6.2.n.8 Log limit
8 Log limit
>Enable<
If the Log limit option is set to Enable, only 3 pairs of activating (opening) and
restoring (or closing) events coming from a single output are recorded in the log
during one set/unset cycle.
Door control example
To program a door control function described in example on page 117, set the
following values:
•
Select filter "Door open" for output 10.
Output 10 can then be used to unlock a door.
•
Select Pulsed mode.
•
Set Delay time to 00:00'00.
•
Set Active time to 00:00'05 s.
See "6.1 Condition filters" on page 117 for more information.
6.2.n.9 Delete output
9 Delete output
>Cancel<
Use the Delete output screen to remove an output from the system. To remove
the output, select OK and press Enter again. The output is deleted.
