9.1.n.5.m Select area
1 Area 1
> <
Set account numbers for each area.
9.1.n.6 Mode
6 Mode
>Primary CS<
The following modes are available for CS.
•
Primary CS: The primary central station must unconditionally receive all
addressed events.
•
Backup CS: The central station can be a backup CS for the previous CS in
the central station list (see "9.1 Central station" on page 163). This means
that the panel reports to this central station only if the primary CS reporting
fails.
For example, if CS 1 and CS 2 are primary CS, and CS 3 and CS 4 are backup
CS, it means that CS 1 has no backup, CS 3 is a backup central station for CS 2,
and CS 4 is a backup for central station 3.
See "Alarm reporting principles" on page 206 for more information.
9.1.n.7 Retry count
7 Retry count
>1<
The Retry count value is the number of retries to make a successful call to the
central station. If the limit is reached, the FTC is generated.
The counter is zeroed when a new event occurs in Global FTC condition. See
"Failed to communicate (FTC)" on page 208 for more information.
The value ranges from 1 to 14. The default value is 1.
9.1.n.8 Protocol opt
1>(X)SIA
2 VOICE
It is possible to customize the communication protocol parameters using the
Protocol opt menu.
9.1.n.8.1 XSIA
1>Area modifier
Off
The XSIA menu allows you to set options for the SIA and XSIA protocol.
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 165
