Page 1: Installation Manual
Alliance AL-4017/AL-4617 Control Panel Installation Manual... - Page 2 Copyright © 2012 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. This document may not be copied or otherwise reproduced, in whole or in part, except as specifically permitted under US and international copyright law, without the prior written consent from UTC Fire &...
- Page 3 2. Term. This Agreement is effective until terminated. You may terminate this Agreement by uninstalling all components of the Software from all Computing Devices and returning the Licensed Product to UTC FIRE & SECURITY. UTC FIRE & SECURITY may terminate this Agreement if You breach any of these terms and conditions.
- Page 4 Alliance AL-4017/AL-4617 Control Panel Installation Manual Restricted rights legend. The Licensed Product is provided with RESTRICTED RIGHTS. In the event the United States Government or an agency thereof is granted a license, the following additional terms apply: Restricted Computer Software, as defined in the Commercial Computer Software–Restricted Rights clause at Federal Acquisition Regulations 52.227-19,...
- Page 5 FCC compliance Part 15 notification This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
- Page 6 Alliance AL-4017/AL-4617 Control Panel Installation Manual...
-
Page 7: Table Of Contents
Contents Preface ............. - Page 8 Alliance AL-4017/AL-4617 Control Panel Installation Manual...
-
Page 9: Preface
Preface This is the Alliance AL-4017/AL-4617 Control Panel Installation Manual for models AL-4017 and AL-4617. This document includes an overview of the product and detailed instructions explaining: • how to install; and • how to wire the units. There is also information describing how to contact technical support if you have questions or concerns. - Page 10 Alliance AL-4017/AL-4617 Control Panel Installation Manual...
-
Page 11: Product Overview
Product overview Alliance is a scalable access control platform integrated with a intrusion alarm package. The Alliance control panels use a modular RS-485 data bus to provide continuous polling of remote arming stations (RAS) and data control panels (DGP). These devices extend the system’s security and access control functions. AL-4017. -
Page 12: Installation
Alliance AL-4017/AL-4617 Control Panel Installation Manual Installation To install the control panel, do the following: 1. Mount the enclosure. A suitable location should include easy access for wiring, good lighting, suitable access to power and earth ground, and ample space to work. The mounting surface should be flat and dry. - Page 13 2. Install the standoffs. Before the board can be installed, you must configure the appropriate standoffs. Use male/female standoffs where threaded holes are aligned with the mounting holes on the board and use clip-in standoffs where square holes are aligned with the mounting holes (Figure 2) Figure 2.
- Page 14 Alliance AL-4017/AL-4617 Control Panel Installation Manual 6. Slide the board’s terminal blocks together as shown in Figure 3 and mount them to the board. Figure 3. Terminal block assembly 7. Use four 6/32 x 1/4 in. screws with internal star washers to mount the board (Figure 4) in the enclosure (Figure 2 on page 3).
-
Page 15: Leds
LEDs Figure 4 on page 4 shows the following LEDs located on the board: L1. Flashes slowly when the panel is operating (the microprocessor is running). RX (Comms). Yellow LED flashes when remote units (RAS and DGP devices) are replying to polling. TX (Comms). -
Page 16: Wiring
Alliance AL-4017/AL-4617 Control Panel Installation Manual Wiring Keep all panel wiring well away from other wiring. Avoid parallel wire runs with other wires. Where parallel wire are unavoidable, keep wires a minimum of 2 in. (5 cm) apart or in EMT. We recommend that you wire Alliance system components that use direct wire transformers into a dedicated circuit breaker and you plug those that use plug-in transformers into an unswitched outlet. -
Page 17: System Bus Connections
System bus connections Connect DGP devices to the system bus to provide extra zones and remote arming stations (RAS) to the control panel. Remote devices can be up to 5,000 ft. (1.5 km) from an Alliance system control panel. DGP and RAS devices must be connected via a twisted-pair, shielded data cable from the system bus connection. -
Page 18: Auxiliary Power Supply Connections
Alliance AL-4017/AL-4617 Control Panel Installation Manual Auxiliary power supply connections In systems where expansion module power is not supplied by the main control panel or an AC-powered DGP with auxiliary outputs, you must use a UL listed power supply suitable for burglar alarm applications, such as the Altonix-AL300ULX. -
Page 19: Nonpower/Power-Limited Wiring
Nonpower/power-limited wiring Keep nonpower-limited wiring away (1/4 in. minimum) from power-limited wiring (Figure 8). Disconnect the AC power via a dedicated circuit breaker before servicing. Figure 8. Power and nonpower wiring Power limited wiring PSTN connection Nonpower- Nonpower- limited limited wiring wiring Power-... -
Page 20: Control Panel Connections
Alliance AL-4017/AL-4617 Control Panel Installation Manual Control panel connections Figure 9 shows the wiring connections on the control panel board. See on page 14 for the Battery capacity appropriate battery type. To wire the panel, use these guidelines: • The total auxiliary power output is 300 mA (including +12 on Comms) for the AL-4017 and 3 Amps (including +12 on Comms) for the AL-4617. -
Page 21: Zone Input Connections
Zone input connections Figure 10 shows zone inputs connections. Figure 10. Alarm input and bell output wiring Zone inputs C 5 C 6 C 7 C 8 C 9 C 10 C 11 C 12 C 13 C 14 C 15 C 16 C Figure 11 shows single and dual zone alarm input wiring. -
Page 22: Pstn Connections
Alliance AL-4017/AL-4617 Control Panel Installation Manual PSTN connections Figure 12 shows two methods to wire the control panel to a PSTN connection. This equipment complies with FCC Part 68 rules (US:GEIAL07B3-4000).We recommend you wire the system to a dedicated PSTN line. -
Page 23: Installer Programming Menu
Installer programming menu Refer to the Alliance System Programming Manual for a complete programming map and programming instructions. The installer programming menu includes: 1. Zone database 28. To remote devices 2. Area database 29. Computer connection 3. RAS database 30. Printer 4. -
Page 24: Battery Capacity
Alliance AL-4017/AL-4617 Control Panel Installation Manual Battery capacity You must do the battery capacity calculations separately for each part of the system that has a separate power supply and standby battery. See on page 16 for a sample worksheet. To... - Page 25 4. Do the following calculations for each worksheet: Formula 1. Transfer the total value at the bottom of the Total standby current column to the first blank in Formula 1. Enter the required number of hours in standby in the corresponding blank, and do the indicated calculation.
-
Page 26: Battery Calculation Worksheet
Alliance AL-4017/AL-4617 Control Panel Installation Manual Battery calculation worksheet Table 3. Battery calculation worksheet Alliance Standby Total standby Alarm current Total alarm Total active components current current per device current Active current current AL-4017 200 mA Aux power 300 mA... -
Page 27: Formulas
Formulas Table 4 provides the formulas to calculate battery requirements. Table 4. Battery calculation formulas Formula Calculation Result Total standby current x Conversion factor x Required hours in standby Ah standby Amp-hours .001Amp/mA hours Ah alarm Amp-hours Total alarm current x Conversion factor x Required minutes in alarm x Conversion factor mA x .001Amp/mA minutes x .0167 hours/min. -
Page 28: Absolute Maximum Loads
Alliance AL-4017/AL-4617 Control Panel Installation Manual Absolute maximum loads Table 5 and Table show the maximum continuous loads that can be supported by two 17.2 Ah batteries or one 17.2 Ah battery. If the total standby current exceeds those listed in the table, you do not meet 24/72-hour standby requirements. -
Page 29: Specifications
Specifications General specifications Current consumption PCB 205 mA nominal End-of-line resistors Default: 4.7 k ohm (other: 10 kohm, 6.8 kohm, 5.6 kohm, 3.74 kohm, 3.3 kohm, 2.2 kohm, 2 kohm, 1.5 kohm) 5%, 0.25 W Housing dimensions 21 x 14.5 x 4.5 in. (533 x 368 x 114 mm) Operating temperature 32 to 120°F (0 to 49°C) Humidity... -
Page 30: Al-4617 External Terminals
Alliance AL-4017/AL-4617 Control Panel Installation Manual AL-4617 external terminals Part Terminal Description Min. Unit Input BATT Battery connection Battery charge Battery AH rating 17.2 34.4 Auxiliary power outputs 13.8 AUX, POWER COMMS System bus power output 13.8 EXT Siren Alarm outputs 13.8... -
Page 31: Ul Compliance Statement
UL compliance statement To maintain compliance with UL365, UL609, and UL1610: Mercantile premises alarm systems Zone types 22, 28, 29, and 30 (auto reset) can not be used. Force arming is not allowed (refer to the Alliance System Programming Manual). Siren time should be programmed for no less than 15 minutes (refer to the Alliance System Programming Manual). -
Page 32: Contacting Technical Support
Alliance AL-4017/AL-4617 Control Panel Installation Manual Contacting technical support For assistance installing, operating, maintaining, and troubleshooting this product, refer to this document and any other documentation provided. If you still have questions, you may contact technical support during normal business hours (Monday through Friday, excluding holidays, between 5 a.m. and 5 p.m. Pacific Time).
