Interlogix Advisor Advanced ATS 000A Series Installation And Programming Manual page 121

4.3.n.3.m.2 Event type <n>
2 Event type 1
>Burglar<
Define a type of the condition filter chosen in "4.3.n.3.m Select filter" on page
110.
The available filter types are listed in "Camera event types" on page 203.
4.3.n.3.m.3 Report as
3 Report as
>Not used<
If the filter has a custom type, it is necessary to assign a reporting event, which
occurs when the filter becomes active.
Notes
•
After you leave this menu, the event is shown as a reporting code in SIA
format. See "Reporting codes used in Advisor Advanced" on page 223 for
details.
•
Only particular reporting events are available.
4.3.n.4 Pics by rep ev
1>Rep. event 1
Not used
The camera can be also triggered by a selected reporting event.
4.3.n.4.m Select event
1 Rep. event 1
>Not used<
Select one of two reporting events to configure.
Choose an event that activates the selected camera.
Notes
•
After you leave this menu, the event is shown as a reporting code in SIA
format. See "Reporting codes used in Advisor Advanced" on page 223 for
details.
•
Only particular reporting events are available.
4.3.n.5 Isolated
5 Isolated
>No<
When the camera is isolated, it does not take pictures. Also, pictures cannot be
sent to the panel.
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 111
