2.2.1.n.2 Keypad address
2>Bus address
0
The bus address is an informational screen showing the bus address set by DIP
switches or programmed within the keypad.
2.2.1.n.3 Keypad options
3>Keypad options
>>>
The Keypad options menu contains the shown below, which are necessary to
configure the selected keypad.
Note:
The available options depend on the keypad type.
2.2.1.n.3.1 Keypad name
1>Keypad name
Keypad 1
Use the Keypad name option to enter a name that identifies the keypad to the
end-user.
When a keypad is created, it is given the default name "Keypad <n>", where <n>
is the keypad number. Enter this menu to edit the current name.
A keypad name can consist of 16 characters.
2.2.1.n.3.2 Tamper area
2>Tamper area
Area 1
The Tamper area option determines which area receives keypad tamper and
fault events. To change it, select the area and press Enter.
2.2.1.n.3.3 View areas
3>View areas
12.4....
The View areas menu lets you specify which area will display information on this
keypad without a user authorization. The areas are displayed as a list. To change
the selection, press Enter and select the appropriate areas.
Note:
After an authorization the area view depends on the user privileges and
system state.
How to select areas to view
See "How to edit a list" on page 39.
Note:
After changing this list, the control of selected areas is also enabled (see
"2.2.1.n.3.4 Control areas" on page 70).
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
69
