(1) Blue LED
(2) Red LED
(3) Dual LED
(4) Yellow LED
(5) Red LED
(6) Numeric keys
(7) Off
(8) On
Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Access granted
On: area set
Flashing: general alert (EN 50131)
Green on: AC mains supply on
Green flashing: AC mains supply off, or unlocked while unset
Red on: all areas set
Red flashing: unlocked while set
On: All zones are in normal state
Flashing: general alert (EN 50131)
Flashing: alarm
Keys 0 to 9, numerical data
Unset an area
Full set an area
