[1] Current available for auxiliary power and battery charge outputs.
[2] Maximum permanent current to power devices external to the control equipment in the
absence of alarm conditions. The sum of the auxiliary and COMM power output current
cannot exceed the maximum current specified in "Auxiliary current and battery capacity" on
page 28.
[3] Battery output provides battery shortcut protection (according to VdS requirements).
[4] The specifications depend on the battery capacity. The above table gives BS127 and BS131
as an example.
[5] If during a manual or a programmed battery test the battery voltage drops below this
threshold, the battery test fails.
[6] A specific fail message is generated when any output fails.
[7] Max ripple voltage only when empty battery is charging.
[8] Overvoltage protection mechanism monitors the power supply voltage and shuts down the
PSU if the voltage raises above indicated value.
General features
Code combinations
End-of-line resistor
Onboard zones
Maximum zone number:
ATS1000A(-IP)
ATS2000A(-IP)
Onboard outputs
Maximum output number
Areas:
ATS1000A(-IP)
ATS2000A(-IP)
Maximum keypad / RAS number
Maximum expander / DGP number
Maximum user number:
ATSx000A(-IP)
User groups
Event log capacity
Data retention (log, program settings)
Ethernet connection (IP only)
Supported standard
Speed
Duplex
Cabling
Autonegotiation
26
From 10,000 (4 digits) to 10 billion (10 digits)
1 kΩ, 1.5 kΩ, 2 kΩ, 2.2 kΩ, 3.3 kΩ, 3.74 kΩ,
4.7 kΩ (default), 5.6 kΩ, 6.8 kΩ, 8.2 kΩ, 10 kΩ
8 (expandable to 16 with 1X ATS608)
32
64
5 (expandable to 9 with 1X ATS624, or to 21 with 1X
ATS626).
See "Standard onboard outputs" on page 27.
128
4
8
8
7
100
16
500
20 years
IEEE 802.3u
10BASE-T or 100BASE-TX
Half-duplex and full-duplex
FTP (foiled twisted pair) Cat 5e cable or better
MDIX
