1 Programming Basics
System Programming Console
Console Components
Refer to Figure 1–1
MLX-20L Console Components
Desk Stand An adjustable stand on the console and the DSS, allows a 20- or 30-degree
(not shown) viewing angle.
Button Labeling Cards labeled with the number or feature assigned to each line button.
Cards
Contrast Control A sliding control at the top of the console, used to brighten or dim the display
(not shown) screen.
Fixed Feature Eight fixed display buttons for most-used features.
Buttons Feature for viewing the Feature screen and selecting features.
HFAI (Hands Free Answer on Intercom) for answering voice-announced
calls without the handset.
Mute for turning the speakerphone's microphone on and off.
Speaker for talking on a call through the speakerphone without lifting the
handset.
Transfer for sending a call to another telephone.
Conf for adding a line or extension to a conference call.
Drop for disconnecting an extension or line from a conference call.
Hold for putting a call on hold.
Dialpad Number pad for dialing telephone numbers.
Direct Station A device that adds extension buttons and other buttons to the console.
Selector
Display Buttons Four fixed display buttons and 10 unlabeled buttons used to view the
different screens and select names, features, and options from the display
screen. See
Display Screen Screen with a 7-line by 24-character display area that shows call
information, features, prompts, date, and time.
Handset The hand-held part of the console you pick up, talk into, and listen from.
LEDs (Light-Emitting Diodes) The lights on the console that assist in checking
feature status.
Line Buttons Twenty buttons to make and receive calls; unlabeled buttons are
programmable for one-step feature use.
Message Light A red light that signals a waiting message.
User Cards A slide-out drawer with erasable cards for noting telephone numbers and
and Tray feature codes.
Volume Control A button for adjusting the volume of the speaker, handset, headset, and
ringer.
for the location of the components described below.
"Console Buttons" on page
1
1
1–7.
