP Relay Service related statistics. ip udp relay no statistics Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • On applying this command, the UDP relay statistics are cleared and the show ip udp relay statistics command display no information.
Page 779: Chapter 16 Vrrp Commands
IPv6 address associated with a virtual router is called the master router, and forwards packets to that IP/ IPv6 address. If the master router becomes unavailable, the highest priority backup router will transition to the master state. The Alcatel-Lucent implementation of VRRP also supports the collective management of virtual routers on a switch.
Page 780 VRRP Commands The VRRP CLI commands are listed here: vrrp vrrp address vrrp track vrrp track-association vrrp trap vrrp delay vrrp interval vrrp priority vrrp preempt vrrp all vrrp set vrrp group vrrp group all vrrp group set vrrp group-association vrrp3 vrrp3 address vrrp3 trap...
Page 781: Vrrp
VRRP Commands vrrp vrrp Configures a new VRRP virtual router or modifies an existing one. Used to enable or disable a virtual router. vrrp vrid vlan_id [enable | disable | on | off] [priority priority] [preempt | no preempt] [[advertising] interval seconds] no vrrp vrid vlan_id Syntax Definitions...
Page 782 vrrp VRRP Commands Defaults parameter default enable | disable | on | off disable (off) priority preempt | no preempt preempt seconds Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of this command to remove a virtual router from the configuration. •...
Page 783 VRRP Commands vrrp Related Commands vrrp address Configures an IP address for a virtual router. show vrrp Displays the virtual router configuration for all virtual routers or for a specific virtual router. MIB Objects alaVrrp3OperTable alaVrrp3OperAdminState alaVrrp3OperPriority alaVrrp3OperPreemptMode alaVrrp3OperAdvertisementinterval alaVrrp3OperRowStatus OmniSwitch CLI Reference Guide March 2011 page 16-5...
Page 784: Vrrp Address
vrrp address VRRP Commands vrrp address Configures an IP address for a virtual router. vrrp vrid vlan_id address ipv4Addr vrrp vrid vlan_id no address ipv4Addr Syntax Definitions vrid The virtual router ID, in the range from 1–255. vlan_id The VLAN on which the virtual router is configured. ipv4Addr The virtual IP address associated with the specified virtual router.
Page 785: Vrrp Track
VRRP Commands vrrp track vrrp track Creates a new tracking policy or modifies an existing tracking policy. vrrp track track_id [enable | disable] [priority value] [ipv4-interface name | ipv6-interface name | port slot/port | address address] no vrrp track track_id Syntax Definitions track_id The ID of the tracking policy;...
Page 786 vrrp track VRRP Commands Examples -> vrrp track 2 enable priority 50 ipv4-interface Marketing -> vrrp track 3 enable priority 60 ipv6-interface Sales -> vrrp track 3 disable Release History Release 7.1.1; command was introduced. Related Commands vrrp track-association Associates a VRRP tracking policy with a virtual router. show vrrp track Displays information about tracking policies on the switch.
Page 787: Vrrp Track-Association
VRRP Commands vrrp track-association vrrp track-association Associates a VRRP tracking policy with a virtual router. vrrp vrid vlan_id track-association track_id vrrp vrid vlan_id no track-association track_id Syntax Definitions vrid The virtual router ID, in the range from 1–255. vlan_id The VLAN ID of the virtual router. track_id The ID of the tracking policy associated with the virtual router;...
Page 788: Vrrp Trap
vrrp trap VRRP Commands vrrp trap Enables or disables SNMP traps for VRRP. vrrp trap no vrrp trap Syntax Definitions Defaults By default, SNMP traps for VRRP are enabled. Platforms Supported OmniSwitch 10K Usage Guidelines SNMP traps must be enabled globally on the switch for VRRP traps to actually be sent. Examples ->...
Page 789: Vrrp Delay
VRRP Commands vrrp delay vrrp delay Configures the amount of time allowed for routing tables to stabilize before virtual routers are started. vrrp delay seconds Syntax Definitions seconds The amount of time after a reboot that virtual routers will wait before they go active;...
Page 790: Vrrp Interval
vrrp interval VRRP Commands vrrp interval Modifies the default advertising interval value assigned to the virtual routers on the switch. vrrp interval seconds Syntax Definitions seconds The default advertising interval for the virtual routers. The valid range is 1–255 seconds. Defaults parameter default...
Page 791 VRRP Commands vrrp interval Related Commands vrrp all Changes the administrative status of all the virtual routers on the switch. vrrp set Sets the new default parameter values to existing virtual routers on the switch. show vrrp Displays the virtual router configuration for all virtual routers or for a specific virtual router.
Page 792: Vrrp Priority
vrrp priority VRRP Commands vrrp priority Modifies the default priority value assigned to the virtual routers on the switch. vrrp priority priority Syntax Definitions priority The default priority value for the virtual routers. The valid range is 1–255. Defaults parameter default priority Platforms Supported...
Page 793 VRRP Commands vrrp priority Related Commands vrrp all Changes the administrative status of all the virtual routers on the switch. vrrp set Sets the new default parameter values to existing virtual routers on the switch. show vrrp Displays the virtual router configuration for all virtual routers or for a specific virtual router.
Page 794: Vrrp Preempt
vrrp preempt VRRP Commands vrrp preempt Modifies the default preempt mode assigned to the virtual routers on the switch. vrrp [preempt | no preempt] Syntax Definitions preempt Specifies that a higher priority router may preempt a lower priority master router by default. no preempt Specifies that a higher priority router may not preempt a lower priority master router by default.
Page 795 VRRP Commands vrrp preempt Related Commands vrrp all Changes the administrative status of all the virtual routers on the switch. vrrp set Sets the new default parameter values to existing virtual routers on the switch. show vrrp Displays the virtual router configuration for all virtual routers or for a specific virtual router.
Page 796: Vrrp All
vrrp all VRRP Commands vrrp all Changes the administrative status of all the virtual routers on the switch. vrrp [disable | enable | enable all] Syntax Definitions disable Disables all the virtual routers on the switch. enable Enables the virtual routers that have not previously been disabled individually or collectively through the vrrp group all command.
Page 797 VRRP Commands vrrp all Related Commands vrrp interval Modifies the default advertising interval value assigned to the vir- tual routers on the switch. vrrp priority Modifies the default priority value assigned to the virtual routers on the switch. vrrp preempt Modifies the default preempt mode assigned to the virtual routers on the switch.
Page 798: Vrrp Set
vrrp set VRRP Commands vrrp set Sets the new default parameter values to existing virtual routers on the switch. vrrp set [interval | priority | preempt | all | none] [ override] Syntax Definitions interval Sets the VRRP advertisement interval value to the new default value. priority Sets the priority value to the new default value.
Page 799 VRRP Commands vrrp set Related Commands vrrp interval Modifies the default advertising interval value assigned to the virtual routers on the switch. vrrp priority Modifies the default priority value assigned to the virtual routers on the switch. vrrp preempt Modifies the default preempt mode assigned to the virtual routers on the switch.
Page 800: Vrrp Group
vrrp group VRRP Commands vrrp group Creates a new virtual router group or modifies the configuration parameters of an existing virtual router group. vrrp group vrgid [interval seconds] [priority priority] [preempt | no preempt] no vrrp group vrgid Syntax Definitions vrgid The virtual router group ID, in the range from 1–255.
Page 801 VRRP Commands vrrp group Examples -> vrrp group 25 interval 50 priority 50 no preempt -> no vrrp group 25 Release History Release 7.1.1; command was introduced. Related Commands vrrp group all Changes the administrative status of all the virtual routers in a vir- tual router group using a single command.
Page 802: Vrrp Group All
vrrp group all VRRP Commands vrrp group all Changes the administrative status of all the virtual routers in a virtual router group using a single command. vrrp group vrgid [disable | enable | enable all] Syntax Definitions vrgid The virtual router group ID, in the range from 1–255. disable Disables all the virtual routers in the group.
Page 803 VRRP Commands vrrp group all Related Commands vrrp group Creates a new virtual router group or modifies the configuration parameters of an existing virtual router group. vrrp group set Sets the new modified default value to all the virtual routers in a vir- tual router group.
Page 804: Vrrp Group Set
vrrp group set VRRP Commands vrrp group set Sets the new modified default value to all the virtual routers in a virtual router group. vrrp group vrgid set [interval | priority | preempt | all] [override] Syntax Definitions vrgid The virtual router group ID, in the range from 1–255. interval Sets the VRRP advertisement interval value to the new default value.
Page 805 VRRP Commands vrrp group set Related Commands vrrp group Creates a new virtual router group or modifies the configuration parameters of an existing virtual router group. vrrp group all Changes the administrative status of all the virtual routers in a vir- tual router group using a single command.
Page 806: Vrrp Group-Association
vrrp group-association VRRP Commands vrrp group-association Adds a virtual router to a virtual router group. vrrp vrid vlan_id group-association vrgid vrrp vrid vlan_id no group-association vrgid Syntax Definitions vrid The virtual router ID, in the range from 1–255. vlan_id The VLAN on which the virtual router is configured. The VLAN must already be created and available on the switch.
Page 807 VRRP Commands vrrp group-association MIB Objects alaVrrpAssoGroupTable alaVrrpAssoGroupRowStatus OmniSwitch CLI Reference Guide March 2011 page 16-29...
Page 808: Vrrp3
vrrp3 VRRP Commands vrrp3 Configures a new VRRP3 virtual router or modifies an existing one. Used to enable or disable a virtual router. vrrp3 vrid vlan_id [enable | disable | on | off] [priority priority] [preempt | no preempt][accept | no accept] [[advertising] interval centiseconds] no vrrp3 vrid vlan_id Syntax Definitions...
Page 809 VRRP Commands vrrp3 Defaults parameter default enable | disable | on | off disable (off) priority preempt | no preempt preempt accept | no accept accept centiseconds Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of this command to remove a virtual router from the configuration. •...
Page 810 vrrp3 VRRP Commands MIB Objects alaVrrp3OperTable alaVrrp3OperAdminState alaVrrp3OperPriority alaVrrp3OperPreemptMode alaVrrp3OperAcceptMode alaVrrp3OperAdvinterval alaVrrp3OperRowStatus page 16-32 OmniSwitch CLI Reference Guide March 2011...
Page 811: Vrrp3 Address
VRRP Commands vrrp3 address vrrp3 address Configures an IPv6 address for a virtual router. vrrp3 vrid vlan_id address [ipv6Addr | ipv6v4Addr] vrrp3 vrid vlan_id no address [ipv6Addr | ipv6v4Addr] Syntax Definitions vrid The virtual router ID, in the range from 1–255. vlan_id The VLAN on which the virtual router is configured.
Page 812: Vrrp3 Trap
vrrp3 trap VRRP Commands vrrp3 trap Enables or disables SNMP traps for VRRP3. vrrp3 trap no vrrp3 trap Syntax Definitions Defaults By default, SNMP traps for VRRP3 are enabled. Platforms Supported OmniSwitch 10K Usage Guidelines SNMP traps must be enabled globally on the switch for VRRP3 traps to actually be sent. Examples ->...
Page 813: Vrrp3 Track-Association
VRRP Commands vrrp3 track-association vrrp3 track-association Associates a VRRP3 tracking policy with a virtual router. vrrp3 vrid vlan_id track-association track_id vrrp3 vrid vlan_id no track-association track_id Syntax Definitions vrid The virtual router ID, in the range from 1–255. vlan_id The VLAN ID of the virtual router. track_id The ID of the tracking policy associated with the virtual router;...
Page 814: Show Vrrp
show vrrp VRRP Commands show vrrp Displays the virtual router configuration for all virtual routers or for a specific virtual router. show vrrp [vrid] Syntax Definitions vrid The virtual router ID, in the range from 1–255. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the show vrrp command to display information about configuration parameters, which may be set through the vrrp command.
Page 815 VRRP Commands show vrrp -> show vrrp 1 Virtual Router VRID = 1 on VLAN = 1 Admin Status = Enabled Priority = 255 Preempt = Yes Adv. Interval Virtual MAC = 00-00-5E-00-02-01 IP Address(es) 192.168.170.1 192.168.170.2 output definitions VRRP default advertisement The default advertising interval for all virtual routers on the switch.
Page 816 show vrrp VRRP Commands Related Commands vrrp Configures a new VRRP virtual router or modifies an existing one. Used to enable or disable a virtual router. vrrp address Configures an IP address for a virtual router. vrrp interval Modifies the default advertising interval value assigned to the virtual routers on the switch.
Page 817: Show Vrrp Statistics
VRRP Commands show vrrp statistics show vrrp statistics Displays statistics about VRRP packets for all virtual routers configured on the switch or for a specific virtual router. show vrrp [vrid] statistics Syntax Definitions vrid The virtual router ID, in the range from 1–255. Defaults Platforms Supported OmniSwitch 10K...
Page 818 show vrrp statistics VRRP Commands output definitions (continued) State The operational state of the VRRP router instance; initialize specifies that the interface or VLAN is either disabled or down, or if the startup delay timer has not expired; backup specifies that this instance is mon- itoring the availability of the master router;...
Page 819 VRRP Commands show vrrp statistics output definitions (continued) IP address list errors The total number of VRRP packets in which the IP address list does not match the configured list for the virtual router. Packet length errors The total number of VRRP packets received with a length less than the length of the VRRP header.
Page 820: Show Vrrp Track
show vrrp track VRRP Commands show vrrp track Displays information about tracking policies on the switch. show vrrp track [track_id] Syntax Definitions track_id The ID of the tracking policy for which you want to display information. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Enter the tracking ID to display information about a particular policy;...
Page 821 VRRP Commands show vrrp track Related Commands vrrp track Creates a new tracking policy or modifies an existing tracking policy. MIB Objects alaVRRPTrackTable alaVrrpTrackState alaVrrpTrackAdminState alaVrrpTrackPriority alaVrrpTrackEntityType alaVrrpTrackEntityVlan alaVrrpTrackEntityPort alaVrrpTrackEntityIpAddress alaVrrpTrackEntityIpv6Interface alaVrrpTrackEntityInterface OmniSwitch CLI Reference Guide March 2011 page 16-43...
Page 822: Show Vrrp Track-Association
show vrrp track-association VRRP Commands show vrrp track-association Displays the tracking policies associated with virtual routers. show vrrp [vrid] track-association [track_id] Syntax Definitions vrid The virtual router ID, in the range from 1–255. track_id The ID of the tracking policy for which you want to display information. Defaults Platforms Supported OmniSwitch 10K...
Page 823 VRRP Commands show vrrp track-association output definitions (continued) Oper State Whether the tracking policy is operational (Up) or not (Down). Track Pri The amount to be decremented from the configured virtual router prior- ity when the tracking policy is applied. Release History Release 7.1.1;...
Page 824: Show Vrrp Group
show vrrp group VRRP Commands show vrrp group Displays the default parameter values for all the virtual router groups or for a specific virtual router group. show vrrp group [vrgid] Syntax Definitions vrgid The virtual router group ID, in the range from 1–255. Defaults By default, the default parameter values are displayed for all the virtual router groups.
Page 825 VRRP Commands show vrrp group Related Commands vrrp group Creates a new virtual router group or modifies the configuration param- eters of an existing virtual router group. vrrp group all Changes the administrative status of all the virtual routers in a virtual router group using a single command.
Page 826: Show Vrrp Group-Association
show vrrp group-association VRRP Commands show vrrp group-association Displays the virtual routers that are associated with a group. show vrrp group-association [vrgid] Syntax Definitions vrgid The virtual router group ID, in the range from 1–255. Defaults By default, all virtual router group associations are displayed. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 827 VRRP Commands show vrrp group-association Related Commands vrrp group-association Adds a virtual router to a virtual router group. MIB Objects alaVrrpAssoGroupTable alaVrrp3OperVrId OmniSwitch CLI Reference Guide March 2011 page 16-49...
Page 828: Show Vrrp3
show vrrp3 VRRP Commands show vrrp3 Displays the virtual router configuration for all virtual routers or for a specific virtual router. show vrrp3 [vrid] Syntax Definitions vrid The virtual router ID, in the range from 1–255. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Use the show vrrp3 command to display information about configuration parameters, which may be set through the vrrp3 command.
Page 829 VRRP Commands show vrrp3 output definitions VRRP trap generation Whether or not VRRP trap generation is enabled or disabled. VRRP startup delay The amount of time after a reboot that virtual routers will wait before they go active; allows time for routing tables to stabilize. VRID Virtual router identifier.
Page 830 show vrrp3 VRRP Commands MIB Objects alaVrrp3OperTable alaVrrp3OperAdminState alaVrrp3OperPriority alaVrrp3OperPreemptMode alaVrrp3OperAcceptMode alaVrrp3OperAdvinterval page 16-52 OmniSwitch CLI Reference Guide March 2011...
Page 831: Show Vrrp3 Statistics
VRRP Commands show vrrp3 statistics show vrrp3 statistics Displays statistics about VRRP3 packets for all virtual routers configured on the switch or for a specific virtual router. show vrrp3 [vrid] statistics Syntax Definitions vrid The virtual router ID, in the range from 1–255. Defaults Platforms Supported OmniSwitch 10K...
Page 832 show vrrp3 statistics VRRP Commands output definitions (continued) VLAN The VLAN associated with the VRRP3 instance. State The administrative state of the VRRP3 instance; initialize specifies that the interface or vlan is either disabled or down and the startup delay timer has not expired;...
Page 833: Show Vrrp3 Track-Association
VRRP Commands show vrrp3 track-association show vrrp3 track-association Displays the tracking policies associated with VRRP3 virtual routers. show vrrp3 [vrid] track-association [track_id] Syntax Definitions vrid The virtual router ID, in the range from 1–255. track_id The ID of the tracking policy for which you want to display informa- tion.
Page 834 show vrrp3 track-association VRRP Commands output definitions (continued) Oper State Indicates whether the tracking policy is operational (Up) or not (Down). Track Pri The amount to be decremented from the configured virtual router prior- ity when the tracking policy is applied. Release History Release 7.1.1;...
Page 835: Chapter 17 Ospf Commands
This means that each area has its own topological data- base, as explained in the previous section. Alcatel-Lucent’s version of OSPF complies with RFCs 1370, 1850, 2328, 2370, 3101, and 3623. MIB information for OSPF is as follows: Filename: AlcatelIND1DrcTm.mib...
Page 836 OSPF Commands The following is a list of the commands for configuring OSPF: Global OSPF Commands ip ospf admin-state ip load ospf ip ospf asbr ip ospf exit-overflow-interval ip ospf extlsdb-limit ip ospf host ip ospf mtu-checking ip ospf default-originate ip ospf default-originate ip ospf default-originate ip ospf route-tag...
Page 837: Ip Ospf Admin-State
OSPF Commands ip ospf admin-state ip ospf admin-state Enables or disables the administration status of OSPF on the router. ip ospf admin-state {enable | disable} Syntax Definitions enable Enables OSPF. disable Disables OSPF. Defaults parameter default enable | disable disable Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 838: Ip Load Ospf
ip load ospf OSPF Commands ip load ospf Loads the OSPF software on the router. ip load ospf Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Example -> ip load ospf Release History Release 7.1.1; command was introduced. Related Commands MIB Objects ALADRCTMCONFIG alaDrcTmIPOspfStatus...
Page 839: Ip Ospf Asbr
OSPF Commands ip ospf asbr ip ospf asbr Configures the router as an Autonomous System Border Router (ASBR). A router running multiple protocols or acting as a gateway to other exterior routers is an ASBR. This command is currently not supported.
Page 840: Ip Ospf Exit-Overflow-Interval
ip ospf exit-overflow-interval OSPF Commands ip ospf exit-overflow-interval This command sets the overflow interval value. ip ospf exit-overflow-interval seconds Syntax Definitions seconds The number of seconds the router waits before attempting to leave the overflow state. Defaults parameter default seconds Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 841: Ip Ospf Extlsdb-Limit
OSPF Commands ip ospf extlsdb-limit ip ospf extlsdb-limit Assigns a limit to the number of External Link-State Database (LSDB) entries that can be learned. ip ospf extlsdb-limit limit Syntax Definitions limit The maximum number of LSDB entries allowed on the router. The accepted value is any number greater than or equal to 1.
Page 842: Ip Ospf Host
ip ospf host OSPF Commands ip ospf host Creates and deletes an OSPF entry for directly attached hosts. Allows for the modification of the host parameters of Type of Service (ToS) and metric. ip ospf host ip_address tos tos [metric metric] no ip ospf host ip_address tos tos Syntax Definitions ip_address...
Page 843 OSPF Commands ip ospf host Related Commands show ip ospf host Displays information on configured OSPF hosts. MIB Objects ospfHostTable ospfHostStatus ospfHostIpAddress ospfHostTOS ospfHostMetric OmniSwitch CLI Reference Guide March 2011 page 17-9...
Page 844: Ip Ospf Mtu-Checking
ip ospf mtu-checking OSPF Commands ip ospf mtu-checking Enables or disables the use of Maximum Transfer Unit (MTU) checking. The MTU limits the size of a transmitted or received packet. ip ospf mtu-checking no ip ospf mtu-checking Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 845: Ip Ospf Default-Originate
OSPF Commands ip ospf default-originate ip ospf default-originate Configures a default external route into the OSPF routing domain. ip ospf default-originate {only | always} [metric-type {type1 | type2}] [metric value] no ip ospf default-originate Syntax Definitions only Advertises only when there is a default route in the routing table. always Advertises the default route regardless of whether the routing table has a default route.
Page 846 ip ospf default-originate OSPF Commands Related Commands ip ospf asbr Configures the router as an Autonomous System Border Router (ASBR). This command is currently not supported. MIB Objects alaProtocolOspf alaOspfDefaultOriginate alaOspfDefaultOriginateMetricType alaOspfDefaultOriginateMetric page 17-12 OmniSwitch CLI Reference Guide March 2011...
Page 847: Ip Ospf Route-Tag
OSPF Commands ip ospf route-tag ip ospf route-tag Configures a tag value for the Autonomous System External (ASE) routes created. ip ospf route-tag tag Syntax Definitions The set tag value. The valid range is 0–2,147,483,647. Defaults parameter default Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 848: Ip Ospf Spf-Timer
ip ospf spf-timer OSPF Commands ip ospf spf-timer Configures timers for Shortest Path First (SPF) calculation. ip ospf spf-timer [delay delay_seconds] [hold hold_seconds] Syntax Definitions delay_seconds Specifies time (from 0 to 65535 seconds) between the reception of an OSPF topology change and the start of an SPF calculation. hold_seconds Specifies the minimum time (from 0 to 65535 seconds) between consec- utive SPF calculations.
Page 849 OSPF Commands ip ospf spf-timer Related Commands show ip ospf Displays the OSPF status and general configuration parameters. MIB Objects alaProtocolOspf alaOspfTimerSpfDelay alaOspfTimerSpfHold OmniSwitch CLI Reference Guide March 2011 page 17-15...
Page 850: Ip Ospf Virtual-Link
ip ospf virtual-link OSPF Commands ip ospf virtual-link Creates or deletes a virtual link. A virtual link is used to restore backbone connectivity if the backbone is not physically contiguous. ip ospf virtual-link area_id router_id [auth-type {none | simple | md5}] [auth-key key_string] [dead-interval seconds] [hello-interval seconds] [retrans-interval seconds] [transit-delay seconds] no ip ospf virtual-link area_id router_id Syntax Definitions...
Page 851 OSPF Commands ip ospf virtual-link Defaults parameter default none | simple | md5 none key_string null string dead-interval seconds hello-interval seconds retrans-interval seconds transit-delay seconds Platforms Supported OmniSwitch 10K Usage Guidelines • The no form of the command deletes the virtual link. •...
Page 852 ip ospf virtual-link OSPF Commands Related Commands show ip ospf virtual-link Displays the virtual link information. MIB Objects ospfVirtIfTable ospfVirtIfAreaId ospfVirtIfNeighbor ospfVirtIfAuthKey ospfVirtIfStatus ospfVirtIfAuthType ospfVirtIfRtrDeadInterval ospfVirtIfHelloInterval ospfVirtIfRetransInterval ospfVirtIfTransitDelay page 17-18 OmniSwitch CLI Reference Guide March 2011...
Page 853: Ip Ospf Neighbor
OSPF Commands ip ospf neighbor ip ospf neighbor Creates a static neighbor on a non-broadcast interface. ip ospf neighbor neighbor_id {eligible | non-eligible} no ip ospf neighbor neighbor_id Syntax Definitions neighbor_id A unique 32-bit IP address identical to the neighbor’s interface address. eligible Sets this router as eligible to be the DR.
Page 854 ip ospf neighbor OSPF Commands Related Commands ip ospf interface type Configures the OSPF interface type. show ip ospf neighbor Displays information on OSPF non-virtual neighbor routers. MIB Objects ospfNbrTable ospfNbrPriority ospfNbmaNbrStatus page 17-20 OmniSwitch CLI Reference Guide March 2011...
Page 855: Ip Ospf Area
OSPF Commands ip ospf area ip ospf area Assigns an OSPF interface to a specified area. ip ospf area area_id [summary {enable | disable}] | [type {normal | stub | nssa}] no ip ospf area area_id Syntax Definitions area_id A unique 32-bit value in IP address format. enable Enables summarization.
Page 856 ip ospf area OSPF Commands Related Commands ip ospf area default-metric Creates or deletes an OSPF default metric. ip ospf area range Creates a route summarization instance whereby a range of addresses will be advertised as a single route. show ip ospf area Displays either all OSPF areas, or a specified OSPF area.
Page 857: Ip Ospf Area Default-Metric
OSPF Commands ip ospf area default-metric ip ospf area default-metric Creates or deletes a default metric for stub or Not So Stubby Area (NSSA) areas. The default metric configures the type of cost metric that a default area border router (ABR) will advertise in the default summary Link State Advertisement (LSA).
Page 858 ip ospf area default-metric OSPF Commands Release History Release 7.1.1; command was introduced. Related Commands ip ospf area Creates or deletes an OSPF area. ip ospf area range Creates a route summarization instance whereby a range of addresses will be advertised as a single route. show ip ospf area Displays either all OSPF areas, or a specified OSPF area.
Page 859: Ip Ospf Area Range
OSPF Commands ip ospf area range ip ospf area range Creates a route summarization instance whereby a range of addresses assigned for the route at the area border router will be advertised. ip ospf area area_id range {summary | nssa} ip_address subnet_mask [effect {admatching | noMatching}] no ip ospf area area_id range {summary | nssa} ip_address subnet_mask Syntax Definitions...
Page 860 ip ospf area range OSPF Commands • An NSSA (Not So Stubby Area) is similar to a stub area. However, where autonomous system (AS) external routes cannot be imported into a stub area, an NSSA will allow the importing of some AS external routes.
Page 861: Ip Ospf Interface
OSPF Commands ip ospf interface ip ospf interface Creates and deletes an OSPF interface. ip ospf interface {interface_name} no ip ospf interface {interface_name} Syntax Definitions interface_name The name of the interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of the command to delete an OSPF interface. •...
Page 862: Ip Ospf Interface Admin-State
ip ospf interface admin-state OSPF Commands ip ospf interface admin-state Enables or disables the administrative status on an OSPF interface. ip ospf interface {interface_name} admin-state {enable | disable} no ip ospf interface {interface_name} admin-state {enable | disable} Syntax Definitions interface_name The name of the interface.
Page 863: Ip Ospf Interface Area
OSPF Commands ip ospf interface area ip ospf interface area Configures an OSPF area identifier for this interface. ip ospf interface {interface_name} area area_id Syntax Definitions interface_name The name of the interface. area_id A unique 32-bit value in IP address format. Defaults Platforms Supported OmniSwitch 10K...
Page 864: Ip Ospf Interface Auth-Key
ip ospf interface auth-key OSPF Commands ip ospf interface auth-key Configures an OSPF authentication key for simple authentication on an interface. ip ospf interface {interface_name} auth-key key_string Syntax Definitions interface_name The name of the interface. key_string An authentication key (8 characters maximum). Defaults The default for the authentication key string is a null string.
Page 865: Ip Ospf Interface Auth-Type
OSPF Commands ip ospf interface auth-type ip ospf interface auth-type Sets the OSPF interface authentication type. Authentication allows the router to only respond to other routers that have the correct authentication information. ip ospf interface {interface_name} auth-type [none | simple | md5] Syntax Definitions interface_name The name of the interface.
Page 866 ip ospf interface auth-type OSPF Commands Related Commands ip ospf interface auth-key Sets the password for simple authentication. show ip ospf interface Displays the status and statistics of an OSPF interface. MIB Objects ospfIfTable ospfIfAuthType page 17-32 OmniSwitch CLI Reference Guide March 2011...
Page 867: Ip Ospf Interface Dead-Interval
OSPF Commands ip ospf interface dead-interval ip ospf interface dead-interval Configures the OSPF interface dead interval. ip ospf interface {interface_name} dead-interval seconds Syntax Definitions interface_name The name of the interface. seconds The dead interval, in seconds. The valid range is 1–65535. Defaults parameter default...
Page 868: Ip Ospf Interface Hello-Interval
ip ospf interface hello-interval OSPF Commands ip ospf interface hello-interval Configures the OSPF interface hello interval. ip ospf interface {interface_name} hello-interval seconds Syntax Definitions interface_name The name of the interface. seconds The hello interval, in seconds. The valid range is 1–65535. Defaults parameter default...
Page 869: Ip Ospf Interface Md5
OSPF Commands ip ospf interface md5 ip ospf interface md5 Creates and deletes the OSPF interface MD5 key identification number. ip ospf interface {interface_name} md5 key_id [enable | disable] Syntax Definitions interface_name The name of the interface. key_id A key identification number. The key identification number specifies a number that allows MD5 encrypted routers to communicate.
Page 870 ip ospf interface md5 OSPF Commands Related Commands ip ospf interface auth-type Sets the OSPF interface authentication type. ip ospf interface md5 key Configures the OSPF key ID and key. show ip ospf interface Displays the status and statistics of an OSPF interface. MIB Objects alaOspfIfMd5Table alaOspfIfMd5IpAddress...
Page 871: Ip Ospf Interface Md5 Key
OSPF Commands ip ospf interface md5 key ip ospf interface md5 key Configures the OSPF key string. This interface MD5 string, along with the key identification number, enables the interface to encode MD5 encryption. ip ospf interface {interface_name} md5 key_id key key_string Syntax Definitions interface_name The name of the interface.
Page 872 ip ospf interface md5 key OSPF Commands MIB Objects alaOspfIfMd5Table alaOspfIfMd5IpAddress alaOspfIfMd5KeyId alaOspfIfMd5Key page 17-38 OmniSwitch CLI Reference Guide March 2011...
Page 873: Ip Ospf Interface Type
OSPF Commands ip ospf interface type ip ospf interface type Configures the OSPF interface type. ip ospf interface {interface_name} type {point-to-point | point-to-multipoint | broadcast | non-broad- cast} Syntax Definitions interface_name The name of the interface. point-to-point Sets the interface to be a point-to-point OSPF interface. point-to-multipoint Sets the interface to be a point-to-multipoint OSPF interface.
Page 874 ip ospf interface type OSPF Commands Related Commands ip ospf neighbor Creates a static neighbor on a Non Broadcast Multi Access (NBMA) interface. show ip ospf interface Displays the status and statistics of an OSPF interface. MIB Objects ospfIfTable ospfIfType page 17-40 OmniSwitch CLI Reference Guide March 2011...
Page 875: Ip Ospf Interface Cost
OSPF Commands ip ospf interface cost ip ospf interface cost Configures the OSPF interface cost. ip ospf interface {interface_name} cost cost Syntax Definitions interface_name The name of the interface. cost The interface cost. The valid range is 0 to 65535. Defaults parameter default...
Page 876: Ip Ospf Interface Poll-Interval
ip ospf interface poll-interval OSPF Commands ip ospf interface poll-interval Configures the OSPF poll interval for a Non Broadcast Multi Access (NBMA) interface. ip ospf interface {interface_name} poll-interval seconds Syntax Definitions interface_name The name of the interface. seconds The poll interval, in seconds. The valid range is 1–2147483647. Defaults parameter default...
Page 877: Ip Ospf Interface Priority
OSPF Commands ip ospf interface priority ip ospf interface priority Configures the OSPF interface priority. The priority number helps determine the eligibility of this router to become the designated router on the network. ip ospf interface {interface_name} priority priority Syntax Definitions interface_name The name of the interface.
Page 878: Ip Ospf Interface Retrans-Interval
ip ospf interface retrans-interval OSPF Commands ip ospf interface retrans-interval Configures the OSPF interface retransmit interval. ip ospf interface {interface_name} retrans-interval seconds Syntax Definitions interface_name The name of the interface. seconds The retransmit interval, in seconds. The valid range 0–3600. Defaults parameter default...
Page 879: Ip Ospf Interface Transit-Delay
OSPF Commands ip ospf interface transit-delay ip ospf interface transit-delay Configures the OSPF interface transit delay. ip ospf interface {interface_name} transit-delay seconds Syntax Definitions interface_name The name of the interface. seconds The transit delay, in seconds. The valid range is 0–3600. Defaults parameter default...
Page 880: Ip Ospf Restart-Support
ip ospf restart-support OSPF Commands ip ospf restart-support Configures support for the graceful restart feature on an OSPF router. ip ospf restart-support {planned-unplanned | planned-only} no ip ospf restart-support Syntax Definitions planned-unplanned Specifies support for planned and unplanned restarts. planned-only This parameter is currently not supported.
Page 881: Ip Ospf Restart-Interval
OSPF Commands ip ospf restart-interval ip ospf restart-interval Configures the grace period for achieving a graceful OSPF restart. ip ospf restart-interval [seconds] Syntax Definitions seconds The hitless restart timeout interval, in seconds. The valid range is 0–1800. Defaults parameter default seconds Platforms Supported OmniSwitch 10K...
Page 882: Ip Ospf Restart-Helper Admin-State
ip ospf restart-helper admin-state OSPF Commands ip ospf restart-helper admin-state Administratively enables and disables the capability of an OSPF router to operate in helper mode in response to a router performing a graceful restart. ip ospf restart-helper [admin-state {enable | disable}] Syntax Definitions enable Enables the capability of an OSPF router to operate in helper mode.
Page 883: Ip Ospf Restart-Helper Strict-Lsa-Checking Admin-State
OSPF Commands ip ospf restart-helper strict-lsa-checking admin-state ip ospf restart-helper strict-lsa-checking admin-state Administratively enables and disables whether or not a changed Link State Advertisement (LSA) will result in termination of graceful restart by a helping router. ip ospf restart-helper strict-lsa-checking admin-state {enable | disable} Syntax Definitions enable Enables whether or not a changed LSA will result in termination of...
Page 884 ip ospf restart-helper strict-lsa-checking admin-state OSPF Commands Related Commands ip ospf restart-support Administratively enables and disables support for the graceful restart feature on an OSPF router. ip ospf restart-helper admin- Administratively enables and disables the capability of an OSPF state router to operate in helper mode in response to a router performing a graceful restart.
Page 885: Ip Ospf Restart Initiate
OSPF Commands ip ospf restart initiate ip ospf restart initiate Initiates a planned graceful restart. ip ospf restart initiate Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • You must execute this command on the primary CMM before executing a takeover command. •...
Page 886: Show Ip Ospf
show ip ospf OSPF Commands show ip ospf Displays the OSPF status and general configuration parameters. show ip ospf Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • This command is used to display the general configuration parameters of the OSPF router. •...
Page 887 OSPF Commands show ip ospf output definitions Router Id The unique identification for the router. OSPF Version Number The version of OSPF the router is running. Admin Status Whether OSPF is currently enabled or disabled on the router. Area Border Router? Whether the router status is an area router or not.
Page 888 show ip ospf OSPF Commands Related Commands ip ospf admin-state Enables or disables the administration of OSPF on the router. ip ospf mtu-checking Enables or disables the use of Maximum Transfer Unit (MTU) checking. ip ospf spf-timer Configures timers for SPF calculation. ip ospf default-originate Enables or disables OSPF redistribution ip ospf asbr...
Page 889: Show Ip Ospf Border-Routers
OSPF Commands show ip ospf border-routers show ip ospf border-routers Displays information regarding all or specified border routers. show ip ospf border-routers [area_id] [router_id] [tos] [gateway] Syntax Definitions area_id A unique 32-bit value in IP address format. router_id A unique 32-bit value, such as an IP address, that identifies a neighbor- ing router in the Autonomous System.
Page 890 show ip ospf border-routers OSPF Commands Release History Release 7.1.1; command was introduced. Related Commands MIB Objects alaOspfBdrRouterAreaId alaOspfBdrRouterId alaOspfBdrRouterTos alaOspfBdrRouterMetric page 17-56 OmniSwitch CLI Reference Guide March 2011...
Page 891: Show Ip Ospf Ext-Lsdb
OSPF Commands show ip ospf ext-lsdb show ip ospf ext-lsdb Displays external Link State Advertisements known by this router. show ip ospf ext-lsdb [linkstate-id ls_id] [router-id router_id] Syntax Definitions ls_id The Link state ID. The ID is a unique 32-bit value such as an IP address.
Page 892 show ip ospf ext-lsdb OSPF Commands Release History Release 7.1.1; command was introduced. Related Commands ip ospf extlsdb-limit Assigns a limit to the number of External Link-State Database (LSDB) entries that can be learned. MIB Objects ospfExtLsdbTable ospfExtLsdbLsid ospfExtLsdbRouterId ospfExtLsdbSequence ospfExtLsdbAge ospfExtLsdbType page 17-58...
Page 893: Show Ip Ospf Host
OSPF Commands show ip ospf host show ip ospf host Displays information on the configured OSPF hosts. show ip ospf host [ip_address] Syntax Definitions ip_address A 32-bit IP address for a directly attached host. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 894 show ip ospf host OSPF Commands Related Commands ip ospf host Creates and deletes an OSPF entry for directly attached hosts. MIB Objects ospfHostTable ospfHostIpAddress ospfHostTOS ospfHostMetric ospfHostStatus ospfHostAreaID page 17-60 OmniSwitch CLI Reference Guide March 2011...
Page 895: Show Ip Ospf Lsdb
OSPF Commands show ip ospf lsdb show ip ospf lsdb Displays LSAs in the Link State Database associated with each area. show ip ospf lsdb [area_id] [rtr | net | netsum | asbrsum] [linkstate-id ls_id] [router-id router_id] Syntax Definitions area_id A unique 32-bit value in IP address format.
Page 896 show ip ospf lsdb OSPF Commands output definitions (continued) Orig Router-Id The router ID of the router that originated the external LSDB. SeqNo The advertisement sequence number (i.e., a value used to identify old and duplicate link state advertisements). The age of the LSA in seconds. That is, the duration for which this entry has existed in the external database.
Page 897: Show Ip Ospf Neighbor
OSPF Commands show ip ospf neighbor show ip ospf neighbor Displays information on OSPF non-virtual neighbor routers. show ip ospf neighbor [ip_address] Syntax Definitions ip_address A 32-bit IP address of the neighboring router. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 898 show ip ospf neighbor OSPF Commands -> show ip ospf neighbor 1.1.1.1 Neighbor's IP Address = 1.1.1.1, Neighbor's Router Id = 0.0.0.0, Neighbor's Area Id = 255.255.255.255, Neighbor's DR Address = 0.0.0.0, Neighbor's BDR Address = 0.0.0.0, Neighbor's Priority = 1, Neighbor's State = Down, Hello Suppressed ?
Page 899 OSPF Commands show ip ospf neighbor output definitions (continued) # of Outstanding LS The number of Link State updates to the neighbor that need to be Retransmissions retransmitted by the OSPF router. Restart Helper Status Indicates whether the router is acting as a hitless restart helper for the neighbor.
Page 900: Show Ip Ospf Routes
show ip ospf routes OSPF Commands show ip ospf routes Displays the OSPF routes known to the router. show ip ospf routes [ip_addr mask tos gateway] Syntax Definitions ip_addr The 32-bit IP address of the route destination in dotted decimal format. mask The IP subnet mask of the route destination.
Page 901 OSPF Commands show ip ospf routes Related Commands show ip ospf Displays the OSPF status and general configuration parameters. MIB Objects Alcatel1INDOspf alaOspfRouteDest alaOspfRouteMask alaOspfRouteNextHop alaOspfRouteMetric1 OmniSwitch CLI Reference Guide March 2011 page 17-67...
Page 902: Show Ip Ospf Virtual-Link
show ip ospf virtual-link OSPF Commands show ip ospf virtual-link Displays virtual link information. A virtual link is used to connect OSPF backbone routers that are not physically contiguous. show ip ospf virtual-link [router_id] Syntax Definitions router_id The router ID of the remote end of the virtual link that is to be viewed. Defaults Platforms Supported OmniSwitch 10K...
Page 903 OSPF Commands show ip ospf virtual-link Related Commands ip ospf virtual-link Creates or deletes a virtual link. show ip ospf virtual-neighbor Displays OSPF virtual neighbors. MIB Objects ospfVirtIfTable ospfVirtIfAreaId ospfVirtIfNeighbor ospfVirtIfState ospfVirtIfAuthType OmniSwitch CLI Reference Guide March 2011 page 17-69...
Page 904: Show Ip Ospf Virtual-Neighbor
show ip ospf virtual-neighbor OSPF Commands show ip ospf virtual-neighbor Displays OSPF virtual neighbors. A virtual neighbor is connected to the router through a virtual link rather than a physical one. show ip ospf virtual-neighbor area_id router_id Syntax Definitions area_id A unique 32-bit value in IP address format.
Page 905 OSPF Commands show ip ospf virtual-neighbor -> show ip ospf virtual-neighbor 0.0.0.1 2.0.0.254 Neighbor's IP Address = 2.0.0.254, Neighbor's Router Id = 2.0.0.254, Neighbor's Area Id = 0.0.0.1, Neighbor's DR Address = 2.0.0.1, Neighbor's BDR Address = 2.0.0.254, Neighbor's Priority = 1, Neighbor's State = Full,...
Page 906 show ip ospf virtual-neighbor OSPF Commands output definitions (continued) # of Outstanding LS The number of Link State requests to this virtual neighbor that have not Requests received a response from this virtual neighbor. # of Outstanding LS Number of Link state Acknowledgements queued up by the local router Acknowledgements to be sent to the virtual neighbor.
Page 907: Show Ip Ospf Area
OSPF Commands show ip ospf area show ip ospf area Displays either all OSPF areas, or a specified OSPF area. show ip ospf area [area_id] Syntax Definitions area_id A unique 32-bit value in IP address format. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 908 show ip ospf area OSPF Commands output definitions Area Identifier The unique 32-bit value, such as IP address, that identifies the OSPF area in the AS. Admin Status Whether the area is enabled or disabled. Operational Status Whether the area is active. Area Type The area type.
Page 909 OSPF Commands show ip ospf area MIB Objects ospfAreaTable ospfAreaId ospfImportAsExtern ospfSpfRuns ospfAreaBdrRtrCount ospfAsBdrRtrCount ospfAreaLsaCount ospfAreaSummary ospfAreaStatus alaOspfIfAugTable alaOspfIfIntfName OmniSwitch CLI Reference Guide March 2011 page 17-75...
Page 910: Show Ip Ospf Area Range
show ip ospf area range OSPF Commands show ip ospf area range Displays all or specified route summaries in a given area. show ip ospf area area_id range [{summary | nssa} ip_address ip_mask] Syntax Definitions area_id A unique 32-bit value in IP address format. summary Specifies that routes are summarized.
Page 911 OSPF Commands show ip ospf area range Related Commands ip ospf area range Creates a route summarization instance whereby a range of addresses assigned for the route at the area border router will be advertised. MIB Objects ospfAreaRangeTable ospfAreaRangeAreaId ospfAreaRangeNet ospfAreaRangeMask ospfAreaRangeStatus ospfAreaRangeEffect...
Page 912: Show Ip Ospf Area Stub
show ip ospf area stub OSPF Commands show ip ospf area stub Displays stub default area metrics, if configured. show ip ospf area area_id stub Syntax Definitions area_id A unique 32-bit value in IP address format. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Examples ->...
Page 913 OSPF Commands show ip ospf area stub MIB Objects ospfStubAreaTable ospfStubAreaId ospfStubTOS ospfStubMetric ospfStubStatus ospfStubMetricType OmniSwitch CLI Reference Guide March 2011 page 17-79...
Page 914: Show Ip Ospf Interface
show ip ospf interface OSPF Commands show ip ospf interface Displays OSPF interface information. show ip ospf interface [interface_name] Syntax Definitions interface_name The name of the interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Not specifying an interface name displays all known interfaces for the OSPF router. Examples No interface name is specified: ->...
Page 915 OSPF Commands show ip ospf interface The following is an example of MD5 authentication (an interface name is used in this example). -> show ip ospf interface vlan-3 Interface IP Name = vlan-3 VLAN Id = 3, Interface IP Address = 100.10.10.2, Interface IP Mask = 255.255.255.0,...
Page 916 show ip ospf interface OSPF Commands The following is an example of simple authentication (an interface name is used in this example): -> show ip ospf interface vlan-3 Interface IP Name = vlan-3 VLAN Id = 3, Interface IP Address = 100.10.10.2, Interface IP Mask = 255.255.255.0,...
Page 917 OSPF Commands show ip ospf interface output definitions (continued) Backup Designated Router IP The IP address of the backup designated router. Address Backup Designated Router The identification number of the backup designated router. RouterId The Maximum Transfer Unit (in bytes) for the interface. Metric Cost The cost added to routes learned on this interface.
Page 918 show ip ospf interface OSPF Commands output definitions (continued) # of 2-Way State Neighbors The number of OSPF 2-way state neighbors on this interface. # of Exchange State Neighbors The number of OSPF neighbors in the exchange state. # of Full State Neighbors The number of OSPF neighbors in the full state.
Page 919 OSPF Commands show ip ospf interface MIB Objects ospfIfTable ospfIfIpAddress ospfIfAreaId ospfIfType ospfIfAdminStat ospfIfRtrPriority ospfIfTransitDelay ospfIfRetransInterval ospfIfHelloInterval ospfIfRtrDeadInterval ospfIfPollInterval ospfIfState ospfIfDesignatedRouter ospfIfBackupDesignatedRouter ospfIfEvents ospfIfAuthType ospfIfStatus ospfIfAuthKey alaOspfIfMd5Table alaOspfIfMd5IpAddress alaOspfIfMd5KeyId alaOspfIfMd5Key alaOspfIfMd5EncryptKey alaOspfIfMd5KeyStartAccept alaOspfIfMd5KeyStopAccept alaOspfIfMd5KeyStartGenerate alaOspfIfMd5KeyStopGenerate alaOspfIfAugTable alaOspfIfIntfName OmniSwitch CLI Reference Guide March 2011 page 17-85...
Page 920: Show Ip Ospf Restart
show ip ospf restart OSPF Commands show ip ospf restart Displays the OSPF graceful restart related configuration and status. show ip ospf restart Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • The minimum hardware configuration for this command is a redundant CMM configuration. This command is not supported on OmniSwitch 10K switches with a single CMM.
Page 921 OSPF Commands show ip ospf restart output definitions (continued) Restart Helper Support The administrative status of the capability of an OSPF router to operate in helper mode in response to a router performing a graceful restart, which can be Enabled or Disabled. Use the ip ospf restart-helper admin-state command to modify this parameter.
Page 922 show ip ospf restart OSPF Commands page 17-88 OmniSwitch CLI Reference Guide March 2011...
Page 923: Chapter 18 Ospfv3 Commands
Note. OSPFv3 is supported only on OmniSwitch 10K Series switches. Alcatel-Lucent’s version of OSPFv3 complies with RFCs 2740, 1826, 1827, 2553, 2373, 2374, and 2460. MIB information for OSPFv3 is as follows: Filename: AlcatelIND1DrcTm.mib...
Page 924 OSPFv3 Commands The following is a list of the commands for configuring OSPFv3: Global OSPFv3 Commands ipv6 ospf admin-state ipv6 load ospf ipv6 ospf host ipv6 ospf mtu-checking ipv6 ospf route-tag ipv6 ospf spf-timer ipv6 ospf virtual-link show ipv6 ospf show ipv6 ospf border-routers show ipv6 ospf host show ipv6 ospf lsdb...
Page 925: Ipv6 Ospf Admin-State
OSPFv3 Commands ipv6 ospf admin-state ipv6 ospf admin-state Enables or disables the OSPFv3 administrative status for the router. ipv6 ospf admin-state {enable | disable} Syntax Definitions enable Enables OSPFv3. disable Disables OSPFv3. Defaults parameter default enable | disable enable Platforms Supported OmniSwitch 10K Usage Guidelines The OSPFv3 protocol should be enabled to route traffic.
Page 926: Ipv6 Load Ospf
ipv6 load ospf OSPFv3 Commands ipv6 load ospf Loads the OSPFv3 software on the router. ipv6 load ospf Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Example -> ipv6 load ospf Release History Release 7.1.1; command was introduced. Related Commands MIB Objects ALADRCTMCONFIG alaDrcTmIPOspf3Status...
Page 927: Ipv6 Ospf Host
OSPFv3 Commands ipv6 ospf host ipv6 ospf host Creates or deletes an OSPFv3 entry for directly attached hosts. ipv6 ospf host ipv6_address [area area_id] [metric metric] no ipv6 ospf host ipv6_address area area_id Syntax Definitions ipv6_address The 128-bit IP address of the OSPF host. area_id Area to which the host route belongs.
Page 928 ipv6 ospf host OSPFv3 Commands MIB Objects ospfv3HostTable ospfv3HostStatus ospfv3HostAreaID ospfv3HostAddress ospfv3HostMetric page 18-6 OmniSwitch CLI Reference Guide March 2011...
Page 929: Ipv6 Ospf Mtu-Checking
OSPFv3 Commands ipv6 ospf mtu-checking ipv6 ospf mtu-checking Enables or disables Maximum Transfer Unit (MTU) checking. The MTU limits the size of a transmitted or received packet. ipv6 ospf mtu-checking no ipv6 ospf mtu-checking Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 930: Ipv6 Ospf Route-Tag
ipv6 ospf route-tag OSPFv3 Commands ipv6 ospf route-tag Configures a tag value for the Autonomous System External (ASE) routes created. ipv6 ospf route-tag tag Syntax Definitions The set tag value. The valid range is 0–2, 147, 483, 647. Defaults parameter default Platforms Supported OmniSwitch 10K...
Page 931: Ipv6 Ospf Spf-Timer
OSPFv3 Commands ipv6 ospf spf-timer ipv6 ospf spf-timer Configures timers for Shortest Path First (SPF) calculation. ipv6 ospf spf-timer [delay delay_seconds] [hold hold_seconds] Syntax Definitions delay_seconds Specifies time (from 0 to 65535 seconds) between the reception of an OSPF topology change and the start of an SPF calculation. hold_seconds Specifies the minimum time (from 0 to 65535 seconds) between consec- utive SPF calculations.
Page 932 ipv6 ospf spf-timer OSPFv3 Commands Related Commands show ipv6 ospf Displays the OSPFv3 status and general configuration parameters. MIB Objects alaProtocolOspf3 alaOspf3TimerSpfDelay alaOspf3TimerSpfHold page 18-10 OmniSwitch CLI Reference Guide March 2011...
Page 933: Ipv6 Ospf Virtual-Link
OSPFv3 Commands ipv6 ospf virtual-link ipv6 ospf virtual-link Creates or deletes a virtual link. A virtual link restores the backbone connectivity if the backbone is not physically contiguous. ipv6 ospf virtual-link area area_id router router_id [dead-interval seconds] [hello-interval seconds] [retrans-interval seconds] [transit-delay seconds] no ipv6 ospf virtual-link area area_id router router_id Syntax Definitions area_id...
Page 934 ipv6 ospf virtual-link OSPFv3 Commands Usage Guidelines • Use the no form of the command to delete the virtual link. • You can define areas in such a way that the backbone is no longer contiguous. In this case, the system administrator can ensure backbone connectivity physically.
Page 935: Ipv6 Ospf Area
OSPFv3 Commands ipv6 ospf area ipv6 ospf area Assigns an OSPFv3 interface to a specified area. ipv6 ospf area area_id [type {normal | stub [default-metric metric]}] no ipv6 ospf area area_id Syntax Definitions area_id A unique 32-bit value in IPv4 address format. normal Sets the area as a regular OSPFv3 area.
Page 936 ipv6 ospf area OSPFv3 Commands MIB Objects ospfv3AreaTable ospfv3ImportAsExtern ospfv3AreaSummary ospfv3StubMetric ospfv3AreaId page 18-14 OmniSwitch CLI Reference Guide March 2011...
Page 937: Ipv6 Ospf Interface
OSPFv3 Commands ipv6 ospf interface ipv6 ospf interface Creates or deletes an OSPFv3 interface. ipv6 ospf interface interface_name no ipv6 ospf interface interface_name Syntax Definitions interface_name The name of the interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • Use the no form of the command to delete an OSPFv3 interface. •...
Page 938: Ipv6 Ospf Interface Admin-State
ipv6 ospf interface admin-state OSPFv3 Commands ipv6 ospf interface admin-state Enables or disables the administration status on an OSPFv3 interface. ipv6 ospf interface interface_name admin-state {enable | disable} no ipv6 ospf interface interface_name Syntax Definitions interface_name The name of the interface. enable Enables the OSPFv3 interface.
Page 939: Ipv6 Ospf Interface Area
OSPFv3 Commands ipv6 ospf interface area ipv6 ospf interface area Configures an OSPFv3 area identifier for this interface. ipv6 ospf interface interface_name area area_id Syntax Definitions interface_name The name of the interface. area_id A unique 32-bit value in IP address format. Defaults Platforms Supported OmniSwitch 10K...
Page 940: Ipv6 Ospf Interface Dead-Interval
ipv6 ospf interface dead-interval OSPFv3 Commands ipv6 ospf interface dead-interval Configures the OSPFv3 interface dead interval. ipv6 ospf interface interface_name dead-interval seconds Syntax Definitions interface_name The name of the interface. seconds The dead interval, in seconds. The valid range is 1–65535. Defaults parameter default...
Page 941 OSPFv3 Commands ipv6 ospf interface dead-interval Related Commands ipv6 ospf interface hello- Configures the OSPFv3 interface hello interval. interval show ipv6 ospf interface Displays the status and statistics of an OSPFv3 interface. MIB Objects ospfv3IfTable ospfv3IfIndex ospfv3IfRtrDeadInterval OmniSwitch CLI Reference Guide March 2011 page 18-19...
Page 942: Ipv6 Ospf Interface Hello-Interval
ipv6 ospf interface hello-interval OSPFv3 Commands ipv6 ospf interface hello-interval Configures the OSPFv3 interface hello interval. ipv6 ospf interface interface_name hello-interval seconds Syntax Definitions interface_name The name of the interface. seconds The hello interval, in seconds. The valid range is 1–65535. Defaults parameter default...
Page 943: Ipv6 Ospf Interface Cost
OSPFv3 Commands ipv6 ospf interface cost ipv6 ospf interface cost Configures the OSPFv3 interface cost. ipv6 ospf interface interface_name cost cost Syntax Definitions interface_name The name of the interface. cost The interface cost. The valid range is 0–65535. Defaults parameter default cost Platforms Supported...
Page 944: Ipv6 Ospf Interface Priority
ipv6 ospf interface priority OSPFv3 Commands ipv6 ospf interface priority Configures the OSPFv3 interface priority. The priority number helps determine the eligibility of this router to become the designated router on the network. ip ospf interface interface_name priority priority Syntax Definitions interface_name The name of the interface.
Page 945: Ipv6 Ospf Interface Retrans-Interval
OSPFv3 Commands ipv6 ospf interface retrans-interval ipv6 ospf interface retrans-interval Configures the OSPFv3 interface retransmit time interval. ipv6 ospf interface interface_name retrans-interval interval Syntax Definitions interface_name The name of the interface. interval The retransmit interval, in seconds. The valid range 0–3600. Defaults parameter default...
Page 946: Ipv6 Ospf Interface Transit-Delay
ipv6 ospf interface transit-delay OSPFv3 Commands ipv6 ospf interface transit-delay Configures the OSPFv3 interface transit time delay. ipv6 ospf interface interface_name transit-delay delay Syntax Definitions interface_name The name of the interface. delay The transit delay, in seconds. The valid range is 0–3600. Defaults parameter default...
Page 947: Show Ipv6 Ospf
OSPFv3 Commands show ipv6 ospf show ipv6 ospf Displays the OSPFv3 status and general configuration parameters. show ipv6 ospf Syntax Definitions Defaults Platforms Supported OmniSwitch 10K Usage Guidelines • This command is used to display the general configuration parameters of the OSPFv3 router. •...
Page 948 show ipv6 ospf OSPFv3 Commands output definitions Status Displays whether OSPFv3 is currently enabled or disabled on the router. Router Id The unique identification for the router. # Areas Number of areas to which the router belongs. # Interface Number of interfaces participating in OSPF Area Border Router Displays whether the router status is an area router or not.
Page 949 OSPFv3 Commands show ipv6 ospf Related Commands ipv6 ospf admin-state Enables or disables the administration of OSPFv3 on the router. ipv6 ospf mtu-checking Enables or disables the use of Maximum Transfer Unit (MTU) checking. ipv6 ospf spf-timer Configures timers for SPF calculation. ipv6 ospf route-tag Configures a tag value for Autonomous System External (ASE) routes created.
Page 950: Show Ipv6 Ospf Border-Routers
show ipv6 ospf border-routers OSPFv3 Commands show ipv6 ospf border-routers Displays information regarding all or specified border routers. show ipv6 ospf border-routers [area area_id] [router router_id] Syntax Definitions area_id A unique 32-bit value in IP address format. router_id A unique 32-bit value, such as an IP address, that identifies a neighbor- ing router in the Autonomous System.
Page 951 OSPFv3 Commands show ipv6 ospf border-routers Release History Release 7.1.1; command was introduced. Related Commands MIB Objects OmniSwitch CLI Reference Guide March 2011 page 18-29...
Page 952: Show Ipv6 Ospf Host
show ipv6 ospf host OSPFv3 Commands show ipv6 ospf host Displays information on the configured OSPFv3 hosts. show ipv6 ospf host [ipv6_address] Syntax Definitions ipv6_address A 128-bit IP address for a directly attached host. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 953 OSPFv3 Commands show ipv6 ospf host Related Commands ipv6 ospf host Creates or deletes an OSPFv3 entry for directly attached hosts. MIB Objects ospfv3HostTable ospfv3HostIpAddress ospfv3HostMetric ospfHostStatus ospfv3HostAreaID OmniSwitch CLI Reference Guide March 2011 page 18-31...
Page 954: Show Ipv6 Ospf Lsdb
show ipv6 ospf lsdb OSPFv3 Commands show ipv6 ospf lsdb Displays Link State Advertisements (LSAs) in the Link State Database (LSDB) associated with each area. show ipv6 ospf lsdb [area area_id] [rtr | net | netsum | asbrsum] [linkstate-id ls_id] [router-id router_id] Syntax Definitions area_id...
Page 955 OSPFv3 Commands show ipv6 ospf lsdb Examples -> show ipv6 ospf lsdb Area Type Link ID Advertising Rtr Sequence # ----------------+----------+------------+-----------------+----------+---------- 8000020f 0.0.0.0 Router 1.1.1.1 1117 80000208 0.0.0.0 Router 3.3.3.3 1121 800001f1 0.0.0.0 Router 5.5.5.5 1117 800000da 0.0.0.0 Router 30.30.30.30 1115 output definitions Area...
Page 956: Show Ipv6 Ospf Neighbor
show ipv6 ospf neighbor OSPFv3 Commands show ipv6 ospf neighbor Displays information on OSPFv3 non-virtual neighbors. show ipv6 ospf neighbor [router ipv4_address][interface interface_name] Syntax Definitions ipv4_address A 32-bit router ID of the neighboring router. interface_name The name of the interface. Defaults Platforms Supported OmniSwitch 10K...
Page 957 OSPFv3 Commands show ipv6 ospf neighbor output definitions Router ID The unique identification for the router. Area/Transit Area The area identifier. State The state of the OSPF neighbor adjacency. Interface The name of the interface. Release History Release 7.1.1; command was introduced. Related Commands MIB Objects ospfv3NbrTable...
Page 958: Show Ipv6 Ospf Routes
show ipv6 ospf routes OSPFv3 Commands show ipv6 ospf routes Displays the OSPFv3 routes known to the router. show ipv6 ospf routes [prefix ipv6_address_prefix][gateway gateway] Syntax Definitions ipv6_address_prefix The 128-bit IPv6 address of the route destination in hexadecimal format. gateway The next hop IPv6 address for this router.
Page 959 OSPFv3 Commands show ipv6 ospf routes Related Commands ipv6 ospf admin-state Displays the OSPFv3 status and general configuration parameters. MIB Objects OmniSwitch CLI Reference Guide March 2011 page 18-37...
Page 960: Show Ipv6 Ospf Virtual-Link
show ipv6 ospf virtual-link OSPFv3 Commands show ipv6 ospf virtual-link Displays virtual link information. A virtual link is used to connect OSPFv3 backbone routers that are not physically contiguous. show ipv6 ospf virtual-link [router_id] Syntax Definitions router_id The router ID of the remote end of the virtual link. Defaults Platforms Supported OmniSwitch 10K...
Page 961 OSPFv3 Commands show ipv6 ospf virtual-link Related Commands ipv6 ospf virtual-link Creates or deletes a virtual link. MIB Objects ospfv3VirtIfTable ospfv3VirtIfAreaId ospfv3VirtIfNeighbor ospfv3VirtIfState OmniSwitch CLI Reference Guide March 2011 page 18-39...
Page 962: Show Ipv6 Ospf Area
show ipv6 ospf area OSPFv3 Commands show ipv6 ospf area Displays either all OSPFv3 areas, or a specified OSPFv3 area. show ipv6 ospf area [area_id] Syntax Definitions area_id A unique 32-bit value in IP address format. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines •...
Page 963 OSPFv3 Commands show ipv6 ospf area output definitions (continued) # Network LSAs The total number of inter-area Link State Advertisements. # of SPF calculations The number of times the area has calculated the Shortest Path. # Interfaces The number of OSPF interfaces. # Intra-area-prefix LSAs The number of intra-area-prefix LSAs, which associates a list of IPv6 address prefixes with a router by referencing a router-LSA.
Page 964: Show Ipv6 Ospf Interface
show ipv6 ospf interface OSPFv3 Commands show ipv6 ospf interface Displays OSPFv3 interface information. show ipv6 ospf interface [interface_name] Syntax Definitions interface_name The name of the interface. Defaults Platforms Supported OmniSwitch 10K Usage Guidelines Not specifying the interface name displays all known interfaces for the OSPFv3 router. Examples ->...
Page 965 OSPFv3 Commands show ipv6 ospf interface -> show ipv6 ospf interface vlan-2071 Type = BROADCAST, Admin Status = Enabled, IPv6 Interface Status = Up, Oper Status = Up, State = DR, Area = 0.0.0.0, Priority = 100, Cost = 1, Designated Router = 3.3.3.3, Backup Designated Router...
Page 966 show ipv6 ospf interface OSPFv3 Commands output definitions (continued) Ifindex The unique value assigned to an interface. IPv6 ifindex The unique value assigned to an IPv6 interface. The Maximum Transfer Unit (in bytes) for the interface. # of attached neighbors The number of OSPFv3 neighbors in the initialization state.
Page 967 OSPFv3 Commands show ipv6 ospf interface MIB Objects ospfv3IfTable ospfv3IfAreaId ospfv3IfType ospfv3IfAdminStat ospfv3IfRtrPriority ospfv3IfTransitDelay ospfv3IfRetransInterval ospfv3IfHelloInterval ospfv3IfRtrDeadInterval ospfv3IfPollInterval ospfv3IfState ospfv3IfDesignatedRouter ospfv3IfBackupDesignatedRouter ospfv3IfEvents ospfv3IfStatus OmniSwitch CLI Reference Guide March 2011 page 18-45...
Page 968 show ipv6 ospf interface OSPFv3 Commands page 18-46 OmniSwitch CLI Reference Guide March 2011...
Page 969: Chapter 19 Bgp Commands
Multiprotocol Extensions to BGP-4 supports the exchange of IPv6 unicast prefixes, as well as the estab- lishment of BGP peering sessions with BGP speakers identified by their IPv6 addresses. The Alcatel-Lucent implementation of BGP-4 and Multiprotocol Extensions to BGP-4 complies with the following RFCs: 4271, 2439, 3392, 2385, 1997, 4456, 3065, 4273, 4760, 2545 Note.
Page 970 BGP Commands The following table summarizes the available commands: Global BGP Commands ip load bgp ip bgp admin-state ip bgp autonomous-system ip bgp bestpath as-path ignore ip bgp cluster-id ip bgp default local-preference ip bgp fast-external-failover ip bgp always-compare-med ip bgp bestpath med missing-as-worst ip bgp client-to-client reflection ip bgp as-origin-interval ip bgp synchronization...
Page 971 BGP Commands Neighbor (Peer) Configuration ip bgp neighbor ip bgp neighbor admin-state ip bgp neighbor advertisement-interval ip bgp neighbor clear ip bgp neighbor route-reflector-client ip bgp neighbor default-originate ip bgp neighbor timers ip bgp neighbor conn-retry-interval ip bgp neighbor auto-restart ip bgp neighbor maximum-prefix ip bgp neighbor md5 key ip bgp neighbor ebgp-multihop...
Page 972 BGP Commands Policy Commands ip bgp policy aspath-list ip bgp policy aspath-list action ip bgp policy aspath-list priority ip bgp policy community-list ip bgp policy community-list action ip bgp policy community-list match-type ip bgp policy community-list priority ip bgp policy prefix-list ip bgp policy prefix-list action ip bgp policy prefix-list ge ip bgp policy prefix-list le...
Page 973 BGP Commands IPv6 BGP Neighbor (Peer) ipv6 bgp neighbor Configuration Commands ipv6 bgp neighbor activate-ipv6 ipv6 bgp neighbor ipv6-nexthop ipv6 bgp neighbor admin-state ipv6 bgp neighbor remote-as ipv6 bgp neighbor timers ipv6 bgp neighbor maximum-prefix ipv6 bgp neighbor next-hop-self ipv6 bgp neighbor conn-retry-interval ipv6 bgp neighbor default-originate ipv6 bgp neighbor update-source ipv6 bgp neighbor ipv4-nexthop...
Page 974: Ip Load Bgp
ip load bgp BGP Commands ip load bgp Loads the BGP protocol software into running memory on the router. The image file containing BGP should already be resident in flash memory before issuing this command. ip load bgp Syntax Definitions Defaults Platforms Supported OmniSwitch 10K...
Page 975: Ip Bgp Admin-State
BGP Commands ip bgp admin-state ip bgp admin-state Administratively enables or disables BGP. The BGP protocol will not be active until you enable it using this command. ip bgp admin-state {enable | disable} Syntax Definitions enable Enables BGP. disable Disables BGP. Defaults parameter default...
Page 976: Ip Bgp Autonomous-System
ip bgp autonomous-system BGP Commands ip bgp autonomous-system Configures the Autonomous System (AS) number for this router. This number identifies this BGP speaker (this router) instance to other BGP routers. The AS number for a BGP speaker determines whether it is an internal or an external peer in relation to other BGP speakers.
Page 977: Ip Bgp Bestpath As-Path Ignore
BGP Commands ip bgp bestpath as-path ignore ip bgp bestpath as-path ignore Indicates whether AS path comparison will be used in route selection. The AS path is the sequence of ASs through which a route has traveled. A shorter AS path is preferred over a longer AS path. The AS path is always advertised in BGP route updates.
Page 978 ip bgp bestpath as-path ignore BGP Commands Related Commands ip bgp aggregate-address as-set Specifies whether AS path aggregation is to be performed or not. ip bgp policy aspath-list Creates or removes an AS path list. ip bgp default local-preference Configures the default local preference (lpref) value to be used when advertising routes.
Page 979: Ip Bgp Cluster-Id
BGP Commands ip bgp cluster-id ip bgp cluster-id Configures a BGP cluster ID when there are multiple, redundant, route reflectors in a cluster. This command is not necessary for configurations containing only one route reflector. ip bgp cluster-id ip_address Syntax Definitions ip_address 32-bit IP address that is the Cluster ID of the router acting as a route reflector.
Page 980 ip bgp cluster-id BGP Commands Related Commands ip bgp admin-state Enables and disables BGP. ip bgp client-to-client reflection Enables route reflection and sets this speaker as the route reflector. MIB Objects alaBgpGlobal alaBgpClusterId page 19-12 OmniSwitch CLI Reference Guide March 2011...
Page 981: Ip Bgp Default Local-Preference
BGP Commands ip bgp default local-preference ip bgp default local-preference Configures the default local preference (lpref) value to be used when advertising routes. A higher local preference value is preferred over a lower value. The local preference value is sent to all BGP peers in the local autonomous system;...
Page 982 ip bgp default local-preference BGP Commands Related Commands ip bgp aggregate-address local- Sets the local preference for a BGP aggregate. preference ip bgp network local-preference Sets the local preference for a BGP network. MIB Objects alaBgpGlobal alaBgpDefaultLocalPref page 19-14 OmniSwitch CLI Reference Guide March 2011...
Page 983: Ip Bgp Fast-External-Failover
BGP Commands ip bgp fast-external-failover ip bgp fast-external-failover Enables fast external failover (FEFO). When enabled, FEFO resets a session when a link to a directly connected external peer is operationally down. The BGP speaker will fall back to Idle and then wait for a connection retry by the external peer that went down.
Page 984 ip bgp fast-external-failover BGP Commands Related Commands ip bgp neighbor clear Restarts a BGP peer. ip bgp neighbor auto-restart Enables or disables BGP peer automatic restart. ip bgp neighbor timers Configures the time interval between KEEPALIVE messages sent by this peer and the tolerated hold time interval, in seconds, for messages to this peer from other peers.
Page 985: Ip Bgp Always-Compare-Med
BGP Commands ip bgp always-compare-med ip bgp always-compare-med Enables or disables Multi-Exit Discriminator (MED) comparison between peers in different autonomous systems. The MED value is considered when selecting the best path among alternatives; it indicates the weight for a particular exit point from the AS. A path with a lower MED value is preferred over a path with a higher MED value.
Page 986: Ip Bgp Bestpath Med Missing-As-Worst
ip bgp bestpath med missing-as-worst BGP Commands ip bgp bestpath med missing-as-worst Configures the MED parameter when it is missing in a BGP path. ip bgp bestpath med missing-as-worst no ip bgp bestpath med missing-as-worst Syntax Definitions Defaults By default this command is disabled. Platforms Supported OmniSwitch 10K Usage Guidelines...
Page 987: Ip Bgp Client-To-Client Reflection
BGP Commands ip bgp client-to-client reflection ip bgp client-to-client reflection Enables or disables this BGP speaker (router) to be a route reflector. Route reflectors advertise routing information to internal BGP peers, referred to as clients. BGP requires all internal routers to know all routes in an AS.
Page 988 ip bgp client-to-client reflection BGP Commands Related Commands ip bgp admin-state Administratively disables BGP in this router. ip bgp neighbor route-reflector- Configures a BGP peer to be a client to the this route reflector. client MIB Objects alaBgpGlobal alaBgpRouteReflection page 19-20 OmniSwitch CLI Reference Guide March 2011...
Page 989: Ip Bgp As-Origin-Interval
BGP Commands ip bgp as-origin-interval ip bgp as-origin-interval Specifies the frequency at which routes local to the autonomous system are advertised. These advertise- ments are also referred to as UPDATE messages. This interval applies to advertisements to internal peers. ip bgp as-origin-interval seconds no ip bgp as-origin-interval Syntax Definitions seconds...
Page 990: Ip Bgp Synchronization
ip bgp synchronization BGP Commands ip bgp synchronization Enables or disables synchronization of BGP prefixes with AS-internal routing information. Enabling this command will force the BGP speaker to advertise prefixes only if the prefixes are reachable through AS- internal routing protocols (IGPs like RIP and OSPF). ip bgp synchronization no ip bgp synchronization Syntax Definitions...
Page 991 BGP Commands ip bgp synchronization Related Commands show ip bgp Displays the current global settings for the local BGP speaker. MIB Objects alaBgpGlobal alaBgpIgpSynchStatus OmniSwitch CLI Reference Guide March 2011 page 19-23...
Page 992: Ip Bgp Confederation Identifier
ip bgp confederation identifier BGP Commands ip bgp confederation identifier Sets a confederation identification value for the local BGP speaker (this router). A confederation is a grouping of sub-ASs into a single AS. To peers outside a confederation, the confederation appears to be a single AS.
Page 993 BGP Commands ip bgp confederation identifier Related Commands ip bgp autonomous-system Sets the AS number for this router. ip bgp confederation neighbor Specifies peers that are members of a confederation. MIB Objects alaBgpGlobal alaBgpConfedId OmniSwitch CLI Reference Guide March 2011 page 19-25...
Page 994: Ip Bgp Maximum-Paths
ip bgp maximum-paths BGP Commands ip bgp maximum-paths Enables or disables support for multiple equal paths. When multipath support is enabled and the path selection process determines that multiple paths are equal when the router-id is disregarded, then all equal paths are installed in the hardware forwarding table.
Page 995: Ip Bgp Log-Neighbor-Changes
BGP Commands ip bgp log-neighbor-changes ip bgp log-neighbor-changes Enables or disables the logging of peer state changes. If enabled, this logging tracks changes in the state of BGP peers from ESTABLISHED to IDLE and from IDLE to ESTABLISHED. Viewing peer state logging requires that certain debug parameters be set.
Page 996: Ip Bgp Dampening
ip bgp dampening BGP Commands ip bgp dampening Enables or disables BGP route dampening or the suppression of unstable routes. Route dampening helps to control the advertisement of routes that are going up and then down at an abnormally high rate. Routes that are changing states (available then unavailable) are said to be flapping.
Page 997 BGP Commands ip bgp dampening • The half-life value configures the half-life duration for a reachable route. After the time interval speci- fied in this command, the penalty value for the route will be reduced by half. This command sets the duration in seconds during which the accumulated stability value is reduced by half if the route is considered reachable, whether suppressed or not.
Page 998 ip bgp dampening BGP Commands MIB Objects alaBgpGlobal alaBgpDampening alaBgpDampMaxFlapHistory alaBgpDampHalfLifeReach alaBgpDampReuse alaBgpDampCutOff page 19-30 OmniSwitch CLI Reference Guide March 2011...
Page 999: Ip Bgp Dampening Clear
BGP Commands ip bgp dampening clear ip bgp dampening clear Clears the dampening history data for all routes on the router, resetting route flap counters and unsup- pressing any routes that had been suppressed due to route flapping violations. ip bgp dampening clear Syntax Definitions Defaults Platforms Supported...
Page 1000: Ip Bgp Aggregate-Address
ip bgp aggregate-address BGP Commands ip bgp aggregate-address Creates and deletes a BGP aggregate route. Aggregate routes are used to reduce the size of routing tables by combining the attributes of several different routes and allowing a single aggregate route to be adver- tised to peers.
