1.2.6.n.6 RSSI in report
6 RSSI in report
>Yes<
If the option is set to yes, the test call event contains RSSI value as a subevent.
The option is only applicable when GSM communication path reporting is used.
1.2.7 IP diagnostic
1>ETH
>>>
The IP diagnostic menu provides an access to diagnostic tools for IP
connectivity.
1.2.7.n Choose interface
1>IP statistics
>>>
Choose an interface for diagnostic. Depending on the panel firmware and
hardware, the following interfaces may be available:
•
ETH: Ethernet
•
GPRS: GPRS via GSM module.
1.2.7.n.1 IP statistics
1>TX packets
5
The IP statistics menu allows viewing of the statistics listed in the table below.
Table 17: IP statistics data and functions
Item
1.2.7.n.1.1 TX packets
1.2.7.n.1.2 RX packets
1.2.7.n.1.3 Rej. packets
1.2.7.n.1.4 TX bytes
1.2.7.n.1.5 RX bytes
1.2.7.n.1.6 Clear stat?
* See "9.3.n.7 Firewall" on page 177 for more information.
1.2.7.n.2 Ping host
Host name
> <
The Ping host command allows you to send a ping to the specified network
address. This command is used to check if the specified host is present and
accessible from the panel in the network.
56
Description
Number of packets sent
Number of packets received
Number of packets that are rejected by built-in firewall*
Number of bytes sent
Number of bytes received
This command clears the data described above
