3. In menu "6.1.n.2 Formula" program the condition filter as below:
# Event or operand
Keypad.1.7
1>
OR
2
Zone.10.1
3
AND
4
Area.1.3
5
The next step is assigning this condition filter to the door lock, connected to
output N, which is described in "Door control example" on page 124.

Filter settings

6.1.n Select filter
Select an existing filter to program.
6.1.n.1 Filter name
1 Filter name
>Filter 52 <
The name identifies the filter for installer, making the programming dependencies
clearer.
6.1.n.2 Formula
0>Add event
----------------
The Formula menu allows definition of the filter formula. Up to 4 events can be
combined in a formula.
6.1.n.2.0 Add event
0>Add event
1 System.0.1
Use the Add event command to add an operand to the current formula. Press
Add event to add the operand.
This menu entry is not available if the formula already contains 4 events.
The next steps depend on whether you select an event or an operator for the
formula.
118
Description
Correct PIN, entered on keypad 1.
Active Zone 10, which is connected to the key switch and set up
in "4 Zones and RF fobs" menu.
Area 1 unset.
