Interlogix Advisor Advanced ATS 000A Series Installation And Programming Manual page 253

Normal / Active / Describes the condition of a zone.
Tamper / Inhibited /
•
Isolated / Masked /
•
Fault
•
•
•
•
•
Nuisance alarm An alarm that is triggered by a security device, without any burglar. It could
be caused by open windows, pets or incorrect projection of security
equipment.
Online / offline Operational/non-operational. A device may be offline due to a malfunction in
the device itself or it may be disconnected from the control.
Output expander A PCB module that connects to the Advisor Advanced control panel or an
expander to provide relay or open collector outputs.
Panic button See hold-up.
Part set The condition of part of an area where a change in the status of certain
zones (from normal to active) causes an alarm. An area or premise is part
set when it is partially unoccupied like the outside of a home is part set but
the inside is still unset.
PIN A 4 to 10 digit number given to, or selected by, a user. It is necessary to
enter a PIN on an Advisor keypad as a prerequisite to perform most Advisor
Advanced options. In the Advisor Advanced configuration the PIN is
associated with a user number, which identifies the PIN holder to the
system.
PIR Passive infrared detector. A security device used to detect intruders in a
certain part of an area or premise. The technique used is based on infrared
detection.
Poll An inquiry message continually sent by the Advisor Advanced control panel
to expanders and keypads. Polling allows the remote unit to transfer data to
the control panel.
RAS Remote arming station. See Keypad.
Reader A device used for access control that can read cards to allow access.
Depending on the needs and the type of cards, the reader can for example
be a magnetic swipe reader or proximity reader. May be integrated into a
keypad.
Remote expander See Expander.
Remote keypad See Keypad.
Reporting See Alarm reporting.
Request to Exit A zone that is programmed to open a door using a button or PIR. Used to
zone allow users to exit without using the door reader. Request to exit is often
abbreviated to RTE. Also called egress.
Screen saver See Armed display.
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Normal: The zone is not activated. For example, fire exit door closed.
Active: The zone is activated. For example, fire exit door open.
Tamper: The zone is open or short-circuited. Someone may have tried
to tamper the security device.
Inhibited: The zone has been inhibited from indicating normal or active
status. It is excluded from functioning as part of the system for particular
time. However, tampers are still monitored.
Isolated: The zone has been inhibited from indicating normal or active
status. It is excluded from functioning as part of the system
permanently.
Masked: Detector is masked.
Fault: Detector reports an internal fault.
243
