Interlogix Advisor Advanced ATS 000A Series Installation And Programming Manual page 214

Table 39: Camera events and reporting codes
Event type Activated by zone type [1]
Burglar alarm 1. Alarm, 2. Entry/Exit 1, 3. Access, 6. 24H, 13. Fire door,
16. Key box, 18. Entry/Exit 2
Fire alarm 4. Fire
Panic alarm 5. Panic
Medical alarm 10. Medical
Tamper alarm 7. Tamper
Fault 11. Technical, 12. Transmission path fault, 14. Aux mains
fault, 15. Aux batt fault
Custom type 1 Not allowed [3]
Custom type 2 Not allowed [3]
[1] Zones of particular types do not activate camera. These are 8. Exit terminator, 9. Keyswitch,
17. Eng. reset. When an assigned zone is one of the listed types, it is ignored when active.
[2] If the camera has been activated by a standard reporting event, another event caused by
camera activation does not occur. Detailed codes and subevent values are described in
"Reporting codes used in Advisor Advanced" on page 223.
[3] Custom type events can only be activated by condition filters.
[4] See "4.3.n.3.m.3 Report as" on page 111 for details.
Each of these types can be configured in "2.2.2.n.4.9.1 Pic settings" on page 79.
Depending on camera event type, the camera can be programmed to take a
single picture or a series of pictures, in low or high resolutions.
How to program a camera:
1. Program the wireless PIR camera expander. See "Devices" on page 66 for
more details.
2. Program a wireless PIR camera as a wireless PIR detector. See "Wireless
device programming" on page 197 for more details.
If the detector is programmed successfully, the appropriate camera is created
automatically. The created camera number is equal to the zone number of the
wireless PIR detector.
3. Program the camera options. See "4.3 Cameras" on page 110.
4. Assign zones to the camera. Choose up to four zones. The camera is useful if
its field of view covers these zones or possible burglar escape paths from
there. See "4.3.n.2 Pics by zone" on page 110.
By default, the first assigned zone is the zone of the wireless detector built in
the configured wireless PIR camera.
5. If necessary, program conditional event filters that activate the camera. See
"4.3 Cameras" on page 110 for details.
6. If necessary, program reporting events that activate the camera. See "4.3
Cameras" on page 110 for details.
204 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
SIA code [2]
BA
FA
PA
MA
TA
UA
Selectable [4]
Selectable [4]
