Note: The ping command must be acceptable by the remote host. Make sure its
firewalls and routers allow ping requests and replies. This applies to all ping
commands.
1.2.7.n.3 Ping PC
1>PC conn 1
----------------
The Ping PC command allows you to send a ping to the specified PC if it is
configured as a PC connection via IP. This function is identical to the one in the
"9.4 PC connection" menu. See "9.4.1.n.4.3 Ping host" on page 191 for more
details. See also "1.2.7.n.2 Ping host" on page 56.
1.2.7.n.4 Ping CS
2>CS 2
----------------
The Ping CS command allows you to send a ping to the specified central station
if it is configured as a CS connection via IP. This function is identical to the one in
the "9.1 Central station" menu. See "9.1.n.4.3 Ping host" on page 168 for more
details. See also "1.2.7.n.2 Ping host" on page 56.
1.2.7.n.5 NTP status
5>NTP status
Inactive
The NTP status screen allows you to check the current status of the Network
Time Protocol server configured. Possible server statuses are listed in Table 18
below.
Table 18: NTP statuses
Status Description
Inactive The NTP server is not queried yet. This status is usually present after panel
restart or NTP configuration.
Unknown The query was sent, but no answer from NTP server was received yet.
Fail No answer from NTP server.
OK NTP server answered the query.
Link error Faulty Ethernet line.
1.2.8 GSM diagnostic
1>PIN status
Normal
The GSM diagnostic menu provides an access to diagnostic tools for GPRS and
SMS connectivity.
