Océ
User manual
VarioPrint 1105
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Oce VarioPrint 1105

Summary of Contents for Oce VarioPrint 1105

  • Page 1 Océ User manual VarioPrint 1105 User Manual...
  • Page 2 Océ-Technologies B.V. Océ-Technologies B.V. Copyright 2008, Océ-Technologies B.V. Venlo, The Netherlands. All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ. Océ-Technologies B.V. makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.

  • Page 3: Table Of Contents

    Perfect Binder PB-501 ..............2-16 2.1.8 Finisher FS-503 ................2-19 2.1.9 Standard/Optional Equipment ............. 2-20 Turning On/Off the Power Switch ..........2-23 2.2.1 To Turn On the Power ..............2-23 2.2.2 To Turn Off the Power ..............2-25 VarioPrint 1105...
  • Page 4 Adding Paste Pellets to Perfect Binder PB-501 ......4-22 Empty Trash Basket of Folding Unit FD-501 .........4-25 Empty Dust Box of Saddle Stitcher SD-501 ........4-27 Empty Dust Box of Perfect Binder PB-501 ........4-29 Removing Finished Sets from Large Capacity Stacker LS-501/502 ..................4-31 VarioPrint 1105...
  • Page 5 Before Making Copies Copy Screen ..................5-3 5.1.1 Machine Status Screen ..............5-5 Features of the VarioPrint 1105............5-7 How to Make a Basic Copy ............5-12 Positioning Originals ..............5-16 5.4.1 Positioning Originals in ADF ............5-16 5.4.2 Positioning Original on Original Glass .......... 5-19 Setting Print Quantity ..............
  • Page 6 Programming Different Settings for an Output Job (Program Job) ..................8-39 8.11 Erasing Outside of the Original (No Image Area Erase) ....8-42 8.12 Reversing Colour in Black and White Image (Neg. Pos. Reverse) .................8-45 8.13 Repeating Selected Image Area (Repeat: Vert./Horiz. Mode) ..8-47 VarioPrint 1105...
  • Page 7 Using Saddle Stitcher SD-501 ............9-34 9.7.1 Making Folded Booklet ..............9-34 9.7.2 Folding Copied Set ..............9-38 Using Post Inserter on Folding Unit FD-501 ......... 9-42 Using Folder/Finisher Functions Manually ........9-46 9.10 Using Perfect Binder PB-501 ............9-50 VarioPrint 1105...
  • Page 8 Change Paper Type/Weight Specified for a Tray .......12-29 13 Adjustment 13.1 Machine Adjustment Outlines ............13-3 13.2 01 Magnification Adjustment ............13-4 13.3 02 Timing Adjustment ..............13-13 13.4 03 Centering Adjustment ..............13-22 13.5 Finisher Adjustment Outlines ............13-24 13.6 01 Stapler Position Adjustment ............13-25 VarioPrint 1105...
  • Page 9 01 Feed Tray Setting ..............16-17 16.2.2 02 ATS Permit ................16-19 16.2.3 03 Auto Paper Type ..............16-21 16.2.4 02 Each Function Setting ............16-23 16.2.5 03 Density Setting ..............16-25 16.2.6 03 Photo Mode Density Setting ..........16-29 VarioPrint 1105...
  • Page 10 01 Authentication Method ............17-51 17.4.2 02 Volume Track .................17-56 17.4.3 03 User Authentication Set ............17-61 17.4.4 04 Non register/Output Set ............17-67 17.5 04 Network Setting ................17-68 17.5.1 01 Machine NIC Setting ..............17-68 17.5.2 02 Controller NIC Setting ............17-70 VarioPrint 1105...
  • Page 11 Transmitting Machine Setting File ..........18-24 18.5 Box Edit ..................18-32 18.6 Web Connection ................18-37 18.7 Access ................... 18-39 18.8 Screen Configuration ..............18-40 18.8.1 Logging in Using Administrator Mode ........18-42 18.9 Administrator Mode ..............18-44 VarioPrint 1105...
  • Page 12 SMB ....................18-72 18.12.7 Apple Talk ...................18-74 18.12.8 E-Mail ..................18-75 18.12.9 SSL/TLS ..................18-77 18.12.10 Authentication ................18-92 19 Security 19.1 Security Functions ................19-4 19.1.1 Environments in which Security Strengthen mode is recommended ..............19-5 19.1.2 Creating a secure environment .............19-5 x-10 VarioPrint 1105...
  • Page 13 20.3.2 Tray Empty ................... 20-9 20.3.3 Inconformity in Paper Presetting ..........20-11 20.4 If “Memory Full” Message Is Displayed (Memory Overflow) ............... 20-13 20.5 If Power OFF/ON Screen Is Displayed ........20-14 20.6 Troubleshooting Tips ..............20-15 VarioPrint 1105 x-11...
  • Page 14 About keys on the character input screen ........23-3 23.1.2 About character input ..............23-4 23.2 Setting Data for Import/Export ............23-5 23.3 Configuration Setting ..............23-10 23.4 Font List ..................23-15 23.5 PCL Font List .................23-26 23.6 Glossary ..................23-29 23.7 Index ....................23-32 x-12 VarioPrint 1105...
  • Page 15 (2, 4, or 8) of pages onto one sheet of copy pa- per. We recommend that you utilize Auto Low Power function, the Automatic Shut-Off function, Automatic Duplex Copying function, and Combination function. VarioPrint 1105 x-13...

  • Page 16: Safety Information

    - The information written in this Operator Manual is subject to change with- out prior notice. Note To operate safely, be sure to read the Safety Information before using the machine. For details, refer to “Safety Information” on page 1-3. x-14 VarioPrint 1105...

  • Page 17: Safety Information

    Safety Information...

  • Page 19: Warning And Precaution Symbols

    This symbol warns against cause burns. A diagonal line indicates a prohibited course of action. This symbol warns against dismantling the device. A solid circle indicates an imperative course of action. This symbol indicates you must unplug the device. VarioPrint 1105...
  • Page 20 Use of an adapter or an extension cord could cause a fire or electrical shock. Contact your authorized service representative if an extension cord is required. • Consult your authorized service representative before connecting other equipment on the same wall outlet. Overload could result in a fire. VarioPrint 1105...

  • Page 21: Safety Information 1

    Dust that accumu- lates between the plug terminals may cause a fire. Grounding WARNING • Connect the power cord to an electrical outlet that is equipped with a grounding terminal. VarioPrint 1105...
  • Page 22 Ventilation CAUTION • Always use this product in a well ventilated location. Operating the product in a poorly ventilated room for an extended period of time could injure your health. Ventilate the room at regular intervals. VarioPrint 1105...
  • Page 23 • When moving this product, always hold it by the locations specified in the User manual or other documents. If the unit falls it may cause severe personal injury. The product may also be damaged or mal- function. VarioPrint 1105...
  • Page 24 • Do not swallow paste pellets. Should you swallow any, drink large amount of water or milk to vomit, and immediately consult a doctor. • Keep out of reach of children in order to avoid unexpected acci- dents. VarioPrint 1105...
  • Page 25 • Do not block up the vent for the fan on the back of the Perfect Bind- er. This will prevent the discharge of heat, and may cause fire or breakdown. • Do not change the temperature setting for the paste tank unit. This may cause fire or breakdown. VarioPrint 1105...

  • Page 26: Regulation Notices

    Dersom apparatet brukes på annen måte enn spesifisert I denne bruk- sanvisning, kan brukeren utsettes for usynlig laserstråling som over- skrider grensen for laser klass 1. Dette en halvleder laser. Maksimal effekt till laserdiode er 15 mW og bøkgelengde er 770 - 800 nm. 1-10 VarioPrint 1105...
  • Page 27 överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 15 mW och våglängden är 770 - 800 nm. Rear side of main body VarioPrint 1105 1-11...

  • Page 28: Ozone Release

    The use of non-shielded cables is likely to result in interfer- ence with radio communications and is prohibited under 89/336/EEC rules. 1.2.5 For German Users Maschinenlärminformations -Verordnung - 3. GSGV, 18.01.1991: Der arbeitsplatzbezogene Immisionswert betraegt 70 dB(A) oder weniger nach ISO 7779. 1-12 VarioPrint 1105...

  • Page 29: Caution Labels And Indicators

    CAUTION This product employs a Class IIIb Laser Diode that emits an invisible laser beam. The cover should not be opened under any circumstances. VarioPrint 1105 1-13...
  • Page 30 Safety Information CAUTION The paste tank unit is very hot. To avoid getting burned DO NOT TOUCH. 1-14 VarioPrint 1105...

  • Page 31: Installation Space

    1,065 kg at maximum, depending on the combination of options. Be sure to choose a level and solid floor for the installation place. Unit: mm Unit: mm Main body + DF-603 + PF-701 + FS-503 Main body + DF-603 + PF-701 + LS-502 VarioPrint 1105 1-15...
  • Page 32 Safety Information Unit: mm Unit: mm Main body + DF-603 + PF-701 + LS-501 + LS-502 Main body + DF-603 + PF-701 + FD-501 + FS-503 Main body + DF-603 + PF-701 + LS-502 (×2) + FS-503 1-16 VarioPrint 1105...
  • Page 33 Safety Information Unit: mm Main body + DF-603 + PF-701 + FD-501 + SD-501 + FS-503 Main body + DF-603 + PF-701 + FD-501 + SD-501 Main body + DF-603 + PF-701 + SD-501 VarioPrint 1105 1-17...
  • Page 34 Safety Information Unit: mm Main body + DF-603 + PF-701 + SD-501 (Side view) Main body + DF-603 + PF-701 + FD-501 + SD-501 + PB-501 Main body + DF-603 + PF-701 + SD-501 + PB-501 1-18 VarioPrint 1105...
  • Page 35 Safety Information Unit: mm Main body + DF-603 + PF-701 + FD-501 + SD-501 + PB-501 Main body + DF-603 + PF-701 + LS-501 + PB-501 Main body + DF-603 + PF-701 + PB-501 VarioPrint 1105 1-19...
  • Page 36 Recycling of this product will help to conserve natural resources and prevent potential negative consequences for the environment and human health caused by inappropri- ate waste handling. 1-20 VarioPrint 1105...

  • Page 37: Preparation For Use

    Preparation for Use Copier...

  • Page 39: Machine Configuration

    Tray 4 (universal tray) is user-adjustable and holds 2,000 sheets from A3 to A5. OHP films and thick paper are available from this tray only. Tray 5 (universal tray) is user-adjustable and holds 2,000 sheets from A3 to A5. VarioPrint 1105...
  • Page 40 Toner unit door opens to allow toner supply. Options see descritpion for each on the following pages Left side door opens together with the Front door to allow removal of mishandled paper or when turning on/off the main power switch. VarioPrint 1105...

  • Page 41: Internal Machine Items

    Fixing unit fuses the toner onto the copy paper. Main power switch used only by service representative turns machine power on/off when pressed. 7 CAUTION The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. VarioPrint 1105...

  • Page 42: Control Panel Layout

    (Clear quantity) allows resetting of print quantity. Access sets the machine to allow copying/scanning/printing only when the User Authentication/Volume Track password is entered. VarioPrint 1105...
  • Page 43 Stop the operation to prevent any unexpected accident. Write down the report code as stated on the 2nd line of the message, then switch off the machine and disconnect from the power socket. Contact your service representative and inform them of the report code. VarioPrint 1105...

  • Page 44: Folding Unit Fd-501

    Upper cover feed tray hold cover sheets to fix the position. guide plates Upper cover opens to allow removal of mishandled paper. Folding unit door opens to allow removal of mishandled paper or waste pa- per. VarioPrint 1105...
  • Page 45 Conveyance knob/1 can be turned counterclockwise to ease removal of mis- handled paper. Outlet lever opens rightward to remove mishandled paper. Upper/Lower right side opens upward to remove mishandled paper. lever VarioPrint 1105...
  • Page 46 Left side lever (right/ opens leftward to remove mishandled paper. left) Upper lever opens upward to remove mishandled paper. Conveyance knob/2 can be turned clockwise to ease removal of mishandled cover paper. 2-10 VarioPrint 1105...
  • Page 47 Non-sort mode. Top cover handle (left) opens to remove mishandled paper. Top cover handle opens to remove mishandled paper. (right) Paper removal indica- lights while the stacker goes down in order to allow takeout of printed sheets. VarioPrint 1105 2-11...
  • Page 48 Inlet lever opens downward to remove mishandled paper. Stacker holds sets output in Non-sort mode or Collated mode (offset). Carriage carries paper together with the stacker. Outlet lever opens downward to remove mishandled paper. 2-12 VarioPrint 1105...

  • Page 49: Saddle Stitcher Sd-501

    Preparation for Use 2.1.6 Saddle Stitcher SD-501 VarioPrint 1105 2-13...

  • Page 50: Internal View

    Stitcher SD-501 Saddle Stitcher tray is withdrawn when using Fold&Staple mode Dust box is withdrawn to remove waste paper. Left side door of Sad- opens for staple supply or to remove mishandled paper. dle Stitcher SD-501 2-14 VarioPrint 1105...

  • Page 51: External View

    Stapling unit staples folded sets. Stapling unit knob can be turned clockwise to feed mishandled paper. Outlet lever opens leftward to remove mishandled paper. Outlet conveyance le- opens downward to remove mishandled paper. VarioPrint 1105 2-15...

  • Page 52: Perfect Binder Pb-501

    Preparation for Use 2.1.7 Perfect Binder PB-501 2-16 VarioPrint 1105...
  • Page 53 Perfect binder tray holds sets output in Perfect Binding mode. Perfect binder tray opens to take out the bound sets from the tray. cover Feeding button is pressed to feed the bound set leftward. VarioPrint 1105 2-17...
  • Page 54 Cover fixing plate re- can be turned clockwise for the left knob and anticlock- leasing knob (right/left) wise for the right knob to release the cover fixing plate for removal of mishandled paper. 2-18 VarioPrint 1105...

  • Page 55: Finisher Fs

    Stapler unit convey- opens downward to remove mishandled paper. ance lever Stapler unit handle withdraws the unit to allow removal of mishandled paper. Stapler unit knob can be turned counterclockwise to ease removal of mis- handled paper. VarioPrint 1105 2-19...

  • Page 56: Standard/Optional Equipment

    + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Finisher FS-503 + Saddle Stitcher SD-501 + Folding Unit FD-501 Large Capacity Stacker LS-502 + Folding Unit FD-501 Finisher FS-503 + Large Capacity Stacker LS-501 + Folding Unit FD-501 2-20 VarioPrint 1105...
  • Page 57 + Saddle Stitcher SD-501 + Folding Unit FD-501 Saddle Stitcher SD-501 Main Body + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Finisher FS-503 + Saddle Stitcher SD-501 Perfect Binder PB-501 + Saddle Stitcher SD-501 Perfect Binder PB-501 VarioPrint 1105 2-21...
  • Page 58 Main Body + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Perfect Binder PB-501 + Large Capacity Stacker LS-501 Large Capacity Stacker LS-502 + Large Capacity Stacker LS-501 Finisher FS-503 + Large Capacity Stacker LS-501 (×2) 2-22 VarioPrint 1105...

  • Page 59: Turning On/Off The Power Switch

    The sub power switch is located on the right side of the control panel. When the sub power switch is turned on, the Power LED will turn green. The Wake-up Screen and Machine Status Screen with warm-up image will be displayed. VarioPrint 1105 2-23...
  • Page 60 For details, refer to “Making User Au- thentication” on page 2-33. If a key counter or copy card is required, follow the instruction on the screen. 2-24 VarioPrint 1105...

  • Page 61: To Turn Off The Power

    Be sure not to turn off the main power switch in usual operation. When turning the main power switch off then on, be sure to wait 10 sec- onds or longer before turning it on again; otherwise the machine may not operate properly. VarioPrint 1105 2-25...

  • Page 62: To Use Machine When Power Save Led Lights

    “Timer interrupt mode / Please input password” displayed in the message area, and the machine operation will be available temporarily by the Timer Interrupt function. For details, refer to “When Weekly Timer Is Activated” on page 2-30. 2-26 VarioPrint 1105...

  • Page 63: Auto Low Power

    To start a copying job, press [Power Save]. The copying operation will become available. Note The Auto shut-off can be set for 30 minutes/ 60 minutes/ 90 minutes/ 120 minutes/ 240 minutes, or can be deactivated. For details, refer to “Lists of the function settings” on page 15-5. VarioPrint 1105 2-27...

  • Page 64: Using Power Save Manually

    Press [Power Save] for one second or longer, then release it. The following message will be displayed. Using Auto Shut-Off: Entry Shut off mode, after 10 second Press key/screen to cancel Using Auto Low Power: Entry Low Power mode, after 10 second Press key/screen to cancel 2-28 VarioPrint 1105...
  • Page 65 Press POWER SAVER continuously more than one second for low power mode Power Save will be activated. The [Power Save] LED will be lit and the LCD screen will be turned off. VarioPrint 1105 2-29...

  • Page 66: When Weekly Timer Is Activated

    The machine power will be turned off automatically after 5 minutes from this state if a password is not entered. Input copy time 0 hour(s) 05 minute(s) If the above message is displayed, proceed to step 3. 2-30 VarioPrint 1105...
  • Page 67 Input copy time 3 hour(s) 07 minute(s) Press [Start]. Details Entering a number smaller than 5 will set the minute at 5. A number larger than 60 is unavailable. Copying is available until the set time is up. VarioPrint 1105 2-31...
  • Page 68 Preparation for Use When the machine operation is finished, press [Power Save] for one second or longer, then release it. The machine returns to OFF condition. 2-32 VarioPrint 1105...

  • Page 69: Making User Authentication

    Copy quantity limit for each section can also be set. When the machine is turned on, one of the following User Authentication screen will be displayed according to the authentication setting. VarioPrint 1105 2-33...
  • Page 70 If the message “Copy limit reached” is displayed and machine operation becomes unavailable, contact your machine manager. When machine operation is completed, press [Access]. The initial state will be restored, with the User Authentication Screen displayed on the touch panel. 2-34 VarioPrint 1105...

  • Page 71: Paper And Original Information

    Paper and Original Information Copier...

  • Page 73: Paper Information

    Refer to the following information on paper capacity for each. 3.1.1 Paper Weight Paper Trays Weight Tray 1 and 2 (Main body trays) 40 ~ 244 g/m Tray 3 and 5 (PF-701 trays) 40 ~ 244 g/m Tray 4 (PF-701 tray) 40 ~ 300 g/m VarioPrint 1105...
  • Page 74 (sub) tray on the left side of the Folding unit. Reminder Be sure to use paper only of the weight specified for the tray; otherwise copy quality may be deteriorated or machine trouble may occur. VarioPrint 1105...

  • Page 75: Tray/ Exit Tray Capacity

    Large capacity Stacker • Max. 5,000 sheets stacker (A3, B4, F4, A4, A4R, 12”x18”, 11”x17”, 8.5”x14”, 8.5"x11", 8.5"x11"R, Wide sizes (Max. 324mm x 460mm) • Max. 2,000 sheets (B5, A5) Secondary (sub) Max. 200 sheets tray VarioPrint 1105...
  • Page 76 Folding unit. Using Letter fold-in, Letter fold-out, Double parallel, or Gate mode, the finished set will be delivered only to the secondary (sub) tray on the left side of the Folding unit. VarioPrint 1105...
  • Page 77 40 mm 45 mm Not specified 6 ~ 15 45 mm 50 mm Not specified Not specified 16 ~ 30 50 mm 55 mm Not specified Not specified 31 ~ 50 60 mm 65 mm Not specified Not specified VarioPrint 1105...

  • Page 78: Paper Size

    Folding unit Post inserter Upper/Lower • STD size: A3 to A5 tray • Wide sizes Large capacity Stacker STD size: A3 to A5 stacker Secondary (sub) Wide sizes: tray Max. 324mm x 460mm ~ Min. B6R VarioPrint 1105...

  • Page 79: To Store Copy Paper

    - Store paper in a cool, dry area. Using damp copy paper may cause a pa- per misfeed. - Keep partially used packages tightly wrapped during storage. - Do not place paper packages vertically to store. - Paper curl due to the vertical storage may cause a paper misfeed. VarioPrint 1105...

  • Page 80: Original Information

    Note Detectable paper size can be changed from only A series to Inch series, AB series, or AB series and Inch series mixed by the machine manager. For details, refer to “07 Size Setting” on page 17-35. 3-10 VarioPrint 1105...
  • Page 81 Paper and Original Information 7 CAUTION Do not place too heavy originals, or do not press strongly when thick original is placed and is under pressure of ADF; otherwise the glass may be broken and you may be injured. VarioPrint 1105 3-11...

  • Page 82: Adf Originals

    • A4R, B5R and A5 mixed Original weight 50 ~ 130 g/m (no special stock) Max. feeder capacity 100 sheets (80 g/m paper) Curling tolerance 10mm or less Original placement Face up (For details, refer to p. 5-17.) 3-12 VarioPrint 1105...
  • Page 83 Detectable original size 297mm x 432mm ~ 128mm x 140mm Original weight • Single-sided original 50 ~ 200 g/m paper • Double-sided original 50 ~ 130 g/m Max. feeder capacity 1 sheet at a time Original placement Face up VarioPrint 1105 3-13...
  • Page 84 Paper and Original Information 3-14 VarioPrint 1105...

  • Page 85: Supplies & Handling

    Supplies & Handling Copier...

  • Page 87: Loading Paper

    Paper type setting for each tray made on the Machine Status Screen can be changed temporarily on the Copy Screen using the Paper Presetting key. Be sure to load the specified paper; otherwise mishandled paper may oc- cur. VarioPrint 1105...

  • Page 88: Loading Paper In Main Body Trays And Paper Feeder Unit Trays

    Be sure that the machine is powered ON before withdrawing the tray. Only one tray can be withdrawn at a time. Reminder Do not withdraw the tray forcibly; otherwise you may be injured. Open the paper feed roller. Tray 1 and 2 Tray 3, 4, and 5 VarioPrint 1105...
  • Page 89 Be sure that the side guide plates and rear edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. When paper is seated properly, close the paper feed roller. VarioPrint 1105...
  • Page 90 Supplies & Handling Push in the tray until it locks into place. The indicator on the Machine Status Screen or Copy Screen will change. Reminder Do not bump the tray into the main body; otherwise machine trouble may be caused. VarioPrint 1105...

  • Page 91: Loading Cover Paper In Cover Feeding Tray Of Perfect Binder Pb-501

    Place cover paper faceup, with the top to be rear in the tray. When making the book bound on the right side, the front side in the tray will be the top. Align it to the paper feed roller side. VarioPrint 1105...
  • Page 92 Be sure that the side guide plates and rear edge guide are securely aligned to the paper; otherwise a paper jam may be caused. When paper is seated properly, close the paper feed roller. Push in the tray until it locks into place. VarioPrint 1105...
  • Page 93 Supplies & Handling Push in the tray until it locks into place. The indicator on the Machine Status Screen or Copy Screen will change. Do not bump the tray into the perfect binder; otherwise machine trou- ble may be caused. VarioPrint 1105...

  • Page 94: Loading Tabbed Sheets In Tray

    For details, refer to “Using Paper Not Specified for Any Tray (Paper Pre- setting)” on page 6-53. Open the paper feed roller. Place paper on the tray. Place paper referring to the illustration shown above. Reminder Do not load above the limit level on the side guide plate. 4-10 VarioPrint 1105...
  • Page 95 When paper is seated properly, close the paper feed roller. Push in the tray until it locks into place. VarioPrint 1105 4-11...
  • Page 96 1st tabbed sheet. Needless Tab Paper Exit may not be allowed depending on the finisher type mounted on the machine. 4-12 VarioPrint 1105...

  • Page 97: Adding Toner

    Do not throw the empty toner bottle into a fire. If it is thrown into a fire, the toner may ignite and cause a dangerous situation. VarioPrint 1105 4-13...
  • Page 98 Add toner according to the procedure as follows. Open the toner unit door. Pull the toner unit lever forward to withdraw the bottle holder until it stops. Remove the empty toner bottle. Shake the new toner bottle several times to loosen toner. 4-14 VarioPrint 1105...
  • Page 99 Return the bottle holder to its original position, then close the toner unit door securely. VarioPrint 1105 4-15...

  • Page 100: Inserting A New Staple Cartridge Into Finisher Fs-503

    Machine Status Screen. Follow the procedure below to set the staple roll into the staple cartridge. Open the Finisher door. Pull out the stapler unit slowly by holding the stapler unit handle until it stops. 4-16 VarioPrint 1105...
  • Page 101 Set the staple cartridge. Return the staple cartridge to its original position as shown below. Push up and in to secure it in place. VarioPrint 1105 4-17...
  • Page 102 Supplies & Handling Return the stapler unit to its original position. Close the Finisher door. 4-18 VarioPrint 1105...

  • Page 103: Inserting A New Staple Cartridge Into Saddle Stitcher Sd-501

    If printing job is in progress, a message will be displayed on the Copy Screen. Follow the procedure below to replace the staple cartridge. Open the left side door of the Saddle Stitcher. Remove the empty cartridge. Hold both left and right sides of the staple cartridge, then draw it forward. VarioPrint 1105 4-19...
  • Page 104 The machine is mounted with two staple cartridges. Be sure to remove the empty one. Set the new cartridge. Reminder Check that the top side of the staple cartridge is up, otherwise it cannot be inserted. Close the left side door of the Saddle Stitcher. 4-20 VarioPrint 1105...

  • Page 105: Adding Paste Pellets To Perfect Binder Pb-501

    Read “Safety Information” on page 1-3 as well. Do not overload the paste hopper with paste pellets. Do not touch the lever in the paste hopper with your hand to avoid break- down. VarioPrint 1105 4-21...
  • Page 106 Supplies & Handling Loosen the paste pellets inside the bag. Open the paste hopper cover. Supply the paste hopper with paste pellet. Reminder Do not add the paste pellet above the limit level indicated inside the paste hopper. 4-22 VarioPrint 1105...
  • Page 107 Supplies & Handling Close the paste hopper cover. VarioPrint 1105 4-23...

  • Page 108: Empty Trash Basket Of Folding Unit Fd-501

    When the trash basket becomes full, the Punch Dust indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to empty the trash basket. Open the Finisher door. Withdraw the trash basket. 4-24 VarioPrint 1105...
  • Page 109 Supplies & Handling Empty the trash basket. Return the trash basket to its original position. Close the Finisher door securely. VarioPrint 1105 4-25...

  • Page 110: Empty Dust Box Of Saddle Stitcher Sd-501

    Follow the procedure below to empty the dust box. Withdraw the dust box. Reminder The dust box cannot be withdrawn while machine operation is in progress. Be sure to confirm that the machine has stopped its operation before withdrawing the dust box. 4-26 VarioPrint 1105...
  • Page 111 Take waste paper out of the dust box. Close the top cover of the dust box, then return it to its original position. Reminder Be sure to return the dust box to its original position, otherwise the trim- ming function cannot be performed. VarioPrint 1105 4-27...

  • Page 112: Empty Dust Box Of Perfect Binder Pb-501

    Reminder Do not open the front door while machine operation is in progress, oth- erwise a paper jam may be caused. Be sure to confirm that the machine has stopped its operation before opening the front door. 4-28 VarioPrint 1105...
  • Page 113 Supplies & Handling Withdraw the dust box. Take waste paper out of the dust box. Return the dust box to its original po- sition. Then close the front door of the per- fect binder. VarioPrint 1105 4-29...

  • Page 114: Removing Finished Sets From Large Capacity Stacker

    The carriage is for the exclusive use of carrying paper. Do not drive it in any other use. Never put yourself in the large capacity stacker. 4-30 VarioPrint 1105...
  • Page 115 Close the large capacity stacker door. Reminder When returning the stacker unit to its original position, fit the two projec- tions of the carriage to the two holes of the stacker unit, otherwise the carriage cannot be returned properly. VarioPrint 1105 4-31...
  • Page 116 Supplies & Handling 4-32 VarioPrint 1105...

  • Page 117: Before Making Copies

    Before Making Copies Copier...

  • Page 119: Copy Screen

    Zoom key is touched to select the desired magnification ratio using preset ratios, user preset ratios, zoom mode or vertical/hor- izontal zoom mode. ×1.0 key is touched to copy in 1.000 magnification ratio. VarioPrint 1105...
  • Page 120 Memory Scan key is touched to store scanned images innto memory. Machine Status icons display to indicate various machine status. Message area displays the machine status and procedure required at that time. VarioPrint 1105...

  • Page 121: Machine Status Screen

    Job list displays the current status of the jobs to be operated on the machine. Controller key is touched to set the controller. Adjustment key is touched to make adjustments of the machine and op- tional equipment. VarioPrint 1105...
  • Page 122 Icon area displays various machine status icons. Message area displays messages concerning printing job, and also in- dicates the warmup status of the main body and optional perfect binder if mounted. VarioPrint 1105...

  • Page 123: Features Of The Varioprint 1105

    Before Making Copies Features of the VarioPrint 1105 All-Image Area Makes copies printed completely to the edges of the paper to avoid im- age loss. AE - Automatic Exposure Automatically adjusts exposure to compensate for quality of the original. AMS - Automatic Magnification Selection Automatically selects an appropriate magnification ratio when paper size is selected manually.
  • Page 124 If an incompatible function is selected in this mode, the latter function will not be selected, and an Error message will be dis- played. VarioPrint 1105...
  • Page 125 For details, refer to “Setting Output Methods” on page 9-3. Overlay Scans an original image and overlays it on the pages of another docu- ment. For example, you may want to incorporate a page heading, graphic design or logo into the pages of your document. VarioPrint 1105...
  • Page 126 Tandem Mode for Two Copiers Works in tandem to distribute a large copying job in half the time of non- tandem mode. 5-10 VarioPrint 1105...
  • Page 127 Copies onto paper slightly larger than the specified regular size. Z-Folded Original This feature sets the ADF to accept Z-folded originals. Zoom Selects fixed ratios, four reduction, four enlargement, and three user-set ratios. Zoom ratios can be selected from 25% ~ 400% in 1% increments. VarioPrint 1105 5-11...

  • Page 128: How To Make A Basic Copy

    Function Key (See p.p. 6-8) Original Setting (See p. 6-10) Special Image (See p. 6-26) Zoom (See p. 6-32) Application (See p. 8-8) Output Application (See p. 9-3) Copy Mode (See p. 6-37) Paper Presetting (See p. 6-53) 5-12 VarioPrint 1105...
  • Page 129 Entered quantity will be displayed on the touch panel. For details, refer to “Setting Print Quantity” on page 5-20. Position originals FACE UP in the document feeder, or FACE DOWN on the original glass. For details, refer to “Positioning Orig- inals” on page 5-16. VarioPrint 1105 5-13...
  • Page 130 Copy Screen. The popup screen will vary depending on this selection. The Job List Screen is provided to change the operation order of reserve jobs or cancel the reserve job. For details, refer to “Overview of Job List Screen” on page 7-3. 5-14 VarioPrint 1105...
  • Page 131 Before Making Copies If [No] is touched, the Machine Status Screen will be restored. The current job will be displayed in the job list, with the count/set quan- tity indicated at the upper right corner of the screen. VarioPrint 1105 5-15...

  • Page 132: Positioning Originals

    If the number of originals exceeds 100, divide them into blocks not ex- ceeding 100 sheets, then load them from the block with the first page. Adjust paper guides. 5-16 VarioPrint 1105...
  • Page 133 For details, refer to “Mixed Original mode” on page 3-12. Position mixed originals FACE UP, aligned with the left rear side of the document feeder tray. Place two-sided originals with page one FACE UP. Up to 100 originals can be set at a time. VarioPrint 1105 5-17...
  • Page 134 Once closed, do not open the document feeder, otherwise the se- lected copy conditions may be altered automatically. Be sure not to use unsuitable ADF originals. For details, refer to “Unsuit- able ADF Originals” on page 3-10. Adjust paper guides. 5-18 VarioPrint 1105...

  • Page 135: Positioning Original On Original Glass

    For details, refer to chapter “8 Applications”. 7 CAUTION Do not place too heavy originals, or do not press strongly when thick original is placed and is under pressure of ADF; otherwise the glass may be broken and you may be injured. VarioPrint 1105 5-19...

  • Page 136: Setting Print Quantity

    The copier is initially set to copy the original set in amounts determined by the print quantity setting, then outputs sorted sets. Enter the desired print quantity from the control panel keypad. Entered quantity will be displayed on the touch panel. 5-20 VarioPrint 1105...

  • Page 137: To Change Print Quantity

    Follow the procedure below to change the print quantity that has been al- ready entered. Press [C] (clear quantity). The quantity displayed on the touch panel will return to 1. Enter the correct quantity. Entered quantity will be displayed on the touch panel. VarioPrint 1105 5-21...

  • Page 138: Setting Job During Warm-Up

    Copy Screen, then check that the message “Ready to copy re- serve” is displayed in the message area. Set the desired copying conditions, and enter the print quantity. Note For details, refer to “Setting Print Quantity” on page 5-20. 5-22 VarioPrint 1105...
  • Page 139 Job List Screen. The popup screen will vary depending on this selec- tion. The Job List Screen is provided to change the operation order of reserve jobs or cancel the reserve job. For details, refer to “Overview of Job List Screen” on page 7-3. VarioPrint 1105 5-23...
  • Page 140 Before Making Copies If [No] is touched, the Machine Status Screen will be restored. The current job will be displayed in the job list, with the count/set quan- tity indicated at the upper right corner of the screen. 5-24 VarioPrint 1105...

  • Page 141: To Stop Scanning/Printing

    The current machine operation of the selected job will be suspended, and the popup menu will be displayed on the Copy Screen. Touch the desired key on the popup menu. The popup menu will vary according to the job in progress. VarioPrint 1105 5-25...
  • Page 142 Touching [Stop Job] will delete all the scanned data. Scanning the job in Memory Scan mode Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Details Touching [Stop Job] will delete all the scanned data. 5-26 VarioPrint 1105...
  • Page 143 Touching [Stop Job] will delete all the scanned data. Scanning and printing the job using Program Job Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Details Touching [Stop Job] will delete all the scanned data. VarioPrint 1105 5-27...
  • Page 144 If machine has been set to display the Copy Screen as the initial screen, touch [MACHINE] tab to restore the Machine Status Screen. Press [Stop]. Machine operation will be ceased, and the following pop- up menu will be displayed. 5-28 VarioPrint 1105...
  • Page 145 Touch Scan to stop scanning the reserve job and continue printing. Touch Print to stop printing and continue the scanning job. Touch Scan/Print to cancel both scanning and printing jobs. Touch Continue to complete both jobs. Details All the data scanned for stopped job will be deleted. VarioPrint 1105 5-29...
  • Page 146 Before Making Copies 5-30 VarioPrint 1105...

  • Page 147: Basic Job Settings

    Basic Job Settings Copier...

  • Page 149: Copy Conditions Incompatible With Basic Settings

    Memory Scan Mode (ADF) 1.000 Magnification ZOOM Preset Magnification Rotation Manual Density Preset Density Text & Photo (Enhance) Low Contrast Photo (*5) Text Background Adjust (+) Background Adjust (-) Mixed Original Z-Folded Original Custom Size Custom Size (Full Area) Tab Paper VarioPrint 1105...
  • Page 150 Basic Job Settings Application / File Edit Application / Image Edit VarioPrint 1105...
  • Page 151 Memory Scan Mode (ADF) 1.000 Magnification ZOOM Preset Magnification Rotation Manual Density Preset Density Text & Photo (Enhance) Low Contrast Photo (*5) Text Background Adjust (+) Background Adjust (-) Mixed Original Z-Folded Original Custom Size Custom Size (Full Area) Tab Paper VarioPrint 1105...
  • Page 152 Basic Job Settings Output Application VarioPrint 1105...
  • Page 153 Rotation is unavailable if staple or punch position will be interfered. Memory Scan mode is selected automatically. If Low Contrast is selected with minus level in Background Adjustment, the minus level will be altered to “0” automatically. Release automatically if using secondary tray for output. VarioPrint 1105...

  • Page 154: Function Key

    - Function key will be void if the job setting assigned to that key is deleted in Mode Memory. Touch the Copy tab on the Machine Status Screen to display the copy Screen. The Copy Screen will be displayed. VarioPrint 1105...
  • Page 155 Basic Job Settings Touch the desired Function key. The copy conditions of Mode Memory assigned to that key will resume on the screen. VarioPrint 1105...

  • Page 156: Original Setting

    For details, refer to “Setting Binding Direction for Duplex Copies” on page 9-13 and “Selecting Binding Direction of Originals” on page 6-12. Touch [Original Setting] on the Copy Screen. The Special Original popup menu will be displayed. 6-10 VarioPrint 1105...
  • Page 157 Touch to highlight the desired original direction key. Touch [OK] to complete the setting and return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. VarioPrint 1105 6-11...

  • Page 158: Selecting Binding Direction Of Originals

    - The machine is set to match the Original binding direction and Copy binding direction automatically. For details, refer to “02 Each Function Setting” on page 16-46. R & L Binding Upper Binding Touch [Original Setting] on the Copy Screen. The Special Original popup menu will be displayed. 6-12 VarioPrint 1105...
  • Page 159 Basic Job Settings Touch [Upper Binding] to highlight it. Touch [OK] to complete the setting and return to the Copy Screen. VarioPrint 1105 6-13...

  • Page 160: Copying Mixed Size Originals (Mixed Original)

    Specifications for Mixed Original: - Use ADF. - Combination of original sizes to be mixed depends on the width of the ADF original guides. For details, refer to “Mixed Original mode” on page 3-12. Mixed size originals 6-14 VarioPrint 1105...
  • Page 161 Position mixed original(s) FACE UP in the document feeder. Arrange the mixed size originals aligning the left and rear sides. Note For details, refer to “Positioning originals in Mixed Original mode” on page 5-17. VarioPrint 1105 6-15...

  • Page 162: Copying Z-Folded Originals (Z-Folded)

    - Use ADF. - This mode requires more scanning time to detect the original size. Z-folded original Touch [Original Setting] on the Copy Screen. The Special Original popup menu will be displayed. Touch [Z-Folded] to highlight it. 6-16 VarioPrint 1105...
  • Page 163 Position Z-folded original(s) FACE UP in the document feeder. Normal originals can be set together with the Z-folded original. Note For details, refer to “Positioning originals in Z-Folded original mode” on page 5-18. VarioPrint 1105 6-17...

  • Page 164: Feeding Single Original From Adf (Single Feed)

    The Special Original popup menu will be displayed. Touch [Single Feed] to highlight it. Touch [OK] to return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. 6-18 VarioPrint 1105...
  • Page 165 Touch [Single Feed] to highlight it. Touch [OK] to return to the Copy Screen. Memory Scan is automatically highlighted on the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. VarioPrint 1105 6-19...
  • Page 166 The set original will be automatically fed and scanned. Reminder Never set more than one original, oth- erwise machine trouble may be caused. Touch Memory Scan to exit the Memory Scan mode (ADF), then press [Start]. The printing job will start. 6-20 VarioPrint 1105...

  • Page 167: Copying Non-Standard Size Originals (Custom Size / Tab Paper)

    - Using Tab Paper mode with tabbed copy paper loaded in a tray, the “Load- Needless Tab Paper Exit function will function. For details, refer to ing Tabbed Sheets in Tray” on page 4-10 Touch [Original Setting] on the Copy Screen. The Special Original popup menu will be displayed. VarioPrint 1105 6-21...
  • Page 168 Basic Job Settings Touch [Custom Size] or [Tab Paper]. The popup menu will appear for Custom Size or Tab Paper size setting. Touch the desired size key. 6-22 VarioPrint 1105...
  • Page 169 Touch [OK] on the popup menu. The popup menu will disappear. Touch [OK] to complete the setting and return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. VarioPrint 1105 6-23...

  • Page 170: Memory Scan Mode

    Repeat this step for all originals. Using ADF: Position originals FACE UP. If the number of originals exceeds 100, divide them into blocks not exceeding 100 sheets and load them from the block with the first page. 6-24 VarioPrint 1105...
  • Page 171 “Scanning the job in Memory Scan mode” on page 5-26. When scanning is completed, touch Memory Scan to exit the Memory Scan mode. Press [Start]. All the data in memory will be output. Press [Stop] to suspend the printing job. VarioPrint 1105 6-25...

  • Page 172: Special Image

    Enhance Mode” on page 16-25. Image Density Selection changes the range of the density level between the darkest and lightest, so that users can obtain the optimum print result according to the originals or print object without degrading image quality. 6-26 VarioPrint 1105...
  • Page 173 Density Shift for Enhance Mode. For details, refer to “04 Image Density Selection” on page 16-31. Touch [Darker] to darken, or [Lighter] to lighten the copy image. Highlight the desired exposure level indicator. Touch [Normal] to select the middle density level. When resuming AE, touch [AE]. VarioPrint 1105 6-27...
  • Page 174 Recall the preset density. Touch [Special Image]. The Special Image popup menu will be displayed. Touch [Preset1] or [Preset2] in the Preset Density area to recall the desired density setting. Touch [OK]. The Copy Screen will be restored. 6-28 VarioPrint 1105...
  • Page 175 Basic Job Settings Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. VarioPrint 1105 6-29...

  • Page 176: Making Copy Quality Closer To Originals (Text/Photo Enhance)

    This function can be set by the machine manager to use in combination with each of four Enhance modes. (Utility Menu Screen>02 Function Set- ting>03 Density Setting>01 Density Shift for Enhance Mode) For details, refer to “01 Density Shift for Enhance Mode” on page 16-25. 6-30 VarioPrint 1105...
  • Page 177 The Special Image popup menu will be displayed. Touch the desired mode key to highlight it. Touch [OK] to return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. VarioPrint 1105 6-31...

  • Page 178: Zoom

    The initial settings may be altered by the machine manager. For details, refer to “01 Initial Setting” on page 16-39. Select additional copy conditions, as desired. Specifying paper size will release 1.000 magnification and set [Auto Zoom] automatically. In this case, touch [x1.0] to highlight it again. 6-32 VarioPrint 1105...

  • Page 179: To Change Magnification Ratio

    - Enlarge/Reduce: Select from the eight ratios (0.500, 0.647, 0.772, 0.785, 1.214, 1.294, 1.545, 2.000) provided on the screen. - Preset Zoom: Select from the three ratios previously programmed. Note For details, refer to “04 Preset Zoom” on page 16-33. Touch [Zoom] on the Copy Screen. VarioPrint 1105 6-33...
  • Page 180 If wrong number is entered, continue by entering the correct number. Touching arrow keys + and , will change the ratio in 0.001 (0.1%) steps. Manual Zoom (individual) Touch the vertical zoom key (the second one in the left side line) in the Manual Zoom area. 6-34 VarioPrint 1105...
  • Page 181 Touching arrow keys + and , will change the ratio in 0.001 (0.1%) steps. Enlarge/Reduce Touch the desired zoom key in the Enlarge/Reduce area. Preset Zoom Touch the desired preset zoom key in the Preset Zoom area. VarioPrint 1105 6-35...
  • Page 182 Basic Job Settings Touch [OK] to return to the Copy Screen. Details Touch [Cancel] to resume the previous setting. 6-36 VarioPrint 1105...

  • Page 183: Copy Mode

    - The machine is set to match the Original binding direction and Copy binding direction automatically. For details, refer to “02 Each Function Setting” on page 16-46. Double-sided original 2-2 Copying Duplex copy 1-2 Copying Duplex copy Single-sided original VarioPrint 1105 6-37...
  • Page 184 Touch the desired original direction key to highlight it. To make normal double-sided copies (having the same edge as page top) from double-sided originals printed upside down on the back pages, touch [Upper Binding] to highlight it. 6-38 VarioPrint 1105...
  • Page 185 For details, refer to “Setting Binding Direction for Duplex Copies” on page 9-13. Select additional copy conditions, as desired. Position originals FACE UP in the document feeder Set originals according to the original direction icon displayed on the Copy Screen. VarioPrint 1105 6-39...

  • Page 186: Making Double-Sided Copies Using Original Glass

    Touch [Original Setting] on the Copy Screen to display the Special Original popup menu. Touch the desired original direction key to highlight it. Touch [OK] to return to the Copy Screen. Note For details, refer to “Specifying Original Direction” on page 6-10. 6-40 VarioPrint 1105...
  • Page 187 Copy Screen, then close the ADF. Be sure to start from the first page. Reminder If Book Copy, No Image Area Erase, Auto Detect mode of Repeat, or Im- age Centring is selected, keep the ADF open throughout the scanning procedure. VarioPrint 1105 6-41...
  • Page 188 Details To delete the scanned data without printing, press [Stop]. For details, re- fer to “Scanning the job in Memory Scan mode” on page 5-26. Press [Start] to print. All the data in memory will be output. 6-42 VarioPrint 1105...
  • Page 189 Basic Job Settings Details Press [Stop] to suspend the printing job. For details, “Batch printing is in progress” on page 5-27. VarioPrint 1105 6-43...

  • Page 190: Making Single-Sided Copies From Double-Sided Originals

    - The normal single-sided copies (having the same edge as page top) can be made from double-sided originals printed upside down on the back pages. 2-1 Copying Double-sided original Simplex copy Touch [2-1] on the Copy Screen to highlight it. 6-44 VarioPrint 1105...
  • Page 191 For details, refer to “Selecting Binding Direction of Originals” on page 6-12. Select additional copy conditions, as desired. Position originals FACE UP in the document feeder Set originals according to the original direction icon displayed on the Copy Screen. VarioPrint 1105 6-45...

  • Page 192: Paper Tray Setting

    For details of this function, contact your machine manager. The following describes how to use APS, AMS, Rotation functions, and how to temporarily change the paper size and other conditions specified for each tray by machine manager. 6-46 VarioPrint 1105...

  • Page 193: To Select Paper Size Automatically (Aps)

    - APS will not select the tray of the size specified as non-standard or wide size. Touch [Auto Paper Select] at lower right corner of the Copy Screen. Select additional copy conditions as desired, then position original(s). VarioPrint 1105 6-47...
  • Page 194 The APS may not function for the tray of the selected size due to the pa- per type/weight specified for that tray. Contact your machine manager. See the table below for the relation of original size, magnification ratio and copy paper size. Paper size Paper size Original size 6-48 VarioPrint 1105...

  • Page 195: To Specify Desired Paper Size (Ams)

    Selected tray key will be highlighted, and the Auto Zoom key will also be highlighted. Details For details, refer to “To Copy in 1.000 Magnification Mode” on page 6-32. Select additional copy conditions as desired, then position original(s). VarioPrint 1105 6-49...
  • Page 196 Press [Start]. Scanned image will be printed on the specified paper size in the mag- nification ratio automatically selected. See the table below for the original size, copy paper size, and magnifi- cation ratio automatically selected. Original size 6-50 VarioPrint 1105...

  • Page 197: Rotation

    - Original sizes: A3, B4, A4, B5 Original Copy Original Copy Rotation copying Rotation copying Normal copying Normal copying The copier is initially set to activate the Rotation function automatically. Follow the procedure below to release/resume this function. VarioPrint 1105 6-51...
  • Page 198 When Rotation is released, the Rotation icon on the Copy Screen will disappear to indicate that this function is cancelled. Touch to deselect [Rotation Off] to resume this function. When Rotation is resumed, the Rotation icon will be displayed on the screen. 6-52 VarioPrint 1105...

  • Page 199: Using Paper Not Specified For Any Tray (Paper Presetting)

    On the Copy Screen, check the tray setting for each tray. Each key displays paper size, paper weight, paper type, and paper amount remaining in the tray. VarioPrint 1105 6-53...
  • Page 200 Basic Job Settings Touch Paper Presetting. The Paper Presetting popup menu will be displayed. Select the tray to change the setting temporarily. Touch the desired tray key on the popup menu. 6-54 VarioPrint 1105...
  • Page 201 Touch [Size Setting], then touch [Custom Size]. Touch the vertical/horizontal size key, then use the screen keypad or arrow keys + and , to enter the desired size. Entered size should fall within 182 mm ~ 324 mm in vertical dimen- VarioPrint 1105 6-55...
  • Page 202 + and , to enter the horizontal size. The entered number should fall within the range from the horizontal size of the standard size corresponding to the selected wide size, to a maximum of 460 mm. 6-56 VarioPrint 1105...
  • Page 203 The dimensions of the wide size selected in step (2) are not correctly set in the initial setting. Touch [Select Size] to return to the Select Size Screen. Touch [OK] to complete the setting. VarioPrint 1105 6-57...
  • Page 204 Touch [Number of Tabs] to display the Number of Tabs Screen, then use the screen keypad or arrow keys + and , to enter the number of tabs. Setting range is from 1 to 15. Touch [OK] to complete the setting. 6-58 VarioPrint 1105...
  • Page 205 Selecting the paper setting Touch [Type/Weight]. Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it. Touch [OK] to complete the setting. VarioPrint 1105 6-59...
  • Page 206 Basic Job Settings Programing a new setting Touch [Change]. Touch [Type], then select the desired paper type key. Touch [OK] to complete the setting. Details For details, refer to “Paper Setting Outlines” on page 12-3. 6-60 VarioPrint 1105...
  • Page 207 Basic Job Settings Touch [Weight]. Touch the desired paper weight key, then touch [OK]. Touch [Coloured Paper]. VarioPrint 1105 6-61...
  • Page 208 (vertical zoom, horizontal zoom, vertical shift, or horizontal shift), and then touch + <--> - to specify the value to be positive or negative. Use the screen keypad or arrow keys + and , to enter the desired ad- justment value, then touch [OK]. 6-62 VarioPrint 1105...
  • Page 209 Load copy paper into the tray with the setting change made. Details The changed setting will be cleared when copying job is completed using that tray. If [Reset] is pressed or Auto Reset functions before completion of the job, the changed setting will also be cleared. VarioPrint 1105 6-63...

  • Page 210: Reserve Job Setting

    If the machine is initially set to display the Copy Screen after scanning job is started, the above popup menu will provide only the Close key. Touch- ing [Close] will also display the Copy Screen to make the reserve job set- ting. 6-64 VarioPrint 1105...
  • Page 211 To check and operate the reserve jobs, touch [JOB LIST] tab to dis- play the Job List Screen. For details, refer to “Overview of Job List Screen” on page 7-3. Printing of the reserve job will automatically start. VarioPrint 1105 6-65...
  • Page 212 Load copy paper specified for that reserve job into the designated tray, touch [Change], then press [Start]. When trouble occurs on a reserve job, refer to “If MACHINE Tab Blinks in Or- ange” on page 20-8. 6-66 VarioPrint 1105...

  • Page 213: Job Management

    Job Management Copier...

  • Page 215: Overview Of Job List Screen

    Touch [JOB LIST] tab on the Copy Screen. The Job List Screen will be displayed. Touch the desired key at the bottom of the screen. See the following pages for details of each subsequent screen. Touch other tab key to exit the Job List Screen. VarioPrint 1105...

  • Page 216: Job Operation On Job List Screen

    Follow the procedure below to check the settings, change the output order, and suspend/delete/stop reserved jobs. Touch [JOB LIST] tab on the Copy Screen, then touch Reserved Job if not highlighted. Check the status of the reserved jobs. Touch [Next] to scroll, if 8 or more jobs are entered. VarioPrint 1105...
  • Page 217 All the data of the selected job will be cleared. To check the settings of reserve job: Touch to highlight the desired reserve job key, then touch [Details]. Check the settings of the selected job on the screen. Touch Close to return to the Job List Screen. VarioPrint 1105...

  • Page 218: To Display Output History

    Check the status of the output jobs. Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. VarioPrint 1105...

  • Page 219: To Display Send History

    Check the status of the transmitted jobs. Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. VarioPrint 1105...

  • Page 220: To Check Incomplete Jobs

    Check the status of the incomplete jobs. Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. VarioPrint 1105...

  • Page 221: To Check/Operate Suspended Jobs

    Touch [JOB LIST] tab on the Copy Screen, then touch [Suspended]. he letters Suspended on the key appears red to prompt you that a suspended job remains in the machine. Check the status of the suspended jobs. Touch [Next] to scroll, if 8 or more jobs are entered. VarioPrint 1105...
  • Page 222 To check the settings of suspended job: Touch to highlight the desired job key, then touch [Details]. Check the settings of the selected job on the screen. Touch [Close] to return to the Job List Screen. 7-10 VarioPrint 1105...

  • Page 223: To Check/Control Spool Jobs

    Touch to highlight the desired job key, then touch [Print Next]. The highlighted job will be moved just under the current print job. Details This will not function if printing operation has already been started for the selected job. VarioPrint 1105 7-11...
  • Page 224 To clear spool job: Touch to highlight the desired job key, then touch Delete. Touch Yes on the popup menu to clear the selected job. Details All the data of the selected job will be cleared. 7-12 VarioPrint 1105...

  • Page 225: Applications

    Applications Copier...

  • Page 227: Copy Conditions Incompatible With Applications

    Neg. Pos. Reverse Repeat Repeat (Auto) (*4) Repeat (2/4/8 Repeat) Frame Erasure Fold Erasure Image Centering Image Shift Reduce & Shift Non-Image Area Erase All-Image Area Stamp Page Numbering Set Numbering Date Watermark Watermark/Numbering Annotation Overlay Memory Overlay (*3) VarioPrint 1105...
  • Page 228 Applications Application / File Edit Application / Image Edit VarioPrint 1105...
  • Page 229 Neg. Pos. Reverse Repeat Repeat (Auto) (*4) Repeat (2/4/8 Repeat) Frame Erasure Fold Erasure Image Centering Image Shift Reduce & Shift Non-Image Area Erase All-Image Area Stamp Page Numbering Set Numbering Date Watermark Watermark/Numbering Annotation Overlay Memory Overlay (*3) VarioPrint 1105...
  • Page 230 Applications Output Application VarioPrint 1105...
  • Page 231 Selecting Auto in Repeat, Non-Image Area Erase will also be selected automati- cally and cannot be released. Release automatically if using secondary tray for output. Back cover using cover paper is unavailable. Available only when Booklet is selected. VarioPrint 1105...

  • Page 232: To Use Application Function

    Follow the procedure below to display the Application popup menu and se- lect the desired copying features. Touch [COPY] tab on the Machine Status Screen to display the Copy Screen. Touch [Application] on the Copy Screen. The Application popup menu will be displayed on the touch panel. VarioPrint 1105...
  • Page 233 Details Selected functions can be directly accessed from the Application area of the Copy Screen to change or clear the setting you made. To cancel the selection of each application function, touch [Function OFF] on the subsequent screen. VarioPrint 1105...

  • Page 234: Inserting Sheets And Covers (Sheet Insertion)

    - Post inserter is available as additional front/back cover tray source. In this case, Post inserter will feed the first (front) cover and the last (back) cover. - Post inserter is also available as additional insertion tray source. - The covers fed from Post inserter cannot be printed. 8-10 VarioPrint 1105...
  • Page 235 Check the tray information on the Machine Status Screen or Copy Screen and use the specified paper; otherwise machine trouble may occur. To use any other paper type/size than the specified paper, touch [Paper Presetting] on the Copy Screen to change the setting temporarily. VarioPrint 1105 8-11...
  • Page 236 When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Sheet Insertion] on the Application popup menu. The Sheet Insertion Screen will be displayed. Select the desired cover mode. If no cover is desired, proceed to the next step. 8-12 VarioPrint 1105...
  • Page 237 Touch [OK] to complete the setting and return to the previous screen. To insert a back cover: Touch [Back Cover]. The Back Cover Screen will be displayed. Select the desired back cover mode, copy mode (Simplex/Duplex), and tray paper to be used. VarioPrint 1105 8-13...
  • Page 238 Enter the desired insertion type setting. The Set 01 key is active to be ready for the first insertion type setting. Select the desired insertion mode (Print/Blank), copy mode (Simplex/ Duplex), and tray paper to be used. 8-14 VarioPrint 1105...
  • Page 239 Touch [Fix] to complete the page entry. The Set 01 setting is fixed and the Set 02 key will be active. To change the insertion type, set the new one and enter the page number. VarioPrint 1105 8-15...
  • Page 240 To clear all the settings, touch [Clear All]. To restore the previous setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF]. Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-16 VarioPrint 1105...

  • Page 241: Locating Title Pages On The Right Side (Chapter)

    1-sided originals Copies in Chapter mode Title pages Title pages Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-17...
  • Page 242 Touch [Set] after each entry to move to the next key. To set more than 15 locations, touch the arrow key to move to the next page. To clear an incorrect entry, touch [Delete]. The entered number will be deleted. 8-18 VarioPrint 1105...
  • Page 243 The Application popup menu will be restored. Details To cancel the setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF]. Touch [OK] on the Application popup menu. The Copy Screen will be restored. VarioPrint 1105 8-19...

  • Page 244: Lay Out Several Pages Onto One Sheet (Combination)

    Original 2 in1 copying 8 in1 copying Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Combination] on the Application popup menu. 8-20 VarioPrint 1105...
  • Page 245 Touch [OK] on the Application popup menu. The Copy Screen will be restored. AMS is automatically selected. When selecting any tray other than the one that is set and displayed on the Copy Screen, touch the desired tray key. VarioPrint 1105 8-21...
  • Page 246 Press [Start]. Details Refer to the table below to select the desired Combination mode. Original Horizontal order Vertical order Layout 2 in 1 4 in 1 8 in 1 4 in1 8 in 1 Portrait type Landscape type 8-22 VarioPrint 1105...

  • Page 247: Making A Multiple Page Signature Booklet (Booklet)

    Load the desired copy paper size in a tray. When selecting cover sheet mode (Cover With Copy Sheet or Cover With Blank Sheet), load the same size paper in any other tray unless it is specified as Thick or Tab paper of the paper type. VarioPrint 1105 8-23...
  • Page 248 Touch to highlight the desired Booklet mode key. When a cover sheet is required, touch [Cover Tray Select] to select the cover sheet tray source. Touch [Left binding] or [Right binding] if you want to change the output order. 8-24 VarioPrint 1105...
  • Page 249 Position originals FACE UP in the document feeder, then press [Start]. Reminder Original pages should be a multiple of 4 in 1-2 mode or a multiple of 2 in 2-2 mode; otherwise blank pages are automatically inserted to the last. VarioPrint 1105 8-25...

  • Page 250: Copying Onto Transparent Films (Ohp Interleave)

    Do not load transparent films in any tray other than Tray 4; otherwise ma- chine trouble may occur. When interleaf sheet is needed, load copy paper in any other tray to match the size of transparent films. 8-26 VarioPrint 1105...
  • Page 251 Touch [Application] on the Copy Screen. Touch [OHP Interleave] on the Application popup menu. Select the desired OHP Interleave mode, then touch [OK]. Details To cancel the setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF]. VarioPrint 1105 8-27...
  • Page 252 Print quantity is already set to 1. You cannot enter any other quantity. Touch to select the tray loaded with transparent films. Position original(s) FACE UP in the document feeder or FACE DOWN on the original glass. Press [Start]. 8-28 VarioPrint 1105...

  • Page 253: Inserting Images Into Printed Sets (Image Insert)

    1-sided originals placed on ADF Insertion originals on original glass 2-sided originals placed on ADF Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-29...
  • Page 254 Touch [Set] after each entry to move to the next key. When setting more than 15 locations, touch the arrow key to move to the next page. To clear an incorrect entry, touch [Delete]. The entered page number will be deleted. 8-30 VarioPrint 1105...
  • Page 255 Scan the document feeder images Position originals FACE UP in the document feeder. If the number of originals exceeds 100, divide them into blocks not ex- ceeding 100 sheets and load them from the block with the first page. VarioPrint 1105 8-31...
  • Page 256 Should memory overflow occur frequently, it is recommended that you contact your service representative to extend the memory capacity in your machine. Touch Memory Scan to exit the Memory Scan mode. Press [Start]. The copier will start printing when ready for output. 8-32 VarioPrint 1105...

  • Page 257: Dividing An Image Into Right And Left Pages (Book Copy)

    - Paper size: A3, B4, A4, A4R, B5, B5R Set original 1-1/2-1 mode 1-2/2-2 mode Touch Application on the Copy Screen. When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-33...
  • Page 258 Touch to highlight the desired mode key. Touch [Left Binding] or [Right Binding] to select the output order ac- cording to the original pagination. Note Option Touch [Booklet] on the Book Copy Screen to use this function. 8-34 VarioPrint 1105...
  • Page 259 When using document feeder, position original(s) FACE UP. For details on scanning originals in Front cover + Full scan and Front/ Back Cover + Full scan mode, see the description on the following page. Press [Start] to scan. VarioPrint 1105 8-35...
  • Page 260 When using original glass, No Image Area Erase and Image Centering are automatically selected. DO NOT CLOSE the document feeder throughout the scanning job. Touch [Memory Scan] to exit the Memory Scan mode. Press [Start]. The copier will start printing when ready for output. 8-36 VarioPrint 1105...
  • Page 261 Front/Back cover + Facing pages Scan from first page Copies Front cover + Facing pages Copies Scan body text Scan front cover Front/Back cover + Facing pages Copies Scan front cover Scan back cover Scan body text VarioPrint 1105 8-37...
  • Page 262 Applications Note Memory overflow may occur during scanning. When using original glass, No Image Area Erase and Image Centering are automatically selected. DO NOT CLOSE the document feeder throughout the scanning job. 8-38 VarioPrint 1105...

  • Page 263: Programming Different Settings For An Output Job (Program Job)

    - Program Job settings cannot be stored in Job Memory. Original A Original B Original C Copied set Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-39...
  • Page 264 Position originals FACE UP in the document feeder or FACE DOWN on the original glass. If the number of document feeder originals exceeds 100, divide them into blocks not exceeding 100 sheets and load them from the block with the first page. 8-40 VarioPrint 1105...
  • Page 265 PLACE AND SCAN EACH ORIGINAL SET IN THE CORRECT ORDER OF PAGINATION. Select the desired output mode and enter the print quantity from the control panel keypad. Touch [Memory Scan] to exit the Memory Scan mode. Press [Start]. VarioPrint 1105 8-41...

  • Page 266: Erasing Outside Of The Original (No Image Area Erase)

    Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [No Image Area Erase] on the Application popup menu. The incompatible function keys will be dimmed to show inactivity. 8-42 VarioPrint 1105...
  • Page 267 (AUTO mode). If desired, display the Utility Menu Screen to specify either mode and the original density level manually so that the No Image Area Erase functions without fail. Oblique Rectangle erase mode erase mode VarioPrint 1105 8-43...
  • Page 268 Applications Having Any Problem? This function may perform incorrectly if the lighting in the work place is di- rectly over the original glass. In this case, consult your service representative about an appropriate place for installation. 8-44 VarioPrint 1105...

  • Page 269: Reversing Colour In Black And White Image (Neg. Pos. Reverse)

    Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Neg. Pos. Reverse] on the Application popup menu. The incompatible function keys will be dimmed to show inactivity. VarioPrint 1105 8-45...
  • Page 270 Applications Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-46 VarioPrint 1105...

  • Page 271: Repeating Selected Image Area (Repeat: Vert./Horiz. Mode)

    Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Repeat] on the Application popup menu. The Repeat Screen will be displayed. VarioPrint 1105 8-47...
  • Page 272 Or, touch [Input With Keypad] to display the popup menu to enter the value from the touch panel keypad. Touch [Vertical] or [Horizontal] on the popup menu, enter the value for each, then touch OK to restore the Repeat Screen. Touch [OK]. The Application popup menu will be restored. 8-48 VarioPrint 1105...
  • Page 273 Copy mode is automatically set to 1-1. When selecting 1-2 mode, Mem- ory Scan mode will function automatically. Enter the desired print quantity from the control panel keypad. Position original FACE DOWN on the original glass. Press [Start]. VarioPrint 1105 8-49...

  • Page 274: Repeat Automatically Or Select Repeat Times (Repeat: Auto Detect/ Repeat Mode)

    - Auto Detect Mode: Use the original glass. ADF cannot be used. - ADF is available with Repeat mode. - Repeat Mode Magnification ratio: 1.000 (100%) fixed Auto Detect mode Repeat mode Copy (2 Repeat) Copy (4 Repeat) Copy (8 Repeat) Touch [Application] on the Copy Screen. 8-50 VarioPrint 1105...
  • Page 275 Touch [2 Repeat], [4 Repeat], or [8 Repeat] to select the desired Re- peat mode. If you want the image upside down on the other side in 2 Repeat mode, touch [R-Reverse] or [L- Reverse]. Touch [OK]. The Application popup menu will be restored. VarioPrint 1105 8-51...
  • Page 276 In this case, magnification ratio will be fixed to 1.000 (100%). Copy mode is automatically set to 1-1. When selecting 1-2 mode, Mem- ory Scan mode will function automatically. Enter the desired print quantity from the control panel keypad. 8-52 VarioPrint 1105...
  • Page 277 Press [Start]. Details The Auto Detect mode may not operate properly if the lighting in the work place is directly over the original glass. In this case, consult your service representative about an appropriate place for installation. VarioPrint 1105 8-53...

  • Page 278: Eliminating Black Copy Marks Along Borders (Frame/Fold Erase)

    Frame/Fold Erasure Fold Erasure Frame Erasure General copying copying copying copying Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. 8-54 VarioPrint 1105...
  • Page 279 The Frame/Fold Erase Screen will be displayed. Touch to highlight the desired mode key. Touch [All sides], [Each side], or [Fold Erasure] to highlight it. Either Frame erasure mode and Fold erasure can be selected in combination. VarioPrint 1105 8-55...
  • Page 280 [Right Side], [Down Side], or [Left Side]. The selected side amount will be highlighted in the left illustration area of the screen. Use the touch panel keypad or up/down arrow key to enter the desired erasure amount, from 1 to 300 mm in 1 mm increments. 8-56 VarioPrint 1105...
  • Page 281 Position original(s) FACE UP in the document feeder or FACE DOWN on the original glass. Details When lowering the document feeder onto thick original (e.g. open book), do not press it down too hard. Keep the document feeder open, if re- quired. Press [Start]. VarioPrint 1105 8-57...

  • Page 282: Copying Image In The Centre Of Copy Paper (Image Centering)

    ADF to scan originals. Image Centering copying Set original Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Image Centering] on the Application popup menu. 8-58 VarioPrint 1105...
  • Page 283 Having Any Problem? The Image Centering function may not operate properly if the lighting in the work place is directly over the original glass. In this case, consult your service representative about an appropriate place for installation. VarioPrint 1105 8-59...

  • Page 284: Printing Images Fully To The Edges (All-Image Area)

    When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [All-image Area] on the Application popup menu. The incompatible function keys will be dimmed to show inactivity. Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-60 VarioPrint 1105...

  • Page 285: Adjusting Position Of Copy Image (Image Shift)

    This setting change can be made on the Utility Menu Screen. - Creep amount: 0 to 50 mm in 1 mm increments - Page space amount: –250 to +250 mm in 1 mm increments Right Right Left Down Original Down Left Copies VarioPrint 1105 8-61...
  • Page 286 When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Image Shift] on the Application popup menu. Touch [Image Shift] on the Image Shift Screen, then specify the shift di- rection and amount. 8-62 VarioPrint 1105...
  • Page 287 Use [+5–] to select “+” in order to in- crease the space between images, or select “–” to decrease. Touch [OK]. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. VarioPrint 1105 8-63...
  • Page 288 Image Repeat has been already selected. Use this function to increase/decrease the blank space between the two images on a page. See the illustration below for details. Page space Booklet Original Page space 2 Repeat in Repeat Page space Original 8-64 VarioPrint 1105...
  • Page 289 Enter the creep amount of the images on the outermost page, while en- tering the page space amount of the images on the innermost page. Creep Creep Page space (+) Creep Page space (-) Creep VarioPrint 1105 8-65...

  • Page 290: Reducing Images To Create Binding Margin (Reduce&Shift)

    This setting change can be made on the Utility Menu Screen. Left binding margin Right Left Down Originals Front Back Right binding margin Front Left Right Down Front Back Back Top binding margin Left Right Left Right Front Down Back 8-66 VarioPrint 1105...
  • Page 291 Touch [Image Shift] on the Application popup menu. Touch [Reduce & Shift] on the Image Shift Screen, then specify the shift direction and amount. Touch [Front] or [Back]. In Reduce & Shift mode, the [Both Sides] key appears dimmed to show inactivity. VarioPrint 1105 8-67...
  • Page 292 If any positioning adjustment is required, touch [Back] and make direction and amount change. Touch [OK]. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-68 VarioPrint 1105...

  • Page 293: Printing Stamp, Page, Date/Time Onto Copies (Stamp)

    STAMP SET NUMBERING Middle-Left Middle M-Right PAGE NUMBERING Lower-Left L-Middle L-Right DATE/TIME Printing positions Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-69...
  • Page 294 Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. Touch to select the desired key in the Stamp area. The subsequent screen will be displayed to allow you to specify the se- lected stamp type. 8-70 VarioPrint 1105...
  • Page 295 Touch [Printed Page] to designate whether to print the selected stamp on the cover only or on all pages. When selecting Set Numbering: Specify the numbering type, print- ing position, character size, printed page and start number. VarioPrint 1105 8-71...
  • Page 296 Touch [Printed Page] to designate whether to print the selected stamp on the front/back cover or insertions. For details, refer to p. 8-76. Touch [Start Number] to designate the starting number, if required. For details, refer to p. 8-74. 8-72 VarioPrint 1105...
  • Page 297 Touch to select another stamp function key to use in combination, if desired. Touch [OK] on the Stamp/Overlay Selection Screen. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. VarioPrint 1105 8-73...
  • Page 298 Start Number Setting Screen: Available from Set Numbering or Watermark Numbering Use the touch panel keypad or up/down arrow key to enter the de- sired start number, then touch [OK] to return to the previous screen. 8-74 VarioPrint 1105...
  • Page 299 Also touch [Start Page] or [Start Chapter] to highlight it, and enter the desired start page number or chapter number. Touch [OK] to return to the previous screen. Change Printing Character Screen: from Page Numbering or Date/Time VarioPrint 1105 8-75...
  • Page 300 Touch to select the desired key, then touch [OK] to return to the previous screen. 8-76 VarioPrint 1105...
  • Page 301 To print the present time, touch [Present Time] to highlight it. To print hte setting time, touch [Setting Time], then use the touch panel keypad to enter the desired date and time. Touch [OK] to return to the previous screen. VarioPrint 1105 8-77...

  • Page 302: Printing Watermark Onto Copies (Stamp)

    Watermark Numbering Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. 8-78 VarioPrint 1105...
  • Page 303 Touch to highlight the desired watermark key and density key on the screen. If fine adjustment of the centred watermark position is required, touch [Fine Adjustment] to display the Fine Adjustment Setting Screen. For details, refer to p. 8-74. VarioPrint 1105 8-79...
  • Page 304 Touch to select another stamp function key to use in combination, if desired. Touch [OK] on the Stamp/Overlay Selection Screen. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-80 VarioPrint 1105...

  • Page 305: Print Words, Date/Time, Annotation Number Onto Copies (Annotation)

    Words to type in before annotation number (up to 20 alphanumerical characters) – Start number of the annotation number – Printing form of the annotation number (2 types provided) – Temporary number (up to 12 alphanumerical characters) – Font type (Gothic/Ming) – Character size (8/10/12/14 point) VarioPrint 1105 8-81...
  • Page 306 Printing position Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. 8-82 VarioPrint 1105...
  • Page 307 The setting registered on that key will be recalled and on the screen. Touch to highlight the desired printing position key on the screen. If fine adjustment is required, touch [Fine Adjustment] to display the Fine Adjustment Setting Screen.For details, refer to page 8-74. VarioPrint 1105 8-83...
  • Page 308 4, the [Temp. No. Set] key will be dimmed to show inactivity on the screen. Touch [OK]. The Stamp/Overlay Screen will be restored. Touch to select another stamp function key to use in combination, if desired. 8-84 VarioPrint 1105...
  • Page 309 Applications Touch [OK] on the Stamp/Overlay Selection Screen. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. VarioPrint 1105 8-85...

  • Page 310: Overlay An Image Onto Each Page Copied In The Job (Overlay)

    2nd and later Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. 8-86 VarioPrint 1105...
  • Page 311 The original image will be scanned into memory. Position the original(s) to be overlaid. Position the original FACE UP in the document feeder or FACE DOWN on the original glass. Press [Start] to scan. Repeat steps 10 and 11 for all originals. VarioPrint 1105 8-87...
  • Page 312 Applications Touch [Memory Scan] on the Copy Screen to exit the Memory Scan mode, then press [Start] to print. 8-88 VarioPrint 1105...

  • Page 313: Store Image In Hdd / Overlay Stored Image (Overlay Memory)

    Recall overlaying image Output Output Recalled image Copies in Overlay originals Overlay Memory mode Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. VarioPrint 1105 8-89...
  • Page 314 Applications Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. Touch [Overlay Memory]. The Store Image Screen will be displayed. Proceed to step 9, when recalling only the stored image. 8-90 VarioPrint 1105...
  • Page 315 The popup menu may be displayed to prompt you that the entered image name has been already used. Position the overlaying original on the original glass. Details The document feeder cannot be used for storing the overlaying image. VarioPrint 1105 8-91...
  • Page 316 Position the original FACE UP in the document feeder or FACE DOWN on the original glass. Press [Start] to scan. Repeat steps 13 and 14 for all originals. Touch Memory Scan to exit the Memory Scan mode, then press [Start] to print. 8-92 VarioPrint 1105...
  • Page 317 If the popup menu with [OK] key is displayed, the entered name is dupli- cated. Touch [OK], then enter a new name. Changing the popup menu for duplicate name and displaying the [Delete] Image key is available in the Utility mode. VarioPrint 1105 8-93...
  • Page 318 Applications 8-94 VarioPrint 1105...

  • Page 319: Setting Output Methods

    Setting Output Methods Copier...

  • Page 321: Copy Conditions Incompatible With Output Modes

    Hole-Punch (Top) Face Up Face Down 1 to N N to 1 Right & Left Binding Upper Binding HDD (*1) Fold&Staple Multi Centre Multi Letter (Inside Print) Multi Letter (Outside Print) Trimming (*6) Tandem Perfect binding (Body Set) VarioPrint 1105...
  • Page 322 Setting Output Methods Application / File Edit Application / Image Edit VarioPrint 1105...
  • Page 323 Hole-Punch (Top) Face Up Face Down 1 to N N to 1 Right & Left Binding Upper Binding HDD (*1) Fold&Staple Multi Centre Multi Letter (Inside Print) Multi Letter (Outside Print) Trimming (*6) Tandem Perfect binding (Body Set) VarioPrint 1105...
  • Page 324 Setting Output Methods Output Application VarioPrint 1105...
  • Page 325 Available only when Booklet is selected. Selecting Auto in Repeat, Non-Image Area Erase will also be selected automatically and cannot be released. Rotation is unavailable if staple or punch position will be interfered. Release automatically if using secondary tray for output. VarioPrint 1105...

  • Page 326: Selecting An Output Tray

    Touch [Output Application] on the Copy Screen. The Output Application Screen appears. Trays that can output paper will be have keys on the front image of the machine, and the tray that is currently set to output paper is shown with a depressed key. VarioPrint 1105...
  • Page 327 Setting Output Methods Touch [Output Tray]. An Output Tray Selection Screen reflecting the combination of optional devices will appear. Select the desired output tray. Touch the desired tray position key to select it. VarioPrint 1105...
  • Page 328 If you touch [Pile Setting], a popup screen will appear. Touch [Permit] if you want to allow paper from several jobs to pile up in the large ca- pacity stacker, or touch [Prohibit] if you do not. 9-10 VarioPrint 1105...
  • Page 329 Touch [OK] on the Output Tray Select Screen. It will return to the Output Application Screen. The output tray location is indicated by a depressed key on the front image of the machine. VarioPrint 1105 9-11...
  • Page 330 Never return the Saddle stitcher tray to its original position with the tray stand opened. Reminder Be careful not to exceed the finisher tray / stacker capacity when select- ing the print quantity, otherwise unexpected trouble may be caused. 9-12 VarioPrint 1105...

  • Page 331: Setting Binding Direction For Duplex Copies

    - Upper binding for duplex printing is available only when duplex mode is selected. - If the machine is reset, the binding mode will go back to right/left binding. Binding Direction for Duplex copying R&L Upper Originals Copies VarioPrint 1105 9-13...
  • Page 332 Setting Output Methods Touch [Output Application] on the Copy Screen. The Output Application Screen appears. Touch [Upper] to select it. Touch [OK]. 9-14 VarioPrint 1105...

  • Page 333: Using Finisher Fs-503

    Example: Make 3 copied sets from 4 original sheets Non-sort Staple Collated Uncollated 2 staples Offset by 30mm 1 oblique staple Offset by 30mm VarioPrint 1105 9-15...
  • Page 334 This section describes the following output methods: - Non-sort / Collated / Uncollated output to the primary (main) tray - Stapled output to the primary (main) tray - Collated / Uncollated output to the secondary (sub) tray 9-16 VarioPrint 1105...

  • Page 335: Non-Sort / Collated / Uncollated Output To The Primary (Main) Tray

    The Output Application Screen appears. The output tray location is indicated by a depressed key on the front image of the machine. If the primary (main) tray is not selected as the output tray, touch Output Tray to select it. VarioPrint 1105 9-17...
  • Page 336 Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 9-18 VarioPrint 1105...

  • Page 337: Stapling Output To The Primary (Main) Tray

    Touch [Staple] on the Copy Screen. Stapled sheets will be delivered to the primary (main) tray. The Output Application Icon shows the stapling position. If you want to change stapling style and position, proceed to the fol- lowing steps. VarioPrint 1105 9-19...
  • Page 338 Touch any stapling position key to select it. Details If you touch [Cancel], it returns to the previous setting. If you touch [Function Off], stapling output will be turned off but the sta- pling position will be kept in memory. 9-20 VarioPrint 1105...
  • Page 339 Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. VarioPrint 1105 9-21...

  • Page 340: Collated / Uncollated Output To The Secondary (Sub) Tray

    - Paper weight: 50 - 300 g/m - The secondary (sub) tray's specifications are described separately. For details, refer to “Paper Information” on page 3-3. Touch [Output Application] on the Copy Screen. The Output Application Screen appears. 9-22 VarioPrint 1105...
  • Page 341 Select an output mode. For collated output, touch Collated to select it. For uncollated output, touch Uncollated to select it. Select output face (Face Down / Face Up), and output order (1 to N / N to 1) as needed. VarioPrint 1105 9-23...
  • Page 342 Touch [OK] on the Output Application Screen. The icon of the specified output application appears on the Copy Screen. Details Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 9-24 VarioPrint 1105...

  • Page 343: Using Large Capacity Stacker Ls-501/Ls-502

    - Different sizes of paper cannot be loaded at the same time. - To remove paper, open the front door and pull out the base car. If two units are connected, paper can be removed from one unit while the other is operating. VarioPrint 1105 9-25...
  • Page 344 If the primary (main) tray is not selected as the output tray, touch [Output Tray] to select it. Note Changing output trays is described separately. For details, refer to “Se- lecting an Output Tray” on page 9-8. 9-26 VarioPrint 1105...
  • Page 345 Touch [OK] on the Output Application Screen. The icon of the specified output application appears on the Copy Screen. Reminder Be careful not to exceed the finisher tray / stacker capacity when select- ing the print quantity, otherwise unexpected trouble may be caused. VarioPrint 1105 9-27...

  • Page 346: Using Folding Unit Fd-501

    (inside print) for each folding mode except Z-fold. This section describes how to set intermediary processing for punching holes in copies and folding copies. 80 mm Z-Fold Letter Fold-out Gate 80 mm Letter Fold-in Double Parallel Folding 9-28 VarioPrint 1105...

  • Page 347: Punching File Holes In Copies

    Folding Unit FD-501. Touch [Punch] on the Copy Screen The Output Application Icon shows the number of punch holes and punch position. If you want to change number of punch holes and position, proceed to the following steps. VarioPrint 1105 9-29...
  • Page 348 Setting Output Methods Touch [Output Application]. The Output Application Screen appears. Touch [Punch] and select the number of punch holes and position. The Hole-Punch Screen appears. Touch any punch key to select it. 9-30 VarioPrint 1105...
  • Page 349 / secondary (sub) tray or to the secondary (sub) tray on the left side of Folding unit FD-501. Be careful not to exceed the capacity of each tray when selecting the print quantity, otherwise unexpected trouble may be caused. VarioPrint 1105 9-31...

  • Page 350: Folding Copies

    - Using Letter fold-in, Letter fold-out, Double parallel, or Gate, the folded sheets will be delivered only to the secondary (sub) tray on the left side of Folding unit FD-501. Touch [Output Application] on the Copy Screen. The Output Application Screen appears. 9-32 VarioPrint 1105...
  • Page 351 Double parallel, or Gate, the folded sheets will be delivered only to the secondary (sub) tray on the left side of Folding unit FD-501. Be careful not to exceed the capacity of each tray when selecting the print quantity, otherwise unexpected trouble may be caused. VarioPrint 1105 9-33...

  • Page 352: Using Saddle Stitcher Sd-501

    For details, refer to “Tray/ Exit Tray Capacity” on page 3-5. - Staple position: Variable (90 ~ 165 mm) - Stapling method: Inline clinch - Trimming width: 2 ~ 10 mm Fold & Staple Fold & Staple and Trimming 9-34 VarioPrint 1105...
  • Page 353 The Output Application Screen appears. Touch [Fold&Staple], then select to use Trimming or not. The Fold&Staple Screen will be displayed. Touch [Trimming] or [Non Trimming] to select it. Touch [OK]. The Output Application Screen will be restored. VarioPrint 1105 9-35...
  • Page 354 The output icon of the selected output mode will be displayed on the Copy Screen. Booklet function in the Application setting has been selected automat- ically. Withdraw the Saddle stitcher tray. Open the tray stand when fully withdrawn. 9-36 VarioPrint 1105...
  • Page 355 If the tray is not fully withdrawn, the machine will detect that the tray is filled up, even with less number of finished sets than that specified in specifications. Reminder Never return the Saddle stitcher tray to its original position with the tray stand opened. VarioPrint 1105 9-37...

  • Page 356: Folding Copied Set

    - Max. number of folded sheets: 5 sheets max. (80 g/m2) - Tray capacity: Multi Centre (Saddle stitcher tray) 30 sets - Multi Letter (Multi-folding tray) 30 sets Multi Centre Multi Centre Multi Letter Multi Letter + Non Trimming + Trimming + Inside Print + Outside Print 9-38 VarioPrint 1105...
  • Page 357 If [Multi Centre] is selected, the [Multi Centre Screen] will be dis- played to specify whether or not to trim the edge of the folded sheets. Touch [Trimming] or [Non Trimming] to select it. Touch [OK]. The Output Application Screen will be restored. VarioPrint 1105 9-39...
  • Page 358 Touch [OK] on the Output Application Screen. The output icon of the selected output mode will be displayed on the Copy Screen. With [Multi Centre] selected, Booklet function in the Application setting has been selected automatically. 9-40 VarioPrint 1105...
  • Page 359 The triple-folded sets will be delivered into the Multi-folding tray. Reminder Never return the Saddle stitcher tray to its original position with the tray stand opened. VarioPrint 1105 9-41...

  • Page 360: Using Post Inserter On Folding Unit Fd-501

    - For the paper size, weight, and type of covers used in Perfect Binding mode, see p. 3-3 to p. 3-8. - Upper/lower paper feed tray capacity: Maximum 500 sheets each (80 g/m paper) - Multi-feed detection function is provided. 9-42 VarioPrint 1105...
  • Page 361 Lower tray Reminder Do not load more than 500 sheets (80 g/m ) for each of the upper and lower trays. Do not load above the load limit line on the guide plate. VarioPrint 1105 9-43...
  • Page 362 Use the sheet insertion or booklet function to place a cover sheet. Reminder Copies will be delivered to the primary (main) tray of Finisher FS-503. Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 9-44 VarioPrint 1105...
  • Page 363 To lock the roller both sides, prevent paper from skewing. Push the both roller lock levers to inside to lock them. Reminder Besure to lock both sides, when locking the paper rollers. Do not lock the paper rollers normally. VarioPrint 1105 9-45...

  • Page 364: Using Folder/Finisher Functions Manually

    8.5"x11"R, Wide size paper (maximum 324 x 460 mm) – Paper weight: 50 - 244 g/m – Number of sheets to be folded&stapled: Maximum number of folded and stapled sheets varies according to the paper weight. For details, refer to p. 3-5. 9-46 VarioPrint 1105...
  • Page 365 Place paper face up. Punching: Place paper face up. Folding: Place the surface to be inside the fold face up. Fold&Staple: Place the surface to be inside the fold face up. Align the guide plate with the paper. VarioPrint 1105 9-47...
  • Page 366 When selecting folding (from 6 styles), press the Fold selection but- ton to turn on the desired mode lamp. Details Punching and stapling can be combined. When combining them, turn on the lamps for both functions. 9-48 VarioPrint 1105...
  • Page 367 For details, refer to “Selecting an Output Tray” on page 9-8. Details To fold or fold&staple booklet-styled prints manually, arrange the printed sheets as shown below before placing them into the post inserter. VarioPrint 1105 9-49...

  • Page 368: Using Perfect Binder Pb-501

    Body set Back side of front cover Back side of back cover Head Cover lead edge adjustment Cover Cover trimming Front side of front cover Spine width Foot Front side of back cover 9-50 VarioPrint 1105...
  • Page 369 Blank Blank Body set: duplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: On, copver print side: simplex Blank Blank Body set: duplex, Cover print: On, copver print side: duplex Body set Cover VarioPrint 1105 9-51...
  • Page 370 Body set: duplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: On, copver print side: simplex Blank Blank Blank Body set: duplex, Cover print: On, copver print side: duplex Blank Body set Cover 9-52 VarioPrint 1105...
  • Page 371 Cover Trimming Adjustment adjusts the trimming width in the range from –5.0 mm to +5.0 mm in 0.1 mm increments. – Cover Image Shift Adjustment adjusts the position of image to be printed on the front cover when using Cover Print mode. VarioPrint 1105 9-53...
  • Page 372 Also, the machine can be set to detect the thickness of body set and to stop the binding operation temporarily if the width of the cover to be used is unsuitable for the body set. For details, refer to “03 Stop Setting for P. B. Cover Unfit Length” on page 17-47. 9-54 VarioPrint 1105...
  • Page 373 If Cover Trimming is desired, be sure to use the size that secures 3 mm to 40 mm of trimming width. When using the Post Inserter, touch [For P.B. Cover] on the Machine Sta- tus Screen to highlight it. VarioPrint 1105 9-55...
  • Page 374 For details, refer to “01 Useful Paper Weight Select” on page 17-43. The number of body set may be limited depending on the selected paper weight. For details, refer to “02 Paper Count Limit for Perfect Binding” on page 17-45. 9-56 VarioPrint 1105...
  • Page 375 Setting Output Methods Touch [Output Application], then touch [Perfect Bind]. The Perfect Binding Screen will be displayed. VarioPrint 1105 9-57...
  • Page 376 Touch Cover Tray to display the Cover Tray Screen. Touch the tray loaded with covers in step 1 to highlight it. Details If any other tray than tray 1 to 5, the Cover Print setting in step 5 will be limited to Cover Print Off. 9-58 VarioPrint 1105...
  • Page 377 1, then touch [OK]. Reminder Be sure to enter the cover paper dimensions precisely; otherwise a mes- sage may be displayed to prompt you that the specified size is inade- quate, or the trimming function may not be performed properly. VarioPrint 1105 9-59...
  • Page 378 Setting Output Methods Specify the paper type and weight. Touch [Change] to display the Change Setting Screen. Touch [Type] to select the desired paper type, then touch [OK]. 9-60 VarioPrint 1105...
  • Page 379 For details, refer to “01 Useful Pa- per Weight Select” on page 17-43. To recall the paper setting previously registered, touch [Type/ Weight] to display the Register Screen, select the desired key, then touch [OK]. Touch [Close]. VarioPrint 1105 9-61...
  • Page 380 For details of finished result with each setting specified, refer to “Using Perfect Binder PB-501” on page 9-50. The original image to be printed on cover varies depending on whether the original count is odd or even. 9-62 VarioPrint 1105...
  • Page 381 If the trimming width estimated by the machine does not fall within the range from 3 to 40 mm, a message will be displayed to inform you that the trimming mode is unavailable. In this case, adjust the cover or spine width to enable this setting. VarioPrint 1105 9-63...
  • Page 382 Touch [OK] to complete the setting. Touch OK to return to the Copy Screen. Select additional copy conditions, as desired. When making double-sided copies, select [1-2] or [2-2]. If the original count exceeds 100, use Memory Scan mode. 9-64 VarioPrint 1105...
  • Page 383 Machine manager can set the machine to display/disappear this popup menu. For details, refer to “01 Useful Paper Weight Select” on page 17-43. VarioPrint 1105 9-65...
  • Page 384 Open the perfect binder tray cover. Details The perfect binder tray cover will not open while the machine operation is in process, and also the feeding button will not function. Take out the books. Then close the perfect binder tray cover. 9-66 VarioPrint 1105...

  • Page 385: Using Two Copiers In Tandem

    Service setting is required to use the tandem mode. Contact your service representative, if desired. Specifications for Tandem Mode: - The combination of the two copiers can be either the two VarioPrint 1105 copiers, two VarioPrint 1105 printers, or VarioPrint 1105 copier and VarioPrint 1105 printer.
  • Page 386 Confirm that both copiers are ready to copy with the Copy Screen displayed. Touch [Output Application] on the Copy Screen of either copier. The Output Application Screen will be displayed. Touch [Tandem] to highlight it, then touch [OK]. 9-68 VarioPrint 1105...
  • Page 387 - Tandem printing job cannot be started if 100 reserve jobs (not in tandem mode) are entered on the tandem machine. Wait until the reserve jobs are completed on the tandem machine. VarioPrint 1105 9-69...
  • Page 388 When the print quantity entered is an odd number, the master machine will copy and output one sheet/set more than the tandem machine to ac- commodate the job. Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass of the master machine. 9-70 VarioPrint 1105...
  • Page 389 Auto shut-off. Release the Auto shut-off mode by pressing [Power Save]. If Auto low power is activated on the tandem machine during the tandem job setting, the power saving mode will be released automatically when printing job starts. VarioPrint 1105 9-71...
  • Page 390 Selected tandem mode will be released automatically when the master machine activates Auto low power/Auto shut-off. Press [Power Save] to release Auto shut-off if required, then select the tandem mode again to restart the procedure. 9-72 VarioPrint 1105...

  • Page 391: To Stop Scanning/Printing

    Touch [Continue] to go on, or [Exit] to delete all the data transmitted to the tandem machine and to release the tandem mode. The master machine will take over the remaining print quantity and complete the job. VarioPrint 1105 9-73...

  • Page 392: Troubleshooting

    When the power is turned off on either the master or tandem machine: The tandem mode will be released automatically in either case. Restart the procedure from the first step. 9-74 VarioPrint 1105...

  • Page 393: Advanced Information

    Advanced Information Copier...

  • Page 395: Checking Feature Selections By Proof Copying

    Or, use Memory Scan mode to scan all originals. Press [Proof Copy] on the control panel. A sample copy will be output while scanning originals in the ADF. If Memory Scan mode has been used, a sample set will be delivered immediately. VarioPrint 1105 10-3...
  • Page 396 The setting keys that cannot be changed or released will appear dimmed to show inactivity. Details If the desired setting cannot be changed, press [Stop] to delete all the data in memory. Press [Start]. The machine will start printing. 10-4 VarioPrint 1105...

  • Page 397: Checking Feature Selections Before Copying (Check Mode)

    - Proof copy is available when using ADF, or when using Memory Scan mode for multiple originals or originals to be scanned from original glass. Select the desired copy conditions on the Copy Screen. Press [Mode Check] on the control panel to display the Check Screen. VarioPrint 1105 10-5...
  • Page 398 See “To Use Appli- cation Function” on page 8-8 for details. Reminder Do not press [Stop] or [Reset] to change the setting, or all the settings will restore the initial condition. 10-6 VarioPrint 1105...
  • Page 399 If making a sample copy, proceed to the next step. To start printing, proceed to step 7. Details The image data can be corrected on a PC using Jobproofer. For details, refer to the CD enclosed with VarioPrint 1105 copier main body. VarioPrint 1105 10-7...
  • Page 400 Copy Screen, then proceed to the next step. Change the print quantity, as required. Position originals, then press [Start]. If proof copying has been made, the machine will simply start printing without scanning originals. 10-8 VarioPrint 1105...

  • Page 401: Interrupt Copying

    - Reserve job cannot be operated in Interrupt mode. - Auto Low Power or Auto Shut-off will not function during Interrupt mode. Press [Interrupt] on the control panel. The [Interrupt] LED starts flashing, then keeps lighted when ma- chine is ready for Interrupt mode. VarioPrint 1105 10-9...
  • Page 402 Position original(s), then press [Start] to start the interrupt copying. When Interrupt copying is completed, press [Interrupt] again. The [Interrupt] LED turns out and the settings of the initial job will be re- stored. Press [Start] to resume copying. 10-10 VarioPrint 1105...

  • Page 403: Storing And Recalling Job Conditions (Mode Memory)

    - Up to 30 jobs can be stored. - Stored job can be registered to the Function key. Make job selections from the Copy Screen. Press [Mode Memory] on the control panel. The Mode Memory Screen will be displayed. VarioPrint 1105 10-11...
  • Page 404 Review the settings, then touch [OK]. The Mode Memory Screen will be restored. Details If any correction is required, touch [Cancel] to return to the Copy Screen. Make new selections, then restart the operation from step 2. 10-12 VarioPrint 1105...
  • Page 405 Enter a job name, then touch [OK]. Enter a job name in up to 16 characters, using the touch panel al- phabet keypad. Use arrow keys * and ) to move the cursor, and use Shift to enter upper case letters or symbols. VarioPrint 1105 10-13...
  • Page 406 Check that the job name has been correctly entered. Details If you do not wish to enter a name, simply touch [OK]. The key displays 16 asterisks (*) in place of a name. Touch [OK] to complete the setting and return to the Copy Screen. 10-14 VarioPrint 1105...

  • Page 407: Recalling Stored Job Settings

    Touch [COPY] tab to display the Copy Screen, then press [Mode Mem- ory] on the control panel. The Mode Memory Screen will be displayed. Touch a job number key to select a job you want to recall. VarioPrint 1105 10-15...
  • Page 408 The Job Recall Check Screen displays to enable you to review the set- tings. Touch [OK]. The settings of the selected job will be recalled on the restored Copy Screen. Position original(s), then press [Start] to print. 10-16 VarioPrint 1105...

  • Page 409: Recalling Previous Job Settings

    - The previous job settings can be recalled even after the machine power is turned off then on. Press [Mode Memory] on the control panel. The Mode Memory Screen will be displayed. VarioPrint 1105 10-17...
  • Page 410 Recalled settings can be altered from this screen. For details, “Change the settings from the Check Screen.” on page 10-6. Touch [OK]. The settings of the previous output job will be recalled on the Copy Screen. Position original(s), then press [Start]. 10-18 VarioPrint 1105...

  • Page 411: Displaying Screen For Operation Guide (Help Mode)

    Screen key information (01~06) can also be displayed from each screen by pressing [Help] on the control panel. To reach item 07, 08, or 09 from any subordinate Help Screens, touch [Top Menu] to display the top page, then select the desired item. VarioPrint 1105 10-19...

  • Page 412: To Display Help Screen

    Advanced Information 10.6.1 To Display Help Screen Pressing [Help] when Machine Status Screen is displayed: Pressing [Help] when Copy Screen is displayed: 10-20 VarioPrint 1105...
  • Page 413 Advanced Information Top Page of the Help Screen: This screen appears when [Top Menu] on the subordinate Help Screen is touched. VarioPrint 1105 10-21...

  • Page 414: Adjusting Response Time Of Touch Keys (Accessibility)

    The Accessibility LED lights in green to indicate that the specified re- sponse time is set on the machine. Details If Normal is selected as response time, pressing [Accessibility] will not make any change in the touch key operation. 10-22 VarioPrint 1105...
  • Page 415 Advanced Information To deactivated this function, press [Accessibility] for one second or longer. The Accessibility LED goes off, and normal response time will be re- stored in touch key operation. VarioPrint 1105 10-23...
  • Page 416 Advanced Information 10-24 VarioPrint 1105...

  • Page 417: Machine Status Screen Setting

    Machine Status Screen Setting POD Administrator...

  • Page 419: Machine Status Screen Setting Outlines

    The Paper Set popup screen is displayed. Specify each tray size, register/delete paper type/weight setting, and also set air assist function on/off from this screen. For the details, refer to “Paper Set- ting Outlines” on page 12-3. VarioPrint 1105 11-3...
  • Page 420 Machine Status Screen Setting Details You may set the other settings on another screen while specifying the pa- per setting. Press the tab key to switch the screens. 11-4 VarioPrint 1105...
  • Page 421 You cannot set the other settings while specifying the Adjustment mode. Controller The Controller Setting Menu Screen is displayed. Specify the settings concerning the Print Controller. For the details, refer to “Function Overview” on page 14-3. Touch the [MACHINE] tab to exit the Controller Setting mode. VarioPrint 1105 11-5...
  • Page 422 Machine Status Screen Setting 11-6 VarioPrint 1105...

  • Page 423: Paper Setting

    Paper Setting POD Administrator...

  • Page 425: Paper Setting Outlines

    2. Weight Select one of the following eight types. 40 - 49 g, 50-61g, 62-71g, 72-91g, 92-130g, 131-161g, 162-209g, 210- 244g, 245-300g Details For details of paper type specifications, refer to “Paper type and weight” on page 12-7. VarioPrint 1105 12-3...
  • Page 426 The coated paper is mostly used for luxury art books, calendars, car brochures, books, magazines, leaflets, and posters. Always specify [Coated A] to a tray to which the coated paper is loaded. 12-4 VarioPrint 1105...
  • Page 427 User When a paper type other than that of which can be specified on this machine is used, use this function. For the details, contact your service representa- tive. VarioPrint 1105 12-5...
  • Page 428 Paper Setting Specify [OHP] to a tray to which transparent films are loaded. Weight is classified into eight types as shown in the following table. 12-6 VarioPrint 1105...

  • Page 429: Paper Type And Weight

    A4 in the simplex print mode. Copying speed becomes slow. Printing speed is 63 sheets per minute when print- ing A4 in the simplex print mode. Copying speed may be slower depending on paper size and environment of the machine. VarioPrint 1105 12-7...
  • Page 430 110.7 121.8 190.0 50.6 70.4 105.2 86.8 116.9 128.5 200.0 53.3 74.1 110.8 91.3 123.1 135.3 210.0 55.9 77.8 116.3 95.9 129.2 142.1 220.0 58.6 81.5 121.8 100.5 135.4 148.8 230.0 61.3 85.2 127.4 105.0 141.5 155.6 12-8 VarioPrint 1105...
  • Page 431 290.0 77.2 107.4 160.6 132.4 178.4 196.2 300.0 79.9 111.1 166.1 137.0 184.6 202.9 Details The Help Screen provides the paper weight conversion table. Press [Help] on the control panel to display the Help Screen, if desired. VarioPrint 1105 12-9...

  • Page 432: Recommended Setting Of Paper Type/Weight

    Details Service representative can make adjustments for all trays at the same time. Contact your service representative, if desired. Refer to a label on a paper package when registering the paper condi- tions. 12-10 VarioPrint 1105...

  • Page 433: Register Paper Type/Weight

    Paper Setting 12.2 Register Paper Type/Weight Follow the procedure below to register paper type/weight according to the paper type to be used. Procedure Touch [Paper Set] - [Register Type/Weight]. VarioPrint 1105 12-11...
  • Page 434 Paper Setting Touch the key to be registered. The Input Condition Screen will be dis- played. 12-12 VarioPrint 1105...
  • Page 435 Touch [Type] to display the Type popup menu, then select the desired paper type. Details For details, refer to “Paper Type Specifications” on page 12-4. Touch [OK] to complete the setting. Touch [Name] on the Input Condition Screen, then enter the name of the paper to be used. VarioPrint 1105 12-13...
  • Page 436 Details For details, refer to “Paper type and weight” on page 12-7. Touch [OK] to complete the setting. Touch [Coloured Paper] on the Input Condition Screen, then select the colour of the paper to be used. 12-14 VarioPrint 1105...
  • Page 437 Paper Setting Touch [OK] to complete the setting. Touch [Hole-Punch] on the Input Condition Screen, then touch [With Punch Hole] if the paper has punch holes. Touch [OK] to complete the setting. VarioPrint 1105 12-15...
  • Page 438 For details, refer to “Setting Items in Paper Setting” on page 12-3. Touch [OK]. Touch [OK] on the Input Condition Screen to complete the setting.The Input Condition Screen will be restored. Touch [Close]. The Machine Status Screen will be restored. 12-16 VarioPrint 1105...

  • Page 439: Delete Paper Type/Weight

    Paper Setting 12.3 Delete Paper Type/Weight Follow the procedure below to delete the paper type/weight previously reg- istered. Procedure Touch [Paper Set] - [Delete Type/Weight]. VarioPrint 1105 12-17...
  • Page 440 Touch [Yes] to delete it, or touch [No] to cancel. If more than one paper type/size is to be deleted, repeat steps 2 and 3. Touch [OK] to complete the setting. Touch [Close]. The Machine Status Screen will be restored. 12-18 VarioPrint 1105...

  • Page 441: Set Paper Size, Conditions, Air Assist Function For A Tray

    Paper Setting 12.4 Set Paper Size, Conditions, Air Assist Function for a Tray Specify the paper sizes, programmed paper type/weight, air assist function for each tray. VarioPrint 1105 12-19...
  • Page 442 Paper Setting Procedure Touch [Paper Set] - [Tray Setting]. Touch the tray key (Tray 1 to 5) to be specified. Touch [Size Setting]. The Size Setting Screen will be displayed. Follow the procedure for each setting. 12-20 VarioPrint 1105...
  • Page 443 Details If 5.5x8.5 is selected on the Search Size Set Screen, the machine will au- tomatically detect 5.5x8.5 instead of A5. Similarly, 8.5x11R will be de- tected instead of A4R, 8x13/8.12x13.2/8.25x13/8.5x13 will be detected instead of 8.5x14. VarioPrint 1105 12-21...
  • Page 444 4. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. 5. Proceed to step 5. (p. 12-27) Reminder The smallest size of the custom size can be changed. Contact your serv- ice representative for details. 12-22 VarioPrint 1105...
  • Page 445 (+) and (,) to enter the horizontal size. The entered number should fall within the range from the horizontal size of the standard size corresponding to the selected wide size, to a maxi- mum of 460 mm. VarioPrint 1105 12-23...
  • Page 446 7. Touch [Select Size] to return to the Select Size Screen. 8. Touch [OK] on the Size Setting Screen to complete the setting. The Tray Setting Screen will be restored. 9. Proceed to step 5. (p. 12-27) 12-24 VarioPrint 1105...
  • Page 447 Setting Tab Paper 1. Touch [Tab Paper] to highlight it. 2. Touch the desired tabbed paper size key to highlight it. 3. If setting the custom tabbed paper size, touch [Custom Size] to display the Size Setting Screen. VarioPrint 1105 12-25...
  • Page 448 Setting range is from 1 to 5. 6. Touch [OK] to complete the setting. 7. Touch [OK] on the Size Setting Screen to complete the setting. The Tray Setting Screen will be restored. 8. Proceed to step 5. (p. 12-27) 12-26 VarioPrint 1105...
  • Page 449 Paper Setting Touch [Type/Weight] on the Tray Setting Screen. Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it. VarioPrint 1105 12-27...
  • Page 450 Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. Touch [Close] on the Tray Setting Screen. The Paper Set Screen will be restored. Touch [Close] on the Paper Set Screen. The Machine Status Screen will be restored. 12-28 VarioPrint 1105...

  • Page 451: Change Paper Type/Weight Specified For A Tray

    Front and Back Page Adjustment is required to execute every time the paper type is changed or as daily maintenance, because a shrinkage ratio varies depending upon the paper type, paper brand, and the temperature and/or humidity of a storage location. VarioPrint 1105 12-29...
  • Page 452 Paper Setting Procedure Touch [Paper Set] - [Tray Setting]. Touch [Change] to display the Change Setting Screen. 12-30 VarioPrint 1105...
  • Page 453 Paper Setting Touch the key of the setting item to be changed. VarioPrint 1105 12-31...
  • Page 454 Paper Setting 12-32 VarioPrint 1105...
  • Page 455 Use a scale to measure. Enter the adjustment value from the screen key- pad. – Setting range: X (horizontal) - 10 (left) to + 10 (right), Y (vertical) - 10 (top) to + 10 (bot- tom), 1 step = 0.1 mm VarioPrint 1105 12-33...
  • Page 456 To newly register the modified setting, touch [Register]. To simply change the setting, proceed to step 10. Touch the desired registration key on the Register Screen. The Input Name Screen will be displayed. Enter the desired name. 12-34 VarioPrint 1105...
  • Page 457 Touch [OK]. To restore the previous setting, touch [Cancel]. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. Touch [Close] to return to the Paper Set Screen. Touch [Close]. The Machine Status Screen will be restored. VarioPrint 1105 12-35...
  • Page 458 Paper Setting 12-36 VarioPrint 1105...

  • Page 459: Adjustment

    Adjustment POD Administrator...

  • Page 461: Machine Adjustment Outlines

    The following adjustments for image control are included in the Machine Ad- justment functions. 01 Magnification Adjustment Provide controls for image magnification. 02 Timing Adjustment Provide controls for image timing. 03 Centering Adjustment Provide the centering control to the direction of paper feed. VarioPrint 1105 13-3...

  • Page 462: Magnification Adjustment

    In the printer control, perform this adjustment to control the magnification for Side 1 to the direction of paper feed. Details This adjustment is a baseline for both sides adjustment enabled in Tray Setting and Register Type/Weight. 13-4 VarioPrint 1105...
  • Page 463 Load A3 paper into the tray, then press [Start] to output the sample pat- tern (No. 16). Measure the resultant magnification to the direction of paper feed. 205.7 Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab to return to the Adjustment Screen. VarioPrint 1105 13-5...
  • Page 464 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to +10 (long), 1 step = 0.05%. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 13-6 VarioPrint 1105...
  • Page 465 In the printer control, perform this adjustment to control the magnification for Side 2 to the direction of paper feed. Details This adjustment is a baseline for both sides adjumstment enabled in Tray Setting and Register Type/Weight. VarioPrint 1105 13-7...
  • Page 466 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to 0 (long), 1 step = 0.05%. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 13-8 VarioPrint 1105...
  • Page 467 Adjustment 03 Printer Horizontal Adjustment <SIDE1> In the printer control, perform this adjustment to control the magnification for Side 1 perpendicular to the direction of paper feed. VarioPrint 1105 13-9...
  • Page 468 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to +10 (long), 1 step = 0.1%. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 13-10 VarioPrint 1105...
  • Page 469 Adjustment 04 Printer Horizontal Adjustment <SIDE2> In the printer control, perform this adjustment to control the magnification for Side 2 perpendicular to the direction of paper feed. VarioPrint 1105 13-11...
  • Page 470 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -5 (short) to 0 (long), 1 step = 0.1%. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 13-12 VarioPrint 1105...

  • Page 471: Timing Adjustment

    Adjustment 13.3 02 Timing Adjustment 01 Printer Restart Timing Adjustment <SIDE1> Perform this adjustment to control the restart timing for Side 1. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE1>. VarioPrint 1105 13-13...
  • Page 472 – PFU lower tray offset Touch the [COPY] tab to display the Copy Screen. Select A3 paper, then press [Start] to output the sample pattern (No. 16). Measure the resultant restart timing. Paper feed direction 13-14 VarioPrint 1105...
  • Page 473 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -30 (short) to +30 (long), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. VarioPrint 1105 13-15...
  • Page 474 Adjustment 02 Printer Restart Timing Adjustment <SIDE2> Perform this adjustment to control the restart timing for Side 2. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE2>. 13-16 VarioPrint 1105...
  • Page 475 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -30 (short) to +30 (long), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. VarioPrint 1105 13-17...
  • Page 476 Adjustment 03 Scanner Restart Timing Adjustment Perform this adjustment to control the restart timing in scanning the original with the original glass. 13-18 VarioPrint 1105...
  • Page 477 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -40 (fast) to +40 (slow), 1 step = 0.1 mm. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. VarioPrint 1105 13-19...
  • Page 478 Adjustment 04 ADF Restart Timing Adjustment Perform this adjustment to control the restart timing in scanning the original with ADF. 13-20 VarioPrint 1105...
  • Page 479 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -50 (fast) to +50 (slow), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. VarioPrint 1105 13-21...

  • Page 480: Centering Adjustment

    Adjustment 13.4 03 Centering Adjustment 01 Printer Centring Adjustment Perform this adjustment to control image centring to the direction of paper feed. 13-22 VarioPrint 1105...
  • Page 481 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -64 (forward) to +63 (backward), 1 step = 0.1 mm. Repeat steps 3 to 6 until the desired result is obtained. Touch [Return] to restore the Centring Adjustment Menu Screen. VarioPrint 1105 13-23...

  • Page 482: Finisher Adjustment Outlines

    05 Saddle Stitcher Adjustment Make adjustments on the Saddle Stitcher SD-501. 06 Perfect Binder Adjustment Make adjustments on the Perfect Binder PB-501. 07 Trimmer Count Adjustment Select the coutn of the trimmer receiver of the Saddle Stitcher SD-501. 13-24 VarioPrint 1105...

  • Page 483: Stapler Position Adjustment

    01 Stapling Centre Position Adjustment Perform this adjustment for the centre position of copied/printed sheets and of staples processed by the Staple Finisher FS-503. The paper width adjustment is supposed to be completed before this adjust- ment. VarioPrint 1105 13-25...
  • Page 484 If the test desired result cannot be obtained, touch the [ADJUSTMENT] tab. Repeat the adjustment steps from 3 to 6 until the desired result is obtained. Touch [Return] to restore the Stapler Position Adjustment Mode Menu Screen. 13-26 VarioPrint 1105...
  • Page 485 Adjustment 02 Paper Width Adjustment Perform this adjustment if stapled sheets are not aligned neatly processed when Straight/Staple mode is selected on the Staple Finisher FS-503. VarioPrint 1105 13-27...
  • Page 486 Note When paper length is 239 mm or longer, the stapler unit cannot be pulled out. In this case, remove the paper before pulling out the stapler unit, then return the paper to the original position. 13-28 VarioPrint 1105...
  • Page 487 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (wide) to +20 (narrow), 1 step = 0.1 mm Note Make the width between fixing plates narrower than the paper width. VarioPrint 1105 13-29...
  • Page 488 If desired adjustment result cannot be obtained, touch the [ADJUST- MENT] tab, then repeat the adjustment steps from 3 to 12 until the de- sired result is obtained. Touch [Return] to restore the Stapler Position Adjustment Mode Menu Screen. 13-30 VarioPrint 1105...

  • Page 489: Multi Folder (Punch) Adjustment

    Adjustment 13.7 02 Multi Folder (Punch) Adjustment 01 Paper Width Adjustment Perform this adjustment for the specific paper size if punch holes processed by the Folding Unit FD-501 dislocate largely. VarioPrint 1105 13-31...
  • Page 490 If the setting is too narrow, the position of punch holes may vary. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Multi Folder (Hole-Punch) Adjustment Mode Menu Screen. 13-32 VarioPrint 1105...
  • Page 491 Adjustment 02 Hole-Punch Vertical Position Adjustment Perform this adjustment for the position of punch holes to the direction of pa- per feed. VarioPrint 1105 13-33...
  • Page 492 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -40 (wide) to +40 (narrow), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 9 until the desired result is ob- tained. 13-34 VarioPrint 1105...
  • Page 493 Adjustment If adjustment in any other hole type or paper size is required, repeat steps from 3 to 10. Touch [Return] to restore the Multi Folder (Hole-Punch) Adjustment Mode Menu Screen. VarioPrint 1105 13-35...

  • Page 494: Multi Folder (Fold) Adjustment

    Adjustment 13.8 03 Multi Folder (Fold) Adjustment 01 Folding Position Adjustment Perform this adjustment for the folding position processed by theFolding Unit FD-501. 13-36 VarioPrint 1105...
  • Page 495 When misalignment (a) of step 5 has occurred, enter the "+" value. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. VarioPrint 1105 13-37...
  • Page 496 The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. 13-38 VarioPrint 1105...
  • Page 497 Fold-in], then press [Start]. A sample pattern (No. 16) will be output. Check a distance (a) and distance (b) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. VarioPrint 1105 13-39...
  • Page 498 The distance (b) in step 5 will increase when the "+" value is entered, and decrease when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 13-40 VarioPrint 1105...
  • Page 499 The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. VarioPrint 1105 13-41...
  • Page 500 Fold-out], then press [Start]. A sample pattern (No. 16) will be output. Check a distance (a) and distance (b) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. 13-42 VarioPrint 1105...
  • Page 501 The distance (b) in step 5 will increase when the "+" value is entered, and decrease when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. VarioPrint 1105 13-43...
  • Page 502 The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. 13-44 VarioPrint 1105...
  • Page 503 Parallel], then press [Start]. A sample pattern (No. 16) will be output. Check a distance (a) and distance (b) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. VarioPrint 1105 13-45...
  • Page 504 The distance (b) in step 5 will decrease when the "+" value is entered, and increase when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 13-46 VarioPrint 1105...
  • Page 505 The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. VarioPrint 1105 13-47...
  • Page 506 Fold], then press [Start]. A sample pattern (No. 16) will be output. Check a distance (a) and distance (b) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. 13-48 VarioPrint 1105...
  • Page 507 The distance (b) in step 5 will increase when the "+" value is entered, and decrease when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. VarioPrint 1105 13-49...
  • Page 508 Triple Fold is calculated from the position of the second fold line, therefore a distance (a), distance (b) and distance (c) in step 5 will be al- tered by changing the position of any fold position. 13-50 VarioPrint 1105...
  • Page 509 [Start]. A sample pattern (No. 16) will be output. Check a distance (a), distance (b) and distance (c) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. VarioPrint 1105 13-51...
  • Page 510 In Triple Fold, the distance (c) in step 5 will decrease when the "+" value is entered, and increase when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 13-52 VarioPrint 1105...

  • Page 511: Stacker Adjustment

    Adjustment 13.9 04 Stacker Adjustment 01 Paper Width Adjustment Perform this adjustment when output sheets are not aligned in a perpendic- ular position to the direction of paper feed processed by the Large Capacity Stacker LS-501/502. VarioPrint 1105 13-53...
  • Page 512 Available range: -20 (narrow) to +20 (wide), 1 step = 0.1 mm If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Stacker Adjustment Mode Menu Screen. 13-54 VarioPrint 1105...
  • Page 513 Adjustment 02 Paper Length Adjustment Perform this adjustment when output sheets are not aligned to the direction of paper feed processed by the Large Capacity Stacker LS-501/502. VarioPrint 1105 13-55...
  • Page 514 Available range: -20 (narrow) to +20 (wide), 1 step = 0.1 mm If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Stacker Adjustment Mode Menu Screen. 13-56 VarioPrint 1105...

  • Page 515: Saddle Stitcher Adjustment

    Perform this adjustment for the centre (folding) position of copied/printed sheets and of staples processed by the Saddle Stitcher SD-501. The paper width adjustment (06) and folding position adjustment (04) are supposed to be completed before this adjustment. VarioPrint 1105 13-57...
  • Page 516 Touch the [COPY] tab to display the Copy Screen. Select the Fold&Staple mode, then press [Start]. A sample copy will be output. Check misalignment (a) of the folded line and stapling position. If the test desired result cannot be obtained, touch the [ADJUSTMENT] tab. 13-58 VarioPrint 1105...
  • Page 517 Available range: -20 (forward) to +20 (backward), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 7 until the desired result is ob- tained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. VarioPrint 1105 13-59...
  • Page 518 Adjustment 02 Stapling Paper Width Adjustment Perform this adjustment if stapled sheets are not aligned neatly processed by the Saddle Stitcher SD-501. 13-60 VarioPrint 1105...
  • Page 519 8.12x13.2 - 8.5x13 - 8.25x13 - 8K - 16KR - 12x18 - A3W - B4W - A4WR - B5WR - 12x18W - 11x17W - 8.5x11WR - Special Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (wide) to +20 (narrow), 1 step = 0.1 mm VarioPrint 1105 13-61...
  • Page 520 91 mm automatically even if the value short- er than 91 mm of staple pitch is entered. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. 13-62 VarioPrint 1105...
  • Page 521 Adjustment 03 Staple Pitch Adjustment Perform this adjustment for the staple pitch processed by Saddle Stitcher SD-501. VarioPrint 1105 13-63...
  • Page 522 Available range: -20 (wide) to +20 (narrow), 1 step = 1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. 13-64 VarioPrint 1105...
  • Page 523 Adjustment 04 Folding Position Adjustment Perform this adjustment for the double-folding position processed by the Saddle Stitcher SD-501. VarioPrint 1105 13-65...
  • Page 524 Available range: -20 to +20, 1 step = 0.1 mm Note When misalignment (a) of step 5 has occurred, enter the "+" value. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. 13-66 VarioPrint 1105...
  • Page 525 Adjustment Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. VarioPrint 1105 13-67...
  • Page 526 The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. 13-68 VarioPrint 1105...
  • Page 527 Letter, then press [Start]. A sample pattern (No. 16) will be output. Check a distance (a) and distance (b) on the output sheet. Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. VarioPrint 1105 13-69...
  • Page 528 The distance (b) in step 5 will increase when the "+" value is entered, and decrease when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. 13-70 VarioPrint 1105...
  • Page 529 Adjustment 06 Fold Paper Width Adjustment Perform this adjustment if folding position processed by the Saddle Stitcher SD-501 dislocates in the folded set. VarioPrint 1105 13-71...
  • Page 530 If the setting is too wide, the distance of misalignment may be larger. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. 13-72 VarioPrint 1105...
  • Page 531 Adjustment 07 Trimming Adjustment Perform this adjustment to increase/decrease the trimming width. VarioPrint 1105 13-73...
  • Page 532 Available range: -400 (wide) to +400 (narrow), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. 13-74 VarioPrint 1105...
  • Page 533 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. VarioPrint 1105 13-75...

  • Page 534: Perfect Binder Adjustment

    13.11 06 Perfect Binder Adjustment 01 Cover Trimming Adjustment Perform this adjustment to increase/decrease the trimming width of the right cover page determined in Perfect Binding mode. Reminder Be sure to perform 02 Cover Lead Edge Adjustment before this adjust- ment. 13-76 VarioPrint 1105...
  • Page 535 Check that the edge of the right cover page is neatly aligned with that of the left cover page. Left cover page Right cover page Trimming position If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. VarioPrint 1105 13-77...
  • Page 536 Available range: -128 (short) to +127 (long), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. 13-78 VarioPrint 1105...
  • Page 537 Adjustment 02 Cover Lead Edge Adjustment Perform this adjustment for the position of left cover page determined in Per- fect Binding mode. VarioPrint 1105 13-79...
  • Page 538 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -128 (short) to +127 (long), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 9 until the desired result is ob- tained. 13-80 VarioPrint 1105...
  • Page 539 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. VarioPrint 1105 13-81...
  • Page 540 Adjustment 03 Spine Corner Forming Position Adjustment Perform this adjustment to regulate the position when forming the spine cor- ner of the cover. 13-82 VarioPrint 1105...
  • Page 541 Available range: -128 (down) to +127 (up), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. VarioPrint 1105 13-83...
  • Page 542 Adjustment 04 Pasting Start Position Adjustment Perform this adjustment for the position to start pasting on the body set. 13-84 VarioPrint 1105...
  • Page 543 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -128 (early) to +127 (late), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 9 until the desired result is ob- tained. VarioPrint 1105 13-85...
  • Page 544 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. 13-86 VarioPrint 1105...
  • Page 545 Adjustment 05 Pasting Finish Position Adjustment Perform this adjustment for the position to finish pasting on the body set. VarioPrint 1105 13-87...
  • Page 546 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -128 (early) to +127 (late), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 9 until the desired result is ob- tained. 13-88 VarioPrint 1105...
  • Page 547 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. VarioPrint 1105 13-89...
  • Page 548 Adjustment 06 Paste Formation Finish Position Adjustment Perform this adjustment for the position to finish equalizing the paste applied on the body set. 13-90 VarioPrint 1105...
  • Page 549 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. VarioPrint 1105 13-91...
  • Page 550 - Melt Tank -Mid: Melt tank temperature sensor/ Md (TH3) - Melt Tank -Low: Melt tank temperature sensor/ Lw (TH4) - Pasting Roller: Pasting roller temperature sensor (TH1) Reminder Do not make unnecessary change of the temperature setting inside the melt tank. 13-92 VarioPrint 1105...
  • Page 551 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: Melt Tank -Top 10 to 200 °C Melt Tank -Mid 140 to 200 °C Melt Tank -Low 140 to 200 °C Pasting Roller 140 to 200 °C VarioPrint 1105 13-93...
  • Page 552 Adjustment Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. 13-94 VarioPrint 1105...
  • Page 553 Details Use this adjustment if the horizontal scanning direction is unequal on all pages of the body set. If unequalness appears mainly on the latter half of body pages, use 09 Clamp CD Width Adjustment instead. VarioPrint 1105 13-95...
  • Page 554 If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (wide) to +20 (narrow), 1 step = 0.1 mm 13-96 VarioPrint 1105...
  • Page 555 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. VarioPrint 1105 13-97...
  • Page 556 Perform this adjustment for the width in horizontal scanning direction of the body set. Details Use this adjustment if the horizontal scanning direction is unequal on the latter half of body pages. If unequalness appears on all pages, use 08 Sub Compile CD Width Adjustment instead. 13-98 VarioPrint 1105...
  • Page 557 If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (wide) to +20 (narrow), 1 step = 0.1 mm VarioPrint 1105 13-99...
  • Page 558 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. 13-100 VarioPrint 1105...
  • Page 559 Adjustment 10 Cover Up/Down CD Width Adjustment Perform this adjustment for the horizontal scanning position of the body set and cover. VarioPrint 1105 13-101...
  • Page 560 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. 13-102 VarioPrint 1105...
  • Page 561 Adjustment 11 Clamp FD Position Adjustment Perform this adjustment for the width in vertical scanning direction of the body set. VarioPrint 1105 13-103...
  • Page 562 If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”. 13-104 VarioPrint 1105...

  • Page 563: Trimmer Count Adjustment

    Details The 07 Trimmer Count Adjustment key is not displayed by default. If this key is desired for making this adjustment, contact your service represent- ative. VarioPrint 1105 13-105...
  • Page 564 Touch [Adjustment] - [02 Finisher Adjustment] - [06 Trimmer Count Ad- justment] to display the Trimming Receiver Count Screen. Touch the display count key to highlight it. Touch [OK] to complete the setting and return to the Finisher Adjust- ment Screen. 13-106 VarioPrint 1105...

  • Page 565: Controller Setting

    Controller Setting POD Administrator...

  • Page 567: Function Overview

    PCL Demo Page Print Print the PCL demo page. PS Demo Page Print (machine Print the PS demo page. with option) PCL Font List Print the PCL font list. PS Font List (machine with Print the PS font list. option) VarioPrint 1105 14-3...

  • Page 568: Printer Setting

    Select the print page order in ini- 1 to N , N to 1 tial state. 12 Print Number Specify the print quantity in initial to 9999 state. 13 Collate Select to use the Sort mode. Collated , Uncollated 14-4 VarioPrint 1105...
  • Page 569 Specify the number of lines per 5 to 128 ( page. 05 Font point size Specify the font size by point. 0.44 to 99.75 ( 12.00 06 Font pitch Specify the font pitch. 0.44 to 99.95 ( 10.00 VarioPrint 1105 14-5...
  • Page 570 * 1: Port No. (9100, etc.) is the initial setting. For details, refer to “02 Printer Setting” on page 14-4. 04 Spool Select to spool the job to HDD. For details, refer to “04 Spool” on page 14-6. Menu Items Description Setting Options Spool Select to spool the job to HDD. Auto, Enable, Disable 14-6 VarioPrint 1105...
  • Page 571 Menu Items Description Setting Options Parallel Timeout Set the timer to terminate the par- 10 to 300 seconds ( allel port. Network Timeout Set the timer to terminate the net- 10 to 300 seconds ( work port. VarioPrint 1105 14-7...

  • Page 572: Report Type

    Touch the desired report type key to select it. Touch [Execute]. The Controller Setting Menu Screen will be restored, and the Data LED on the control panel blinks to indicate that the printing operation is in progress. To return to the previous screen, touch [Return]. 14-8 VarioPrint 1105...
  • Page 573 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. VarioPrint 1105 14-9...

  • Page 574: Printer Setting

    02 PCL Setting specifies the settings concerning printer protocol. 03 PS Setting specifies the setting concerning PS error print. 04 TIFF Setting specifies the settings concerning TIFF image. Procedure Touch [Controller] - [02 Printer Setting]. Specify the setting number. 14-10 VarioPrint 1105...
  • Page 575 Use the touch screen keypad to enter the setting number for your set- ting. Available range is from 1 to 6. Touch [Set] to complete the setting. If wrong number is entered, touch [Reset] to reenter the correct number. Perform the Basic Setting. VarioPrint 1105 14-11...
  • Page 576 16 Banner Option: Select to print the banner page. 17 Banner Tray: Select the paper feed tray for printing banner page. 18 Convert Paper Size: Select to change the paper size. 19 Combination: Specify the desired combination function. 14-12 VarioPrint 1105...
  • Page 577 Touch [Return] to complete the setting and restore the Printer Setting Screen. Perform the PCL Setting. Touch [02 PCL Setting]. The PCL Setting Menu Screen will be dis- played. Make the desired setting. 01 Font Source: Select the medium of font source. VarioPrint 1105 14-13...
  • Page 578 Specify the font pitch. 07 CR/LF Mapping: Select the line feed code. Touch [Return] to complete the setting and restore the Printer Setting Screen. Perform the PS Setting (option). Touch [03 PS Setting]. The PS Setting Screen will be displayed. 14-14 VarioPrint 1105...
  • Page 579 Touch [ON] to complete the setting. The PS Setting Screen will be re- stored. Touch [Return] to complete the setting and restore the Printer Setting Screen. Perform the TIFF Setting. Touch [04 TIFF Setting]. The TIFF Setting Menu Screen will be dis- played. VarioPrint 1105 14-15...
  • Page 580 Touch [Return] on the Printer Setting Screen. The Controller Setting Menu Screen will be restored. If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. 14-16 VarioPrint 1105...

  • Page 581: Select Printer Setting

    [Default(9100)], then enter the desired port number. Touch [Set] to complete the setting. If wrong number is entered before touching [Set], touch [Reset] to reenter the correct number. Touch [Return]. The Controller Setting Menu Screen will be restored. VarioPrint 1105 14-17...
  • Page 582 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. 14-18 VarioPrint 1105...

  • Page 583: Spool

    Touch [OK] to complete the setting. The Controller Setting Menu Screen will be restored. If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. VarioPrint 1105 14-19...

  • Page 584: Interface Setting

    [Set], the time initially entered is designated. If the wrong number is entered before touching [Set], touch [Reset] to reenter the correct number. Touch [Return]. The Controller Setting Menu Screen will be restored. 14-20 VarioPrint 1105...
  • Page 585 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. VarioPrint 1105 14-21...
  • Page 586 Controller Setting 14-22 VarioPrint 1105...

  • Page 587: Utility Screen Settings

    Utility Screen Settings POD Administrator...

  • Page 589: Utility Screen Setting Outlines

    The Utility Screen includes two types of setting items: one in which a user can set and the other in which a machine manager is required to enter a password. This section describes the user setting and the machine manager setting separately in two parts. VarioPrint 1105 15-3...
  • Page 590 The following items can be disabled so that users cannot access them from the Utility screen. Contact your service representative, if desired. - Utility > Touch Screen Adjustment - Utility > System Setting > Default Screen Setting > JOB List 15-4 VarioPrint 1105...
  • Page 591 07 Change User Password Enter new password Change a user password which the user has registered for user authentication. Five keys 08 Function Key Setting Specify copy conditions for the function keys displayed on the Copy Screen. VarioPrint 1105 15-5...
  • Page 592 +1 - -5 (7 levels) 04 Image Density Selection Set the image density lighter or set the maximum dark level darker, without degrading the image quality. 04 Preset Zoom Three types Preset the magnification ratio which is frequently used. 15-6 VarioPrint 1105...
  • Page 593 Select to continue or release the tandem mode after the current tandem job is completed. User Paper1 /User Paper2/User 06 User Paper Selection Select the user paper setting to be used when "User" is Paper3 specified as paper type. VarioPrint 1105 15-7...
  • Page 594 Select the Finisher mode when Full Auto is selected late/Fold & Staple/Folding/Face UP/ as pressing [Reset]. Face Down /Off 03 Initial by Key Counter Insert Select to reset the copying conditions to the initial setting when inserting the key counter and the copy card. 15-8 VarioPrint 1105...
  • Page 595 Output Mode Screen after completion of each copying job. Hold/ Not hold Status Hold When Auto Reset When Auto Reset functions, select to reset the Platen/ RADF mode to the initial setting, or save the previous setting. VarioPrint 1105 15-9...
  • Page 596 Specify the scanning density level from AES and 9 manual setting selvels. Also select the desired Special Image mode according to the original shifted. 05 Touch Screen Adjustment Check the touch screen and realign the position of the touch sensor that may have shifted. 15-10 VarioPrint 1105...
  • Page 597 Output the list of service modes, account values, and ROM version of the machine. Font Pattern List Output the list of font patterns used with this machine. Audit Log Report Output the audit log report of the security mode. VarioPrint 1105 15-11...
  • Page 598 Set the detected paper type of the original. ries /Full Size /5.5x8.5/B5/A4/8.5x11 Orig. Glass Small Size Set the smallest size when copying by placing the original on the original glass. 08 Annotation Setting Newly register an annotation, or edit/delete the anno- tation previously registered. 15-12 VarioPrint 1105...
  • Page 599 Register, Change, Add or Delete the user authentica- long Section/Useable Function tion when the User Authentication is set in "01>01 Au- (Copy, Scanner, Store/Recall, Print- thentication Setting." /Off 04 Non register/Output Set Set to count the output of non-registered users and sections. VarioPrint 1105 15-13...
  • Page 600 13 Web Connection (For details, p. 17-119) Set to use Web Connection. 14 Network Setting Clear (For details, p. 17-121) Restore the network settings to the factory default setting. 15 SNMP Trap (For details, p. p. 17-123) Specify the SNMP Trap settings. 15-14 VarioPrint 1105...
  • Page 601 10 Original Glass SDF Face Up/ Face Down Set the exit direction when copying one set of the original on the original glass. 11 SDF Auto Setting 06 System Connection Start 01 User Call Touch [Start] when calling CSRC. VarioPrint 1105 15-15...
  • Page 602 03 Change HDD Lock Password Change the password when accessing data stored in HDD. 03 Security Strengthen mode Set the Security Strengthen mode. 08 Scanner Address Register Edit or delete the registered scanner address. 15-16 VarioPrint 1105...

  • Page 603: User Setting

    User Setting POD Administrator...

  • Page 605: System Setting

    Select the language used in the touch panel. The initial setting is American English. Procedure Touch [01 System Setting] - [01 Language Setting]. Select the desired English mode. Touch [OK] to complete the setting and return to the Utility Menu Screen. VarioPrint 1105 16-3...

  • Page 606: Buzzer Setting

    User Setting 16.1.2 02 Buzzer Setting 01 Buzzer ON/OFF, Volume Setting Set the buzzer sound (the touch key sound) as touching the screen, and also select the buzzer volume. 16-4 VarioPrint 1105...
  • Page 607 [Small] or [Big] to regulate the buzzer volume of the touch keys. Touch [Off] to highlight it. The buzzer will go off. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-5...
  • Page 608 User Setting 02 Buzzer for Job Stop Setting Select the duration of the buzzer sound when the machine stops. 16-6 VarioPrint 1105...
  • Page 609 Touch [01 System Setting] - [02 Buzzer Setting]. Touch [02 Buzzer for Job Stop Setting]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-7...

  • Page 610: 1Shot Indication Time

    “Original size A4.” Procedure Touch [01 System Setting] - [03 1 SHOT Message Indication Time]. Touch [3 seconds] or [5 seconds] to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-8 VarioPrint 1105...

  • Page 611: Default Screen Setting

    Select the initial screen to be displayed when the power switch is turned on. Procedure Touch [01 System Setting] - [04 Default Screen Setting]. Select the desired initial screen to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. VarioPrint 1105 16-9...

  • Page 612: Auto Reset Setting

    Procedure Touch [01 System Setting] - [05 Auto Reset Setting]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-10 VarioPrint 1105...

  • Page 613: Key Response Time

    Select the response time between touching the key and the machine re- sponses to it. Procedure Touch [01 System Setting] - [06 Key Response Time]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. VarioPrint 1105 16-11...

  • Page 614: Change User Password

    User Setting 16.1.7 07 Change User Password Change a user password which the user has registered for user authentica- tion. Details The changed password is reflected to the user authentication setting de- scription. 16-12 VarioPrint 1105...
  • Page 615 Enter the user name and the password then touch [OK]. Enter a new user password in [New Password]. Reenter the new user password in [Check Input]. Touch [OK] to complete the setting and return to the Utility Menu Screen. VarioPrint 1105 16-13...

  • Page 616: Function Key Setting

    Details The job setting to be registered to a function key should firstly be regis- tered using Mode Memory. For details, refer to “Storing and Recalling Job Conditions (Mode Memory)” on page 10-11. 16-14 VarioPrint 1105...
  • Page 617 Touch to select the Mode Memory item key to be registered. Touch [<Entry]. If the function key selected in step 2 has already been used for another Mode Memory job setting, a popup menu appears to confirm that the key will be overwritten. Touch [Yes]. VarioPrint 1105 16-15...
  • Page 618 Even though deleted from the function key, the job setting still re- mains in Mode Memory. Touch [Yes] to delete, or touch [No] to cancel. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-16 VarioPrint 1105...

  • Page 619: Function Setting

    16.2 02 Function Setting 16.2.1 01 Feed Tray Setting 01 Feed Tray Auto Selection Select the tray size setting to be detected when ATS functions. You may also select the priority of the detection for each tray. VarioPrint 1105 16-17...
  • Page 620 Touch to highlight the desired tray key under [Tray Priority], then change its priority by using the arrow keys (,) and (+). Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-18 VarioPrint 1105...

  • Page 621: Ats Permit

    User Setting 16.2.2 02 ATS Permit Set ATS On or Off. VarioPrint 1105 16-19...
  • Page 622 Touch [02 ATS Permit]. Select [On] when ATS is used, and [Off] when ATS is not used. Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-20 VarioPrint 1105...

  • Page 623: Auto Paper Type

    Select the paper type setting of the tray which is automatically selected when ATS functions. When the paper type that is not specified with this function is designated to the tray that is automatically selected by ATS, the machine in- dicates the paper type unmatched. VarioPrint 1105 16-21...
  • Page 624 Type], [Weight], [Colored Paper], and [Hole-Punch]. You may choose more than one key for each item. Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-22 VarioPrint 1105...

  • Page 625: Each Function Setting

    - Select whether or not to print the standard-sized original having tab part image printed on the right edge properly onto tabbed copy paper by shifting the scanned image 12.5 mm to the right side. Procedure Touch [02 Function Setting] - [02 Each Function Setting]. VarioPrint 1105 16-23...
  • Page 626 Shift (Tab Print) to specify whether or not to use those functions. Touch [OK] to complete the setting and return to the Utility Menu Screen. Details The Needless Tab Paper Exit key may not be displayed depending on the finisher type mounted on the machine. 16-24 VarioPrint 1105...

  • Page 627: Density Setting

    Select the desired copy density level manually from nine levels on the Copy Screen, and also shift each of nine density levels to three levels lighter or three levels darker. Density shift can be applied to each Enhance modes: Auto (Text/photo), Low Contrast, Photo, and Text. VarioPrint 1105 16-25...
  • Page 628 Touch the desired numeric key (from 0 to 5) for each Enhance mode to specify the desired Density shift. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-26 VarioPrint 1105...
  • Page 629 The copy density level is divided into 16 levels between Darker and Normal, and between Normal and Lighter, respectively. Select and preset two levels from the 32 levels. The preset density level setting can be recalled from Spe- cial Image on the Copy Screen. VarioPrint 1105 16-27...
  • Page 630 Density] then touch the [COPY] tab. Place the original on the original glass, and press [Start] on the control panel. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-28 VarioPrint 1105...

  • Page 631: Photo Mode Density Setting

    User Setting 16.2.6 03 Photo Mode Density Setting Set the density level of Photo Mode to be specified in AE. VarioPrint 1105 16-29...
  • Page 632 Touch [03 Photo Mode Density Setting]. Select the desired density key from [Lighter], [Normal] and [Darker]. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-30 VarioPrint 1105...

  • Page 633: Image Density Selection

    (maximum dark) or lighter, just like off- set printing. Similar to printing materials such as books, this feature is useful to make texts lighter in order to ease the eye strain. VarioPrint 1105 16-31...
  • Page 634 Touch [02 Function Setting] - [03 Density Setting]. Touch [04 Image Density Selection]. Touch the desired density key to highlight it. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-32 VarioPrint 1105...

  • Page 635: Preset Zoom

    Touch the desired preset key (from 1 to 3) and display the desired zoom ratio on the right side of the keys using the touch panel keypad. Touch [OK] to complete the setting and return to the Utility Menu Screen. VarioPrint 1105 16-33...

  • Page 636: Tandem Setting

    04 Tandem setting after JOB completion: Continue/Release Select [Continue] so that the tandem mode remains to be specified after the tandem printing job is completed. Select [Release] so that the tandem mode will be released after the tandem printing job is completed. 16-34 VarioPrint 1105...
  • Page 637 User Setting VarioPrint 1105 16-35...
  • Page 638 User Setting 16-36 VarioPrint 1105...
  • Page 639 Touch [03 Tandem Machine Shift Data Setting], select [Master Ma- chine Shift data] or [Tandem Machine Shift data], then touch [OK]. Touch [04 Tandem setting after JOB completion], select [Continue] or [Release], then touch [OK]. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-37...

  • Page 640: User Paper Selection

    Procedure Touch [02 Function Setting] - [06 User Paper Selection]. Touch the desired User Paper key (from 1 to 3) to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-38 VarioPrint 1105...

  • Page 641: Copy Setting

    - Original Setting: standard - Special Image: standard - Auto Zoom: On - Zoom: 1.000 - Output Application: See “02 Reset Function Setting” - Copy Mode: 1-1 - Auto Paper Select: On - Rotation: On - ADF: On VarioPrint 1105 16-39...
  • Page 642 User Setting 16-40 VarioPrint 1105...
  • Page 643 Follow the same procedure as setting it on the Copy Screen. Touch [ADF] to select the ADF mode as the initial setting. Touch [OK] to complete the setting and return to the Reset Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-41...
  • Page 644 (Full Auto), Initial Set which is set at “03 Copy Setting - 01 Re- set Setting - 01 Initial Setting”, or the copying condition which is preset to Mode Memory 30. In addition, alter Output Application of Full Auto as de- sired. 16-42 VarioPrint 1105...
  • Page 645 Select Output Application for Full Auto. Touch any key on the right side of [Finisher Mode for Full Auto]. Touch [OK] to complete the setting and return to the Reset Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-43...
  • Page 646 User Setting 03 Initial by Key Counter Insert Select to reset or not when inserting the key counter and the copy card. 16-44 VarioPrint 1105...
  • Page 647 Touch [On] to reset and [Off] not to reset, when inserting the key coun- ter or the copy card. Touch [OK] to complete the setting and return to the Reset Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 16-45...

  • Page 648: Each Function Setting

    Original Screen and the binding position setting made on the Output Mode Screen after completion of each copying job. Status Hold When Auto Reset When Reset functions, select to reset the Platen/ADF mode to the initial setting, or save the previous setting. 16-46 VarioPrint 1105...
  • Page 649 User Setting VarioPrint 1105 16-47...
  • Page 650 Select On/Off or touch the desired key to each item on the left side of the screen. There are two setting screens. Touch [Next] and [Previous] to switch between the screens. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-48 VarioPrint 1105...

  • Page 651: Scanner Setting

    16.4.1 01 Default Address Setting Select the default destination of the image scanned when selecting the Scanner Screen. Select one from the following four destinations: - E-Mail (E-Mail address) - HDD (Box No.) - FTP (FTP server address) - SMB VarioPrint 1105 16-49...
  • Page 652 User Setting Procedure Touch [04 Scanner Setting] - [01 Default Address Setting]. Touch the desired key for the destination. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-50 VarioPrint 1105...

  • Page 653: Each Function Setting

    Select the default scanning quality from 600dpi, 400dpi, 300dpi, and 200dpi. Special Image/Density Setting Specify the scanning density level from AE and 9 manual setting levels. Also select the desired Special Image mode according to the original type. VarioPrint 1105 16-51...
  • Page 654 Touch [OK] to complete the setting and return to the Utility Menu Screen. Details When transmitting simultaneously to multiple destinations, the file form setting cannot be specified individually. When transmitting simultaneously, the file form setting will be selected in the following priority: E-Mail>HDD>FTP>SMB 16-52 VarioPrint 1105...

  • Page 655: Touch Screen Adjustment

    Touch each [Check Button] at the upper left and lower right corners on the screen to check if the buzzer tone functions normally. VarioPrint 1105 16-53...
  • Page 656 4, repeat the adjustment pro- cedure from steps 2 to 4 or contact your service representative. Press [1] of the control panel keypad to return to the screen before pressing [Utility/Counter] on the control panel. 16-54 VarioPrint 1105...

  • Page 657: Machine Manager Setting

    Machine Manager Setting POD Administrator...

  • Page 659: Machine Manager Setting Outlines

    It is recommended to assign the ma- chine manager who will be the sole person to execute operations that are explained in this section. Details Please contact your service representative to set up your machine man- ager password. VarioPrint 1105 17-3...
  • Page 660 Machine Manager Setting How to access the Machine Manager Setting Menu Press [Utility/Counter] on the control panel to display the Utility Menu Screen. 17-4 VarioPrint 1105...
  • Page 661 Touch [06 Machine Manager Setting]. The Machine Manager Setting Menu is displayed. When the Password Input Screen is displayed, enter the eight-digit ma- chine manager password then touch [OK]. Set each function items. Touch [Return] to restore the Utility Menu Screen. VarioPrint 1105 17-5...

  • Page 662: System Setting

    Low Power and Auto Shut Off. Procedure Touch [01 System Setting] - [01 Power Save Setting]. Specify the Power Save mode to be set manually by pressing [Power Save] on the control panel, by selecting [Auto Low Power] or [Auto Shut Off]. 17-6 VarioPrint 1105...
  • Page 663 Auto Low Power, the period of time for Auto Low Power will be forcibly reset to the same period of time as Auto Shut Off. Auto Low Power will not function. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-7...

  • Page 664: Time And Date Setting

    (in 24-hour expression). Enter the time by using the touch panel keypad. Touch [Set] to move the highlighted section to the number to be changed. Repeat the same procedure for month, date, and time. 17-8 VarioPrint 1105...
  • Page 665 (e.g. Enter “-0600” for six hours later than the Universal time.) Touch [OK] to return to the Time and Date Setting Screen. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-9...

  • Page 666: Weekly Timer Setting

    If the Weekly Timer needs to be activated on your machine, contact your service representative. Conditions required to use the Weekly Timer - The power plug is inserted into the socket. - The power switch is turned on. - The current date and time are correctly set. 17-10 VarioPrint 1105...
  • Page 667 Machine Manager Setting 01 Weekly Timer On/Off Setting Enable and disable the Weekly Timer function. VarioPrint 1105 17-11...
  • Page 668 Off] to deactivate Weekly Timer. The default setting is [Weekly Timer Off]. The selected key will be highlighted. Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-12 VarioPrint 1105...
  • Page 669 Use this function to set the On/Off times in hours and minutes for each day of the week or set the collective time for the entire week, i.e., the same On/ Off time for a certain day of the week. VarioPrint 1105 17-13...
  • Page 670 When setting Sunday Off-time, Monday On-time is highlighted again. To set the On/Off time collectively for more than one day of the week, touch [Block Set] to display the Weekly Timer On/Off Time Collective Setting Screen. 17-14 VarioPrint 1105...
  • Page 671 Weekly Timer setting changes are required, select the desired menu item from 1 to 5. Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-15...
  • Page 672 Use this function to set the timer On/Off for a given day of a given month. Set the On-Off condition for specific days individually or collectively for all Mon- days through Sundays of the given month. Note The default setting is collective: On for Mondays through Saturdays, and Off for Sundays. 17-16 VarioPrint 1105...
  • Page 673 The Timer Action On/Off Setting Screen will be restored. Touch [OK] on the Timer Action On/Off Setting Screen to complete the setting and return to the Weekly Timer Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-17...
  • Page 674 Lunch Hour Off Setting to shut down the power during the lunch break and then turn it on again according to the Weekly Timer function setting. Only one off-time interval can be programmed. Note The factory default setting is [Function Invalid]. 17-18 VarioPrint 1105...
  • Page 675 Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-19...
  • Page 676 05 Set Password for Timer Interrupt Use this password setting mode to establish a four-digit password required for using the Timer Interrupt function. The default password of 0000 allows the timer function to be interrupted without entering the password. 17-20 VarioPrint 1105...
  • Page 677 (a period of time to turn the machine power on). Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-21...

  • Page 678: Management List Print

    Machine Manager Setting 17.2.4 04 Management List Print Use this function to print out the list selected from the following items. Mode memory list Programmed contents of Mode memory User management list Home position settings selected by user 17-22 VarioPrint 1105...
  • Page 679 Machine Manager Setting Use management list Information controlled by user authentication or division authentication Font pattern list Font patterns used in the machine VarioPrint 1105 17-23...
  • Page 680 Machine Manager Setting Audit log report Audited log 17-24 VarioPrint 1105...
  • Page 681 Press [Start] on the control panel to start printing the selected list. To suspend printing, press [Stop]. Touch the [UTILITY] tab to return to the Management List Print Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-25...

  • Page 682: Operation Prohibit Set

    Permit/prohibit to transmit scanned data via E-Mail. Scanner function (HDD): Permit/prohibit to save scanned data in HDD. Scanner function (FTP): Permit/prohibit to transmit scanned data to an FTP server. Scanner function (SMB): Permit/prohibit to transmit scanned data to a public folder. 17-26 VarioPrint 1105...
  • Page 683 Use the arrow keys to scroll to the desired Mode memory number, if required. Touching the locked key will clear the locking mark and release locking. Touching the key with a name not entered will not lock the key and will not display the lock mark. VarioPrint 1105 17-27...
  • Page 684 Touch [OK] to complete the setting and return to the Operation Pro- hibit Setting Screen. Touch to highlight [Permit] or [Prohibit] for each item. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-28 VarioPrint 1105...

  • Page 685: Expert Adjustment

    Set the machine to delete the outside area of the original only when APS or AMS is activated. Except Orig. Glass (1:1): Set the machine to delete the outside area of the original except when copying in real size on the original glass. VarioPrint 1105 17-29...
  • Page 686 Touch [01 System Setting] - [06 Expert Adjustment] - [01 Original Scan Area Setting]. Touch the desired key to highlight it. Touch [OK] to complete the setting and return to the Expert Adjustment Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-30 VarioPrint 1105...
  • Page 687 Machine Manager Setting 02 ADF Frame Erasure Setting Set Frame Erasure to function anytime when copying in ADF mode, and set the amount of the outside area to be deleted. VarioPrint 1105 17-31...
  • Page 688 Touch the desired amount of outside area to be deleted. Touch [None] if deleting the outside area is not necessary. Touch [OK] to complete the setting and return to the Expert Adjustment Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-32 VarioPrint 1105...
  • Page 689 Machine Manager Setting 03 Non Image Area Erase Setting Use this function to select the erase mode, and set the density level of the original (five levels). The default setting is [Auto]. VarioPrint 1105 17-33...
  • Page 690 It may not function appropriately depending upon the original even when selecting [Oblique Erase] or [Rectangle Erase]. In this case, select [Auto]. Touch [OK] to complete the setting and return to the Expert Adjustment Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-34 VarioPrint 1105...

  • Page 691: Size Setting

    Select the minimum size of the original to be detected in APS mode. Touch the desired key to highlight it on the right side of [Orig. Glass Small Size]. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-35...

  • Page 692: Annotation Setting

    Specify the character size and font of the item to be printed as annota- tion. (Character size: 8/ 10/ 12/ 14 point, Font: Gothic/ Ming) Combination method for items: Select whether to print the specified items in a line or in three lines. 17-36 VarioPrint 1105...
  • Page 693 Machine Manager Setting VarioPrint 1105 17-37...
  • Page 694 Machine Manager Setting 17-38 VarioPrint 1105...
  • Page 695 Machine Manager Setting VarioPrint 1105 17-39...
  • Page 696 Machine Manager Setting 17-40 VarioPrint 1105...
  • Page 697 The Input Type In Screen will be displayed. Enter the desired words to be printed, then touch [OK]. When [Date/Time] is selected: The Date/Time Setting Screen will be displayed. Select the desired style for each from 5 Date keys and 3 Time keys, then touch [OK]. VarioPrint 1105 17-41...
  • Page 698 Touch the registered title key on the Annotation Setting Screen, then touch [Delete]. A popup menu will be displayed to confirm that the selected register will be deleted. Touch [Yes] to delete, or [No] to cancel. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-42 VarioPrint 1105...

  • Page 699: Perfect Binding Setting

    Machine Manager Setting 17.2.9 09 Perfect Binding Setting 01 Useful Paper Weight Select Use this function to specify the paper weight available for each of body and cover when using Perfect Binder. VarioPrint 1105 17-43...
  • Page 700 “unsuitable” message displayed. Touch [OK] to complete the setting and return to the Perfect Binding Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-44 VarioPrint 1105...
  • Page 701 Machine Manager Setting 02 Paper Count Limit for Perfect Binding Use this function to specify the minimum and maximum paper count to be bound each for paper weight. VarioPrint 1105 17-45...
  • Page 702 Touch the desired minimum and maximum count limit keys for each paper weight to highlight it. Touch [OK] to complete the setting and return to the Perfect Binding Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-46 VarioPrint 1105...
  • Page 703 Machine Manager Setting 03 Stop Setting for P. B. Cover Unfit Length Use this function to stop/continue the current job when the cover width is not suitable for the body paper size and thickness. VarioPrint 1105 17-47...
  • Page 704 P. B. Cover Unfit Length]. Touch [Temporary Stop] or [Not Temporary Stop] to highlight it. Touch [OK] to complete the setting and return to the Perfect Binding Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-48 VarioPrint 1105...

  • Page 705: Manager/Machine Register

    Machine Manager Setting 17.3 02 Manager/Machine Register 17.3.1 01 Machine Manager Register Use this function to register the machine manager name and the extension number which are displayed on the left side of the Utility Menu Screen. VarioPrint 1105 17-49...
  • Page 706 Utility Menu Screen. The number which is entered will be displayed from the last digit, and it is shifted leftward as a next number is entered. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-50 VarioPrint 1105...

  • Page 707: Use Auth./Volume Track

    1,000 will be dis- tributed as user authentication. Details It is recommended to distribute authentication for both the user and the section, otherwise either party cannot be assigned authentication if it is distributed to only one party. VarioPrint 1105 17-51...
  • Page 708 Machine Manager Setting 17-52 VarioPrint 1105...
  • Page 709 Enter the number to distribute using the keypad or the arrow keys (,) and (+), then touch [OK]. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-53...
  • Page 710 The message “Copy limit reached” is displayed, and the machine stops its operation. When [Warning Only] is selected, the message “Copy limit reached” is dis- played as reaching the copy limit, and the next job can be continuously ex- ecuted. 17-54 VarioPrint 1105...
  • Page 711 Select [Immediately], [After Print], or [Warning Only] on the right side of [Limit Reached Stop Setting]. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-55...

  • Page 712: Volume Track

    Use this function to assign a number to each section, and set a section name, password and limit value to each number. The registered section management setting is listed on the screen. Select the section management setting from the list and change, reset or delete the setting. 17-56 VarioPrint 1105...
  • Page 713 Machine Manager Setting VarioPrint 1105 17-57...
  • Page 714 Machine Manager Setting 17-58 VarioPrint 1105...
  • Page 715 Touch [Section Name] to display the input screen. Enter the section name and touch [OK]. You may enter eight characters for the sec- tion name. For the details on entering texts in the input screen, see the appendix. VarioPrint 1105 17-59...
  • Page 716 Touch [All Count Reset] to display the Reset Confirmation popup screen. Touch any key to reset. Touch [Cancel] when not resetting. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-60 VarioPrint 1105...

  • Page 717: User Authentication Set

    Use this function to assign a number to each user, and set a user name, password and limit value to each number. The registered user setting is listed on the screen. Select the user setting from the list and change, reset or delete the setting. VarioPrint 1105 17-61...
  • Page 718 Machine Manager Setting 17-62 VarioPrint 1105...
  • Page 719 Machine Manager Setting VarioPrint 1105 17-63...
  • Page 720 Touch [Password] to display the input screen. Enter the password and touch [OK]. You may enter eight digits for the password. For the details on entering texts in the input screen, see the appendix. 17-64 VarioPrint 1105...
  • Page 721 To delete user settings: Touch [Next] or [Previous] to display the user name to be deleted and touch to highlight it. Touch [Delete] to display the Delete Confirmation popup screen. Touch [Yes] to delete, or touch [No] to cancel. VarioPrint 1105 17-65...
  • Page 722 Touch [All Count Reset] to display the Reset Confirmation popup screen. Touch any key to reset. Touch [Cancel] when not resetting. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-66 VarioPrint 1105...

  • Page 723: Non Register/Output Set

    Touch [On] to activate this function, or touch [Off] to deactivate this function. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-67...

  • Page 724: Network Setting

    Machine Manager Setting 17.5 04 Network Setting 17.5.1 01 Machine NIC Setting Control the NIC settings such as the IP address and line speed of the ma- chine. 17-68 VarioPrint 1105...
  • Page 725 Enter the IP address of the tandem machine working in tandem. Line Speed Setting Specify the line speed of the network. Choose from the options pro- vided. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-69...

  • Page 726: Controller Nic Setting

    Specify RAW port numbers and to be used or not. (Set between 1 - 65535.) TCP/IP Filter permission settings * Specify to use the permission settings or not, and the range in which to permit connections. 0.0.0.0 - 0.0.0.0 (0 - 255) 17-70 VarioPrint 1105...
  • Page 727 Bindery File Server Name Max. 47 characters combining Specify the bindery file server name. symbols and alphanumerics can be used. VarioPrint 1105 17-71...
  • Page 728 When a password is entered in the field, it must be the same as the one that is allocated to NetWare by using PCONSOLE or NWADMIN. The password entered here is stored in the print server setting memory. 17-72 VarioPrint 1105...
  • Page 729 Specify the place in which to install the printer. symbols and alphanumerics can be used. Max. 127 characters combining Printer Information Specify printer information. symbols and alphanumerics can be used. Printer URI Printer URI's are set. Max. 8 addresses VarioPrint 1105 17-73...
  • Page 730 FTP server. * 1: By selecting Not Use , access to VarioPrint 1105 (TWAIN, Visual Count) will be prohibited. It is possible to save Scan to HDD jobs, but clients can no longer obtain them. * 2: By selecting...
  • Page 731 Max. 15 characters combining symbols and alphanumerics can be used. * 1: Used when communicating with VarioPrint 1105 using applications. Specify the SMB printing setting, and to use Scan to SMB for transmission. For details, refer to “06 SMB” on page 17-98.
  • Page 732 Max. 31 characters combining Current Zone Specify the current zone. symbols and alphanumerics can be used. 17-76 VarioPrint 1105...
  • Page 733 DIGEST-MD5, be used. this field must be entered. Max. 250 characters combining Machine Manager Mail Address Specify the e-mail address of the Machine Manag- symbols and alphanumerics can be used. VarioPrint 1105 17-77...
  • Page 734 Setting options (highlighted: de- fault) 09 HDD Specify the duration for which Scan to HDD data are Not Delete/12 hours/ 1 day /2 days/ stored in the printer controller HDD before they are au- 3 days/7 days/30 days tomatically deleted. 17-78 VarioPrint 1105...
  • Page 735 Specify the duration used for POP before SMTP. 0 - 60 seconds ( Max. 63 characters combining SMTP Authentication User Name SMTP Authentication If Authentication Setting symbols and alphanumerics can set to , specify a user name. be used. VarioPrint 1105 17-79...
  • Page 736 On/Off Auto Check Interval Time Specify the interval by which to check incoming e- 1 - 60 minutes ( mail automatically. CSRC Communication Test Start * 1: The following authentication methods are supported: DIGEST-MD5, CRAM-MD5, LOGIN, PLAIN 17-80 VarioPrint 1105...
  • Page 737 Specify the Network Setting Clear setting. For details, refer to “14 Network Setting Clear” on page 17-121. Specific setting and Description Setting options (highlighted: de- fault) 14 Network Setting Clear Initialize Execute Restore the initial network settings specified at the time of shipment. VarioPrint 1105 17-81...
  • Page 738 Report Items 8 items Select the desired items. (More than one item can Service Call/ Jam/ Paper Supply/ be selected.) Toner Supply/ PM Call/ Staple Car- tridge Supply/ Finisher Tray Full/ Dispose of Trash Basket Clear All 17-82 VarioPrint 1105...
  • Page 739 Machine Manager Setting 01 TCP/IP Specify the settings for connecting a network printer and network scanner, and the settings for TCP/IP, RAW port numbers, IP Filter (permission/denial), and ping. VarioPrint 1105 17-83...
  • Page 740 Machine Manager Setting 17-84 VarioPrint 1105...
  • Page 741 Touch [DNS Host Name] to display the input screen. After entering in the field, touch [OK]. DNS Domain Name Touch [DNS Domain Name] to display the input screen. After enter- ing in the field, touch [OK]. Select [Enable] or [Disable]. VarioPrint 1105 17-85...
  • Page 742 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-86 VarioPrint 1105...
  • Page 743 Machine Manager Setting 02 NetWare Specify the settings for connecting network printer, and the NetWare set- tings. Where Novell NetWare is not used, make sure that [Not Use] is selected. VarioPrint 1105 17-87...
  • Page 744 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [02 NetWare]. For each item, select or enter a required value. Use [Previous] or [Next] as required. 17-88 VarioPrint 1105...
  • Page 745 Maximum 10 file server names can be entered. Queue Name Maximum 10 queue names can be entered. Touch [OK] to complete the settings and return to the Controller NIC Setting Menu Screen. Touch [Return] to specify other settings, or touch [Exit] to finish setting. VarioPrint 1105 17-89...
  • Page 746 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-90 VarioPrint 1105...
  • Page 747 Machine Manager Setting 03 IPP Specify the settings for connecting network printer and the IPP settings. VarioPrint 1105 17-91...
  • Page 748 Machine Manager Setting 17-92 VarioPrint 1105...
  • Page 749 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-93...
  • Page 750 Machine Manager Setting 04 FTP Specify to use Scan to HDD/Scan to FTP for transmission, the proxy server setting, and the passive function. 17-94 VarioPrint 1105...
  • Page 751 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-95...
  • Page 752 Machine Manager Setting 05 SNMP Specify the SNMP settings. 17-96 VarioPrint 1105...
  • Page 753 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-97...
  • Page 754 Machine Manager Setting 06 SMB Specify the SMB printing setting, and to use Scan to SMB for transmission. 17-98 VarioPrint 1105...
  • Page 755 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-99...
  • Page 756 Machine Manager Setting 07 AppleTalk Specify the settings for connecting network printer and the AppleTalk set- tings. 17-100 VarioPrint 1105...
  • Page 757 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-101...
  • Page 758 Machine Manager Setting 08 E-Mail Specify the settings for an e-mail send/receive, division for transmitted data and authentication, and save the template of titles and bodies frequently used. 17-102 VarioPrint 1105...
  • Page 759 Machine Manager Setting VarioPrint 1105 17-103...
  • Page 760 Machine Manager Setting 17-104 VarioPrint 1105...
  • Page 761 [OK]. Realm Touch [Realm] to display an input screen. After entering in the field, touch [OK]. Machine Manager Mail Address Touch [Machine Manager Mail Address] to display an input screen. After entering in the field, touch [OK]. VarioPrint 1105 17-105...
  • Page 762 Touch [Return] on the E-Mail Setting Menu Screen to specify other set- tings, or touch [Exit] to finish setting. After you have changed the settings, turn off the sub power, then turn off and on the main power. 17-106 VarioPrint 1105...
  • Page 763 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-107...
  • Page 764 Machine Manager Setting 09 HDD Specify the duration for which Scan to HDD data are stored in the printer controller HDD before they are automatically deleted. 17-108 VarioPrint 1105...
  • Page 765 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-109...
  • Page 766 Machine Manager Setting 10 Alert Mail Specify the settings for e-mail error notification. 17-110 VarioPrint 1105...
  • Page 767 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-111...
  • Page 768 Machine Manager Setting 11 CSRC CS Remote Care includes service tools, which you do not necessarily have to set. Contact your service representative for details. 17-112 VarioPrint 1105...
  • Page 769 Machine Manager Setting VarioPrint 1105 17-113...
  • Page 770 Touch [SMTP Server Address] to display an input screen. After en- tering in the field, touch [OK]. Port Number Touch [Port No.] to display an input screen. After entering in the field, touch [OK]. The range to be used is between 1 and 65535. 17-114 VarioPrint 1105...
  • Page 771 Password Touch [Password] to display an input screen. After entering in the field, touch [OK]. APOP Select [On] or [Off]. Port Number Touch [Port No.] to display an input screen. After entering in the field, touch [OK]. VarioPrint 1105 17-115...
  • Page 772 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-116 VarioPrint 1105...
  • Page 773 Machine Manager Setting 12 AP I/F Specify the settings for AP I/F. VarioPrint 1105 17-117...
  • Page 774 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-118 VarioPrint 1105...
  • Page 775 Machine Manager Setting 13 Web Connection Specify to use Web Connection. VarioPrint 1105 17-119...
  • Page 776 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-120 VarioPrint 1105...
  • Page 777 Machine Manager Setting 14 Network Setting Clear Recover the initial network settings specified at the time of shipment. VarioPrint 1105 17-121...
  • Page 778 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 17-122 VarioPrint 1105...
  • Page 779 Machine Manager Setting 15 SNMP Trap Specify the SNMP Trap settings. Details Before setting the SNMP Trap, specify to use SNMP in [04 Network Set- ting] - [02 Controller NIC Setting] - [05 SNMP]. VarioPrint 1105 17-123...
  • Page 780 Machine Manager Setting 17-124 VarioPrint 1105...
  • Page 781 Touch [SMTP Trap Trans Address] to display an input screen. After entering in the field, touch [OK]. SNMP Trap Trans Port No. Touch [SNMP Trap Trans Port No.] to display an input screen. After entering in the field, touch [OK]. VarioPrint 1105 17-125...
  • Page 782 The authentication failure transmission will be performed even if all report items are cleared. Touch [OK] to complete the settings and return to the Controller NIC Setting Menu Screen. Touch [Return] to specify other settings, or touch [Exit] to finish setting. 17-126 VarioPrint 1105...
  • Page 783 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. VarioPrint 1105 17-127...

  • Page 784: Copy/Printer Setting

    Set the machine to offset the copies/printouts of different jobs. Procedure Touch [05 Copy/Printer Setting] - [01 JOB Offset Operating]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-128 VarioPrint 1105...

  • Page 785: Continuation Print(Print)

    Set the machine to output multiple reserved print jobs in succession. Procedure Touch [05 Copy/Printer Setting] - [02 Continuation Print(Print)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-129...

  • Page 786: Page No. Position (Booklet)

    Booklet with Page Numbering in Stamp. Procedure Touch [05 Copy/Printer Setting] - [03 Page No. Position (Booklet)]. Touch [On Outside Page Print)] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-130 VarioPrint 1105...

  • Page 787: Fixing Prerotation Set

    Procedure Touch [05 Copy/Printer Setting - [04 Fixing Prerotation Set. Touch [Rotation On] or [Rotation Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-131...
  • Page 788 Machine Manager Setting Note If pressing [Start] after altering the paper type and weight when [Rotation On] is selected, the message “Machine is warming up.” Is displayed. Please wait until copying is enabled. 17-132 VarioPrint 1105...

  • Page 789: Image Auto Rotation

    APS, AMS or reduce is activated. Procedure Touch [05 Copy/Printer Setting] - [05 Image Auto Rotation]. Touch the desired key to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-133...

  • Page 790: Interruption Suspend

    Procedure Touch [05 Copy/Printer Setting] - [06 Interruption Suspend]. Touch [When Current Set Complete] or [Stop Immediately] to highlight Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-134 VarioPrint 1105...

  • Page 791: Copy Reserve Operation

    Touch [05 Copy/Printer Setting] - [07 Copy Reserve Operation]. Touch highlight [Enabled by Operation] or [Enabled by Set Original] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-135...
  • Page 792 Machine Manager Setting Details Copy Reserve by placing the original on the original glass When the Machine Status Screen is displayed, the screen can altered to the Copy Screen by placing the original in the ADF. 17-136 VarioPrint 1105...

  • Page 793: Scan Stop (Pull Out Tray)

    Select to stop scanning when pulling out the tray during scanning the origi- nal. Procedure Touch [05 Copy/Printer Setting] - [08 Scan Stop (pull out tray)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-137...

  • Page 794: Continuation Print (Copy)

    Select the machine to output multiple reserve jobs in succession. Procedure Touch [05 Copy/Printer Setting] - [09 Continuation Print (Copy)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-138 VarioPrint 1105...

  • Page 795: Original Glass Sdf

    Procedure Touch [05 Copy/Printer Setting] - [10 Original Glass SDF]. Touch [Face Up] or [Face Down] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-139...

  • Page 796: Sdf Auto Setting

    ADF in the Memory Scan mode, or feed it by pressing [Start]. Procedure Touch [05 Copy/Printer Setting] - [11 SDF Auto Setting]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 17-140 VarioPrint 1105...

  • Page 797: System Connection

    The monitored information will be useful for maintenance. Procedure Touch [06 System Connection] - [01 User Call]. Touch [Start]. Touch [Return] to restore the Machine Manager Setting Menu. VarioPrint 1105 17-141...

  • Page 798: Security Setting

    Machine Manager Setting 17.8 07 Security Setting 17.8.1 01 Machine Manager Password Set the new machine manager password. 17-142 VarioPrint 1105...
  • Page 799 Touch [07 Security Setting] - [01 Machine Manager Password]. Touch [Input Manager Password] to display the Input Manager Pass- word Screen. Enter the new password. Touch [OK]. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. VarioPrint 1105 17-143...

  • Page 800: Hdd Management Setting

    The user can create a folder or a box when saving images in a personal, pub- lic or secure folder. The machine manager can refer to the name, password, number or creation time of the folder created by the user, and delete the fold- er or box if necessary. 17-144 VarioPrint 1105...
  • Page 801 Machine Manager Setting VarioPrint 1105 17-145...
  • Page 802 Machine Manager Setting 17-146 VarioPrint 1105...
  • Page 803 Touch [Delete] to display the Delete Confirmation popup screen. Touch [Yes] to delete, or touch [No] to suspend deleting. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-147...
  • Page 804 02 HDD Data Auto Delete Period Setting Specify the period of time (12 hours to 30 days) to keep data so that it will be deleted automatically when specified period has passed. The initial setting is Not Delete. 17-148 VarioPrint 1105...
  • Page 805 Touch [Not Delete] to highlight it when not setting the automatically de- leting period. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-149...
  • Page 806 Machine Manager Setting 03 Change HDD Lock Password Change the HDD lock password. Note The HDD Lock Password cannot be changed unless the Security Strengthen mode is set to On. 17-150 VarioPrint 1105...
  • Page 807 [OK]. Touch [Check Input] to enter the same new password, then touch [OK]. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-151...

  • Page 808: Security Strengthen Mode

    Set the Security Strengthen mode On/Off. Note In order to set the Security Strengthen mode to On, it is required by your service representative to set a CE password and a machine manager password to your machine. 17-152 VarioPrint 1105...
  • Page 809 Touch [Yes] to complete the setting. The machine power will be turned off, then on. Touch [No] to cancel the setting. Touch [Cancel] at the lower right side of the screen to restore the Machine Manager Setting Menu Screen. VarioPrint 1105 17-153...

  • Page 810: Scanner Address Register

    Change or delete the destination of the scanned image. The following four addresses can be registered: - E-Mail (mail address) - HDD (box No.) - FTP (FTP server address) - SMB The Group of registered E-Mail addresses can be deleted. 17-154 VarioPrint 1105...
  • Page 811 Machine Manager Setting VarioPrint 1105 17-155...
  • Page 812 Select the changing item from [Address], [Name] and [Reference Name], and change it in the input screen. Set Daily Use by touching [On] or [Off]. Touch [OK]. To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. 17-156 VarioPrint 1105...
  • Page 813 Set Daily Use by touching [On] or [Off]. Touch [OK]. To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. To delete the unregistered box, touch [Non Reg. Box.] Delete as fol- lowing the step (5) above. VarioPrint 1105 17-157...
  • Page 814 Machine Manager Setting 17-158 VarioPrint 1105...
  • Page 815 Address], [File Path], [Login Name] and [Password] ,and change it in the input screen. Set Daily Use by touching [On] or [Off]. Touch [OK]. To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. VarioPrint 1105 17-159...
  • Page 816 Address], [File Path], [Login Name] and [Password], and change it in the input screen. Set Daily Use by touching [On] or [Off]. Touch [OK]. To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. 17-160 VarioPrint 1105...
  • Page 817 Display the Register Name of the destination address using the search key or the arrow keys (,) and (+). Touch the Register Name to highlight it. Touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. VarioPrint 1105 17-161...
  • Page 818 Machine Manager Setting Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-162 VarioPrint 1105...

  • Page 819: Browser Control Setting

    Browser Control Setting POD Administrator...

  • Page 821: Web Utilities

    Enter the administrator password previously specified on the machine. 00000000 is initially applied. Once entered, the user name and password are not necessary to be re- entered unless the web browser is restarted. Details To clear the text boxes, click on [Reset]. VarioPrint 1105 18-3...

  • Page 822: Web Utilities

    Enter the URL (http:// [IP address or host name of the machine]), then click on [OK]. The Main Page of the Web Utilities will be displayed. Details The Web Utilities window is subject to change without notice. 18-4 VarioPrint 1105...

  • Page 823: Setting Account Track Data

    An error message may be displayed when the data entry has not been completed due to the machine operation in progress. Please click on [Ap- ply] while the machine is in an idle state. VarioPrint 1105 18-5...

  • Page 824: Adding Account Track

    The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed. 18-6 VarioPrint 1105...
  • Page 825 Click on [Volume Track data add]. The Volume Track Data Add window will be displayed. Enter a new account track data. Section Name (Account Name) : 8 characters max. Password: 8 digits max. Limit: 99,999,999 copies max. VarioPrint 1105 18-7...
  • Page 826 The new account track data will be transmitted to the machine imme- diately so that is valid for the user operations. Click on [Back] to return to the Volume Track Setting menu or any menu item to jump to the desired window. 18-8 VarioPrint 1105...

  • Page 827: Editing Account Track Data

    The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed. VarioPrint 1105 18-9...
  • Page 828 Browser Control Setting Click on [Volume Track setting]. The Volume Track Setting menu will be displayed. Click on [Volume Track data list]. The Volume Track List will be displayed. 18-10 VarioPrint 1105...
  • Page 829 For details in entering procedure, refer to “Enter a new account track data.” on page 18-7. Click on [Apply]. The edited content will be displayed in the window. The edited data will be transmitted to the machine immediately so that is valid for the user operations. VarioPrint 1105 18-11...
  • Page 830 Browser Control Setting Click on [Back] to return to the Account Track Data List window. 18-12 VarioPrint 1105...
  • Page 831 Click on the radio button (a white circle) heading the "Copy/Printer Count reset." or "Scan Count reset." Click on [Apply]. The Counter Reset Confirmation window will be displayed. Click on [Apply] to immediately reset the counters to zero. The message "Setting was changed" will be displayed. VarioPrint 1105 18-13...
  • Page 832 If all the data are to be cleared, click on [SelectAll]. Click on the radio button (a white circle) heading the "Delete (Ex- cept for Another user count)". Click on [Apply]. The Delete Confirmation window will be displayed. 18-14 VarioPrint 1105...
  • Page 833 Click on [Apply] to immediately delete the data. The message "Setting was deleted" will be displayed. Click on [Back] to return to the Volume Track Data List or any menu item to jump to the desired window. VarioPrint 1105 18-15...
  • Page 834 Browser Control Setting Save Counter. Click on [Save this table as a file]. Click on [Save]. 18-16 VarioPrint 1105...
  • Page 835 The data cannot be saved while the machine is in operation. In this case, try this procedure again after the machine starts idling. Click on [Back] in the browser window to return to the Account Track Data List for starting over. VarioPrint 1105 18-17...
  • Page 836 Browser Control Setting Example: Account track data list stored as a file The "Another user count" will be stored by the name of "UNKNOWN" in the last line. 18-18 VarioPrint 1105...

  • Page 837: Setting Scan Transmission Function

    - The HDD Box No. will be registered as a 9-digit number. - For example, entering [1] will be registered as [000000001]. Procedure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialog box will be displayed. VarioPrint 1105 18-19...
  • Page 838 Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Administrator Setting menu will be displayed. Click on [Scan transmission setting]. The Scan Transmission Setting window will be displayed. 18-20 VarioPrint 1105...
  • Page 839 Browser Control Setting Register the E-Mail, HDD, FTP, and SMB, as required. VarioPrint 1105 18-21...
  • Page 840 Click on [Back] to return to the Scan Transmission Setting window. Display the Entry List. Click on [Entry List] of the desired item under the entry box to dis- play the Entry List. Click on [Back] to return to the Scan Transmission Setting window. 18-22 VarioPrint 1105...
  • Page 841 Click on the entry name to be changed. The window for changing the selected item will be displayed. Change the contents as desired, then click on [Registration]. The registered content will be displayed. Click on [Back] to return to the Scan Transmission Setting window. VarioPrint 1105 18-23...
  • Page 842 The window for deleting the selected item will be displayed. Confirm the registered name to be deleted, then click on [Yes]. Click on [Back] to return to the Entry List window. Click on [Back] to return to the Scan Transmission Setting window. 18-24 VarioPrint 1105...

  • Page 843: Transmitting Machine Setting File

    (account track data) ip_email.txt (E-mail data of Scan Transmission Setting data) ip_hdd.txt (HDD data of Scan Transmission Setting data) ip_ftp.txt (FTP data of Scan Transmission Setting data) ip_smb.txt (SMB data of Scan Transmission Setting data) VarioPrint 1105 18-25...
  • Page 844 The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed. 18-26 VarioPrint 1105...
  • Page 845 Browser Control Setting Click on [Setting data Import/Export]. The Setting Data Import/Export window will be displayed. Export the machine setting file. Select the desired file type from the pull-down menu, then click on [Export..] VarioPrint 1105 18-27...
  • Page 846 The File Download dialog box will be displayed. Click on [OK]. In the dialog box, designate the folder for saving the machine set- ting file, then click on [Save]. A dialog box will be displayed when the saving operation is completed. Click on [Close]. 18-28 VarioPrint 1105...
  • Page 847 See page 17-54 for details. Import the machine setting file. Click on [Browse...] to designate the machine setting file to be im- ported, then click on [Import]. The result message will be displayed when the registration is complet- VarioPrint 1105 18-29...
  • Page 848 Confirm that the data is the machine setting file. Check if the file size exceeds 100,000 bytes. The data cannot be registered Check if inappropriate description is made in the machine setting file. Check if the file entries are already over the limit. 18-30 VarioPrint 1105...
  • Page 849 - Begin the file with #IP_EMAIL. - A line should include NAME, ADDRESS, REFERENCE, and DAILY, sepa- rated by a tab. - NAME should be 24 bytes or less. - ADDRESS should be 250 bytes or less. VarioPrint 1105 18-31...
  • Page 850 - LOGINNAME should be 47 bytes or less. - PASSWORD should be 14 bytes or less. - REFERENCE should be 24 bytes or less. - Mark DAILY USE with "1" or DAILY NOT USE with "0" in each column. 18-32 VarioPrint 1105...

  • Page 851: Box Edit

    Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. VarioPrint 1105 18-33...
  • Page 852 Selected user name will be marked with an asterisk (*) at its head. The user name marked with “L” is locked and cannot be selected. Details The number in parentheses on the right side of the title “User Name” in- dicates the count of registered users. 18-34 VarioPrint 1105...
  • Page 853 Clicking on the desired box name (as in step 6), a text box will appear at the top of the Box Name area. Enter the new name within 20 alphanumeric characters. Click on [Change] on the right side of the text box. The new name will be registered and enabled immediately. VarioPrint 1105 18-35...
  • Page 854 The number in parentheses on the right side of the title “File Name” indi- cates the count of registered files. The file name will be listed in datal order of save. Only the top page of the file can be displayed as thumbnail. You cannot specify any other page. 18-36 VarioPrint 1105...
  • Page 855 The new name will be registered and enabled immediately. Details When changing the file name, a message may inform you that the entered name has been already used. In this case, reenter a new name or consult your service representative. VarioPrint 1105 18-37...

  • Page 856: Web Connection

    Web Connection is a device control utility program provided by the HTTP server built into the image controller of the Océ VarioPrint 1105. This utility can be used with a Web browser to display the status of the Océ VarioPrint 1105.
  • Page 857 - Netscape Navigator Select [Preferences] under [Edit]. Click [Advanced] and then click [Cache]. Check [Every time I view the page] under [Compare the page in the cache to the page on the network:]. VarioPrint 1105 18-39...

  • Page 858: Access

    When the IP address of the image controller is 192.168.0.10: http://192.168.0.10 The Web Connection screen appears. Operation Web Connection operation is identical to Internet Web pages. You can click a link on the Web page to jump to the link destination. 18-40 VarioPrint 1105...

  • Page 859: Screen Configuration

    Sets the display language for the browser. [Auto] indicates the same lan- guage as the operating system being used and the other options indicate the same language as displayed on the control panel. Tabs Select the categories of items to be displayed. System VarioPrint 1105 18-41...
  • Page 860 For the details of each menu, see the following sections. Information and Setting Details Displays the details of the selected menu. Help If an online manual URL has been set, the online manual will appear. For details, refer to “Online Assistance” on page 18-47. 18-42 VarioPrint 1105...

  • Page 861: Logging In Using Administrator Mode

    [System] area of Administrator Mode. For details, refer to “Administrator Mode” on page 18-45. You can also change it using the touch panel of the main body. Contact your service store for details. VarioPrint 1105 18-43...
  • Page 862 Browser Control Setting In order to ensure the security against data used in Administrator Mode, set SSL. SSL can be set on the [Network] tab of Administrator Mode. For details, “SSL/TLS” on page 18-78. 18-44 VarioPrint 1105...

  • Page 863: Administrator Mode

    The password is displayed in asterisks (*). Retype New Password: Retype the new password as entered above for confirmation. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. VarioPrint 1105 18-45...

  • Page 864: Device Information

    Click [Device Information] on the [System] tab of the User Mode Screen to display this screen. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-46 VarioPrint 1105...

  • Page 865: Rom Version

    You can use the screen to enter information concerning product support. Click [Online Assistance] on the [System] tab of the User Mode Screen to dis- play information entered on this screen. Contact Name: Enter the support contact for the product. Maximum 63 alphanumeric characters can be used. VarioPrint 1105 18-47...
  • Page 866 Click the button to clear the settings that were entered or selected. Note If the online manual URLs are not used, users must save the online help file on their PCs. In this case, the [Help] button will not function. 18-48 VarioPrint 1105...

  • Page 867: Import/Export

    (The file format must be con- firmed.) [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. VarioPrint 1105 18-49...

  • Page 868: Maintenance

    Click the [Clear] button to display the confirmation screen. Click [OK] to clear. Details It may take few minutes for clearing the network settings. After clearing the settings is completed, you can access the network again. When you use the network, restart the Web browser. 18-50 VarioPrint 1105...
  • Page 869 Click the [Reset] button to restart the network only to enable new pa- rameters. Details It may take few minutes for resetting the network. After resetting the net- work, you can access the network again. When you use the network, re- start the Web browser. VarioPrint 1105 18-51...

  • Page 870: E-Mail Alert

    Enter the e-mail address to which to send alert mail. Maximum 250 char- acters can be used. Alert: Choose notification items. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. 18-52 VarioPrint 1105...

  • Page 871: Administrator Mode - Print Tab

    Parallel Timeout: Set parallel port timeout (10-300 seconds). Network Timeout: Set receive network timeout (10-300 seconds). [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-53...

  • Page 872: Port Settings

    RAW port number List the RAW port numbers 1 to 6 that are set in [TCP/IP] on the [Network] tab. Status Show enable or disable of each RAW port. 18-54 VarioPrint 1105...

  • Page 873: Default Settings

    Paper Size, Orientation, Resolution, Spool Setting, Banner Option, Banner Page Tray, Convert Paper Size, 1 Page/Sheet, Booklet, Print Po- sition. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-55...
  • Page 874 These settings also appear if you select Controller Settings on the touch pan- el's Device Status screen - 02 Printer Settings - 03 PCL Settings. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-56 VarioPrint 1105...
  • Page 875 Select whether or not to print the error report when an error occurs while rasterizing PostScript data. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-57...
  • Page 876 Device Status screen - 02 Printer Settings - 04 TIFF Settings. Enter for individual items. Auto Paper Select, Image Position. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-58 VarioPrint 1105...

  • Page 877: Administrator Mode - Scan Tab

    Click the button to apply the new settings. [Edit] button: Click the button to open the editing screen. [Clear] button: Click the button to set it to the default before changes were applied. [Delete] button: Click the button to delete a selected subject. VarioPrint 1105 18-59...
  • Page 878 Enter the subject on the Subject Registration screen, and click the [Ap- ply] button. You can use maximum 64 characters. Click the [OK] button on the Completed screen. It will take you back to the subject list screen. 18-60 VarioPrint 1105...
  • Page 879 Check the number of the subject to delete, and click the [Delete] but- ton. Click the [OK] button on the Subject Deletion screen. Click the [OK] button on the Completed screen. It will take you back to the subject list screen. VarioPrint 1105 18-61...

  • Page 880: Body Registration

    Click the button to apply the new settings. [Edit] button: Click the button to open the editing screen. [Clear] button: Click the button to set it to the default before changes were applied. [Delete] button: Click the button to delete a selected body text. 18-62 VarioPrint 1105...
  • Page 881 Enter the text on the Body Registration screen, and click the [Apply] button. You can use maximum 255 characters. Click the [OK] button on the Completed screen. It will take you back to the body text list screen. VarioPrint 1105 18-63...
  • Page 882 Check the number of the body text to delete, and click the [Delete] but- ton. Click the [OK] button on the Body Deletion screen. Click the [OK] button on the Completed screen. It will take you back to the body text list screen. 18-64 VarioPrint 1105...

  • Page 883: Administrator Mode - Network Tab

    You can also use the screen to enable or disable access permission, access refusal, and their ranges of TCP/IP filtering. When the same range is specified for the accept setting and the refuse setting, the refuse setting has priority over the accept setting. VarioPrint 1105 18-65...
  • Page 884 Enter for individual items. Access Permission Addresses and their ranges, Access Refusal Ad- dresses and their ranges. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were selected. 18-66 VarioPrint 1105...

  • Page 885: Netware

    - Enter for individual items. NetWare Print Frame Type Mode Pserver Print Server Name Print Server Password Print Queue Scan Rate Bindery/NDS Bindery Preferred File Server Preferred NDS Context Name Preferred NDS Tree Name Nprinter/Rprinter Printer Name Printer Number VarioPrint 1105 18-67...
  • Page 886 [Clear] button: Click the button to clear the settings that were selected. NetWare Status This screen appears when you click [NetWare Status] under the [NetWare] menu on the [Network] tab. This screen is used to confirm NetWare status. 18-68 VarioPrint 1105...

  • Page 887: Ipp

    Enter for individual items. IPP Print, Printer Name, Printer Location, Printer Information, Operations Supported. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-69...

  • Page 888: Ftp

    Enter for individual items. FTP Client, Proxy Server Address, Proxy Server Port Number, FTP Server Timeout, Port Number. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-70 VarioPrint 1105...
  • Page 889 [Server] under the [FTP] menu. The screen is used to enter and confirm var- ious settings concerning the FTP server. FTP Server: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-71...

  • Page 890: Snmp

    This screen appears when you click [SNMP] on the [Network] tab. The screen is used to enter and confirm settings concerning SNMP. SNMP: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-72 VarioPrint 1105...

  • Page 891: Smb

    [Scan] under the [SMB] menu. The screen is used to enter and confirm set- tings concerning SMB scan. SMB Scan: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-73...
  • Page 892 Enter for individual items. SMB Print, NetBIOS Name, Print Service Name, Work Group. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-74 VarioPrint 1105...

  • Page 893: Apple Talk

    When Apple Talk is set to disable, you still need to set parameters. Make sure to enter parameters correctly. Enter for individual items. Apple Talk, Printer Name, Zone Name. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-75...

  • Page 894: E-Mail

    Enter for individual items. Receive, Receiving Server Address, User Name, Password, APOP Au- thentication, Connection Timeout, Port Number. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-76 VarioPrint 1105...
  • Page 895 Mail Size, SMTP Server Capacity, Administrator Mail Address, Authenti- cation, POP Before SMTP, SMTP Authentication, User Name, Password, Realm, Binary Division, Division Size. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-77...

  • Page 896: Ssl/Tls

    This screen appears when you click [SSL/TLS] on the [Network] tab. The screen is used to enter and confirm settings concerning SSL/TLS. You can configure them separately depending whether or not certificates are in- stalled. Creating a self-signed certificate 18-78 VarioPrint 1105...
  • Page 897 Following the screen indicating that the certificate is being created, an- other screen appears, saying, "The certificate has been created. SSL/ TLS can now be used." Click [OK]. It will take you back to the SSL/TLS Information screen of the self- signed certificate. VarioPrint 1105 18-79...
  • Page 898 Browser Control Setting Requesting a certificate to install 18-80 VarioPrint 1105...
  • Page 899 Browser Control Setting VarioPrint 1105 18-81...
  • Page 900 Check [Install a Certificate], and click [Next]. The certificate installation screen appears. Enter the data of the certificate that you requested. Click [Next]. The Encryption Strength Setting and the Mode using SSL/TLS screen appears. Enter discretionary settings, and click [Create]. Creation results appear. 18-82 VarioPrint 1105...
  • Page 901 Browser Control Setting Click [OK]. It will take you back to the SSL/TLS Information screen. VarioPrint 1105 18-83...
  • Page 902 Browser Control Setting Requesting a certificate to switch information 18-84 VarioPrint 1105...
  • Page 903 Browser Control Setting VarioPrint 1105 18-85...
  • Page 904 Enter the data of the certificate that you requested. Click [Next]. The Encryption Strength Setting and the Mode using SSL/TLS screen appears. Enter discretionary settings, and click [Create]. Creation results appear. Click [OK]. It will take you back to the SSL/TLS Information screen. 18-86 VarioPrint 1105...
  • Page 905 Browser Control Setting Changing mode settings Changing encryption strength setting VarioPrint 1105 18-87...
  • Page 906 The SSL/TLS Setting screen appears. Check [Set a Encryption Strength], and click [Next]. The Encryption Strength Setting screen appears. Select a discretionary value. Click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 18-88 VarioPrint 1105...
  • Page 907 Browser Control Setting Changing mode using SSL/TLS VarioPrint 1105 18-89...
  • Page 908 The SSL/TLS Setting screen appears. Check [Mode using SSL/TLS], and click [Next]. The Mode using SSL/TLS screen appears. Select a discretionary mode, and click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 18-90 VarioPrint 1105...
  • Page 909 Browser Control Setting Removing a certificate VarioPrint 1105 18-91...
  • Page 910 The SSL/TLS Setting screen appears. Check [Remove a Certificate], and click [Next]. The Remove a Certificate screen appears. Click [Remove]. The removal confirmation screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 18-92 VarioPrint 1105...

  • Page 911: Authentication

    The screen is used to enter and confirm settings concerning logout time. Enter for individual items. Admin Logout Time, User Logout Time. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. VarioPrint 1105 18-93...
  • Page 912 AP I/F. Enter for individual items. Port Number, Use SSL/TLS, Port Number (SSL/TLS). [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 18-94 VarioPrint 1105...

  • Page 913: Security

    Security Security...
  • Page 915 - Controller control program (IP Controller Control P1) version: 10-0000, 11-0000, 20-0000 About the ROM version display function: The VarioPrint 1105 Control Software (Image control program / Controller control program) version mentioned above can be confirmed by using the service representative (CE) service mode ROM version display function.

  • Page 916: Security Functions

    Security 19.1 Security Functions The VarioPrint 1105 device has two security modes. Normal mode Use this mode if the machine is used by a single person and there is a low possibility of illicit access and operations. This is the default mode when shipped from the factory.

  • Page 917: Environments In Which Security Strengthen Mode Is Recommended

    (CE). Clearly state in the service contract that the service rep- resentative will not engage in any fraudulent actions. Secure LAN We recommend that you use an apparatus such as WEP code (802.11x) to prevent tapping during communication when setting up a local area network. VarioPrint 1105 19-5...

  • Page 918: Security Strengthen Mode

    Box. Machine NIC setting - When the Security Strengthen mode is ON, the Machine NIC cannot be used. External access prohibited - No access is allowed over telephone lines other than CS Remote Care. 19-6 VarioPrint 1105...

  • Page 919: Data Protected By Security Strengthen Mode

    If Security Strengthen mode is OFF, data can potentially be accessed, so be careful. If data is accessed in Security Strengthen mode, the machine manager may not notice until he/she analyzes the audit log. Be careful when the machine manager is absent for a long time. VarioPrint 1105 19-7...

  • Page 920: Protect And Delete Data After Use

    - Data in the Box will be overwritten when a delete order is issued. - If data is sent externally, it will be overwritten when the transmission is complete. - If the machine manager issues a delete order for each Box, it will be over- written. 19-8 VarioPrint 1105...

  • Page 921: User Authentication In Security Strengthen Mode

    HDD, all authentication operations with password will be saved in an au- dit log. Initially, the user authentication is not available on the machine. To acti- vate this function, the distribution number for each section should be changed. VarioPrint 1105 19-9...

  • Page 922: To Register A New User

    Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch panel keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. 19-10 VarioPrint 1105...
  • Page 923 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. VarioPrint 1105 19-11...
  • Page 924 Security Touch [Add] to display the User Registration Screen. Touch [User No.], [User Name], [Password], or [Belong Section] to dis- play each subsequent screen, then make the desired setting. 19-12 VarioPrint 1105...
  • Page 925 Touch [OK] to return to the User Registration Screen. To enter the User Name: Touch [User Name] on the User Registration Screen. Enter the desired user name from the touch panel keypad. Touch [OK] to return to the User Registration Screen. VarioPrint 1105 19-13...
  • Page 926 Touch the desired section key to highlight it. Touch [OK] to return to the User Registration Screen. Touch [OK]. When settings are completed, touch [OK] on the User Registration Screen. The User Authentication Setting Screen will be restored. 19-14 VarioPrint 1105...

  • Page 927: To Change User Data

    Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch panel keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. VarioPrint 1105 19-15...
  • Page 928 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. 19-16 VarioPrint 1105...
  • Page 929 Security Touch the user name to be changed, then touch [Change]. The Change Registered User Screen will be displayed. Touch [User Name], [Password], or [Belong Section] to display each subsequent screen, then make the desired setting change. VarioPrint 1105 19-17...
  • Page 930 To change the Password: Touch [Password] on the User Registration Screen. Enter the desired password from the touch panel keypad. Touch [OK] to return to the Change Registered User Screen. Note The current password cannot be used again. 19-18 VarioPrint 1105...
  • Page 931 Touch the desired section key to highlight it. Touch [OK] to return to the Change Registered User Screen. Touch [OK]. When settings are completed, touch [OK] on the Change Registered User Screen. The User Authentication Setting Screen will be restored. VarioPrint 1105 19-19...

  • Page 932: To Delete A User

    Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch screen keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. 19-20 VarioPrint 1105...
  • Page 933 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. VarioPrint 1105 19-21...
  • Page 934 Touch [Delete]. The popup menu will be displayed to confirm that the selected user will be deleted. Touch [Yes] to delete the selected user name, password, and also the Personal Folder that belongs to the deleted user. 19-22 VarioPrint 1105...

  • Page 935: To Change Password By User

    We recommend that a user himself/herself changes the password assigned by the machine manager for security. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [01 System Setting]. The System Setting Menu Screen will be displayed. VarioPrint 1105 19-23...
  • Page 936 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. When user authentication is completed successfully, the Change User Password Screen will be displayed. 19-24 VarioPrint 1105...
  • Page 937 The System Setting Menu Screen will be restored. Details If password setup doesn’t proceed successfully, the information will be saved in the audit log. The password currently used cannot be entered as a new password. Touch [Exit]. The Copy Screen will be restored. VarioPrint 1105 19-25...

  • Page 938: Hdd Store Function In Security Strengthen Mode

    On the User Authentication Screen, touch [User Name] and [Password] to enter your user name and password. Touch [User Name] to display the Input User Name Screen. Enter the user name, then touch [OK] to return to the User Authentica- tion Screen. 19-26 VarioPrint 1105...
  • Page 939 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. VarioPrint 1105 19-27...
  • Page 940 Security Touch [OK]. The Copy Screen will be displayed. Touch [Output Application] on the Copy Screen. Touch [HDD Store] on the Output Application Screen. The HDD Box List Screen will be displayed. 19-28 VarioPrint 1105...
  • Page 941 Security Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. Touch [Store]. The Input File Name Screen will be displayed. VarioPrint 1105 19-29...
  • Page 942 Box. When operation is completed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operation without entering a user name and password. 19-30 VarioPrint 1105...

  • Page 943: Store Scanned Data In A Box

    Enter the user name, then touch [OK] to return to the User Authentica- tion Screen. Touch [Password] to display the Input Password Screen. Enter the password, then touch [OK] to return to the User Authentica- tion Screen. VarioPrint 1105 19-31...
  • Page 944 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [OK]. The Copy Screen will be displayed. 19-32 VarioPrint 1105...
  • Page 945 If you touch [STORE], then touch [Scanner to HDD]. The HDD Box List Screen will be displayed. Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. VarioPrint 1105 19-33...
  • Page 946 Security Touch [Store], then enter. Enter the file name, then touch [OK]. The Scanner Basic Screen will be displayed. 19-34 VarioPrint 1105...
  • Page 947 Make the desired setting, then press [Start] on the control panel to scan and store the image data. When operation is competed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operations without entering a user name and password. VarioPrint 1105 19-35...

  • Page 948: Recall/Delete Data In A Box

    On the User Authentication Screen, touch [User Name] and {Password] to enter your user name and password. Touch [User Name] to display the Input User Name Screen. Enter the user name, then touch [OK] to return to the User Authen- tication Screen. 19-36 VarioPrint 1105...
  • Page 949 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. VarioPrint 1105 19-37...
  • Page 950 Touch [OK]. The Copy Screen will be displayed. Touch [RECALL]. The HDD Box List Screen will be displayed. Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. 19-38 VarioPrint 1105...
  • Page 951 [Auto Output], as desired, and then touch [OK]. Specify the output page. Touch [Output Page.] To output one desired page only, [Touch Page Select], press the control panel keypad, then touch [OK]. To output all pages, touch [All Pages], then touch [OK]. VarioPrint 1105 19-39...
  • Page 952 The selected file will be deleted, and return to the File Selection Screen. When operation is completed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operation without entering a user name and password. 19-40 VarioPrint 1105...

  • Page 953: Output Data In The Secure Box

    On the User Authentication Screen, touch [User Name] and [Password] to enter your user name and password. Touch [User Name] to display the Input User Name Screen. Enter the user name, then touch [OK] to return to the User Authen- tication Screen. VarioPrint 1105 19-41...
  • Page 954 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. 19-42 VarioPrint 1105...
  • Page 955 Security Touch [OK]. The Copy Screen will be displayed. Touch [RECALL]. The HDD Box List Screen will be displayed. VarioPrint 1105 19-43...
  • Page 956 Touch [Secure Folder] to display the Secure Box List Screen. Select the desired secure box. Enter the secure password setup in secure printing. Touch [OK]. The Secure File List Screen will be displayed. Select the desired secure file. 19-44 VarioPrint 1105...
  • Page 957 Touch [Wait Output], [Proof Output], or [Auto Output] as desired. When operation is completed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operation without entering a user name and password. VarioPrint 1105 19-45...

  • Page 958: Machine Manager Security Functions

    The following is an explanation of how to turn Security Strengthen mode ON/ OFF. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. 19-46 VarioPrint 1105...
  • Page 959 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. VarioPrint 1105 19-47...
  • Page 960 Security Touch [07 Security Setting]. Touch [03 Security Strengthen Mode]. 19-48 VarioPrint 1105...
  • Page 961 If you want to turn Security Strengthen mode ON, touch [On] to high- light it. If you want to turn it OFF, touch [Off] to highlight it. Touch [OK]. The Restart Confirmation popup screen will appear. Touch [Yes]. The machine will restart and the new setting will be activated. VarioPrint 1105 19-49...

  • Page 962: Hdd Lock Password

    ON. When turned OFF, the message “Please set Security Strengthen mode” will be displayed. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. 19-50 VarioPrint 1105...
  • Page 963 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. VarioPrint 1105 19-51...
  • Page 964 Security Touch [07 Security Setting]. Touch [02 HDD Management Setting]. The HDD Management Setting Menu Screen will be displayed. 19-52 VarioPrint 1105...
  • Page 965 Details The main body serial number will be printed at the upper right corner of the audit log. For details, see the next section “Print audit log” and p. 47 for the sample log. VarioPrint 1105 19-53...
  • Page 966 The current password cannot be used again as a new password. Touch [OK] to return to the previous screen. Touch [Check Input] to re-enter the same password as above. Touch [OK] to return to the previous screen. Touch [OK]. 19-54 VarioPrint 1105...

  • Page 967: Print Audit Log

    All the audit log data can be output as follows. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. VarioPrint 1105 19-55...
  • Page 968 OK key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [01 System Setting]. 19-56 VarioPrint 1105...
  • Page 969 The Management List Print Screen will be displayed. Touch [Audit Log Report], then touch [COPY]. Press [Start] on the control panel. Details To stop printing, press [Stop] on the control panel, then touch [Cancel] on the confirmation popup screen. VarioPrint 1105 19-57...

  • Page 970: Analyze Audit Log

    The machine is supposed to store up 750 logs per month. If more than 750 logs are assumed to be stored in a month, carry out the analysis in a shorter period before the unanalyzed logs reach that number. 19-58 VarioPrint 1105...
  • Page 971 Check details of operation that action indicates in the following table. result: Result of an operation. For password authentication, success or failure will be indicated as OK and NG. For operations without password authentication, all log entries will be in- dicated as OK. VarioPrint 1105 19-59...

  • Page 972: Table Of Items Saved In Audit Log

    Password authentication for Secure user ID OK/NG secure printing / Unregistered user ID Access to secure print file Secure user ID Delete secure print file Secure user ID Change HDD lock pass- Machine Manag- word er ID 19-60 VarioPrint 1105...
  • Page 973 - Even if password authentication succeeded (OK), it shows whether a le- gitimate user created the action. You need to check carefully when suc- cessful authentication occurs after series of failures especially during times other than normal operating hours. VarioPrint 1105 19-61...
  • Page 974 - If you cannot find documents that should be in a box or if you find a doc- ument with changed content, unauthorized actions may have occurred. Similar countermeasures are needed. 19-62 VarioPrint 1105...

  • Page 975: Troubleshooting

    Troubleshooting...

  • Page 977: If "Please Call Service" Message Is Displayed

    In this case, you don’t have to make a call for the report code, because your machine has been monitored automatically by your service repre- sentative. After calling for service using the Utility setting, be sure to turn OFF the power immediately, then unplug the machine as described here. VarioPrint 1105 20-3...
  • Page 978 A copying job can continue without using the troubled portion of the ma- chine (ex. Tray 2). 7 CAUTION EVEN IF THE COPYING JOB CAN BE CONTINUED WITH THE ABOVE OPERATION, BE SURE TO CONTACT YOUR SERVICE REPRESENT- ATIVE IMMEDIATELY WHEN THE CALL FOR SERVICE SCREEN IS DISPLAYED. 20-4 VarioPrint 1105...

  • Page 979: Clearing Mishandled Paper

    [Illustration] will display subsequent screens for the disposal action. Follow the procedure below to remove mishandled paper. Details A jam code can be displayed in the message area of the Jam Position Screen. Contact your service representative, if desired. VarioPrint 1105 20-5...
  • Page 980 If any misfeed location is left, the Jam Position Screen will be restored with the next disposal procedure in the message area and the location number in the jam position display. Repeat steps 1 to 2 until all the lo- cations are cleared. 20-6 VarioPrint 1105...
  • Page 981 Be especially careful when pushing back in the paste tank unit which has moved and halted in the front side due to the machine trouble. Do not hold the front side but the far right side in order to return the paste tank unit to its original position. VarioPrint 1105 20-7...

  • Page 982: If Machine Tab Blinks In Orange

    [MACHINE] tab may blink in orange. If the Jam Position Screen is displayed after touching [Detail Check], follow the procedure “Clearing Mishandled Paper” on page 20-5 to remove mis- handled paper. 20-8 VarioPrint 1105...

  • Page 983: Tray Empty

    To change the tray selection Touch the desired tray key. Touch [OK] to restore the Machine Status Screen. Press [Start]. Copy paper will be delivered from newly selected tray to continue the printing operation. VarioPrint 1105 20-9...
  • Page 984 To supply the empty tray with paper Load paper in the empty tray. For details, refer to “Loading Paper” on page 4-3. Touch [Close] to restore the Machine Status Screen. Press [Start]. Printing operation will resume using the tray supplied with paper. 20-10 VarioPrint 1105...

  • Page 985: Inconformity In Paper Presetting

    Follow the procedure for each to continue the machine operation. Using Custom size/Wide size/Tabbed standard size paper of different size or in different condition Replace paper in the tray with that specified in the paper presetting, then touch [Change]. Press [Start] to start the printing operation. VarioPrint 1105 20-11...
  • Page 986 Replace paper in the tray with that specified in the paper presetting. Touch [Change], then press [Start] to start the printing operation. Details If wrong size is loaded in the tray, the above popup screen will be dis- played. Replace with the correct size, then touch [Close]. 20-12 VarioPrint 1105...

  • Page 987: If "Memory Full" Message Is Displayed (Memory Overflow)

    Occasional memory overflow may occur if the installed memory is inade- quate for the copy conditions selected, and the machine will stop its opera- tion with the following popup screen displayed. Touch [Stop]. All the scanned data will be cleared to terminate the job. VarioPrint 1105 20-13...

  • Page 988: If Power Off/On Screen Is Displayed

    Follow the procedure below to turn the machine power off then on. Turn OFF the sub power switch. Turn OFF the main power switch. Wait about 10 seconds. Turn ON the main power switch and sub power switch. 20-14 VarioPrint 1105...

  • Page 989: Troubleshooting Tips

    Magnification cannot be changed - Reduce & Shift is incompatible with magnification. - Press [Reset] and set desired copying conditions without using Reduce & Shift. Duplex modes cannot be selected Fully close ADF, then select the desired duplex mode again. VarioPrint 1105 20-15...
  • Page 990 - Properly close finisher door/Folding unit door. Add toner message is displayed New toner supply is needed. Follow instructions for adding toner. Call for PM is displayed in message area Contact your service representative for Preventive Maintenance. 20-16 VarioPrint 1105...
  • Page 991 Finisher staple result is not as expected - The 2 staple position functions only on copy paper that is loaded vertical- ly (portrait style). - Check to see if Rotation functions. Release it, if necessary. VarioPrint 1105 20-17...
  • Page 992 Usint Perfect binding, copies cannot be bound - Check to see if the front door of perfect binder, perfect binder tray cover or paste hopper cover is open. Securely close the front door/perfect binder tray cover/paste hopper cov- 20-18 VarioPrint 1105...

  • Page 993: Maintenance

    Maintenance...

  • Page 995: Cleaning Image Scanning Section

    The glass may also clean with a soft cloth dampened slightly with water, if it is diffi- cult to clean. Reminder Never use paint solvents, such as ben- zene or thinners, to clean the original glass. VarioPrint 1105 21-3...

  • Page 996: Cleaning The Adf Guide Cover

    Raise the document feeder, then clean the ADF guide cover with a clean soft cloth. Reminder Never use paint solvents, such as ben- zene or thinners, to clean the ADF guide cover. 21-4 VarioPrint 1105...

  • Page 997: Precautions For Paste Pellets And The Perfect Binder

    Perfect Binder, since then apply to the binder as well. - Do not overload the paste hopper with paste pellets. - Do not touch the lever in the paste hopper with your hand to avoid break- down. VarioPrint 1105 21-5...

  • Page 998: Checking Copy Count

    CMS part count list (part name, P/N, limit), and also resetting the count. For details, please contact your service repre- sentative. Press [Utility/Counter] on the control panel. The Utility Menu Screen will be displayed. 21-6 VarioPrint 1105...
  • Page 999 The counter information will be displayed on the left side of the screen. Touching [Exit] will return to the previous screen. Touch [Detail]. The PM count, Developer count, and Drum count will be displayed. Touching [Exit] will exit the Utility mode and restore the previous screen. VarioPrint 1105 21-7...
  • Page 1000 Touch [COPY] tab to display the Copy Screen. Select the desired paper size, then press [Start]. After the Counter list is printed out, the Utility mode will be released automatically and the previous screen will be restored. 21-8 VarioPrint 1105...

  • Page 1001: Preventive Maintenance

    The machine manager can call for service using the Utility setting. For de- tails, refer to “01 User Call” on page 17-141. In this case, you don’t have to make a call for preventive maintenance, because your machine has been monitored automatically by your service representative. VarioPrint 1105 21-9...
  • Page 1002 Maintenance 21-10 VarioPrint 1105...

  • Page 1003: Machine Specifications

    Machine Specifications...

  • Page 1005: Main Body Specifications

    Machine Specifications Machine Specifications These specifications are subject to change without notice. 22.1 Main Body Specifications 22.1.1 Main Body Specifications Name VarioPrint 1105 Type Console type Transfer method Indirect electrostatic method Original glass Fixed Light-sensitive unit Light source Xenon lamp...
  • Page 1006 (main body + PF-701 + FD-501 + SD-501 + PB-501) Required space 200 mm or more from the back side; 100 mm or more from both right and left sides * Space required for the safe operation 22-4 VarioPrint 1105...

  • Page 1007: Adf (Df-603)

    Original capacity 100 sheets max. (80 g/m Original insertion Automatic feed at a time Dimensions 650 (W) x 570 (D) x 170 (H) mm (paper feed tray excluded) Weight Approx. 22 kg Power source Supply from main body VarioPrint 1105 22-5...

  • Page 1008: Option Specifications

    • Stacker: 5,000 sheets (or 2,000 sheets for B5 and A5) • Secondary (sub) tray: 200 sheets Dimensions 785 (W) x 656 (D) x 1020 (H) mm Weight Approx. 110 kg Power source • LS-501: Internal battery • LS-502: Supply from main body 22-6 VarioPrint 1105...

  • Page 1009: In-Bin Stapler Finisher Fs-503

    Staple cartridge 5,000 staples Dimensions • 544 (W) x 656 (D) x 1020 (H) mm • Width including primary (main) tray: 781 mm/ 866 mm (pulled out) Weight Approx. 80 kg Power source Supply from main body VarioPrint 1105 22-7...

  • Page 1010: Folding Unit Fd-501

    Stack capacity using PI 500 sheets max. (80 g/m paper) for each tray Dimensions 400 (W) x 656 (D) x 1190 (H) mm Weight Approx. 120 kg Power source Internal battery 22-8 VarioPrint 1105...

  • Page 1011: Saddle Stitcher Sd-501

    30 sets max. (Multi Centre, Multi Letter) Saddle stitcher tray capacity See page 3-5. Dimensions • 1170 (W) x 775 (D) x 1020 (H) mm • 1441(D) mm with Saddle stitcher tray fully withdrawn Weight Approx. 263 kg Power source Internal battery VarioPrint 1105 22-9...

  • Page 1012: Perfect Binder Pb-501

    11 sets x 2 (approx. 6,600 sheets) For details, see page 3-5. Warm-up time Approx. 20 minutes Dimensions 1303 (W) x 775 (D) x 1223 (H) mm Weight Approx. 210 kg Power source Internal battery Power consumption 1,000W max. 22-10 VarioPrint 1105...
  • Page 1013 Appendix...

  • Page 1015: How To Input Characters

    This key determines the characters you input, and the character input screen closes. [Cancel] This key cancels the characters you input, and the character input screen closes. [Shift] This key switches between an upper case letter and a lower case letter, and between numbers and signs. VarioPrint 1105 23-3...

  • Page 1016: About Character Input

    The followings describe basic steps to input characters on the character in- put screen. Touch the corresponding key to input the desired character. Touch [OK]. The character input screen closes. The input characters are displayed on the corresponding column. 23-4 VarioPrint 1105...

  • Page 1017: Setting Data For Import/Export

    Product Help URL Corporate URL Supplies and Accessories Online Help URL E-Mail Alert AlertMail Notice of E-Mail Notice of E-Mail Address Item Paper Empty Paper Jam Maintenance Staple Empty Toner Empty Output Full Service Call Punch Waste Remove VarioPrint 1105 23-5...
  • Page 1018 Banner Page Tray Convert Paper Size 1 Page/Sheet Booklet Print Position Default Setting- Font Name Symbol Set Line/Page Font Point Size Font Pitch CR/LF Mapping Default Setting- Print To PS Error Default Setting- Auto Paper Select TIFF Image Position 23-6 VarioPrint 1105...
  • Page 1019 Start address 4 - Ending address 5 NetWare Netware NetWare Print Frame Type Mode Pserver Print Server Name Print Server Password Print Queue Scan Rate Bindery/NDS Bindery Preferred File Server Preferred NDS Context Preferred NDS Tree Name Nprinter/Rprinter Printer Name Printer Number VarioPrint 1105 23-7...
  • Page 1020 APOP Authentication Connection Timeout Port Number Email-Send Send SMTP Server Capacity Port Number Connection Timeout Max Mail Size SMTP Server Capacity Administrator Mail Address Authentication POP Before SMTP SMTP Authentication User Name Password Realm Binary Division Division Size 23-8 VarioPrint 1105...
  • Page 1021 Sub menus Target items SSL/TLS SSL/TLS Infor- Encryption Strength mation Validity Period Organization Organization Unit Locality State/Province Country Authentication Auto Logout Admin Logout Time User Logout Time AP I/F AP I/F Port Number Use SSL/TLS Port Number(SSL/TLS) VarioPrint 1105 23-9...

  • Page 1022: Configuration Setting

    Appendix 23.3 Configuration Setting Print Sample 23-10 VarioPrint 1105...
  • Page 1023 Appendix Print Sample VarioPrint 1105 23-11...
