Cameras

For more details on cameras, see also "Using cameras" on page 203.
4.3 Cameras
17>Camera 17
18 Camera 18
The menu allows you to configure camera modules in wireless PIR cameras.
4.3.n Select camera
1>Camera name
Camera 17
Select an appropriate camera to configure.
4.3.n.1 Camera name
1 Camera name
>Camera 17 <
Enter camera name.
4.3.n.2 Pics by zone
1>Zone 17
2 Zone 2
Choose 1 to 4 zones that can trigger the camera when active.
By default, the first zone assigned is the zone with PIR detector of this wireless
PIR camera.
Choose a zone position to assign a zone, or an existing zone to remove it from
the associated zone list.
4.3.n.3 Pics by filter
1>Filter 1
>>>
Additionally to the zones listed in "4.3.n.2 Pics by zone" above, there can be up
to two condition filters that also trigger the camera.
4.3.n.3.m Select filter
1>Filter 1
Not used
Select one of two filters to configure.
4.3.n.3.m.1 Choose filter
00>Not used
01 Internal sire
Choose a filter that activates the selected camera.
110 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
