Actions; Action Settings - Interlogix Advisor Advanced ATS 000A Series Installation And Programming Manual

Actions

7.2 Actions
0>Add Action
1 Action 1
Action is a user programmed function, which can be done automatically by the
system according to the programmed schedule. There can be up to 64
programmable actions in the Advisor Advanced system. Each action can be
programmed with a number of options. Before going any further, select the action
to program.

Action settings

7.2.0 Add action
Access the menu to add an action. If the action is created successfully, the
following message appears:
INFO
Action added
The new action is given the default name "Action N" and placed on the end of the
action list. You can now start editing the action details for the new action.
7.2.n Select action
1>Name
Action 1
Select an action to program.
7.2.n.1 Action name
1 Name
>Action 1 <
Every action can be programmed with a name to identify it.
Use the Action name screen to enter or edit the action name. The action name
can contain up to 16 characters.
7.2.n.2 Start time
2 Start time
>00:00<
Provide the time of the day in 24-hour HH:MM format when the selected action is
performed.
7.2.n.3 Active
3 Active
>Off<
The Active action menu allows you to disable or enable the action permanently.
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 129
