Inserting The Memory Card - Lucent Technologies MERLIN LEGEND Release 6.0 System Programming Manual

MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
3 Common Administrative Procedures
Memory Card
Inserting the Card
To insert the card, hold the card with the Lucent logo facing up and the arrow
pointing toward the slot. See Figure 3-5 for the proper way to insert the memory
card into the slot on the processor module.
Figure 3–5.
PROCESSOR
MODULE
Push in
to remove
Memory
Card

Inserting the Memory Card

3
Error/Status Code
Display
PCMCIA
Interface Slot
IN S E R
T
C O P
Y R IG
A L L H T ©
R IG 1 9 9
H T S
3 A T
R E S & T
E R V
E D
Memory
Card
Alarm Status
LED
Issue 1
February 1998
Page 3-281
