Expanders

2.2.2 Expander devices
0>Add expander
1 Expander 1
On the Expander devices menu, press 0 to add an expander, or a number to
configure an existing one.
Note: The maximum number of devices allowed on the databus is given in
"General features" on page 26.

Expander options

2.2.2.0 Add expander
Expander number
>_<
One the Add expander menu, enter the number for the new expander and press
Enter to confirm, or Clear to exit without adding a device.
After the device is added, the expander configuration options are shown.
2.2.2.n Select expander
Select the expander number to configure.
2.2.2.n.1 Expander type
1>Expander type
ATS1201
The expander type is an informational screen. The type is set by the expander.
2.2.2.n.2 Expander address
2>Exp address
01
The expander address is an informational screen providing the DIP switch
address.
2.2.2.n.3 Expander range
3>Expander range
113-128
Expander range is an informational screen. It shows zone range available for this
expander.
Note: In case of 32-zone devices there are two zone ranges.
3>Expander range
113-128 353-368
See "2.2.2.n.4.6 Expander mode" on page 78 for more details.
