Zones

4.1 Zone menu
0>Add zone
1 Zone 1
This menu lets you see all programmed zones, select an existing zone, or create
a new one.

Zone options

4.1.0 Add zone
1>Panel
2 Input Exp
Use the Add zone menu to add a new zone. When adding a zone, specify
whether the zone is connected to the control panel PCB, an internal or a remote
expander. See "Zone and output addressing" on page 23 for available zone
addresses.
If the chosen zone already exists, a warning is displayed.
If the zone is created successfully, you are moved to the menu "4.1.n.1 Zone
name".

Adding a wireless sensor

If the selected expander is a wireless expander, adding zone results in learning
the wireless sensor by the wireless expander.
Wireless sensor learning is described in "Wireless device programming" on page
197.
If the device is a wireless PIR camera, a corresponding camera will be also
created in the camera database. See "Cameras" on page 110.
4.1.n Select zone
1>Zone name
Zone 1
Select an existing zone to program. Every zone has a number between 1 and 16,
depending on the location in the system.
4.1.n.1 Zone name
1 Zone name
>Zone 1 <
Use the Zone name option to set a zone name. The zone name identifies the
zone to the end-user for alarm reporting or for display of status or error message.
Without a proper name, the end-user would not be able to resolve problems that
arise in a particular zone.
