Option
Enter the menu entry Enter menu entry number, or
Show help
Exit the menu entry
You can now select the menu option you want to program. See "Programming
Map" on page 251 for a diagram of all the menu entries available in the
programming menu.

What the LCD display tells you

The LCD display on the keypad has two lines of characters.
A programming option occupies both lines:
Expander number
>_<
A menu command usually occupies one line. Two commands of a menu are
shown below:
1>Keypad devices
2 Exp devices
Particular menu entries occupy the whole screen, and the line ">>>" indicates a
submenu.
3>Keypad options
>>>

Editing the options

Once you have selected the menu option you want to program, most options can
be programmed using the standard procedure shown in "How to program" below.
How to program
The method of programming depends on the options to be programmed. Some
options require a value, others require a Yes/No setting.
How to program values
3 Entry time
> <
•
1 to 0: Enter the new information
•
Enter: Confirm the entry
•
Clear: Exit without changes
38
Action
Press Enter or Right to enter
the selected one
Press Help
Press Left or Clear
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Result
Jump to a specific menu entry
The description of the selected menu
entry is displayed (if available)
Exit the menu entry
