2.2.1.n.3.12 Area ind.LED2
12 Area ind.LED2
>........<
Use Area ind.LED2 to program LED 2 indicator in the same way as described in
"2.2.1.n.3.11 Area ind.LED1" on page 72.
2.2.1.n.3.13 Status ind.
13 Status ind.
>List<
Status indication defines how the area status list is displayed. The following
options are available:
•
List: The areas are displayed as a vertical list with names and statuses, which
requires scrolling.
•
Symbolic: All areas are displayed in one screen. Only area numbers and
statuses are displayed.
See Advisor Advanced User Guide for more information on area selection.
2.2.1.n.3.14 LCD backlight
14 Status ind.
>Always on<
LCD backlight option defines when the keypad display backlight is lit. There are
the following options available:
•
Always on: LCD backlight never switches off.
•
Normal: LCD backlight switches off after the particular idle time.
•
Excl. entry: LCD backlight is off during the entry time, until a key is pressed.
Note:
The backlight timeout depends on the particular keypad firmware.
2.2.1.n.3.15 ACK on keypad
1>Rkp 1
2 Rkp 2
The ACK on keypad option allows you to select an additional LCD keypad that
displays an acknowledgement prompt after the system is unset using the
selected non-LCD keypad or reader.
Note:
This option is only available for non-LCD keypads and card readers.
See also "4.1.n.6.25 ACK on keypad" on page 101 for more details.
2.2.1.n.3.16 EE 1 buzzer
16 EE 1 buzzer
>Yes<
If the option is set to Yes, the buzzer of the selected keypad is active during
entry/exit time 1.
See "2. Entry/Exit 1" on page 233 for more details.
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
73
